ELECTRIC MOTION Epure Lite 2021 User manual
Trial Magazine Picture
–
USER MANUAL - 2021
3
Table of contents
1. 1. Manual introduction .................................................................. 5
1.1 Important message from Electric Motion................................ 5
1.2 About this manual................................................................... 6
2. Safety instructions ......................................................................... 7
2.1 Regulatory use ........................................................................ 7
2.2 Operating information ............................................................ 7
2.3 Protective clothing .................................................................. 8
2.4 Environment............................................................................ 8
2.5 Location of important labels ................................................... 9
2.6 Fire hazard............................................................................... 9
2.7 Fall or accident ........................................................................ 9
3. Important observations and general information........................ 10
3.1 Emission information ............................................................ 10
3.2 Manufacturer's warranty and legal warranty ....................... 10
3.3 Vehicle range......................................................................... 10
3.4 Transport of the vehicle ........................................................ 11
3.5 Spare parts and accessories .................................................. 11
3.6 Lifetime optimization ............................................................ 11
3.7 Power supply......................................................................... 12
3.8 Parts and consumables.......................................................... 12
3.9 Operation under extreme conditions.................................... 12
3.10 Reception of the motorcycle ............................................... 12
4. Vehicle identification ................................................................... 13
4.1 Chassis number ..................................................................... 13
4.2 European certification label .................................................. 13
4.3 Engine number (references).................................................. 13
4.4 Battery number (references)................................................. 13
5. Overall view of the vehicle........................................................... 14
5.1 Right view.............................................................................. 14
5.2 Left view................................................................................ 14
6. Technical data .............................................................................. 15
6.1 Engine.................................................................................... 15
6.2 Tires....................................................................................... 15
6.3 Fork ....................................................................................... 15
6.4 Shock absorber...................................................................... 15
7. Controls and Components............................................................ 16
7.1 Front/rear brake system and adjustment ............................. 16
7.2 Throttle grip .......................................................................... 16
7.3 Lighting system...................................................................... 17
USER MANUAL - 2021
4
7.4 Turn signals ........................................................................... 18
7.5 Left-hand side handlebars switches ...................................... 19
7.6 Main magnet switch and map button ................................... 19
7.7 Side stand.............................................................................. 20
7.8 Vue d’ensemble du tableau de bord ..................................... 20
7.9 Battery pack .......................................................................... 21
7.10 Battery charger ................................................................... 24
8. Commissioning............................................................................. 25
8.1 Preparation on receipt of the motorcycle in a shipping box . 25
8.2 Instructions for initial commissioning ................................... 26
8. Battery Charging Procedure .................................................... 27
9. Operating the motorcycle ............................................................ 30
9.1 Inspection before use............................................................ 30
9.2 Starting the motorcycle......................................................... 31
9.3 Motor’s behavior adjustment ............................................... 32
9.4 Braking .................................................................................. 33
9.5 PRB & PELS (option) .............................................................. 33
9.6 Clutch (RACE model) ............................................................. 34
9.7 Stopping your motorcycle ..................................................... 35
9.8 Cleaning the motorcycle ....................................................... 35
9.9 Motorcycle storage ............................................................... 36
10. Setting the motorcycle controls ................................................. 37
11. Maintenance .............................................................................. 39
11.1 Raising the bike on a stand.................................................. 39
11.2 Front fork dismounting –mounting .................................... 39
11.2 Clean the fork ...................................................................... 41
11.3 Chain tension adjustment ................................................... 41
11.4 Shock absorber setting........................................................ 42
11.4.1 Hydraulic setting..................................................... 42
11.4.2 Spring pre-load adjustment.............................................. 42
11.5 Removing and refitting the front mudguard ....................... 43
11.6 Dismantling and reassembling the handlebars ................... 43
11.7 Dismantle and reassemble the motorbike cover ................ 44
11.8 Maintenance ....................................................................... 46
11.9 ON road display setting ....................................................... 47
12. Clutch ......................................................................................... 48
12.1 Clutch oil maintenance (RACE) ............................................ 48
INDEX ............................................................................................... 49
USER MANUAL - 2021
5
1. 1. Manual introduction
1.1 Important message from Electric Motion
Congratulation and thank you for purchasing Electric Motion Epure
electric motorcycle. We welcome you in our family devoted to
electrons.
Electrical production on national grids becoming more and more
clean and renewable, we are proud to provide you with an
alternative to internal combustion engines and therefore allowing
you to take part in solving the serious challenges we all face with air
pollution and global warming.
The use of this electric motorcycle requires you to respect some
recommendations and precautions in order to enjoy all the
advantage that can offer this new clean alternative.
It is therefore imperative to read this manual which contains all the
necessary information for preparing for the motorcycle first use, on
how to operate it, on how to maintain the motorcycle and on what
checks need to be carried. Furthermore, this manual contains all the
information to prevent yourself and third parties from risks and
accidents linked to the use of an electric motorcycle.
Because the Electric Motion team is continuously improving their
products, it is possible that some information contained in this
manual might change due to updates. If you have any doubt, do not
hesitate to check our website www.electric-motion.fr and download
the latest version of the manual. Thus, no juridical claim can be
carried out based on the information contained in this manual.
The content of this manual will allow you to maintain your bike in
perfect working order in the most secure way possible.
USER MANUAL - 2021
6
1.2 About this manual
This manual only includes all the operating and maintenance
information for the Epure model of the Electric Motion brand. Under
no circumstances should these instructions be used for the
maintenance of other models of the brand.
Keep the user manual in an easily accessible location, so that it is
close to hand when required.
The "right" and "left" designations refer respectively to the right or
the left of the rider when he is in the driving position.
To illustrate all the maintenance operations, or to clearly designate
elements of the motorcycle, pictures were used. Since Electric
Motion is constantly improving their product, it is possible that
certain parts of the motorcycle will change in geometry or in colors.
However, this does not affect the operational processes explained in
the manual.
The owner's manual is an important part of the vehicle. It must be
transferred from owner to owner upon resale of the vehicle.
In this manual, the CAUTION designation will alert you to an
object or situation that may cause injury to you or a third party or
also damage your vehicle.
USER MANUAL - 2021
7
2. Safety instructions
2.1 Regulatory use
The Electric Motion Epure has been designed and built to withstand
mechanical stress resulting from road and off-road use.
The Epure model has been assembled in order to be homologated
and thus has all the equipment necessary to be ridden on roads
opened to traffic. It is therefore forbidden to modify the accessories
installed as standard on the motorcycle. Electric Motion cannot be
held liable for any modifications to the accessories installed on the
motorcycle.
Use only Electric Motion parts. These parts have been tested
and approved by Electric Motion. Under no circumstances should
you try to replace the motorcycle components such as the battery
pack or the engine with components of another brand, at the risk of
causing irreversible damages to your vehicle.
Electric Motion does not assume any responsibility for the
adaptation of unapproved parts.
2.2 Operating information
In order to guarantee a safe operation of the motorcycle, it is
forbidden to carry out any modification on the vehicle.
For example, it is formally prohibited to use the vehicle if the
vehicle, or one of its components, hasn’t been properly maintained
or if it is used outside the scope of the intended use. It is also
forbidden to open the motor or the battery pack.
Any modification carried out on the vehicle by the customer
does not render Electric Motion liable and voids any form of
manufacturer's warranty.
Do not use the vehicle under the influence of alcohol, any
medicine that could alter your capacity to drive or illegal drugs, or if
you are not physically or mentally able to drive.
When using the vehicle, some components will start moving
(chain, wheels) and will become dangerous for the user. It is
important to take the right measures to avoid any unnecessary risks.
USER MANUAL - 2021
8
2.3 Protective clothing
To reduce the risks of potential injury while riding an Epure
motorcycle, on road or off road, it is necessary to be equipped with
all compulsory protective clothing.
For any kind of trip and for any person that will ride the motorcycle,
it is necessary to wear the correct protective clothing (helmet,
boots, gloves, trousers and jacket equipped with protective means).
Failure to wear safety clothing or wearing damaged safety
clothing is a serious safety hazard and can result in serious injury or
death.
Like the driver, the passenger must also carry all the necessary
protective clothing when riding the motorcycle behind the driver.
Only use protective clothing that is in perfect condition and
complies with the legal requirements of the country of use.
2.4 Environment
In order to guarantee the durability of motorcycle driving, it is
necessary to respect the rules of goodwill on the road with other
users, motorized or not. Ensure that you remain within the legal
framework of the use of a motorcycle. Be respectful to the
environment and road users and take into account the rights of
other road users.
When the motorcycle parts are disposed of, be sure to comply with
the recycling regulations of the country of use, in particular the
battery pack.
Electrical components (motor, battery, etc.) and electrical
appliances (battery charger) should not be treated as household
waste and require strict recycling.
If you have any questions about the rules for recycling, contact
Electric Motion Customer Service.
USER MANUAL - 2021
9
2.5 Location of important labels
Safety instructions are present in various places on the motorcycle.
They allow the user to protect himself from certain risks associated
with the maintenance of the motorcycle and to preserve the
physical integrity of the motorcycle, its driver and its passenger.
1
Manufacturer label
2
Warning label
Never remove the warning labels. They allow the driver to
avoid getting injured by exposing himself to a danger that cannot be
recognized without the presence of these stickers.
2.6 Fire hazard
As long as the battery pack remains in good working condition, there
is no particular fire hazard on this vehicle. However, if the vehicle
catches fire, it is necessary to inform the fire brigade that the fire
originated from an electric vehicle with a lithium-ion battery.
When the battery pack is damaged, it may present a fire
hazard.
If the battery pack is damaged, contact Electric Motion customer
service promptly.
2.7 Fall or accident
A fall or a road accident can damage the motorcycle significantly.
After a fall or an accident, make a complete inspection of the vehicle
to make sure that the users of the motorcycle do not expose
themselves to any danger before riding again.
A vehicle damaged for any reason may become a danger to
users. In case of damage to the electrical components, please
contact the Electric Motion customer service promptly.
1
2
1
2
USER MANUAL - 2021
10
3. Important observations and general information
3.1 Emission information
The development of the Epure by Electric Motion has made it
possible to obtain a zero emission motorcycle that does not emit
any harmful particles for the environment. Therefore, it has no
exhaust or evaporative emission.
This motorcycle does not use gasoline, engine oil or any other liquid
fuel.
3.2 Manufacturer's warranty and legal warranty
All the work detailed in the maintenance guide must be carried out
exclusively by a professional in order to retain the warranty right.
The warranty is cancelled in the event of damages resulting from
manipulation or modification on the vehicle made by a person not
certified by Electric Motion.
For additional information on the manufacturer's warranty and how
to obtain it, contact Electric Motion customer service.
3.3 Vehicle range
The Epure range is defined as the distance the vehicle travels on a
single full charge of the battery.
It is then easy to understand that the range of the vehicle depends
on how it is used. The more conservative you ride, the better range
you can expect from your motorcycle.
There are many factors affecting the range, such as speed,
acceleration, number of regenerative braking, weather conditions,
tire pressure and payload.
For the first use of your Epure, you are advised to remain cautious
so you become fully aware of the range of your vehicle according to
your driving style.
After you were able to make your own idea about the potential of the
Epure model, you can adapt your driving style to the range you would
like to achieve.
USER MANUAL - 2021
11
The range values in this manual are measured according to
different standards, which may vary depending on the country of
use.
In order to improve the range of your vehicle, all these
characteristics must be considered:
Low range
Important range
Travelling at high speed
Low speed travel
Bad road condition
Good road condition
Important elevation
Low elevation
Aggressive driving
Smooth driving
Important payload
Low payload
Cold temperature
Hot temperature
Adverse weather conditions
Good weather conditions
Under inflated tires
Properly inflated tires
Poor general maintenance of
the motorcycle
Good general maintenance of
the motorcycle
3.4 Transport of the vehicle
The transport of the motorcycle can be carried out with the help of
an approved trailer or a utility vehicle.
It is important to ensure that the motorcycle is securely fastened
before transporting it on the public road. The use of certified straps
to maintain the motorcycle is recommended to avoid any accidents
related to the loss of the vehicle on public roads.
3.5 Spare parts and accessories
For safety reasons, we recommend that users of Epure only use
spare parts and accessories authorized and recommended by
Electric-Motion and have them fitted by a professional.
The company Electric Motion will decline any responsibility in case
of equipment deterioration caused by products not approved by the
brand.
For information on spare parts and their installation, contact the
Electric Motion customer service or on our website www.electric-
motion.fr.
3.6 Lifetime optimization
In order to optimize the life of the vehicle, it is important to perform
the maintenance tasks listed in the user manual at the right
mileage/time of use.
Maintaining maintenance intervals is important to keep a vehicle in
good working condition and to avoid early wear.
What’s more, incorrect adjustments of the chassis results in
premature wear of the vehicle.
It is important to refer to the vehicle maintenance manual.
USER MANUAL - 2021
12
3.7 Power supply
It’s possible to mount / dismount the battery pack during some
maintenance process. ( 16.1).
3.8 Parts and consumables
To maintain your vehicle, it is important to use parts and
consumables (lubricants and maintenance products) in accordance
with the specifications given in the user manual.
3.9 Operation under extreme conditions
The Epure is not sensitive to water and rain. However, care must be
taken to ensure that the water level on the road being ridden does
not exceed the foot-rest height.
In the event the rider is stopped on a road with a high level of
water, it is necessary to turn off the motorcycle to avoid a short
circuit or a breakdown.
The Epure can be used over a wide range of temperatures: -15°C to
+55°C (5°F to 131°F).
The battery life of the Epure model depends on the operating
temperature:
Operating
temperature
(°C)
-15°C
(5°F)
-10°C
(14°F)
0°C
(32°F)
25°C
(77°F)
40°C
(104°F)
55°C
(131°F)
Decrease in
battery range
-30%
-25%
-15%
-0%
-3%
-4%
Use of the vehicle in extreme conditions (sand, mud) leads to
premature wear of the motorcycle's consumables (chain, brake
pads, various bearings). It is then necessary to carry out the checks
and the maintenance operations more often than prescribed in the
manual of use.
3.10 Reception of the motorcycle
When receiving the Epure model, it is necessary to perform some
operations to make the motorcycle usable (assembly of parts
protected during transport). Please refer to the corresponding
chapter ( 8).
Model
Epure
Lite
Epure
Sport
Epure
Race
Epure
Escape
Voltage
Min: 42V / Nom: 50.4V / Max : ≈58V
USER MANUAL - 2021
13
4. Vehicle identification
4.1 Chassis number
4.2 European certification label
4.3 Engine number (references)
4.4 Battery number (references)
1
2
3
4
USER MANUAL - 2021
14
5. Overall view of the vehicle
5.1 Right view
5.2 Left view
USER MANUAL - 2021
15
6. Technical data
6.1 Engine
Motor type
BLDC permanent magnet
motor
Nominal power
6 kW
Peak power
11 kW
Maximal torque
600 N.m
Engine max speed
6500 RPM
Cooling system
Air
6.2 Tires
6.3 Fork
EPURE Lite / ESCAPE : TECH Steel Ø 39 mm
EPURE Sport / EPURE Race : TECH Aluminium Ø 39 mm
6.4 Shock absorber
Model
Epure
Lite
Epure
Sport
Epure
Race
Epure
Escape
Tyres
MICHELIN X11
Model
Epure
Lite
Epure
Sport
Epure
Race
Epure
Escape
Rear
R 16 V
USER MANUAL - 2021
16
7. Controls and Components
7.1 Front/rear brake system and adjustment
The front brake lever is located on the handlebars right-hand side.
The rear brake pedal is located near to the right foot peg.
Before each use, check the condition of the brake system. A
faulty brake system makes you vulnerable as well as the other road
users.
7.2 Throttle grip
The throttle grip is located on the handlebars right-hand side.
Before each use, check that the throttle grip rotates and
returns correctly to prevent any accident.
Throttle
Front brake
lever
USER MANUAL - 2021
17
7.3 Lighting system
The headlight is installed on the forks located on the vehicle front
and the taillight is installed on the rear subframe of the vehicle.
Electric Motion advises to always have the lights turned on.
Headlight:
The headlight can get hot when it is turned on.
Taillight:
Make sure that the lighting system is always in working order.
Riding without a lighting system does not allow other users to see
you and does not allow you to see other users.
It is mandatory to have a lighting system in good working order.
USER MANUAL - 2021
18
7.4 Turn signals
Front turn signals:
Rear turn signals:
USER MANUAL - 2021
19
7.5 Left-hand side handlebars switches
On the left side of the handlebar, le main magnet switch is lightning
when the bike is ON and when the battery is ON
When you switch OFF the battery, this red LED will be OFF
The total extinction of this led can take some minutes, but the
battery is well shut.
7.6 Main magnet switch and map button
On the left side of the handlebar, the magnet switch is needed to
switch ON the motorcycle.
When the magnet is installed, the motorcycle is ON.
Cluster switch ON.
Now you just have to push the map button to select the map needed.
2
1
3
Magnet
switch
Map button
USER MANUAL - 2021
20
7.7 Side stand
7.8 Vue d’ensemble du tableau de bord
1
Right and left turn signals indicator
2
Low battery Indicator
3
High temperature indicator
4
Headlight high beam Indicator
5
“Ready to ride” Indicator
6
System warning indicator
7
Speed (km/h à mph : 10sec on MODE button)
8
Battery charge indicator
9
Total motorcycle mileage or trip odometer
10
Select button
11
Adjust button (MODE)
12
Battery charge indicator (SET)
4
5
6
1
2
3
7
9
Stand
8
11
10
12
This manual suits for next models
3
Table of contents
Other ELECTRIC MOTION Motorcycle manuals
