ELECTRO-OPTICS SIG SAUER BUCKMASTERS 10X42MM User manual

OPERATOR’S MANUAL
BUCKMASTERS
BUCKMASTERS™ 10X42MM BINOCULARS
ELECTRO-OPTICS
™

2
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Contents: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Features: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Identication: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
SIG SAUER Electro-Optics Innite Guarantee ®/Limited Lifetime Warranty . . . . . 12
Please visit sigsauer.com for Operator’s Manuals downloads
WARNING: CANCER AND REPRODUCTIVE HARM—www.P65warnings.ca.gov

3
INTRODUCTION
“I have been truly blessed to be able to hunt and entertain millions of deer hunters for over 33
years now. It has totally amazed me how the technology of our sport has grown. Now we have
partnered with one of the best brands in the industry, SIG SAUER. SIG Electro-Optics are top
quality, with built-in technology that is in a class of its own. Check out the new SIG Buckmasters
line of riescopes, rangenders, and binoculars this fall at your favorite retailer. They will bring
incredible value to every deer hunter.”
– Jackie Bushman
The BUCKMASTERS™ Binocular produces a bright and clear high-contrast image with true
color across the entire eld of view. Included with the binocular comes a custom binocular
harness strap to help keep your binoculars secure and readily available.

4
CONTENTS:
• BUCKMASTERS™ Binoculars
• Eyepiece and Objective Lens Cover
• Binocular Harness Strap
• Neck/Shoulder Strap
• Lens Cloth
• Padded Ballistic Nylon Case

5
KEY FEATURES:
• Fully multi-coated lenses
• Closed bridge design
• BAK-4 Prism
• IPX-7 rated (Protected against water immersion for 30 minutes at a depth of up to 1 meter)
• Tripod mount capable
• Multi-Position eye cups

6
PRODUCT IDENTIFICATION:
A. Adjustable Eye Cups
B. Diopter Ring
C. Strap Attachment
D. Focus Wheel
E. Objective Lens
F. Tripod Adapter Cover
A
B
C
EF
D
C
BUCKMASTERS™ BINOCULARS SHOWN

7
OPERATION
SETTING THE DIOPTER ADJUSTMENT
Setting the diopter adjustment of your binocular is very important, as properly adjusted binoculars
will prevent eye strain and provide you with a crisp, sharp image.
To set the diopter adjustment on right eyepiece diopter adjustment models:
1. View an object about 100 yards in the distance.
2. Close your right eye.
3. Adjust the center focus wheel (located between the two
barrels) until the image presented to your left eye is clear
and sharp.
CENTER FOCUS WHEEL

8
4. Close your left eye.
5. Adjust the diopter ring located around the right barrel,
near the eyepiece, until the image presented to your
right eye is clear and sharp.
Your binocular is now focused for your eyesight. To make
any adjustments in the eld, simply turn the center focus wheel while viewing through both
barrels.
ADJUSTABLE EYECUPS
SIG SAUER binoculars feature adjustable eyecups to
accommodate the eye relief distance required when wearing
eyeglasses.
DIOPTER RING

9
INTERPUPILLARY DISTANCE OF BINOCULARS
Interpupillary distance is the distance between your right and left eye.
1. Set the distance between the centers of the right and left ocular lens of the binoculars to
your interpupillary distance.
2. Look at a distant object to make an adjustment while folding back the main body of the
binoculars.
3. Your interpupillary distance is correctly set when the eld of view can be seen by both eyes
as a single circle (see below illustration).
Interpupillary distance
is not appropriately set
Shade
Interpupillary distance
is appropriately set
Field of view

10
CLEANING
IMPROPER CLEANING CAN RESULT IN SCRATCHES TO YOUR BINOCULAR LENSES.
• Clean the fully armored body by simply wiping o󰀨 any accumulated dirt or dust.
• Clean the lenses only when necessary.
• Use a standard lens brush/blower brush rst, to remove dust and debris from the lenses.
• Never wipe the lenses with a cloth.
• Use pure alcohol, high-grade glass cleaner, or pure water on a cotton swab.
• Always apply the alcohol, water, or glass cleaner to the swab and not directly to the lens.
CAUTION

11
BUCKMASTER™ BINOCULAR SPECIFICATIONS
Model/Magnification 10x42mm
Eye Relief 15mm
Exit Pupil 4.2mm
Linear FOV FT @ 1000 yards 315 ft
Linear FOV FT @ 1000 meters 105 m
Objective Clear Aperture 42mm
Angular FOV 6 degrees
Close Focus Distance 8.2 ft
Interpupillary Distance 58mm - 73mm
Diopter Range +/- 4
Weight 592.50g / 20.90 oz
Length 5.57in / 141.58mm

12
SIG SAUER ELECTRO-OPTICS INFINITE GUARANTEE ®/LIMITED LIFETIME
WARRANTY
SIG SAUER® has manufactured the most rugged, dependable, high-performance rearms for more than two
centuries. Our heritage of design, engineering, and precision-manufactured quality predates the existence
of any other optics company worldwide. We understand the importance of quality in the line of re, at the
shooting range or on your next hunt. SIG SAUER Electro-Optics had to earn the right to wear that badge and
the Innite Guarantee has your back, forever. Period.
We will repair or replace your SIG SAUER product in the event it becomes damaged or defective, at no charge
to you. If we cannot repair your product, we will replace it with a product in perfect working order of equal or
better physical condition.
SIG SAUER® Innite Guarantee®
• Unlimited Lifetime Guarantee
• Fully Transferable
• No Warranty Card Required
• No Receipt Required
• No Time Limit Applies
• No Charge

13
Please note that our Innite Guarantee excludes coverage for intentional damage, misuse, cosmetic damage
that does not a󰀨ect the performance of the optic, loss, theft, or unauthorized repair or modication. Excludes
electronic and Tritium components.
Customers seeking warranty coverage must rst obtain a Return Merchandise Authorization (RMA) by
contacting SIG SAUER Customer Service, and return the product unloaded and freight prepaid.
ANY WARRANTIES IMPLIED BY LAW, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED. REPAIR, ALTERATION,
OR REPLACEMENT AS PROVIDED HEREIN IS YOUR EXCLUSIVE REMEDY FOR ANY DEFECTIVE
PRODUCT. IN NO EVENT SHALL SIG SAUER OR ANY COMPANY AFFILIATED WITH SIG SAUER BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND ARISING
OUT OF THE PURCHASE OR USE OF THIS PRODUCT, WHETHER BASED UPON CONTRACT, TORT,
STATUTE, OR OTHERWISE. Some states do not allow the exclusion or limitation of implied warranties, or
the exclusion or limitation of incidental or consequential damages, so some or all of the above limitations or
exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other
rights which vary from State to State.
THIS WARRANTY APPLIES TO COMMERCIAL CUSTOMERS ONLY, AND DOES NOT APPLY TO
GOVERNMENT, MILITARY, LAW ENFORCEMENT, OR NON-US CUSTOMERS. NON-US COMMERCIAL
CUSTOMERS MUST PURCHASE PRODUCT THROUGH AN AUTHORIZED SIG SAUER DEALER WITHIN
THEIR COUNTRY OF RESIDENCE FOR THIS WARRANTY TO APPLY.

14
SIG SAUER®ELECTRONIC COMPONENT LIMITED 5-YEAR WARRANTY
SIG SAUER warrants that the electronic and tritium components of the enclosed product
were originally manufactured free of defects in workmanship, material, and mechanical
function. For a period of ve (5) years from the date of manufacture, SIG SAUER agrees
to correct any defect in these components by repair, adjustment, or replacement, at
SIG SAUER’s option, with the same or comparable quality components (or by replacing
the product at SIG SAUER’s option); provided however that a Return Merchandise
Authorization (RMA) is rst obtained by contacting SIG SAUER Customer Service, and that
the product is returned unloaded and freight prepaid.
This limited warranty is null and void if the product has been misused, damaged (by accident or otherwise),
damaged through failure to provide reasonable and necessary maintenance as described in the user’s manual,
or if unauthorized repair or any alteration, including of a cosmetic nature, has been performed on the product.
This limited warranty does not apply to normal cosmetic wear and tear of any parts.
ANY WARRANTIES IMPLIED BY LAW, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY DISCLAIMED. REPAIR, ALTERATION,
OR REPLACEMENT AS PROVIDED HEREIN IS YOUR EXCLUSIVE REMEDY FOR ANY DEFECTIVE
PRODUCT. IN NO EVENT SHALL SIG SAUER OR ANY COMPANY AFFILIATED WITH SIG SAUER BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES OF ANY KIND ARISING
OUT OF THE PURCHASE OR USE OF THIS PRODUCT, WHETHER BASED UPON CONTRACT, TORT,
STATUTE, OR OTHERWISE.
L
I
M
I
T
E
D
5
Y
E
A
R
W
A
R
R
A
N
T
Y
E
L
E
C
T
R
O
N
I
C
&
T
R
I
T
I
U
M

15
Some states do not allow the exclusion or limitation of implied warranties, or the exclusion or limitation of
incidental or consequential damages, so some or all of the above limitations or exclusions may not apply to
you. This warranty gives you specic legal rights, and you may also have other rights which vary from State to
State.
THIS WARRANTY APPLIES TO COMMERCIAL CUSTOMERS ONLY, AND DOES NOT APPLY TO
GOVERNMENT, MILITARY, LAW ENFORCEMENT, OR NON-US CUSTOMERS. NON-US COMMERCIAL
CUSTOMERS MUST PURCHASE PRODUCT THROUGH AN AUTHORIZED SIG SAUER DEALER WITHIN
THEIR COUNTRY OF RESIDENCE FOR THIS WARRANTY TO APPLY.

P/N 7403950-01 REV00
