Electro-Voice Xw15A Manual

Output 1 Output 2 Output 3 Output 4 Output 5 Output 6 Output 7 Output 8
Output Label XW15a LF XW15a HF XW15a LF XW15a HF XW15a LF XW15a HF XW15a LF XW15a HF
Output Delay 125us 0s 125us 0s 125us 0s 125us 0s
Polarity Invert no no no no no no no no
Output Gain 0dB -9dB 0dB -9dB 0dB -9dB 0dB -9dB
HP Filte
r
Type BW24 LR24 BW24 LR24 BW24 LR24 BW24 LR24
Frequency 50Hz 1.5kHz 50Hz 1.5kHz 50Hz 1.5kHz 50Hz 1.5kHz
LP Filte
r
Type LR24 BW12 LR24 BW12 LR24 BW12 LR24 BW12
Frequenc
y
1.5kHz 18.2kHz 1.5kHz 18.2kHz 1.5kHz 18.2kHz 1.5kHz 18.2kHz
All-Pass Filte
r
Frequency
Slope out out out out out out out out
Q
Filter 1
Filter Type Loshelf PEQ Loshelf PEQ Loshelf PEQ Loshelf PEQ
Frequency 69.4Hz 1.21kHz 69.4Hz 1.21kHz 69.4Hz 1.21kHz 69.4Hz 1.21kHz
Slope/Q 12dB 4.8 12dB 4.8 12dB 4.8 12dB 4.8
Gain 6dB 3dB 6dB 3dB 6dB 3dB 6dB 3dB
Filter 2
Filter Type PEQ PEQ PEQ PEQ PEQ PEQ PEQ PEQ
Frequency 170Hz 2.67kHz 170Hz 2.67kHz 170Hz 2.67kHz 170Hz 2.67kHz
Q1.58 3.6 1.58 3.6 1.58 3.6 1.58 3.6
Gain 5dB 4dB 5dB 4dB 5dB 4dB 5dB 4dB
Filter 3
Filter Type PEQ PEQ PEQ PEQ PEQ PEQ PEQ PEQ
Frequency 250Hz 3.74kHz 250Hz 3.74kHz 250Hz 3.74kHz 250Hz 3.74kHz
Q3.6 4.8 3.6 4.8 3.6 4.8 3.6 4.8
Gain -3dB -2dB -3dB -2dB -3dB -2dB -3dB -2dB
Filter 4
Filter Type PEQ PEQ PEQ PEQ PEQ PEQ PEQ PEQ
Frequency 2.13kHz 18.2kHz 2.13kHz 18.2kHz 2.13kHz 18.2kHz 2.13kHz 18.2kHz
Q7.21 1.78 7.21 1.78 7.21 1.78 7.21 1.78
Gain -4dB 3dB -4dB 3dB -4dB 3dB -4dB 3dB
Filter 5
Filter Type
Frequency
Q
Gain
Filter 6
Filter Type Hishelf Hishelf Hishelf Hishelf
Frequency 8.79kHz 8.79kHz 8.79kHz 8.79kHz
Slope/Q 12dB 12dB 12dB 12dB
Gain 6dB 6dB 6dB 6dB
Compressor
Threshold (dBu)
Ratio (N to 1)
Insert (In/Out) out out out out out out out out
Attack (us)
Release (ms)
Knee (Hard/Soft)
Limiter
Threshold (dBu) 2dBu -2dBu 2dBu -2dBu 2dBu -2dBu 2dBu -2dBu
Release (ms) 100ms 3ms 100ms 3ms 100ms 3ms 100ms 3ms
XW15a DN9848(e) P3000 0dBu V2.0
Output levels and limiter settings assume equal amplifier power to each passband with amplifier input sensitivity of 0dBu
Notes: DN9848e and DN9848 with firmware V4.01 and higher have the ability to toggle between Q and BW for parametric filters. DN9848
with firmware V3.05 and older only use BW, use attached conversion spreadsheet to convert. Do not adjust output filters, use input filters for
room and system tuning. DN9848 with firmware V3.05 and older has a maximum of 100ms release time for limiters. For these versions,
change Subwoofer and LF release times to 100ms.

Q value BW value Q value BW value
18.03 0.08 1.78 0.8
14.42 0.1 1.58 0.9
7.21 0.2 1.41 1
4.8 0.3 1.17 1.2
3.6 0.4 0.92 1.5
2.87 0.5 0.67 2
2.39 0.6 0.511 2.5
2.04 0.7 0.4 3
DN9848e BW to Q conversion
