Electro-Voice TS940S User manual

Description
In the TS940S, Electro-Voice has combined
itsexpertiseinconstant-directivityhorns,high-
frequency compression drivers and low-fre-
quency speakers and enclosures to produce a
compact, easily installed theatre stage system
withsuperiorperformanceinall areas: uniform
dispersion to the highest frequencies, high ef-
ficiency,highpowercapacityandwide,smooth
frequency response, all in a small, compact
system.
The TS940S matches the only second-genera-
tion constant-directivity high-frequency to a
world class high-frequency driver, providing
accurate reproduction and coverage of fre-
quency from 500 Hz to 20,000 Hz. Electro-
Voiceinventedconstant-directivitytechnology,
firstintroduced in our HR series horns in1974.
The HP horn in the TS940S is a significant
refinement. Constant directivity means that all
frequencies are evenly spread over the horn's
ratedcoverageangle, so every seat in the house
canreceivebothcleardialogueandsubtlehigh-
frequencyeffects.Forlow-frequencies,asingle
15-inch woofer is used in an optimally vented
radiating en
closure. The high-excursion
woofer is, mounted in an optimally vented,
Thiele-Small enclosure, provide high-impact
bassfrom40through800Hz,ataveragepow-
ers up to 800 watts, when required. In the
field, the TS940S's combination of high- and
low-frequency reproduction has proven to be
an excellent choice for small to medium size
houses.
The TS940S incorporates a number of in-
staller-recommended features, for quick,
trouble-free and low-cost installations.
Among these features is a dedicated cross-
over/equalizer that is easily flush mounted
in the pre-sized, pre-drilled hole located on
the side of the low-frequency enclosure. Side
mounting provides easy wiring access when
thesystemisinstalledagainst a wall. Through
the use of the horn mounting kit and pre-
drilled holes in the low-frequency section is
easily mounted in the proper position on top
of the low-frequency enclosure. All pre-
drilled holes are T-nut loaded, including the
bassdriver mounting holes. This means quick
and easy driver replacement. All components
of the TS940S are finished in matte black, to
eliminate any reflections back through the
screen.
Limited Warranty
Electro-Voice products are guaranteed
against malfunction due to defects in mate-
rials or workmanship for a specified period,
as noted in the individual product-line
statement(s)below,orinthe individual prod-
uct data sheet or owner’s manual, beginning
with the date of original purchase. If such
malfunction occurs during the specified pe-
riod, the product will be repaired or replaced
(at our option) without charge. The product
will be returned to the customer prepaid. Ex-
clusions and Limitations: The Limited
Warranty does not apply to: (a) exterior fin-
ish or appearance; (b) certain specific items
described in the individual product-line
statement(s)below, orin the individual prod-
uct data sheet or owner’s manual; (c) mal-
function resulting from use or operation of
the product other than as specified in the
product data sheet or owner’s manual; (d)
malfunction resulting from misuse or abuse
of the product; or (e) malfunction occurring
at any time after repairs have been made to
TS940S
Theatre Stage System
Electro-Voice
Theatre Sound System®
Atec Lansing
Voice of the Theatre®
R
Systems

TS940S Theatre Stage System
TS940S Theatre Stage System
theproductbyanyoneotherthanElectro-Voice
Service or any of its authorized service repre-
sentatives. Obtaining Warranty Service:
To obtain warranty service, a customer must
delivertheproduct, prepaid, to Electro-Voice
Service or any of its authorized service rep-
resentatives together with proof of purchase
of the product in the form of a bill of sale or
receipted invoice. A list of authorized ser-
vice representatives is available from Elec-
tro-VoiceService at 600 Cecil Street, Bucha-
nan, MI 49107 (800/234-6831 or FAX
616/695-4743). Incidental and Conse-
quential Damages Excluded: Product re-
pair or replacement and return to the cus-
tomer are the only remedies provided to the
customer. Electro-Voice shall not be liable
for any incidental or consequential damages
including, without limitation, injury to per-
sons or property or loss of use. Some states
do not allow the exclusion or limitation of
incidental or consequential damages so the
above limitation or exclusion may not apply
to you. Other Rights: This warranty gives
you specific legal rights, and you may also
have other rights which vary from state to
state.
For warranty repair or service informa-
tion, contact the service repair department
at: 616/695-6831 or 800/685-2606.
Fortechnical assistance, contact Technical
Support at 800/234-6831 or 616/695-6831,
M-F, 8:00 a.m. to 5:00 p.m. Eastern Time.
Specifications subject to change without no-
tice.

TS940S Theatre Stage System
TS940S Theatre Stage System
Figure 1—Dimensions
Figure 2—Frequency response
4 Volts/20 Feet

TS940S Theatre Stage System
TS940S Theatre Stage System
Part Number 531095-9821
600 Cecil Street, Buchanan, MI 49107
616/695-6831, 616/695-1304 Fax
Manufacturing Plants at,
Buchanan, MI • Newport, TN • Sevierville, TN • Austin, TX
©Telex Communications, Inc. 1998 • Litho in U.S.A.
Specifications**
Usable Frequency Response:
45-20,000 Hz
Sound Pressure Level at 1 Watt, 1 Meter
100 dB
Power Capacity Per EIA Standard
RS-426A,
Long-Term Average:
100 watts
Short-Term Peak:
400 watts
Crossover Frequency:
800 Hz
Dispersion,
Horizontal:
90
Vertical:
40
Nominal Impedance:
8 ohms
Components:
DH1A: High-frequency driver
HP940T: High-frequency theatre horn
HMK-1: Horn mounting kit
XEQ-808: Crossover/equalizer
TL606AXT: Low-frequency system
Dimensions (see Figure1),
Height :
101.6 cm (40.0 in.)
Width:
53.3 cm (21.0 in.)
Depth:
41.4 cm (16.3 in.)
Finish:
Matte black
Net Weight:
42.4 kg (93.4 lb)
Shipping Weight:
46.9 kg (103.5 lb)
