Electroconcept SCANNER 30 User manual

SCANNER 30
CLUBSCAN 30
Instruction manual
Thank you for purchasing this pro uct.
Please carefully rea this manual before using this scanner

Responsibility :
On no account the Electroconcept company shall be held responsible for any damages of any nature
whatsoever, notably the operating loss, destruction of consumables (tape, disc, CD) or any other
financial loss resulting from the use or the impossibility to use your equipment. n addition
Electroconcept shall not be held responsible for damages due to an improper use of this product.
Warranty :
Electroconcept products have a 2 years manufacturer warranty. The equipment shall be returned
prepaid (at the customer's own expense). Any freight collect will be refused. The equipment shall be
returned in its original packaging. The equipment's restitution will be at our own expense.
Are excluded from warranty: damages due to fault, negligence, lack of maintenance by the user
(broken, burnt, heated, wet, sandy...etc devices), already installed devices of which the failure would
originate from an improper installation or use by the customer.
This manual is an integral part of this pro uct, you will nee to keep it uring all of
your pro uct shelf-life. In the event of cession of your pro uct to a thir party, you
must also give this manual to this thir party.
TABLE OF CONTENTS
1. Safety instructions
2. Technical specifications
3. Scanner starting up
1. Access to main functions
2. DMX wiring
4. DMX control channels and values
5. Troubleshooting
6. Cleaning
2

1. Safety instructions
Please carefully read these instructions as they include
valuable information for installation, o eration and
maintenance of this device.
Warning
Keep this manual for future consultations. f you resell your scanner to an other individual,
make sure to also give him this manual.
Unpack and carefully check that the scanner didn’t take any damages during the transport
before using it.
Before any connection, make sure that both the voltage and the frequency of your power
source match your scanner specifications.
Check your device as well as your equipment’s grounding.
This device is only meant for indoor use ; protect it from heat and humidity (allowed
ambient temperature from 10 to 40°C).
The scanner must be set up in a ventilated area, at least 50cm away from any adjacent
surface. Check that no ventilation hole is blocked.
Unplug the scanner’s power source before any maintenance or handling operation.
Only replace the fuse by a fuse of the same type.
n order to avoid any fire hazard, check for any flammable source nearby.
Use safety cables to secure the scanner. Take into account the weight of the scanner upon
positioning it on a high up structure in order to avoid the fall of the structure and thus
risks of injury.
Switch off the power and let the scanner cool down for about 15 minutes before transport,
for the scanner’s surface may be hot still.
n the event of a serious functioning problem, stop immediately to use the device. Do no
ever try to repair the device by yourself. Repairs made by unqualified individuals may
cause damages or malfunctions. Contact the nearest approved technical support center.
Always use spare parts of the same type.
Do no connect the scanner to any dimmer or power pack.
Do no open the device during its operation, the high voltage may cause a lethal electrical
shock.
n order to prevent or reduce risks of electrical shock or fire, do not expose the device to
rain or humidity.
Do not ever touch the led with your bare fingers after use to avoid serious injuries, for the
led may be very hot still.
Do not start the scanner without led to avoid degradation of the box..
3

Re lace the box and the lenses if they are visually damaged (for exam le cracks or
dee cuts during trans ort or handling). This is essential.
Do not look straight at the light going out of led when the scanner is switched on.
n order to prevent any risks of electrical shock you must not remove the cover. There
is no useful part for the user inside. Refer the repair to qualified personnel.
Installation
The scanner must be attached via its screw holes to the support with help of the provided
hook. Always make sure the scanner is firmly attached to avoid vibrations and sliding during
the operation.. Always make sure the structure to which the scanner is attached is secured and
able to bear 10 times the scanner’s weight.
2. Technical s ecifications.
This device does not roduce radio interference. This device meets Euro ean and
French requirements. Com liance has been established, and statements and
res ective documents have been registered by the manufacturer. This device has been
made for indoor decorative lighting effects.
Power supply : AC 220-250V 50/60Hz
Power: 50 W
Lamp : LED 30W
Shutter/Dimmer : Blackout, 0~100 variable strobe speed and soft transition
Movement: Pan: 180° / Tilt: 70°
Beam angle: 13,6°
Functions:
- Color wheel 7 colors+ white
- Gobos wheel 7 fixed gobos + open
- 3 facet rotating prism
- manual focus
Operating mode
-DMX control 9 or 11 channels/Stand-Alone with built-in microphone/Stand-Alone with
automatic mode /Master/Slave Mode
3.Scanner starting up
3.1. Access to main functions :
Control anel:
”MENU“ “▼ ” “▲” ”ENTER”
Press the “MENU” button to access to functions then « ▼ » or « ▲ » to browse through sub-menus,
« ENTER » to confirm.“MENU” to go back.
2 Operating modes are available : DMX control, Stand-Alone mode
4

MENU DESCR PT ON
Mode DMX
Master Mode slave1,slave2
Stand-Alone Mode : Auto 0/Auto 1 /Auto 2/Auto 3
Sound Mode / volume control
Activation/Deactivation backlight
pan and tilt inversion
reset configuration
DMX Set Adress DMX address selection 001-512 (A001-A512)
Channel Set Selection of DMX mode 9 or 11 channels
Mode Set MAST/SL 1/SL 2 Master/Slave mode selection
Show Set Show1/2/3/0 Auto Mode selection 0/1/2/3
Sound Sense 0-100 Micro sensitivity from 0 to 100
No DMX set bLAc/Auto/Soun/Hlod DMX512 Mode off
Led Backlight ON/OFF Activation/Deactivation backlight
Pan Inverse ON/OFF pan inversion
Tilt Inverse ON/OFF tilt inversion
Reset ON/OFF
3.2 DMX wiring
This product uses 3-pin XRL connectors for the DMX512 connection:
Pin 1 : Ground , Pin 2 : Data (-), Pin 3 : Data (+).
Example : connection between different fixtures in Master/Slave mode:
NB : in order to reduce signal errors, think of using a plug a the end of your DMX link.
5

4.DMX Control channels an values 199 and 11 channels
CHANNEL VALUE FUNCT ON
1 PAN 0-255 Pan
2 T LT 0-255 Tilt
3 Colors
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
100-109
110-119
120-129
130-139
140-255
White
Red
Green
Blue
Yellow
Purple
Light Blue
Orange
Orange+ Light Blue
Light Blue + Purple
Purple + Yellow
Yellow + Blue
Blue + Green
Green+ Red
Rotation from slow to fast
4 、Gobos Wheel
0-7
8-15
16-23
24-31
32-39
40-47
48-55
56-63
64-71
72-79
80-87
88-95
96-103
104-111
112-119
120-127
128-255
white
Gobo1
Gobo2
Gobo3
Gobo4
Gobo5
Gobo6
Gobo7
white
Gobo1 Shake
Gobo2 Shake
Gobo3 Shake
Gobo4 Shake
Gobo5 Shake
Gobo6 Shake
Gobo7 Shake
Rotation from slow to fast
5 Shutter/Strobe
0-9
9-249
250-255
Shutter closed
STROBOSCOPE from slow to fast
Shutter open
6 Dimmer 0-255 Linear Dimmer 0-100 %
7 Pan/Tilt speed 0-255 pan/tilt speed adjustment
8 Show Modes 0-59 No Function
6

60-159
160-255
Programs
Auto + Sound
9, Reset
0-20
21-100
101-200
201-249
250-255
No function
PAN reset
T LT reset
PAN/T LT reset
General reset
CHANNEL VALUE FUNCT ON
1 PAN 0-255 Pan
2 PAN F NE 0-255 Pan 16 bits
3 T LT 0-255 Tilt
4 T LT F NE 0-255 Tilt 16 bits
5 Colors
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-79
80-89
90-99
100-109
110-119
120-129
130-139
140-255
White
Red
Green
Blue
Yellow
Purple
Light Blue
Orange
Orange+ Light Blue
Light Blue + Purple
Purple+ Yellow
Yellow + Blue
Blue + Green
Green + Red
Rotation from slow to fast
6 、Gobos wheel
0-7
8-15
16-23
24-31
32-39
40-47
48-55
56-63
64-71
72-79
80-87
88-95
96-103
104-111
112-119
120-127
128-255
white
Gobo1
Gobo2
Gobo3
Gobo4
Gobo5
Gobo6
Gobo7
white
Gobo1 Shake
Gobo2 Shake
Gobo3 Shake
Gobo4 Shake
Gobo5 Shake
Gobo6 Shake
Gobo7 Shake
Rotation from slow to fast
7 Shutter/Strobe 0-9 Shutter closed
7

9-249
250-255
STROBOSCOPE from slow to fast
Shutter open
8 Dimmer 0-255 Linear Dimmer 0-100 %
9 Pan/Tilt speed 0-255 Pan/tilt speed adjustment
10 Show Modes
0-59
60-159
160-255
No Function
Programs
Auto + Sound
11 Reset
0-20
21-100
101-200
201-249
250-255
No Function
PAN reset
T LT reset
PAN/T LT reset
General reset
5. Troubleshooting
A. The scanner does not work, no lights nor fan :
1. Check the power cord and the main fuse.
2. Check that your electrical system is working.
B. No res onse to DMX controller
1. A dot must flash on the device control screen. f it’s not the case, check if cables are
properly connected and in good condition.
2. f the dot flashes, check your addressing as well as the polarity of your DMX wiring.
3. Try an other DMX controller
4. Avoid to lay your DMX cables alongside high-voltage lines to avoid interference.
C. In Master/Slave Mode some devices don’t ro erly res ond
1. Check cables and the connection diagram.
2. Check that devices are properly assigned in Master/Slave mode.
6. Cleaning
Before any cleaning operation, unplug the scanner power cord in order to avoid any
electrocution risk. Cleaning the optic must be done periodically in order to optimize the
scanner’s brightness. The cleaning frequency depends on the operating environment. Smoke
and dust may cause a large accumulation of dirt upon the scanner’s optics :
-Clean it with a soft dry cloth.
- Do not use liquid or detergent products.
- Clean external lenses approximately every 20 days, with a soft dry cloth, without overly
pressing on the lenses.
8
