Electrolux EDW 1001 User manual

© Electrolux
Muggenhofer Straße 135
D-90429 Nürnberg
ermany
Fax [phone]
Spares Operation
,17(16,9


=(,7
925:$+/

K
K
K
5(,1,*(1
(,1$86
752&.1(1
(1'(
6$/=
./$563h/(5
1250$/

1250$/
%,2 925
63h/(1
48,&.

FAVORIT
30 MINUTEN
Publ.-Nr.:
599 515 006
09.02
R.Kurzke
Ausgabe:
EN
SERVICE MANUAL
DISHWASHER
EDW 1001
Dishwasher
+
EDW 1001
+

- 2 -
09.2002 R.K. 599 515 006 EN
Index
1. Control panel ..........................................................................3
2. Dimensions.............................................................................3
3. Components ...........................................................................4
3.1 Electronic ............................................................................... 4
3.2. Circulation pump ....................................................................4
3.3 Drain pump .............................................................................4
3.4 Flow heater ............................................................................4
3.5 Detergent dispenser ...............................................................5
3.6 NTC thermal sensor ...............................................................6
3.7 Pressure switch ...................................................................... 6
3.8 Interference filter ....................................................................6
3.9 Spray arms .............................................................................7
3.10 Drying fan ...............................................................................7
3.11 Regeneration dosing with condensor .....................................8
3.11.1 Water softening/regeneration ................................................8
4. Repair informations ................................................................9
4.1 Open the housing ................................................................... 9
4.2 Position of the components .................................................... 10 12
5. Water course Scheme ............................................................ 13
5.1 All Around Water Protection ..................................................14
5.2 Water intake ...........................................................................15
5.2.1 Water load steps .................................................................... 16 17
5.3 Draining ..................................................................................18 19
6. Electronic ...............................................................................20
6.1 Modifications EDW 1000 / EDW 1001 ...................................20
6.2 In and Output Elements ........................................................ 21
6.3 General .................................................................................. 22
6.4 Input philosophy: Choose programs and options ................... 23
6.5 Input philosophy: From program start to stop .......................24
6.6 Input philosophy: Delete change cancel ............................25
6.7 Input philosophy: Displays .....................................................26
6.8 Operating errors and flow interruption ................................... 27
6.9 Servicefunction / Adjust water hardness ................................ 28
6.10 Servicefunction / Switching off the rinsing agent display .......29
6.11 Servicefunction / Manufactur ..................................................30
6.12 Servicefunction / Customer support .......................................31
6.13 Overview of service and customer support functions .............32
6.14 Overview of error displays ...................................................... 33
7. Program steps ........................................................................ 34
8. Wirings ...................................................................................35
8.1 electric circuit diagram ...........................................................35
8.2 Wiring diagramn ..................................................................... 36

- 3 -
09.2002 R.K. 599 515 006 EN
1. Control panel
2. Dimensions
Build-in dimensions for Integrated
Dishwashers
ÖKO-FAVORIT
* Appliances with
height
adjustable feet
* Appliances with height-adjustable feet
Plinth height for appliances 820 mm high
100 - 175 mm
Plinth height for appliances 870 mm high
150 - 2 0 mm
Build-in dimensions for Built-Under
Dishwashers
ÖKO-FAVORIT
Dimensions for Freestanding Dishwasher
Height 5 cm
Width 60 cm
Depth 60 cm
Height with worktop removed 2 cm
Feet adjustment 1 cm
Control lamps
On/Off button
Door handleControl lamps
Progamme buttons
Function buttons
Delay start
button
Indicator lamps
delayed start

- 4 -
05.2002 R.K. 599 514 DE
3.2 Circulation Pump
The circulation pump is driven by an asynchronous motor with
an auxiliary winding. The auxiliary winding ist in circuit with a 3
mF capacitor. A tacho generator is used for speed control.
There are three speeds for rinsing.
2 00 1/min, 2200 1/min, 1900 1/min, 1700 1/min, 1600 1/min,
Power output50 W.
Wicklungswiderstände
Hauptwicklung 45 - 55 Ohm
Hilfswicklung 110 - 140 Ohm
Tacho ca. 220 Ohm
3.3 Drain Pump
The drain pump is driven by a synchronous motor.
Power output 26 W.
Pump rate 15 l/min.
3.4 Flow Heater
The flow heater heats the water to the required temperature.
During the wash cycle, water is contantly passing through the
flow heater.
Power output 2000 W
Resistor 25 W
Protector 9 °C ± 5 K
Thermal fuse 260 °C
3. Components
3.1 Electronic
On electronic models, a micro processor controls all
components, this is done using triacs. The electronic also
memorizes all programme data.
The heating is switched by a relay on the electronic board.
Nur bei Ausführungen mit Deckensprüharm

- -
05.2002 R.K. 599 514 DE
3.5 Detergent dispenser
Dosing of detergent
prewash 10 ml
wash 20 - 30 ml
Dosing of rinse aid
position 1 - 6 2 ml - 7 ml
Capacity
140 ml
display lack of rinse aid
dosing of rinse-aid
maximum filling level
outlet of rinse-aid
detergent tray
detergent tray for pre wash
Spule
EIN
AUS
Zeit
The detergent compartment 1 is filling corresponding to the set dosing
quantity when the door is open. Possibly existing rinse-aid in compartments
2 and 3 flows back into the storage tank of the rinse-aid. The detergent
trays are filled up. The door will be closed and the detergent for prewash
will be rinsed out through the slots in the detergent dispenser cover.
During the washing cycle the coil is switched on and the detergent
compartment cover releases the detergent. The rinse-aid flows from
compartment 1 into compartment 2.
After switching off the coil, the rinse-aid flows from compartment 2 into
compartment 3.
During the rinse cycle, the coil will be switched on when the rinse is warmed
and the rinse-aid runs from compartment 3 into the rinse tank. At the same
time, the remaining rinse-aid (15 %) runs from compartment 1 into
compartment 2.
With the coil switched off, the rinse-aid flows from compartment 2 into
compartment 3.
During the rinse cycle, the coil is always switched on twice. When it is
switched on the second time, the remaining rinse-aid flows into the rinse
tank.
EIN
AUS
Zeit
EIN
AUS
Zeit
EIN
AUS
Zeit
EIN
AUS
Zeit
EIN
AUS
Zeit
coil

- 6 -
05.2002 R.K. 599 514 DE
3.6 N C- emperature Sensor
3.7 Pressure Switch
The pressure switch controls the water level.
Without water, contact 11 - 12 is closed.
fN Switch point with level 65 mm Ws
Reset point with level 45 mm Ws
The pressure switch is not adjustable.
3.8 Interference Filter
The interference filter is connected in the terminal board paral-
lel to the mains feed.
Temp. Resistor
10°C 9653 Ohm
25°C 4843 Ohm
60°C 1204 Ohm
90°C 445 Ohm

- 7 -
05.2002 R.K. 599 514 DE
3.9 Spray arms
The new cutlery basket is placed at the upper diswasher basket. The celling sprayarm sprays the water
directly onto the cutlery basket and tguarantees an excellent washing result with the cutlery placed in
that basket.
Function mode of the condensing drying
Rinse tank, fan and regenerating dosing with
condenser form a closed circuit. The humid air is
sucked from the top of the rinse tank and blown
through an air guide between rinse tank and
regenerating dosing. Thereby the air gets dry and
the condensate is guided to the drain tub.
The dry air gets through the rinse tank ventilation
into the rinse tank. During the drying phase, the
condenser is additionally cooled with 1 liter of
water.
fan
air guide for
condenser
rinse tank
ventilation
drain tub
3.10 Drying fan
The new drying fan is located at
the top on the rinse tank.
Celling spray arm upper spray arm lower spray arm
Active Drying
ctive Drying means the ventilation of a container without any movable parts
plastic container is clipped into the opening in the container cover, from where
a hose is passed to the appliance base.
Function
small quantity of moist air and some condensate
emerge from the hose. The condensate is collected
in the base side sections where it will evaporate.
If a larger quantity of condensate should be present
(due to many subsequent programme cycles) the
hose end will be immerged, thus stopping both the
convection and the condensating process in the
hose.
Flooding of the sections is therefore excluded. Only
very little moist air will be present.

- 8 -
05.2002 R.K. 599 514 DE
3.11.1 Water softening/regeneration
2
1
2
1
1. softener unit
2. regeneration dosage
chamber
3.11 Regenerating dosing
with condenser
The water softening can be adjusted in 10 levels. The incoming
water flows until positon 5 to 5 % through the softener which
works according to the ion exchange principle. The ion exchanger
is filled with small epoxy resin balls. The resins exchange the
hardness constituents (calcium and magnesium), for sodium
ions.
When all the sodium ions are used up, it is necessary to
regenerate the softener. This is done by flushing a brine solution
through the softener.
Afterwards the softener is washed out with fresh water and is now
fully effective.
Depending on the water hardness, regeneration is only necessary
after several wash cycles.
The remaining 15 % of water flow through the rinse tank ventilation
directly into the appliance.
From setting of level 6, the whole water flows through the
softener. For this purpose you also have to set mechanically from
0 to 1 with the regenerating dosing.
With the setting of level 9, it is additionally regenerated after the
washing in a rinse cycle. With the settings 1 to , it is regenerated
after the final rinse depending on need. The softening system is
designed for a water hardness of up to 70 °dH.
With every filling step, the condenser
cools down due to the cold incoming
water. Therefore another 1 liter of water
is required during the drying cycle.

- 9 -
05.2002 R.K. 599 514 DE
4. Service tips
4.1 Open the housing
Remove the screws (Abb.1) of the
upper plate on the left and right side.
Push the upper plate in front direction
to remove the plate (Abb.2).
12
1
23
1
2
To remove side panel remove fixing screws, pull
the panel away from the rear, and gently out of
the front trim. (pic.1).
Removing the
cover plates of the
base area, remove
these screwst
(Abb1+2).
Remove the screws (1) to pull the
outer door away.
To remove the panel, remove the
fixing screws (2) .
You need
Torx epuipment

- 10 -
05.2002 R.K. 599 514 DE
On/Off-Switch (1)
Electronic (2)
Electronic
Panel (1)
Detergent dispenser (2)
Thermal sensor (3)
Drain pump (4)
Pressure switch (5)
4.2 Position of Components
Detergent dispenser (1)
Spray arms (2)
Roof-mounted shower (3)
Salt container (4)
Filter (5)
Type plate (6)1
2
3
45
6
12
1
2
345

- 11 -
05.2002 R.K. 599 514 DE
Back side view
- Flow heater (1)
- Terminal box (2)
- Inlet hose (3)
- Drain hose (4)
- Water inlet for above spray arm (5)
Removing the detergent dosage chamber:
- disengage locking tabs (1), disconnect hoses (2)
- holding the top of the chamber, pull upwards
disengaging it from the softener.
Removing the softener unit :
- remove the securing nut located under the salt cap.
- press softener (1) down and remove it through the front
from the base area
- CAUTION if accessible release reed switch.
1
23
4
5
1
2
1

- 12 -
05.2002 R.K. 599 514 DE
Removing the base :
- remove side panels, rear panel and plinth panel
- gently release base fixing clips with a screwdriver (figure)
- take off base carefully and release circulation pump,
electronic and heater relay
- disconnect the float switch
1
2
3
45
With base removed, following components are accessible:
- Drain pump (1)
- Circulation pump (2)
- Flow heater (3)
- Temperature sensor / Turbidity sensor (4)
- Pressure switch (5)

- 13 -
09.2002 R.K. 599 515 006 EN
1 Inlet valve
2 Air break
3 Regeneration water dosage
4 Overflow safety level
5 Safety overflow
6 Inlet to sum from regeneration dosage chamber
7 Regeneration dosage chamber
8 Softener
9 Salt container
10 Non-return valve salt container
11 Regeneration valve
12 Safety inlet hose
13 Base tray
14 Float switch
15 Pressure switch
16 Filter
17 Circulation um
18 Flow heater
19 Drain um
20 Non-return valve
21 S ray arms
22 Roof-mounted shower
23 Tub vent
24 Sum assembly
5. Water Course Scheme
2
322
21
21
24
23
7
1
12
6
5
8
10
11 9
15
16 17
14
18
13
19
4
20
ohne
Sicherheitszulaufschlauch
Ausführung:
Kurze Regenerier osierung

- 14 -
09.2002 R.K. 599 515 006 EN
All-Around Water Protection
Aqua-Control Inlet Hose
The inlet hose has a double-wall construction. The inner hose is equipped with a flow restrictor built into the
tap connection, and has a flow rate of 4 litres per minute. If the inner tube starts bursting, the water reaches
the floor pan, gets diverted to the float switch in the floor pan and enables the drainage protection.
In this case the electric valve at the water hose get voltage free and the water connection gets locked.
The drain pump additionally pumps off the dishwasher so that no damage by water could be
produced.
An additional overflow protection is a defined overflow through the regeneration chamber. The water flows
into the bottom tray and activates the float switch, which energises the drain pump. This drains the
dishwasher preventing water damage.
Safety level
If the water level in the detergent dispenser transcends the overflow protection switch Safety level (4), the
water passes over the overflow protection switch (5) in the floor pan and also activates the float switch.
Leakage Protection
The anti-flood switch in the base tray will activate the drain pump and drain the water from the tub in the
event of an internal leakage. If the float switch is activated, all electric components are switched off except
the electronic and the drain pump.
18
1
2
3
4
5
6
7
89
10
11
12
13 14
15
16 17
19
20
21
22
23 24
1 Inlet valve
2 Air break
3 Regeneration water dosage
4 Overflow safety level
5 Safety overflow
6 Inlet to sum from regeneration dosage chamber
7 Regeneration dosage chamber
8 Softener
9 Salt container
10 Non-return valve salt container
11 Regeneration valve
12 Safety inlet hose
13 Base tray
14 Float switch
15 Pressure switch
16 Filter
17 Circulation um
18 Flow heater
19 Drain um
20 Non-return valve
21 S ray arms
22 Roof-mounted shower
23 Tub vent
24 Sum assembly
03.03. RK

- 15 -
09.2002 R.K. 599 515 006 EN
5.2 Water Inlet
The water flows into the regeneration dosage chamber (7) via inlet valve (1), over air break (2), into
regeneration dosage chambers (3) into softener (8). At this oint the water divides. 1/4 of the water
enters the tub through the vent (23). 3/4 of the water enters the sum (24) through hose (6).
The level control chamber built into the sum o erates the ressure switch (15).
1 Inlet valve
2 Air break
3 Regeneration water dosage
4 Overflow safety level
5 Safety overflow
6 Inlet to sum from regeneration dosage chamber
7 Regeneration dosage chamber
8 Softener
9 Salt container
10 Non-return valve salt container
11 Regeneration valve
12 Safety inlet hose
13 Base tray
14 Float switch
15 Pressure switch
16 Filter
17 Circulation um
18 Flow heater
19 Drain um
20 Non-return valve
21 S ray arms
22 Roof-mounted shower
23 Tub vent
24 Sum assembly
18
1
2
3
4
5
6
7
89
10
11
12
13 14
15
16 17
19
20
21
22
23 24

- 16 -
09.2002 R.K. 599 515 006 EN
5.2.1 Water load steps (Example)
Static filling
- Static filling until pressure switch point.
failure code:
If this point isnt reached after max. 2 minutes (Timeout 1), a
failure code is displayed and the program is stopped. The pro-
gram phase display PPD-LED LD9 is blinking.
Dynamic filling
- 10 seconds filling at reduced circulation pump speed
- 5 seconds pause
- 10 seconds filling at reduced circulation pump speed
- filling with increasing circulation pump speed. As soon as the
target speed has been reached, it is filled up to the pressure
switchpoint.
Failure code:
If this dynamic switchpoint isnt reached within total 4 minutes
(Timeout 2), the dynamic filling can be repeated 3 times. Only
after non-successful repeating 3 times, a failure code is displayed
and the program is stopped. The PPD-LED LD9 is blinking.
LD9
LD10
LD11
LD9
LD10
LD11
*) The target
speed is
dependent on
the subsequent
pulse wash.
Timeout1
Timeout2
staticwater
load
tolevel
dynamic water
load
with level control
max. 4
repetitions
valve
off
on
water
in L
0
dynamic
water load
speed
in U/min
0
10 Sek.
time
in S ek.
target-
speed

20 Sek.
time
inSek.
time
in S ek.
filing fillingis possible
level check:
water fai lur e dis played
if level notreached!
ca. 1,6
3,6 -4
static
water load
level check:
water failur e dis played
if level not reached!
5 Sek.
1600
5 Sek.
SXOVHZDVK SXOVHPLQ 3DXVHPLQ WDUJHWVSHHGLQG\QDPLFILOOLQJ
 VHF VHF PLQ
 VHF VHF PLQ
 VHF VHF PLQ

- 17 -
09.2002 R.K. 599 515 006 EN
New pulse wash with random functionality
*) The variable speed is
1600 1/min at the
moment and equal to all
appliances.
Random-function
Thigh,r = time for high speed (calculated with random funktion)
Thigh = time for high speed (cycle definition)
Tr= random time
Tlow = time for low speed
Ratio = factor for low speed (eeprom definition)
Circulation
The circulation pump (17) pumps the water simultaneously into the ceiling shower (22) and into both
spray arms (21). The water is filtered in the sieves (16) and led to the circulation pump.
Function of the new pulse wash with random functionality
After the filling steps, the circulation pump is running at two rotational speeds.
The ratio of pulse
time and pause is
always 1 : 5.
T high, r =T
high + T r
T low =T
high, r + Ratio
water
inL
0
20 Sec.
start-routine
time
insec.
pressureswitch
point
water level
dynamic
pulse wash
level
speed
inU/min
0time
insec.
2800
variable
speed
1600
Thigh,r Thigh,r Tlow Tlow Thigh,r
-function
Thigh,r = time (high speed) + r andom time
3XOVH:DVK 8VHZLWK:DVK&\FOHV
'HILQLWLYH7LPH 5DQGRP7LPH 'HILQLWLYH7LPH 5DQGRP7LPH
 VHF VHF  VHF SUHZDVKLQWHQVLYH
ZDVKLQWHQVLYH
 VHF VHF  VHF ZDVKDQGLQWHUPHGLDWHZDVK
SUHZDVKQRUPDO
 VHF VHF  VHF ULQVH
3XOVHWLPHPLQ 3DXVHPLQ

- 18 -
09.2002 R.K. 599 515 006 EN
5.3 Draining
During the wash cycle the water is pumped out at various stages. First the draining water cleans the
filters (16). The filters are open at the bottom which allows any soilage to be rinsed off sufficiently.
There is a non-return valve ( 0) at the inlet connection to the drain pump (19). This valve prevents the
water
1 Inlet valve
2 Air break
3 Regeneration water dosage
4 Overflow safety level
5 Safety overflow
6 Inlet to sum from regeneration dosage chamber
7 Regeneration dosage chamber
8 Softener
9 Salt container
10 Non-return valve salt container
11 Regeneration valve
12 Safety inlet hose
13 Base tray
14 Float switch
15 Pressure switch
16 Filter
17 Circulation um
18 Flow heater
19 Drain um
20 Non-return valve
21 S ray arms
22 Roof-mounted shower
23 Tub vent
24 Sum assembly
18
1
2
3
4
5
6
7
89
10
11
12
13 14
15
16 17
19
20
21
22
23 24

- 19 -
09.2002 R.K. 599 515 006 EN
Sequence draining with pressure switch level check
on
off
drain pump
T2(variable) T3(variable) T1(variable)
1 drainingsequence
withvariabletiming
level check!
'UDLQ&\FOH 777
)LUVWGUDLQLQJEHIRUHHYHU\ZDVKF\FOH VHF VHF VHF
'UDLQLQJDIWHUWKHZDVKF\FOHV VHF VHF VHF
New draining with sequence draining
- The draining step contains of 3 time sequences.
In the middle sequence, during time T2 the drain pump is stopped.
- At the end of the drain step, the water level is checked.
- If the switch back is reached, the drain step is terminated.
If the switch back isnt reached, the drain step is repeated.
- A failure code is displayed, if after 2 drain steps, the switch back couldnt be reached.
In this case, the program is stopped and PPD-LED LD10 is blinking.
LD9
LD10
LD11

6.10RGLILFDWLRQVIURP(':WR(':
Author: Doris ReißWPD/EP - Basis EDW1000 (C0901m10.s2)
1R *URVV'HVFULSWLRQRIWKH&KDQJH 'HWDLOHG'HVFULSWLRQ
1 Fan control
2Program Reset during Drying in case of power failure
(switching ON/OFF)
3Water hardness setting procedure changed.
Operation Manual needs to be adapted for existing machines.
4
Rinsing agent deconnectable
(Clip handle as for water hardness setting, but key 2)
for cleansing agent with integr. rinsing product. Rinsing agent
LED is deactivated.
Operation Manual needs to be adapted
You should not make the user aware of filling up
rinsing agent, if this is already integrated in the
cleansing agent.
5Automatic half-charge detection
Limit and correcting factors in the EEPROM As with ET/ET plus by means of heating speed
6Automatic Start for Super Simple
only when switching ON/OFF by use of main switch You can define the program for automatic start in the EEPROM
7Selection of two programs by one key only
Super Simple only (toggle function)
8 Superwash 120 min
9 Intensive program 80 min Only with ZM
10 Eat Load Run program Duration 30 min
11 Point of rinsing with programs for new drying modified from
program start to Drying.
12 Wasserzulauf Trocknen wegen neuer Reg-dos
(New Water system) 1 l water admission for drying support
13 New Reg-dos (New Water system) -
Change of rinsing to 2 litres in the EEPROM
14 With half-full detection - 5°C during Wash
not with Intensive) With half-full detection, the temp. is reduced by 5K during Wash.
15 New energy-saving program for BAB
16 Adaptation of minimum program durations for hot water
connection.
17 Intensive and normal programs without impulse rinsing for ZM
as well
18 5HPRYHG
Alternating spray beam drive by ball
19 5HPRYHG
Alternating spray beam drive by ball with half-full
20 5HPRYHG
Tablets option no longer possible
21 5HPRYHG
Subprograms no longer required were canceled.
22 5HPRYHG
Change of manufacture testing program for ZM
23 5HPRYHG
Program counter over the life cycle Readable in the EEPROM
