Electrolux ESL 63040R User manual

ESL 63040R
................................................ .............................................
EN DISHWASHER USER MANUAL

CONTENTS
1. SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3. CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. PROGRAMMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7. DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8. HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9. CARE AND CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
11. TECHNICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12. ENVIRONMENT CONCERNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it
decades of professional experience and innovation. Ingenious and stylish, it has been designed
with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great
results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available.
The information can be found on the rating plate. Model, PNC, Serial Number.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2www.electrolux.com

1. SAFETY INSTRUCTIONS
Before the installation and use of the ap-
pliance, carefully read the supplied in-
structions. The manufacturer is not re-
sponsible if an incorrect installation and
use causes injuries and damages. Always
keep the instructions with the appliance
for future reference.
1.1 Children and vulnerable
people safety
WARNING!
Risk of suffocation, injury or per-
manent disability.
• Do not let persons, children included,
with reduced physical sensory, reduced
mental functions or lack of experience
and knowledge use the appliance. They
must have supervision or instruction for
the operation of the appliance by a per-
son who is responsible for their safety.
• Do not let children play with the appli-
ance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the
appliance door when it is open.
1.2 Installation
• Remove all the packaging.
• Do not install or use a damaged appli-
ance.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• Obey the installation instruction sup-
plied with the appliance.
• Make sure that the appliance is installed
below and adjacent to safe structures.
Electrical connection
WARNING!
Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information
on the rating plate agrees with the pow-
er supply. If not, contact an electrician.
• Always use a correctly installed shock-
proof socket.
• Do not use multi-plug adapters and ex-
tension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Contact the Service or an electrician to
change a damaged mains cable.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
• Do not touch the mains cable or the
mains plug with wet hands.
• This appliance complies with the E.E.C.
Directives.
Water connection
• Make sure not to cause damage to the
water hoses.
• Before you connect the appliance to
new pipes or pipes not used for a long
time, let the water flow until it is clean.
• The first time you use the appliance,
make sure that there is no leakage.
• The water inlet hose has a safety valve
and a sheath with an inner mains cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged, im-
mediately disconnect the mains plug
from the mains socket. Contact the
Service to replace the water inlet hose.
ENGLISH 3

1.3 Use
• This appliance is intended to be used in
household and similar applications such
as:
– Staff kitchen areas in shops, offices
and other working environments
– Farm houses
– By clients in hotels, motels and other
residential type environments
– Bed and breakfast type environ-
ments.
WARNING!
Risk of injury, burns, electrical
shock or fire.
• Do not change the specification of this
appliance.
• Put knives and cutlery with sharp points
in the cutlery basket with the points
down or in a horizontal position.
• Do not keep the appliance door open
without supervision to prevent to fall on
it.
• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous.
Obey the safety instructions on the de-
tergent packaging.
• Do not drink and play with the water in
the appliance.
• Do not remove the dishes from the ap-
pliance until the programme is comple-
ted. There can be detergent on the
dishes.
• The appliance can release hot steam if
you open the door while a programme
operates.
• Do not put flammable products or items
that are wet with flammable products
in, near or on the appliance.
• Do not use water spray and steam to
clean the appliance.
1.4 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent chil-
dren and pets to get closed in the ap-
pliance.
4www.electrolux.com

2. PRODUCT DESCRIPTION
12
3
4
7
95
6
11
8
10
1Upper spray arm
2Lower spray arm
3Filters
4Rating plate
5Salt container
6Water hardness dial
7Rinse aid dispenser
8Detergent dispenser
9Cutlery basket
10 Lower basket
11 Upper basket
3. CONTROL PANEL
2
1
3
54
AB
1On/off button
2Programme indicators
3Indicators
4Programme button
5Delay button
Indicators Description
End indicator.
ENGLISH 5

Indicators Description
Rinse aid indicator. This indicator is off while the programme oper-
ates.
Salt indicator. This indicator is off while the programme operates.
4. PROGRAMMES
Programme
1)
Degree of
soil
Type of load
Programme
phases
Duration
(min)
Energy
(kWh)
Water
(l)
2)
Heavy soil
Crockery, cut-
lery, pots and
pans
Prewash
Wash 70 °C
Rinses
Dry
120 - 130 1.8 -
2.0
22 - 24
Normal soil
Crockery and
cutlery
Prewash
Wash 65 °C
Rinses
Dry
105 - 115 1.5 -
1.7
23 - 25
3)
Fresh soil
Crockery and
cutlery
Wash 60 °C
Rinse
30 0.9 9
4)
Normal soil
Crockery and
cutlery
Prewash
Wash 50 °C
Rinses
Dry
130 - 140 1.0 -
1.2
14 - 16
5)
All Prewash 12 0.1 5
1) The pressure and the temperature of the water, the variations of the mains supply, the
options and the quantity of dishes can change the programme duration and the
consumption values.
2) This programme has a high temperature rinsing phase for better hygiene results. During the
rinsing phase, the temperature stays at 70 °C for 10 to 14 minutes.
3) With this programme you can wash a load with fresh soil. It gives good washing results in a
short time.
4) With this programme you have the most efficient use of water and energy consumption for
crockery and cutlery with normal soil. (This is the standard programme for test institutes).
5) Use this programme to quickly rinse the dishes. This prevents the remaining food to bond
on the dishes and bad odours to come out from the appliance.
Do not use detergent with this programme.
Information for test institutes
For all the necessary information for test performance. send an email to:
[e-mail]
Write down the product number (PNC) that is on the rating plate.
6www.electrolux.com

5. OPTIONS
5.1 Acoustic signals
The acoustic signals operate in these
conditions:
• When the programme is completed.
• A malfunction occurs to the appliance.
Factory setting: on.
You can deactivate the acoustic
signals.
Deactivating the acoustic signals
1. Press the on/off button to activate the
appliance.
2. Make sure that the appliance is in set-
ting mode. Refer to ‘SETTING AND
STARTING A PROGRAMME’.
3. Press and hold the programme button
until the programme indicator (A)
flashes and the programme indicator
(B) comes on.
4. Press immediately the programme
button.
• The programme indicator (A) comes
on with a fixed light.
• The programme indicator (B) starts
to flash.
5. Wait until the programme indicator (A)
goes off and the end indicator comes
on (the programme indicator (B) con-
tinues to flash).
• The acoustic signals are on.
6. Press the programme button. The end
indicator goes off.
• The acoustic signals are off.
7. Deactivate the appliance to confirm
the setting.
Activating the acoustic signals
1. Refer to ‘Deactivating the acoustic sig-
nals’, step (1) through (4).
2. Wait until the programme indicator (A)
goes off. The end indicator is off and
programme indicator (B) continues to
flash.
• The acoustic signals are off.
3. Press the programme button. The end
indicator comes on.
• The acoustic signals are on.
4. Deactivate the appliance to confirm
the setting.
6. BEFORE FIRST USE
1. Make sure that the set level of the wa-
ter softener agrees with the water
hardness in your area. If not, adjust
the water softener. Contact your local
water authority to know the water
hardness in your area.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Processing residues can stay in the
appliance. Start a programme to re-
move them. Do not use detergent and
do not load the baskets.
6.1 Adjusting the water softener
Water hardness Water softener
adjustment
German
degrees
(°dH)
French
degrees
(°fH)
mmol/l Clarke
degrees
Manual Elec-
tronic
51 - 70 91 - 125 9.1 - 12.5 64 - 88 2
1)
10
43 - 50 76 - 90 7.6 - 9.0 53 - 63 2
1)
9
ENGLISH 7

Water hardness Water softener
adjustment
German
degrees
(°dH)
French
degrees
(°fH)
mmol/l Clarke
degrees
Manual Elec-
tronic
37 - 42 65 - 75 6.5 - 7.5 46 - 52 2
1)
8
29 - 36 51 - 64 5.1 - 6.4 36 - 45 2
1)
7
23 - 28 40 - 50 4.0 - 5.0 28 - 35 2
1)
6
19 - 22 33 - 39 3.3 - 3.9 23 - 27 2
1)
5
1)
15 - 18 26 - 32 2.6 - 3.2 18 - 22 1 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 1 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 1 2
< 4 < 7 < 0.7 < 5 1
2)
1
2)
1) Factory position.
2) Do not use salt at this level.
You must adjust the water soften-
er manually and electronically.
Manual adjustment
Turn the water hardness dial to the posi-
tion 1 or 2.
Electronic adjustment
1. Press the on/off button to activate the
appliance.
2. Make sure that the appliance is in set-
ting mode. Refer to ‘SETTING AND
STARTING A PROGRAMME’.
3. Press and hold the programme button
until the programme indicator (A)
starts to flash and the programme in-
dicator (B) comes on.
4. Wait until the programme indicator (B)
goes off and the end indicator starts to
flash (the programme indicator (A)
continues to flash).
5. Press the programme button.
• The end indicator flashes intermit-
tently. The number of flashes shows
the level of the water softener, e.g. 5
flashes + pause + 5 flashes = level
5.
6. To adjust the level of the water soften-
er, press the programme button. Each
time you press the programme button
you go to the next level.
7. Deactivate the appliance to confirm
the setting.
8www.electrolux.com

6.2 Filling the salt container
1. Turn the cap counterclockwise and
open the salt container.
2. Put 1 litre of water in the salt contain-
er (only for the first time).
3. Fill the salt container with dishwasher
salt.
4. Remove the salt around the opening
of the salt container.
5. Turn the cap clockwise to close the
salt container.
CAUTION!
Water and salt can come out from
the salt container when you fill it.
Risk of corrosion. To prevent it,
after you fill the salt container,
start a programme.
6.3 Filling the rinse aid dispenser
M
A
X
1
2
3
4
+
-
AB
D
C
1. Press the release button (D) to open
the lid (C).
2. Fill the rinse aid dispenser (A), no
more than the mark 'max'.
3. Remove the spilled rinse aid with an
absorbent cloth to prevent too much
foam.
4. Close the lid. Make sure that the re-
lease button locks into position.
You can turn the selector of the
released quantity (B) between po-
sition 1 (lowest quantity) and posi-
tion 4 (highest quantity).
7. DAILY USE
1. Open the water tap.
2. Press the on/off button to activate the
appliance. Make sure that the appli-
ance is in setting mode, refer to ’SET-
TING AND STARTING A PRO-
GRAMME’.
• If the salt indicator is on, fill the salt
container.
• If the rinse aid indicator is on, fill the
rinse aid dispenser.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme
for the type of load and the degree of
soil.
ENGLISH 9

7.1 Using the detergent
20
30
M
A
X
1
2
3
4
+
-
AB
C
1. Press the release button (B) to open
the lid (C).
2. Put the detergent in the compartment
(A) .
3. If the programme has a prewash
phase, put a small quantity of deter-
gent on the inner part of the appli-
ance door.
4. If you use detergent tablets, put the
tablet in the compartment (A).
5. Close the lid. Make sure that the re-
lease button locks into position.
7.2 Using the combi detergent
tablets
When you use tablets, that contain salt
and rinse aid, do not fill the salt container
and the rinse aid dispenser. The rinse aid
indicator always comes on if the rinse aid
dispenser is empty.
1. Adjust the water softener to the lowest
level.
2. Set the rinse aid dispenser to the low-
est position.
If you stop to use the combi
detergent tablets, before you
start to use separately
detergent, rinse aid and
dishwasher salt, do these steps:
1. Press the on/off button to activate the
appliance.
2. Set the water softener to the highest
level.
3. Make sure that the salt container and
the rinse aid dispenser are full.
4. Start the shortest programme with a
rinsing phase, without detergent and
without dishes.
5. Adjust the water softener to the water
hardness in your area.
6. Adjust the released quantity of rinse
aid.
7.3 Setting and starting a
programme
Setting mode
The appliance must be in setting mode to
accept some operations.
The appliance is in setting mode when,
after the activation, all the programme in-
dicators are off and the end indicator
flashes.
If the control panel shows other condi-
tions, press and hold the programme but-
ton until the appliance is in setting mode.
Starting a programme without
delay start
1. Open the water tap.
2. Press the on/off button to activate the
appliance. Make sure that the appli-
ance is in setting mode.
3. Press continuously the programme
button until the indicator of the pro-
gramme you want to set comes on.
4. Close the appliance door. The pro-
gramme starts.
Starting a programme with delay
start
1. Set the programme.
2. Press the delay button to delay the
start of the programme of 3 hours.
The delay indicator comes on.
3. Close the appliance door. The count-
down starts.
10 www.electrolux.com

• When the countdown is completed,
the programme starts.
Opening the door while the
appliance operates
If you open the door, the appliance stops.
When you close the door, the appliance
continues from the point of interruption.
Cancelling the delay start while
the countdown operates
1. Open the appliance door.
2. Press the delay button, the delay indi-
cator goes off.
3. Close the appliance door. The pro-
gramme starts.
Cancelling the programme
1. Open the appliance door.
2. Press and hold the programme button
until the indicator of the set pro-
gramme goes off and the end indica-
tor flashes.
Make sure that there is detergent
in the detergent dispenser before
you start a new programme.
At the end of the programme
When the programme is completed, an
intermittent acoustic signal operates and
the end indicator comes on.
1. Press the on/off button to deactivate
the appliance.
2. Close the water tap.
• Let the dishes become cold be-
fore you remove them from the
appliance. Hot dishes can be
easily damaged.
• First remove the items from the
lower basket, then from the up-
per basket.
• There can be water on the
sides and on the door of the
appliance. Stainless steel be-
comes cool more quickly than
the dishes.
8. HINTS AND TIPS
8.1 The water softener
Hard water contains a high quantity of
minerals that can cause damage to the
appliance and bad washing results. The
water softener neutralises these minerals.
The dishwasher salt keeps the water soft-
ener clean and in good conditions. It is
important to set the right level of the water
softener. This makes sure that the water
softener uses the correct quantity of dish-
washer salt and water.
8.2 Using salt, rinse aid and
detergent
• Only use salt, rinse aid and detergent
for dishwasher. Other products can
cause damage to the appliance.
• The rinse aid helps, during the last rins-
ing phase, to dry the dishes without
streaks and stains.
• Combi detergent tablets contain deter-
gent, rinse aid and other added agents.
Be sure that these tablets are applica-
ble to the water hardness in your area.
Refer to the instructions on the packag-
ing of the products.
• Detergent tablets do not fully dissolve
with short programmes. To prevent de-
tergent residues on the tableware, we
recommend that you use the tablets
with long programmes.
Do not use more than the correct
quantity of detergent. Refer to the
instructions on the detergent
packaging.
8.3 Loading the baskets
Refer to the supplied leaflet with
examples of the load of the bas-
kets.
• Only use the appliance to wash items
that are dishwasher-safe.
ENGLISH 11

• Do not put in the appliance items made
of wood, horn, aluminium, pewter and
copper.
• Do not put in the appliance items that
can absorb water (sponges, household
cloths).
• Remove remaining food from the items.
• To remove easily remaining burned
food, soak pots and pans in water be-
fore you put them in the appliance.
• Put hollow items (cups, glasses and
pans) with the opening down.
• Make sure that cutlery and dishes do
not bond together. Mix spoons with
other cutlery.
• Make sure that glasses do not touch
other glasses.
• Put the small items in the cutlery bas-
ket.
• Put the light items in the upper basket.
Make sure that they do not move.
• Make sure that the spray arms can
move freely before you start a pro-
gramme.
8.4 Before starting a
programme
Make sure that:
• The filters are clean and correctly instal-
led.
• The spray arms are not clogged.
• The position of the items in the baskets
is correct.
• The programme is applicable for the
type of load and for the degree of soil.
• The correct quantity of detergent is
used.
• There is dishwasher salt and rinse aid
(unless you use combi detergent tab-
lets).
• The cap of the salt container is tight.
9. CARE AND CLEANING
WARNING!
Before maintenance, deactivate
the appliance and disconnect the
mains plug from the mains socket.
Dirty filters and clogged spray
arms decrease the washing re-
sults.
Make a check regularly and, if
necessary, clean them.
9.1 Cleaning the filters
A
B
C
C
1. Turn the filter (A) counterclockwise
and remove it.
12 www.electrolux.com

A1
A2
2. To disassemble the filter (A), pull
apart (A1) and (A2).
3. Remove the filter (B).
4. Wash the filters with water.
5. Put the filter (B) to its initial position.
Make sure that it assembles correctly
under the two guides (C).
6. Assemble the filter (A) and put it into
position in filter (B). Turn it clockwise
until it locks.
An incorrect position of the filters
can cause bad washing results
and damage to the appliance.
9.2 Cleaning the spray arms
Do not remove the spray arms.
If the holes in the spray arms are clogged,
remove remaining parts of soil with a thin
pointed object.
9.3 External cleaning
Clean the appliance with a moist soft
cloth.
Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads
or solvents.
10. TROUBLESHOOTING
The appliance does not start or it stops
during operation.
Before you contact the Service, refer to
the information that follows for a solution
to the problem.
With some problems, different indica-
tors flash continuously or intermit-
tently at the same time to show an
alarm code.
ENGLISH 13

Alarm code Problem
• The indicator of the set programme
flashes continuously.
• The end indicator flashes 1 time in-
termittently.
The appliance does not fill with water.
• The indicator of the set programme
flashes continuously.
• The end indicator flashes 2 times in-
termittently.
The appliance does not drain the water.
• The indicator of the set programme
flashes continuously.
• The end indicator flashes 3 times in-
termittently.
The anti-flood device is on.
WARNING!
Deactivate the appliance before
you do the checks.
Problem Possible solution
You cannot activate the appli-
ance.
Make sure that the mains plug is connected
to the mains socket.
Make sure that there is not a damaged fuse in
the fuse box.
The programme does not start. Make sure that the appliance door is closed.
If the delay start is set, cancel the setting or
wait for the end of the countdown.
The appliance does not fill with
water.
Make sure that the water tap is open.
Make sure that the pressure of the water sup-
ply is not too low. For this information, con-
tact your local water authority.
Make sure that the water tap is not clogged.
Make sure that the filter in the inlet hose is not
clogged.
Make sure that the inlet hose has no kinks or
bends.
The appliance does not drain the
water.
Make sure that the sink spigot is not clogged.
Make sure that the drain hose has no kinks or
bends.
The anti-flood device is on. Close the water tap and contact the Service.
After the checks are completed, activate
the appliance. The programme continues
from the point of interruption.
If the problem occurs again, contact the
Service.
If other alarm codes appear, contact the
Service.
14 www.electrolux.com

10.1 If the washing and drying
results are not satisfactory
Whitish streaks or bluish layers on
glasses and dishes
• The released quantity of rinse aid is too
much. Adjust the rinse aid selector to a
lower position.
• The quantity of detergent is too much.
Stains and dry water drops on
glasses and dishes
• The released quantity of rinse aid is not
sufficient. Adjust the rinse aid selector
to a higher position.
• The quality of the detergent can be the
cause.
Dishes are wet
• The programme is without a drying
phase or with a low temperature drying
phase.
• The rinse aid dispenser is empty.
• The quality of the rinse aid can be the
cause.
Refer to ‘HINTS AND TIPS’ for
other possible causes.
11. TECHNICAL INFORMATION
Dimensions Width / Height / Depth (mm) 596 / 818 - 898 / 550
Electrical connection Refer to the rating plate.
Voltage 200 V
Frequency 50/60 Hz
Water supply pressure Min. / max. (bar / MPa) (0.5 / 0.05 ) / (8 / 0.8 )
Water supply
1)
Cold water or hot water
2)
max. 60 °C
Capacity Place settings 12
Power consumption Left-on mode 0.99 W
Off-mode 0.10 W
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
2) If the hot water comes from alternative sources of energy, (e.g. solar panels, aeolian
energy), use the hot water supply to decrease energy consumption.
12. ENVIRONMENT CONCERNS
Recycle the materials with the symbol
. Put the packaging in applicable
containers to recycle it.
Help protect the environment and human
health and to recycle waste of electrical
and electronic appliances. Do not dispose
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
ENGLISH 15

www.electrolux.com/shop
117916940-A-212012
