Electrolux EDH 97981W User manual

user manual
Tumble dryer
EDH 97981W

Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
CONTENTS
Important safety information 2
Environment 4
Installation 4
Product description 7
Control panel 8
Before first use 8
Programme chart 9
Daily use 10
Drying rack 13
Cleaning and maintenance 14
What to do if ... 15
Technical information 17
Machine settings 17
Service 17
Subject to change without notice
IMPORTANT SAFETY INFORMATION
Important! In the interest of your safety
and to ensure the correct use, before
installing and first using the appliance,
read this user manual carefully,
including its hints and warnings. To
avoid unnecessary mistakes and
accidents, it is important to ensure that
all people using the appliance are
thoroughly familiar with its operation
and safety features. Save these
instructions and make sure that they
remain with the appliance if it is moved
or sold, so that everyone using it
through its life will be properly
informed on appliance use and safety.
- Please read the instruction book
before using this appliance.
General safety
• It is dangerous to alter the specifications
or attempt to modify this product in any
way.
• This appliance is not intended for use by
persons (including children) with reduced
physical and sensory conditions or lack
of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
• Make sure that small children and pets
do not climb inside the drum. To avoid
this, please check into the drum before
using.
• Any objects such as coins, safety pins,
nails, screws, stones or any other hard,
sharp material can cause extensive dam-
age and must not be placed into the ma-
chine.
• In order to avoid danger of fires caused
by excessive drying, do not use appli-
ance to dry the following items: Cush-
ions, quilts etc. (these items accumulate
heat).
• Items such as foam rubber (latex foam),
shower caps, waterproof textiles, rubber
backed articles and clothes or pillows fit-
ted with foam rubber pads should not be
dried in the tumble dryer.
• Always unplug the appliance after use,
cleaning and maintenance.
• Under no circumstances should you at-
tempt to repair the machine yourself. Re-
pairs carried out by inexperienced per-
sons may cause injury or serious mal-
functioning. Contact your local Service
Centre. Always insist on genuine spare
parts.
• Items that have been soiled with sub-
stances such as cooking oil acetone,
petrol, kerosene, spot removers, turpen-
tine, waxes and wax removers should be
washed in hot water with an extra
amount of detergent before being dried in
the tumble dryer.
•Danger of explosion: Never tumble dry
items that have been in contact with in-
flammable solvents (petrol, methylated
spirits, dry cleaning fluid and the like). As
these substances are volatile, they could
cause an explosion. Only tumble dry
items washed with water.
•Risk of fire: items that have been spot-
ted or soaked with vegetable or cooking
2 electrolux

oil constitute a fire hazard and should not
be placed in the tumble dryer.
• If you have washed your laundry with
stain remover you must execute an extra
rinse cycle before loading your tumble
dryer.
• Please make sure that no gas lighters or
matches have accidentally been left in
pockets of garments incase they are loa-
ded into appliance
Warning!
•Risk of fire! Never stop a tumble
dry before the end of the drying
cycle unless all items are quickly
removed and spread out so that
the heat is dissipated.
•Lint must not be allowed to accu-
mulate around the tumble dryer.
•Risk of electric shock! Do not spray
down the appliance with jets of water.
• The final part of a tumble dryer cycle oc-
curs without heat ( cool down cycle ) to
ensure that the items are left at a temper-
ature that ensures that items will not be
damaged.
• The tumble dryer is not to be used if in-
dustrial chemicals have been used for
cleaning.
• Ensure you have good ventilation in the
installation room to avoid the back flow of
gases into the room from appliances
burning other fuels, including open fires.
Installation
• This appliance is heavy. Care should be
taken when moving it.
• When unpacking the appliance, check
that it is not damaged. If in doubt, do not
use it and contact the Service Centre.
• All packaging must be removed before
use. Serious damage can occur to the
product and to property if this is not ad-
hered to. See relevant section in the user
manual.
• Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.
• If the machine is situated on a carpeted
floor, please adjust the feet in order to al-
low air to circulate freely under the appli-
ance.
• After having installed the appliance,
check that it is not pressing or standing
on its electrical supply cable.
• If the tumble dryer is placed on top of a
washing machine, it is compulsory to use
the stacking kit (optional accessory).
Use
• This appliance is designed for domestic
use. It must not be used for purposes
other than those for which it was de-
signed.
• Only wash fabrics which are designed to
be machine dried. Follow the instructions
on each garment label.
• Do not dry unwashed items in the tumble
dryer.
• Do not overload the appliance. See the
relevant section in the user manual.
• Clothes which are dripping wet should
not be placed in the dryer.
• Garments which have been in contact
with volatile petroleum products should
not be machine dried. If volatile cleaning
fluids are used, care should be taken to
ensure that the fluid is removed from the
garment before placing in the machine.
• Never pull the power supply cable to re-
move the plug from the socket; always
take hold of the plug itself.
• Never use the tumble dryer if the power
supply cable, the control panel, the work-
ing surface or the base are damaged so
that the inside of the tumble dryer is ac-
cessible.
• Fabric softeners, or similar products
should be used as specified by the fabric
softener instructions.
•Caution - hot surface : Do not touch
the door light cover surface when the
light is switched on.
(Only dryers equipped with internal drum
light)
Child safety
• This machine is not intended for use by
young children or infirm persons without
supervision.
• Children often do not recognise the haz-
ards associated with electrical applian-
ces. Children should be supervised to
ensure that they do not play with the ap-
pliance.
electrolux 3

Warning!
• Danger of suffocation! The packag-
ing components (e.g. plastic film,
polystyrene) can be dangerous to
children - Keep them out of chil-
dren’s reach.
• Keep all detergents in a safe place out of
children’s reach.
• Make sure that children or pets do not
climb inside the drum.
ENVIRONMENT
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will
help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling of
this product. For more detailed information
about recycling of this product, please
contact your local council, your household
waste disposal service or the shop where
you purchased the product.
Environmental information
The packaging materials are environmental-
ly friendly and can be recycled. The plastic
components are identified by markings, e.g.
>PE<, >PS<, etc. Please dispose of the
packaging materials in the appropriate con-
tainer at the community waste disposal fa-
cilities.
Important! The heat pump of your tumble
dryer contains a closed refrigerant circuit
filled with a refrigerant which is free from
fluoro-chloro-hydrocarbons. The refrigerant
circuit in the heat pump must not be
damaged.
Warning! When a unit is no longer
being used:
• Pull the plug out of the socket.
• Cut off the cable and plug and dis-
pose of them.
• Dispose of the door catch. This pre-
vents children from trapping them-
selves inside and endangering their
lives.
Environmental tips
• In the dryer, laundry becomes fluffy and
soft. Fabric softeners are not therefore
needed when washing.
• Your dryer will function most economical-
ly if you:
– Always keep the ventilation slots on the
base of the dryer unobstructed;
– Use the loading volumes specified in
the programme overview;
– Ensure you have good ventilation in the
installation room;
– Clean the micro-fine filter and fine
strainer after each drying cycle;
– Spin the laundry well before drying.
Energy consumption depends on spin-
ning speed set in washing machine.
Higher spinning speed - lower energy
consumption.
INSTALLATION
Transporting the appliance
Important! Only tip the appliance on its left
side to transport (see illustration), if it cannot
be transported in an upright position.
Warning! If the appliance was not
transported in an upright position, leave
it to stand for 12 hours before
connecting it to the electricity supply
and using it for the first time, so that
the oil can flow back to the
compressor. Otherwise the
compressor could be damaged.
4 electrolux

Appliance positioning
• It is recommended that, for your conven-
ience, the appliance is positioned close
to your washing machine.
• The tumble dryer must be installed in a
clean place, where dirt does not build up.
• Air must be able to circulate freely all
round the appliance. Do not obstruct the
front ventilation grille or the air intake
grilles at the back of the appliance.
• To keep vibration and noise to a mini-
mum when the tumble dryer is in use, it
should be placed on a firm, level surface.
• Once in its permanent operating position,
check that the tumble dryer is absolutely
level with the aid of a spirit level. If it is
not, raise or lower the feet until it is.
• The feet must never be removed. Do not
restrict the floor clearance through deep
pile carpets, strips of wood or similar.
This might cause heat built-up which
would interfere with the operation of the
appliance.
Important!
• The hot air emitted by the tumble dryer
can reach temperatures of up to 60°C.
The appliance must therefore not be in-
stalled on floors which are not resistant to
high temperatures.
• When operating the tumble dryer, the
room temperature must not be lower
than +5°C and higher than +35°C, as it
may affect the performance of the appli-
ance.
• Should the appliance be moved, it must
be transported vertically.
• The appliance must not be installed be-
hind a lockable door, a sliding door a
door with a hinge on the opposite side to
that of the appliance in such a way that a
full opening of the tumble dryer is restric-
ted.
Removing transport safety packaging
Caution!
Before use all parts of the transport pack-
aging must be removed.
1. Open loading door
2. Pull off adhesive strips from inside ma-
chine on top of drum.
3. Remove foil hose and polystyrene pad-
ding from the machine.
Drying rack unpacking
Caution! Before appliance use all
packaging parts and drying rack must
be removed from the drum. The inside
of the drum must be clean.
4 3
1 2
To unpack the rack:
electrolux 5

1. Remove middle polystyrene part by pull-
ing it.
Loosen polystyrene parts 3 and 4.
2. Lift slightly rack and take it carefully out
from the drum.
3. Remove right polystyrene part by pulling
it.
4. Remove left polystyrene part by pulling
it.
Electrical connection
Details on mains voltage, type of current
and the fuses required should be taken
from the type plate. The type plate is fitted
near the loading aperture (see “Product de-
scription” chapter).
Connect the machine to an earthed
socket, in accordance with current wir-
ing regulations.
Warning! The manufacturer
declines any responsibility for
damage or injury through failure to
comply with the above safety
precautions.
Should the appliance power supply
cable need to be replaced, this
must be carried out by our Service
Center.
Warning! The plug must be
accessible after installing the
machine.
6 electrolux

Door reversal
To make it easier to load or unload the
laundry, the door can be reversed.
Warning! The door must only be
reversed by an authorised service
engineer.
Please contact your local Service Force
Centre. The engineer will carry out the door
reversal at your cost.
Special accessories
•Stacking kit
These intermediate installation kits can
be used to arrange the dryer and a wash-
ing machine (60 cm wide, front loaded)
as a space-saving washer/dryer stack.
The washing machine is at the bottom
and the dryer is at the top.
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
•Draining kit
Installation kit for direct draining of the
condensed water into a basin, siphon,
gully, etc. The water reservoir then no
longer has to be drained, it must however
remain in its intended position in the ma-
chine.
Fixed hose has to be on the suitable
height from minimum of 50 cm to maxi-
mum of 1 m from floor level and cannot
be looped. If possible shorten the drain-
ing hose.
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
•Pedestal with the drawer
To situate the dryer at the optimal height
and have some additional space to store
(e.g. laundry).
Read carefully the instructions supplied
with the kit.
Available from your Service Force Cen-
tre or your specialist dealer
PRODUCT DESCRIPTION
1
3
5
7
9
11
13
2
4
6
8
10
12
14
1Control panel
2Water reservoir
3Fine fluff filters
4Drum light
5Loading door (reversible)
6Drying rack
7Course fluff filters
8Fluff filters
9Push button for base door opening
10 Rating plate
11 Airflow grille
12 Fluff filter
13 Adjustable feet
14 Heat exchanger door
electrolux 7

CONTROL PANEL
Control panel
1 2 3 4 5 6 7 8 9 10
1Programme selector and off switch
2Display
3Extra delicate programme selection
button
4Dryness button
5Long anti-crease button
6Buzzer button
7Time button
8Start/Pause button
9Warning lights: Condenser, Fil-
ters, Full tank
10 Delay button
Display
Symbol Description
Extra delicate off
Symbol Description
Extra delicate on
1)
Minimal dryness level
Medium dryness level
Maximal dryness level
Auto dryness level
Time to end (time of time
programme, time of start de-
lay)
Cycle performance, auto
dryness detection
Long anti-crease guard
Child lock
Alarm
Delay start
Drying phase
Cooling phase
Anti-crease guard phase
Error, wrong selection
1) only for synthetics programmes
BEFORE FIRST USE
Warning! If the appliance was not
transported in an upright position, leave
it to stand for 12 hours before
connecting it to the electricity supply
and using it for the first time, so that
the oil can flow back to the
compressor. Otherwise the
compressor could be damaged.
In order to remove any residues which may
have been produced during production,
wipe the dryer drum with a damp cloth or
carry out a brief drying cycle (ca. 30 min.)
with damp cloths in the machine.
At the beginning of drying cycle (3-5 min.)
there could be a slightly higher sound level.
It is because of start of the compressor that
is normal for compressor powered applian-
ces such: refrigerators, freezers .
8 electrolux

PROGRAMME CHART
Pro-
gramme
Load
1)
Application/properties Options Care
label
Cottons
Extra 7 kg To dry thick or multi- layered fabrics, e.g.
terry towelling items, bathrobes.
Dryness , Long anti-
crease , Buzzer , De-
lay
Cup-
board 7 kg To dry fabrics of even thicknesses, e.g. ter-
ry towelling items, knitwear, towels.
Dryness , Long anti-
crease , Buzzer , De-
lay
Iron 7 kg To dry normal thickness cotton or linen
laundry, e. g. bedding, table linen.
Dryness , Long anti-
crease , Buzzer , De-
lay
Synthetics
Extra 3 kg To dry thick or multi-layered fabrics, e. g.
pullovers, bedding, table linen.
Extra delicate , Dry-
ness , Long anti-
crease , Buzzer , De-
lay
Cup-
board 3 kg
To dry thin fabrics which are not ironed,
e.g. easy care shirts, table linen, baby
clothes, socks, lingerie with bones or wires.
Extra delicate , Dry-
ness , Long anti-
crease , Buzzer , De-
lay
Iron 3 kg To dry thin fabrics which are also to be ir-
oned, e.g. knitwear, shirts.
Extra delicate , Dry-
ness , Long anti-
crease , Buzzer , De-
lay
Special
Time 7 kg To dry laundry with the time set by the
user.
Long anti-crease ,
Buzzer , Time , Delay
Quick
35' 2 kg To quickly dry cotton or synthetic clothes in
only 35 minutes.
Dryness , Long anti-
crease , Buzzer , De-
lay
Mix 3 kg To dry cotton and synthetic fabrics, uses
low temperature.
Dryness , Long anti-
crease , Buzzer , De-
lay
Jeans 7 kg
To dry leisure clothing, such as jeans,
sweatshirts, etc., of different material thick-
nesses (e.g. at the neck, cuffs and seams).
Dryness , Long anti-
crease , Buzzer , De-
lay
Easy
Iron
1 kg
(or 5
shirts)
To dry easy care cloths such as shirts and
blouses. After this programme the cloths
iron easiest. To have good result, we rec-
ommend to shake the wet cloths and put
straight in the tumble dryer. After the pro-
gramme end, remove the cloths and put on
the cloths hanger.
Dryness , Long anti-
crease , Buzzer , De-
lay
Rack
electrolux 9

Pro-
gramme
Load
1)
Application/properties Options Care
label
Wool
2)
1 kg
To dry the cloths made of wool. With this
programme you must set the time with the
Time function. We recommend to remove
the cloths immediately after the programme
end.
Buzzer , Time , Delay
Sport
Shoes
2)
1 pair
To dry one pair of sport shoes, washed and
spun before at 1000 rpm. With this pro-
gramme you must set the time with the
Time function.
Buzzer , Time , Delay
Refresh 1 kg To quickly air the clothes. Buzzer
1) maximal weight of dry clothes
2) To dry with the rack only.
DAILY USE
Sorting laundry
• Sort by fabric type:
–Cotton/linen for programmes in
Cottons programme group.
– Mixtures and synthetics for pro-
grammes in Synthetics programme
group.
• Sort by care label: The care labels mean:
Drying in the tumble dryer possible in
principle
Drying at normal temperature
Drying at reduced temperature
Drying in the tumble dryer not possi-
ble
Important! Do not place in the appliance
any wet laundry which is not specified on
the care label as being suitable for tumble-
drying.
This appliance can be used for all wet laun-
dry items which are labelled as suitable for
tumble-drying.
• Do not dry new, coloured textiles togeth-
er with light-coloured laundry items. Tex-
tile colours may bleed.
• Do not dry cotton jersey and knitwear
with the Extra programme. Items may
shrink!
• Wool and wool-like textiles can be dried
using the Wool programme. Before
the drying cycle spin the woollen textiles
as well as possible (max. 1200 rpm). Only
dry woollen textiles together of similar or
the same material, colour and weight.
Please dry heavy laundry items made of
wool separately.
Preparing laundry
• To avoid laundry becoming tangled:
close zips, button up duvet covers and
tie loose ties or ribbons (e.g. of aprons).
• Empty pockets. Remove metal items (pa-
per clips, safety pins, etc).
• Turn items with double-layered fabrics in-
side out (e.g. with cotton-lined anoraks,
the cotton layer should be outermost).
These fabrics will then dry better.
Important! Do not overload the appliance.
Observe max. loading volume of 7kg.
Average laundry weights
bathrobe 1200 g
quilt cover 700 g
man’s work shirt 600 g
man’s pyjamas 500 g
sheet 500 g
tablecloth 250 g
man’s shirt 200 g
night dress 200 g
pillow case 200 g
towelling towel 200 g
10 electrolux

blouse 100 g
ladies’ briefs 100 g
men’s underpants 100 g
napkin 100 g
tea cloth 100 g
Switching machine on
Turn the programme selector to any pro-
gramme. The machine switches on. When
the loading door is open, the internal lamp
illuminates the drum.
Operating
Drying options
Extra delicate
this function decreases the movement of the
laundry during the cycle. The laundry after the
cycle is more soft and loose. For synthetic pro-
grammes only.
Dryness
increases the dryness of the dried laundry ade-
quately to the selected level:
- maximum
- medium
- minimum
- inactive with some programmes
this option helps to achieve satisfying result of
drying
Long anti-crease
prolongs anti-crease phase to 90 min., helps
to keep laundry free from creases after drying;
laundry can be removed at any time
Buzzer
audible confirmation of:
•cycleend
• anti-crease phase start and end
• cycle interruption
• error
Time
allows to set individual time of drying from min-
imum 20 min. to maximum of 3 hours (in 10
min. steps - press the button repeatedly until
the desired programme duration is shown in
the display, e.g. - for a pro-
gramme of 1 hour and 20 minutes ); active with
suitable programme
Delay
allows to delay the start of a drying programme
from minimum of 30 min. to maximum of 20
hours
1. select the drying programme and additional
drying options
2. press the Delay button repeatedly until the
desired delay start is shown on the display,
e.g. Hif the programme has to start
after time of 12 hours
3. to activate the delay timer, press the Start/
Pause button - time to start elapses on the
display
electrolux 11

Starting the programme
Press the Start/Pause button. The pro-
gramme starts.
The programme progress is shown by
elapsing dry time and animated icon
on LCD.
Setting child lock
The child lock can be set to prevent a pro-
gramme being accidentally started or a pro-
gramme in operation being accidentally
changed. The child lock function locks all
buttons and the programme selector. The
child lock can be activated or deactivated
by holding down the Buzzer and Time but-
tons simultaneously for 5 seconds.
The symbol: on the display means that
the child lock is active.
Any changes of drying parameters re-
quire child lock deactivation.
The child lock cannot be deactivated in
the last phase of the drying cycle.
Changing programme
To change a programme which has been
selected by mistake once the programme
has started, first turn the programme selec-
tor to off and then reset the programme.
The programme can no longer be
changed directly once the programme
has started. If nevertheless there is an
attempt to change the programme on
the programme knob, the programme
progress display and the maintenance
indicators flash. If an option button (ex-
cluding the Buzzer button) is pressed,
appears on the display. The dry-
ing programme is not however affected
by this (laundry protection).
Drying cycle complete / removing
laundry
Once the drying cycle is complete, the dis-
play shows the anti-crease icon and
flashing as well as warning
lamps: filter and full tank. If the Buz-
zer button has been pressed, an acoustic
signal sounds intermittently for about one
minute.
The drying cycles (except from the
Wool programme) are automatically fol-
lowed by an anti-crease phase which
lasts around 30 minutes. The drum ro-
tates at intervals during this phase. This
keeps the laundry loose and free of
creases. The laundry can be removed
at any time during the anti-crease
phase. (The laundry should be taken
out towards the end of the anti-crease
phase at the latest to prevent creases
from forming.) If Long anti-crease func-
tion has been selected, the anti-crease
phase is lengthened by 60 minutes.
1. Open door.
2. Before removing the laundry, remove
fluff from the micro-fine filter. It is best to
use a damp hand for this purpose. (See
“Cleaning and maintenance”.)
3. Remove laundry.
4. Turn the programme selector to off.
Important! After each drying cycle:
- Clean the micro-fine filter and fine filter
- Drain the condensed water container
(See chapter “Cleaning and mainte-
nance”.)
5. Close the door.
12 electrolux

DRYING RACK
Special equipment for gentle drying washa-
ble woollens and sport shoes. Incompara-
ble for drying wet woollens - eliminated
movement, protection from matting.
For drying rack unpacking see Installa-
tion chapter.
Important! Before drying rack installation
check the dryer drum. It must be empty!
Sport shoes cannot be dry without the dry-
ing rack - drum damage.
Installation and use
1. Open the loading door.
2. Insert the rack carefully resting its two
support brackets on the front of plastic
flange.
3. Place the woollens or pair of sport
shoes on the rack.
4. Select the suitable rack drying pro-
gramme and drying time.
5. Press the START/PAUSE button.
6. When cycle is finished open the loading
door and remove the woollens or shoes.
7. Turn the programme selector to OFF.
8. Take out the drying rack of the drum.
Drying tips
• for the best drying result spread the
woollens out loosely on the drying rack
and roll it up
• do not squash and fold the woollens
• open support and put sport shoes on it
• the insoles should be placed beside the
shoes on the drying rack and the shoela-
ces should be tied
electrolux 13

CLEANING AND MAINTENANCE
Cleaning fluff filters
The filters collect all the fluff which accumu-
lates during drying. To ensure that the dryer
works perfectly, the fluff filters (fine filters
and fluff filters) must be cleaned after each
drying cycle.
Caution! Never operate the dryer
without fluff filters or with damaged or
blocked fluff filters.
3 4
21
1 2
3 4
Clean the door seal
Wipe the door seal with a damp cloth im-
mediately after the drying cycle has finish-
ed.
Emptying the water reservoir
Empty the water reservoir after every drying
cycle.
Warning! The condensed water is not
suitable for drinking or for preparing
foodstuffs.
If the programme has been interrupted
as a result of the water reservoir being
full: Press the Start/Pause button to
continue the drying cycle.
Cleaning heat exchanger filter
Important!
• Never operate the dryer without the fluff
filters.
• Clogged filters cause higher energy con-
sumption (drying cycle elongation) and
dryer damage.
• A dirty heat pump can only be cleaned
up by means of a costly process.
• As necessary, approx. once every 6
months, remove the fluff from the heat
exchanger using the sponge supplied.
When doing this, please use rubber
gloves (picture 7).
14 electrolux

Cleaning the drum
Caution! Do not use abrasives or steel
wool to clean the drum.
Lime in the water or cleaning agents
may form a barely visible lining on the
inside of the drum. The degree to
which the laundry has been dried is
then no longer detected reliably. The
laundry is damper than expected when
removed from the appliance.
Use a standard domestic cleaner (e.g. vine-
gar-based cleaner) to wipe down the inside
of the drum and drum ribs.
Clean control panel and housing
Caution! Do not use furniture cleaners
or aggressive cleaning agents to clean
the machine.
Use a damp cloth to wipe down the control
panel and housing.
WHAT TO DO IF ...
Troubleshooting by yourself
Problem
1)
Possible cause Remedy
Dryer does
not work.
Dryer not connected to mains supply. Plug in at mains socket. Check fuse in
fuse box (domestic installation).
Loading door opened. Close loading door
The START PAUSE button not pressed. Press the START PAUSE button.
Unsatisfactory
drying results.
Incorrect programme set. Set suitable programme.
2)
Fluff filters clogged. Clean fluff filters.
3)
Heat exchanger clogged. Clean heat exchanger.
3)
Max. loading exceeded. Respect max. loading volume.
electrolux 15

Covered ventilation grill. Uncover ventilation grill in base area.
Residue inside the drum. Clean the drum inside.
High water hardness. Set suitable water hardness
4)
.
Loading door
does not
close
Filters not locked in place. Install fine filter and/or snap course filter
into place.
Err (Error) on
the LCD.
5)
Attempt to change parameters after
start of the programme.
Turn the dryer off and on. Set requested
parameters.
No drum light Programme selector in OFF position. Turn it to DRUM LIGHT (if available) or
to any programme.
Defective light bulb. Replace light bulb (see next section).
Abnormally
elapsing time
on the LCD
5)
Time to end is calculated on the basis
of: type, volume and dampness of laun-
dry.
Automatic process; this is not a ma-
chine fault.
Programme
inactive Full water reservoir. Empty water reservoir
3)
, press START
PAUSE button.
Drying cycle
to short
Small laundry volume./Too dry laundry
for selected programme.
Select time programme or higher drying
level (e.g. EXTRA DRY ).
Drying cycle
to long
6)
Fluff filters clogged. Clean fluff filters.
To high loading volume. Respect max. loading volume.
Laundry insufficiently spun. Spun adequately the laundry.
Particularly high room temperature - no
machine fault. Lower the room temperature if possible.
1) In case of error message on the LCD (e.g. E51- only dryers with the LCD): Switch the dryer off and on. Set
programme. Press the START PAUSE button. Does not work? - inform local service and quote the error code.
2) follow program recommendation - see Programme overview chapter
3) see Care and cleaningchapter
4) see Machine settings chapter
5) only dryers with the LCD
6) Note: After around 5 hours the drying cycle ends automatically (see Drying cycle complete section).
Changing the bulb for interior lighting
Only use a special bulb which is designed
specially for dryers. The special bulb can be
obtained from your local service centre.
Important! When the appliance is switched
on, the interior lighting switches itself off
after 4 minutes when the door is open.
Warning! Do not use standard bulbs!
These develop too much heat and may
damage the appliance!
Before replacing the bulb, disconnect
the mains plug; with a permanent con-
nection: fully unscrew or deactivate the
fuse.
1. Unscrew cover above the bulb (this can
be found directly behind the loading
aperture, at the top; refer to "Descrip-
tion of machine" section.)
2. Replace defective bulb.
3. Screw cover back down.
Check the correct positioning of o-ring gas-
ket before screwing back the door light
cover. Do not operate the dryer when miss-
ing o-ring gasket on door light cover.
Warning! For safety reasons, the cover
must be screwed down tightly. If this is
not done, the dryer must not be
operated.
16 electrolux

TECHNICAL INFORMATION
height x width x depth 85 x 60 x 58 cm
drum volume 108 l
depth with the load door opened 109 cm
adjustable height 1.5 cm
the appliance weight 59 kg
maximum load volume 7kg
voltage 230 V
necessary fuse 6 A
total power 900 W
energy efficiency class A
energy consumption kWh/cycle
1)
1,58 kWh
annual energy consumption 104,4 kWh
type of use Domestic
permitted ambient temperature + 5°C to + 35°C
1) 7 kg of cotton, centrifuged at 1000 rpm with reference to EN 61121
MACHINE SETTINGS
Setting Implementation
Buzzer permanent
on/off
The alarm is by default always off. To set permanent alarm on (off):
1. Turn the programme selector to any programme.
2. Press simultaneously the Dryness and Long anti-crease buttons and
hold down for approx. 5 seconds.
Water hardness
1)
1. Turn the programme selector to any programme.
2. Press simultaneously the Long anti-crease and Start/Pause buttons
and hold down for approx. 5 seconds.
3. Press the Start/Pause button until you set desired level:
- low conductivity <300 μS/cm
- medium conductivity 300-600 μS/cm
- high conductivity >600 μS/cm
4. To memorize setting press simultaneously the Long anti-crease and
Start/Pause buttons or turn knob to off position
1) Water contains, a variable quantity of limestone and mineral salts of which quantities vary according to
geographical locations thus varying its conductivity values. Relevant variations of the conductivity of the water
compared to those prefixed by the factory could slightly influence the residual humidity of the laundry at the end of
the cycle. Your dryer allows you to regulate the sensitivity of the drying sensor based on conductivity values of the
water.
SERVICE
If there are technical faults, first check if you
can remedy the problem yourself with the
help of the operating instructions - see
chapter What to do if….
If you cannot remedy the problem on your
own, get in touch with the Customer Care
Department or one of our service partners.
To assist you quickly, these data are neces-
sary:
electrolux 17

– Model description
– Product number (PNC)
– Serial number (S No. is on rating plate
stuck to the product - to find it see chapter
Product description))
– Type of failure
– Any error messages shown by the dis-
play.
So that you have the necessary reference
numbers from your appliance at hand, we
recommend that you write them in here:
Model descrip-
tion:
........................................
PNC: ........................................
S No: ........................................
18 electrolux

electrolux 19

136914840-A-412010
www.electrolux.com/shop
