Electrolux T5190LE User manual

MaintenanceManual
Tumbledryer
T5190LE
TypeN1190..
4389098-10/EN
Originalinstructions2014.06.12

Contents
Contents
1Symbols.............................................................................................................................5
2General..............................................................................................................................5
3Maintenance.......................................................................................................................6
3.1Cleanthelintlters.....................................................................................................6
3.2Speciallter................................................................................................................7
3.3Airintakeandfanmotor.............................................................................................8
3.4Cleanthewatervalve.................................................................................................9
3.5Maintenancetobecarriedoutbyqualiedservicepersonnel....................................9
Themanufacturerreservestherighttomakechangestodesignandcomponentspecications.

Symbols5
1Symbols
Caution
Caution,hotsurface
Readtheinstructionsbeforeusingthemachine
2General
Itistheresponsibilityoftheownerofthemachine/thelaundrymanagertomakesurethatthe
followingmaintenanceisperformed.
Checkandcleanlteronaregularbasisorifthemachinenotify“CLEANSPECIALFILTER”.
Duetovariousinstallationsanddependingontheuseofthemachineotherintervalsmaybe
necessary.
Note!
Addingtoomuchdetergentinthewashingprocesswillincreasecleaningintervalofthe
lintlters.
Note!
Hardwatermayrequiremoremaintenanceofltersduetotendancyofusingtoomuch
detergentinthewashingprocess.
Note!
Lackofmaintenancemaydeterioratetheperformanceofthemachineandmaycause
damagetocomponents.
Note!
Allthreelintltersmustbeinplacewhenthemachineisrunning.

6Maintenance
3Maintenance
3.1Cleanthelintlters
Disconnectthepowertothemachine.
Openthedoor.
Checkthatthetwolters(A)and(B)arecleanandunbroken.(Thosetwoltersshallbecleaned
aftereachdryingcyclebytheuser).
Cleanorreplaceifnecessary.
①
A
B
g.8015C

Maintenance7
3.2Speciallter
TheSpeciallter(C)isplacedunderthelintlter(B).
Pullouttheltersasfaraspossible.
Loosenthetwonutsonthelockingbracket.
Itisalsopossibletoreachthenutsfrombehindthelter(A).Demountthelter(A)andloosen
thetwonutsonthelockingbracket.
RemovetheltersandcleantheSpeciallter(C)withavacuumcleaner.
②
B
C
A
g.W00731
Note!
ReplacetheSpeciallterwhenneeded.Itcanbevacuumcleaneduptofourtimes.
Note!
DonotusewatertocleantheSpeciallter.
Whenremounting;positiontheSpeciallter(C)belowthelintlter(B).MakesuretheSpeciallter
(C)isincenterpositionwheninsertingtheltersonthelterbracket.
Makesuretheltersareinpositionandbelowthelockingbracket.Tightenthenutsonthelocking
bracket,pressthelockingbracketdownatthesametimeastighteningthenuts.
Ifthelter(A)hasbeendemounted;remountthelter(A).

8Maintenance
3.3Airintakeandfanmotor
Atregularbasis,checkthattheairintakeonthefrontofthemachineisnotcloggedbylintand
dustorotherwiseblocked.
Disconnectthepowertothemachine.
Removethescrewstothelter(A),pulloutthelter(B)andcleantheairinletandthefanwheel
withavacuumcleaner.Becarefulnottodamagetheparts.
③
A
B
g.8016A

Maintenance9
3.4Cleanthewatervalve
Atregularbasis,checkthewatervalveandlter.
Disconnectthepowertothemachine.
Disconnectthewatersupplytotheheatpump.
Disassemblethewatervalve(A)andcheckthattheholeisnotblocked.Checkthelter.
Checkthedrainforcondensedwater(B)andthedrainforcoolingwater(C).
④
A
B
C
g.8038A
Cleanandremoveanydirtorcoatingifnecessary.
Remountthevalve.
3.5Maintenancetobecarriedoutbyqualiedservicepersonnel
Serviceshouldbedoneaccordingtotheservicemanual.Ifneglectedperformancewilldecrease
andthemachinecanbedamaged.
After800hoursofoperationoronceayear,whichevercomesrst,contactqualiedservice
personneltoperformthefollowingmaintenancefore.g:
•Cleantheheatpumpunitinside.
•Cleancondenser,evaporatorandfan.
•Cleantheareaaroundthedrum.
•CleantheglidesurfaceontheRMCgraphitecollector.
•Cleanthemotor.
•Cleanthecomponentunit.
