The Electrolux range of freezer counters combines the con-
venience of worktop space with cold storage located below.
This range of counters is manufactured throughout in AISI
304 Stainless steel to meet the highest hygiene standards.
The range comprises three sizes of counter, with built-in com-
pressor units, in various door and drawer configurations and
in refrigerator or freezer versions.The model detailed on this
sheet benefit from the advantages of smart electronic con-
trol. It has two full doors and operates over the temperature
range of -5 °F to -11 °F (-15 °C to -24 °C).
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Main features
EASY TO INSTALL
• Mounted on legs with height adjustment.
• Built-in compressor to suit operating conditions.
• Suitable for use in ambient temperatures of up to 109 °F (43 °C).
• Touch pad selection for the five most common food staffs the smart
electronic control sets the appropriate temperature and humidity.
EASY TO CLEAN
• Constructed from AISI 304 stainless steel throughout to meet the highest
hygiene standards.
• Rounded internal corners for ease of cleaning.
• Mounted on stainless steel legs to give 6″(150 mm) clearance for
ease of cleaning the floor.
• The SMART defrosting cycle only starts if it is necessary (by checking the
intensity of ice on the evaporator).
EASY TO USE
• Adjustable temperature range from -5 °F to -11.2 °F (-15 °C to -24 °C)
to suit meat, fish and dairy storage requirements.
• Anti-tilt runners accept GN1/1 containers.
• Electronic microprocessor control with external digital temperature display.
• Forced air circulation for rapid cooling and an even temperature distribution.
• HACCP incorporated - all events are recorded, displaying, date and time.
• A memory function keeps the information for working even when a probe
failed.
• Worktop in AISI 304 stainless steel with a 2″(50 mm) thickness.
EASY TO MAINTAIN
• Access to all components from the front.
• In compliance with ETL requirements.
• Fault code display.
EASY ON THE ENVIRONMENT
• CFC and HCFC free (ecological refrigerant type: R404a, - gas in foam:
cyclopenthane).
•2.36″(60 mm) insulation for energy saving.
• Less on energy consumption due to smart defrosting cycles.
• Developed and produced in ISO 9001 and ISO 14001 certified factory.
Included Accessories
• 1/1 GN grey “RILSAN” grid (PNC 881435)
Optional Accessories
• Plastic container GN 1/1 H = 3.93″(100 mm) (PNC 811451)
• Top panel(flat) for 3-door HD tables (PNC 880154)
• Kit 2 drawers 1/2 + rack-ref. counters (PNC 880156)
• Kit 3 drawers 1/3 + rack-ref. counters (PNC 880157)
• Kit 1 bottler + 1 drawer-ref. counter (PNC 880158)
• 2 wheels, one with brake, (PNC 880539)
for HD refrigerated undercounters
(recommended to order 2 sets per unit)
• Plastic container GN 1/1 H = 2.55″ (65 mm) (PNC 881038)
• Plastic container GN 1/1 H = 6.0″ (150 mm) (PNC 881040)
• 1/1 GN grey “RILSAN” grid (PNC 881435)
• Lock for refrigerated counter (PNC 881499)
Refrigeration
SMART Undercounter 3 Door Freezer
726686 (RCEF3M3U) 15.5 ft3Full Size
Undercounter Freezer -
3 door 115 V/1p/60Hz
Refrigeration
SMART Undercounter 3 Door Freezer
Refrigeration
SMART Undercounter
3 Door Freezer
5-20P
