SERVICE MANUAL
© AEG Hausgeräte GmbH
Muggenhofer Straße 135
D-904 9 Nürnberg
Germany
Fax [phone]
TSE - N
Publ.-Nr.:
599 50 82 27
685
05.00
EN
Edition:
Induction Glass Ceramic
Cooking Surface
C 67600 M
C 68000 M
C 88000 M
HOBS

- 2 -
TSE-N 05.00 A. B. 599 50 82 27 EN
CONTENTS
Special notes on induction cooking zones ......................................................................3
How to avoid damaging your appliance ..........................................................................4
Appliance description...................................................................................................4 - 9
Function and the way the induction cooking zone works ................................................5
Features o the ceramic hob ...........................................................................................6
The digital displays..........................................................................................................7
Sa ety cuto o the cooking zone (Hobs C67600M, C6800M)........................................7
Sa ety cuto o the cooking zone (Hob C88000M) .........................................................7
Resetting the sa ety cut-out ............................................................................................7
Suitable kitchenware or induction cooking zones ..........................................................8
Pan size ..........................................................................................................................8
Automatic pan sensing....................................................................................................8
Pots and pans or rapid-glowing standard cooking zones (Hob C67600M)....................8
Be ore using or the irst time ..........................................................................................9
Using the cooking zones ............................................................................................10 - 12
Cooking zone switches .................................................................................................10
Activating the power unction ........................................................................................10
The power unction is not permissible or is deactivated i  ........................................11
Switching the casserole zone on and o ......................................................................11
Cooking without the automatic eature .........................................................................11
Cooking with Automatic Heating Up .............................................................................12
Tips on Cooking with or without the automatic eature .................................................12
Cleaning and care .......................................................................................................13 - 14
Advantages or cleaning and caring or the induction cooking zone ............................13
Glass ceramic cooking sur ace .....................................................................................13
Problem dirt ...................................................................................................................14
What to do if ... ............................................................................................................15
Installation Instructions .............................................................................................15 - 17
Technical data (C67600M) ............................................................................................15
Technical data (C68000M, C88000M) ..........................................................................16
Sa ety instructions or the installer ................................................................................17
Electrical connection .....................................................................................................17
Additional information for the service ......................................................................18 - 22
Cooktop assembly ........................................................................................................18
Cooktop technology ......................................................................................................18
Compatibility..................................................................................................................18
Cooktop assembly 4 Induction ......................................................................................19 - 20
Cooktop assembly 2 Induction ......................................................................................21 - 22
pe ss b e o s deact ated

- 3 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Special notes on induction cooking zones
- Scienti ic investigations have shown that an in luence on or endan-gering o patients with
implanted heart pace makers by AEG induc-tion cooking zones are normally not to be expected.
The distance between the trunk and the cooking zone should howe-ver never be less than 30 cm!
- Electromagnetic ields can in luence electronic circuits and inter ere with transistor radios.
- Do not put magnetically rechargable objects (e.g. credit cards, casset-tes etc.) on the glass
ceramic sur ace while the induction cooking zone(s) is (are) in use!
- Do not put any metallic objects (e.g. spoons, pan lids etc.) on the induction sur ace, since they can
be warmed up when the induction sur ace is in use.
Certain cooking pots may produce some noise during cooking on induction cooking zones. This,
however, is no mal unction o the cooking zone and this does not a ect the unction in any way.

- 4 -
TSE-N 05.00 A. B. 599 50 82 27 EN
How to avoid damaging our appliance
- Do not use the cooking sur ace as a work sur ace or or storage.
- Do not use the cooking zones with empty pots and pans.
- Glass ceramic is insensitive to temperature shock and very robust, however it is not unbreakable.
Especially sharp and hard objects that all on the cooking sur ace can damage it.
- Do not use pans with damaged bases that are rough and have burrs. Scratching may occur when
the pans are slid.
- Do not place any pans on the cooking sur ace rame. Scratching may occur or the paint damaged.
- Make sure that no acidic liquids, e.g. vinegar, lemon or descaling agents are spilt onto the rame o
the cooking sur ace, since these cause matte spots.
- I sugar or a preparation with sugar comes into contact with the hot cooking zone and melts there it
must be cleaned o immediately with a scraper while it is still hot. I it cools, damage to the sur ace
may occur on removal.
- Keep all items and materials that can melt away rom the glass cera-mic sur ace, e.g. plastics,
aluminium oil, or oven oils. I something o this nature should melt onto the glass ceramic sur ace,
it must also be removed immediately using the scraper.
- Avoid boiling pans dry. The bases could be irreparably damaged in the process and the glass
ceramic cooking sur ace also damaged.
Appliance description
Function and the wa the induction cooking zone works
A copper wire induction coil is beneath the glass ceramic cooking sur ace. This generates
electromagnetic ields, which act directly on the base o the pots and pans and not, as with other heating
up methods, irst heat up the glass ceramic. This means that the base of the pan is immediately heated
up, which saves time and energy. Since the heat required or cooking is generated directly in the base o
the pan the cooking zone itsel hardly warms up. It only receives the re lected heat rom the pan base.
Note:
If there is no pot or pan on the cooking zone there is no energ transfer (heating up) and thereb
absolute securit against acci-dental switching on.
For technical reasons it is necessary that a cooling blower operates
when the induction cooking zone is on.

- 5 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Features of the ceramic hob C67600M
Oven steam outlet
Cooking zone 1:
Induction cooking zone 2200 W;
with power unction 3000 W
Cooking zone 4:
Induction cooking zone
1400 W
Cooking zone 3:
Radiant heat casserole zone
2400 W
Cooking zone 2:
Radiant heat single ring zone
1200 W
Touch control sensor ield adding on
casserole zone with pilot light
4- old digital display
(separate or each cooking zone)
Features of the ceramic hob C68000M
Oven steam outlet
Cooking zone 1:
Induction cooking zone 2200 W;
with booster unction 3000 W
Cooking zone 4:
Induction cooking zone
1800 W
Cooking zone 3:
Induction cooking zone
1800 W
Cooking zone 2:
Induction cooking zone
1400 W
4- old digital display
(separate or each cooking zone)

- 6 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Features of the ceramic hob C88000M
Oven steam outlet
Cooking zone 1:
Induction cooking zone 2200 W;
with power unction 3000 W
Cooking zone 4:
Induction cooking zone 1800 W
with power unction 2300 W
Cooking zone 3:
Induction cooking zone 1800 W
Cooking zone 2:
Induction cooking zone 1400 W
4- old digital display
(separate or each cooking zone)
The digital displa s
Digits 1 to 9 and our di erent letters can appear in the display.
- The digits show the cooking stage set.
=the lowest capacit
=the highest capacit
=intermediate stage (= 6,5)
- The letters indicate the unctions:
=Error Displa
lashes i the cooking zone is switched on
- no pan is on the cooking zone or
- an unsuitable pot or pan is being used.
=Automatic Heating Up (possible for all cooking zones)
is lit, i the cooking zone is set to automatic heating up; (is lit until the automatic eature
switches over to the set urther cooking stage).
=Residual Heat Displa
Danger! Cooking zone still hot; it extinguishes when the cooking zone has cooled
down. This display appears only i the cooking zone is switched o .
=Power Function
lights up when the Power Function is activated. The Power Function delivers extra-high
heating power. It can be switched on or cooking zone 1 ( ront le t ø 210 mm).
= lights up when
- the cooking zone is overheated or
- the automatic switch-o unction has been activated.
(also see What to do when ...)

- 7 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Safet cutoff of the cooking zone (Hobs C67600M, C68000M)
All cooking zones are automatically switched o 3 hours a ter a coo-king zone was last switched on.
Should a cooking process take longer than 3 hours you can extend the cooking time o one cooking
zone by a urther 3 hours by switching it o and on again quickly.
Safet cutoff for the rings
I one o the rings is not switched o a ter a certain time or i the cooking setting is not changed, all the
rings are automatically switched o . appears in the cooker and the ceramic hob ring displays o all
the rings that were switched on.
- Cooking setting 1  2.5 a ter 6 hours
- Cooking setting 3  4 a ter 5 hours
- Cooking setting 4.5  5.5 a ter 4 hours
- Cooking setting 5.5  9 a ter 1.5 hours
Resetting the safet cut-out
Turn all the ring switches to the zero position to cancel the active sa ety cuto o the rings. The rings are
then ready or operation again.
appears in the ceramic hob display i residual heat is still present.
Suitable kitchenware for induction cooking zones
Pots and Pans
- In principle all pots and pans with magnetic bases are suitable. These are steel, steel-enamel as
well as cast-iron pots and pans.
- High grade steel pans with a mixed metal base (sandwich base, e.g. Te al with an aluminium/
copper base) are suitable or induction only i the manu acturer has expressly marked them as
such. In that case they have a erromagnetic percentage in the base.
- I you wish to use a special type o pan (e.g. a pressure cooker, sim-mering pan, wok, etc.), please
observe the manu acturers instruc-tions.
- Aluminium, copper, brass, stainless steel pots and pans (unless especi-ally designated as suitale
or induction), glass, ceramic or porcelain are not suitable or induction cooking zones. The
cooking zone reacts as i it were being used without a pot or pan: Error code .
Look for the label: Suitable for induction!
Suitability Test
I you are not sure i a pot or pan is suitable or cooking or rying on
the induction cooking zone you can check this as ollows:
- Place a pot illed with a little water (3-5 mm illing height) on the cooking zone. Switch the cooking
zone to ull power (switch setting 9).
Caution: The pan base of suitable kitchenware heats up within a few seconds!
- You can also check this with a magnet. I it remains ixed to the base the pan is suitable or
induction cooking zones.

- 8 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Pan size
Up to a certain limit the induction cooking zone adapts itsel to the size o the pan base diameter.
However, the pan base diameter must be o a minimum size, depending on the size o the cooking zone.
For example: Diameter of the cooking zone 14,5 cm
For example: Diameter o the pan base at least 12 cm
For example: Diameter of the cooking zone 18 cm
For example: Diameter o the pan base at least 14,5 cm
For example: Diameter of the cooking zone 21 cm
For example: Diameter o the pan base at least 18 cm
Note:
Please note the diameter of the pan base when buying new pans, since the manu acturers usually
speci y the top edge diameter o their pans.
Automatic pan sensing
The induction cooking zone does not unction when unsuitable pans are used.
If the cooking zone is switched on without a suitable pan on it flashes in the digital displa of
the cooking zone.
A ter about 10 minutes the cooking zone switches itsel o automati- cally. appears in the digital
display.
Also when overheating occurs (e.g. heating up a pan cooked empty) or with aults in the electronics the
display is lit. The cooking zone switches itsel o automatically.
To be able to switch it on again the cooking zone must have been irst switched o and then set to the
required stage anew.
Pots and pans for rapid-glowing standard cooking zones (Hob C67600M)
- On principle all pots and pans with level bases are suitable or radiant heat cooking zones. You
can recognise good quality pans by the base o the pan, and not rom the material rom which the
pan is made.
- The base should be as thick and lat as possible. Rough bases (e.g. cast iron pots) scratch the hob
sur aces when they are slid about.
- Pots with aluminium or copper bases can cause metallic discolouring on the glass ceramic sur ace,
which is very di icult or impossible to remove.
- The saucepan base and cooking zone should be the same size.
Attention! Avoid letting enamel saucepans and rying pans boil dry. The base could be damaged and
then scratch the cooking sur ace when slid. Saucepans and rying pans with sharp edges and burrs will
also scratch.

- 9 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Energy saving tips
- Always place pans on the cooking zone be ore switching on.
- Ensure that the pots and pans are in the centre o the cooking zone and cover the heated/marked
sur ace.
- Dirty cooking zones and pan bases damage the glass ceramic cooking sur ace and increase
electricity consumption.
- Switch the cooking zone o be ore cooking is inished to use the residual heat.
- Cooking times are reduced by up to 50%. Not only do you save energy, but more vitamins and
minerals are retained.
You will waste energy i the....
Pan is too small Pan lid is not
itted properly
Pan base is
uneven
Pan is too large
(glass ceramic)
Before using for the first time
Initial Cleaning
Wipe the glass ceramic cooking sur ace with a damp cloth.
Important: Do not use any caustic, abrasive cleaners! The sur ace could be damaged.

- 10 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Using the cooking zones
Cooking zone switches
With the cooking zone switches you have a choice o setting the heating capacity to 14 steps (with
intermediate settings)
= the lowest capacit
= the highest capacit
= Automatic
= power function
You can select intermediate settings in the ranges 2 to 7. In the digital display these are marked with a
top le t dot.
C67600M and C68000M
C88000M
Activating the power function
To switch the power function on (*only provided or cooking zone 1, ront le t ø 210 mm) turn the
cooking zone switch up to the stop and then back to stage and then let go. A appears immediately
in the digital display on the glass ceramic sur ace. is displayed in the coo-king stage display next to
the switch.
The booster unction is activated at the most or 10 minutes. Then the cooking zone switches
automatically to cooking stage .
Oven panel Cooking ield

- 11 -
TSE-N 05.00 A. B. 599 50 82 27 EN
The power function is not permissible or is deactivated if
C67600M
- Cooking zone 2 (radiant heat cooking zone rear le t-hand ø 145 mm) is switched on or added on.
or i
- Cooking zone 4 ( ront right induction cooking zone ø 145 mm) is or will be set to heating stage 8-9
. In the digital display P changes to a ter 3 seconds.
C68000M
cooking zone 2 (rear le t ø 145 mm) is set to or will be set to stage 8 to 9 , since otherwise the total
heating capacity o both cooking zones together would exceed the limit value. In the digital display
changes to a ter 3 seconds.
C88000M
one o the rear cooking zones is set to or will be set to stage 8 to 9 , since other-wise
the total heating capacity o both cooking zones together would exceed the limit value. In the digital
display changes to a ter 3 seconds.
Switching the casserole zone on and off (C67600M)
To switch the casserole zone on and o place your inger latly on the
touch control sensor ield adding on casserole zone, until the pilot
light lights up or goes out.
Cooking without the automatic feature
1. For heating up/browning, select a high power.
2. As soon as steam starts to orm or the oil is hot, turn back to the heat setting necessary or urther
cooking.
3. To stop cooking, turn back to the zero position.
Note:
When cooking with the induction cooking zone you should take into account that
- the heating up times are reduced by the direct energy trans er to the pan!
- the cooking process stops immediately a ter the cooking zone is swit-ched o (no boiling over!).

- 12 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Cooking with automatic heating up
This automatic eature operates at its ull capacity ( ) or a given time and then automatically switches
down to the set urther cooking stage. The duration o the automatic heating up boost depends on the
selected urther cooking stage.
1. Turn the cooking zone switch to the right to the stop . In the cooking stage display o the cooker
lights up or a moment, then the display changes to . A appears in the digital display o the
cooking zone.
2. Then you must turn back to the required urther cooking stage ( 1 to 8 ). This is shown in the
cooking stage display o the cooker. is still lit in the digital display o the cooking zone.
The digital display changes to the relevant digit as soon as the selected urther cooking stage is
active 1 to 8 (in the example ).
Tips on cooking with or without the automatic feature
We recommend the automatic heating up feature for:
- dishes that are put on cold, heated up with a high capacity and do not have to be supervised
constantly during the urther cooking stage.
- or dishes put into a hot pan.
The automatic feature is not suitable for:
- Goulash, bee olive and similar braised dishes which are browned, moistened and braised until
they reach the right degree o browning and are then cooked until done.
- Dumplings, pasta dishes cooked in a great deal o liquid.
- Cooking in pressure cookers
- Large quantities o soups/stews with more than 2 l liquid.

- 13 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Cleaning and care
Advantages for cleaning and caring for the induction cooking zone
The cleaning e ort or induction glass ceramic cooking sur aces is
considerably less than or cooking sur aces with radiant heating:
- The induction cooking zone reacts aster to switching down and o . Boiling over and burning in o
dishes is avoided to a large degree.
- The temperaturs on the glass ceramic sur ace are clearly lower with inductive cooking than with
the conventional radiant heating systems.
Since the heat is generated in the pan, ood or oodstu s possibly on the glass ceramic sur ace are not
burnt in as badly.
Glass ceramic cooking surface
It is important to clean the cooking sur ace a ter every use!
Attention! Never use aggressive cleaning agents such as, or example, coarse scouring cleaners or
scratching scouring pads.
Always clean the cooking sur ace when it is only a little dirty. Use a damp cloth and a little washing up
liquid. Then rub the cooking sur ace dry with a clean cloth. Remnants o cleaner must not be le t on the
sur ace.
Clean the entire cooking sur ace thoroughly once a week. For cleaning use Sidol-Edelstahlglanz,
Stahl-Fix, WK-Top or Cillit.
Then rinse the entire cooking sur ace with plain water and rub it dry
with a clean cloth. Please ensure that no residues (cleaner) remain on the sur ace. The coo-king
sur ace would otherwise be damaged!

- 14 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Problem dirt
Residues from food t at as boiled over
First so ten these using a wet cloth and then remove residues using a glass or
razor blade scraper.
Danger! Take care not hurt yoursel !
Then clean the cooking sur ace with the clea-ners identi ied above.
Burnt-in sugar, melted plastic you must remove immediately  while it is
still warm (not hot)  with a glass scraper otherwise damage can be incurred.
Then clean the cooking sur ace normally. You can prevent damages by sugar
or sugar-containing oods by caring or the cooking sur ace with Collo-Pro i or
Cera- ix.
Spots
Limescale stains, mother-o -pearl-like shiny stains, metallic iridiscent
discolourations, pan abrasions that have ormed during coo-king can be
removed best while the cooking zones are still warm. Use one o the cleaners
mentioned above. I necessary repeat the cleaning process.
Danger!
Do not put vinegar, lemons or scale remo-vers on the hob rame, they will
make the sur ace matt. Grains o sand that have allen on the coo-king
sur ace can cause scratches when the pans are slid around. Ensure, there ore,
that no grains o sand remain on the cooking sur ace.
Abraded decor
In time the decor is abraded by the use o aggressive cleaners and scouring
pan bases and dark stains develop.
You can obtain suitable cleaning and caring agents as well as glass
scrapers from the AEG customer service.

- 15 -
TSE-N 05.00 A. B. 599 50 82 27 EN
What to do if ...
... The letters flashes in the digital displa ?
Check whether:
- The pan is on the right cooking zone.
- The diameter o the pan base is too small or the cooking zone!
- The pan is suitable or induction cooking!
... appears in the digital displa ?
- Check whether the cooking zone could be overheated. For these checks turn the cooking zone o
and let it cool o . Try to switch the cooking zone on again a ter a ew minutes with a suitable pan
on it.
- The automatic switch-o eature or the cooking zone has responded. You can reactivate the
cooking zone by turning it quickly o and then on again.
Installationsinstructions
Important! This appliance must be installed by qualified personnel, according to the manu acturers
instructions and to the relevant coun-try standards.
Please observe this instruction, otherwise the warranty will not cover any damage that may occur.
Technical data (C67600M)
Appliance Dimensions
Width 570 mm
Depth 500 mm
Height 52 mm
Cut-Out Dimensions
Width 560 mm
Depth 490 mm
Corner radius R3
Power Consumption
Radiant heat single ring cooking zone ø 145 mm 1200 W
Radiant heat casserole zone ø 170 mm - ø 265 mm 2400 W
Induction cooking zone ø 145 mm 1400 W
Induction cooking zone ø 210 mm 2200 W
Induction cooking zone ø 210 mm (P) 3000 W
Heater Element Voltage 230 V ~
Total Electrical Load Max. 7.2 kW

- 16 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Technical data (C68000M)
Appliance Dimensions
Width 570 mm
Depth 500 mm
Height 53 mm
Cut-Out Dimensions
Width 560 mm
Depth 490 mm
Corner radius R3
Power Consumption
Induction cooking zone ø 145 mm 1400 W
Induction cooking zone ø 180 mm 1800 W
Induction cooking zone ø 210 mm 2200 W
Induction cooking zone ø 210 mm (P) 3000 W
Heater Element Voltage 230 V ~
Total Electrical Load Max. 7.2 kW
Technical data (C88000M)
Appliance Dimensions
Width 761 mm
Depth 501 mm
Height 47 mm
Cut-Out Dimensions
Width 750 +2 mm
Depth 490 mm
Corner radius R3
Power Consumption
Induction cooking zone ø 145 mm 1400 W
Induction cooking zone ø 180 mm 1800 W
Induction cooking zone ø 180 mm (P) 2300 W
Induction cooking zone ø 210 mm 2200 W
Induction cooking zone ø 210 mm (P) 3000 W
Heater Element Voltage 230 V ~
Total Electrical Load Max. 7.2 kW

- 17 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Safet instructions for the installer
- This hob must be installed by quali ied personnel, according to the manu acturers instructions and
to the relevant country standards.
- In respect o ire protection, this appliance corresponds to type Y (IEC 335-2-6). Only this type o
appliance may be installed with a high cupboard or wall on one side.
- It is not permitted to it drawers below the cooking sur ace.
- Protection against electric shock must be provided by the installation.
- The kitchen unit in which the appliance is itted must satis y the requirements o DIN 68930 in
respect o stability.
- Built-in ovens and cooking sur aces are itted with special connector systems. They may only be
combined with appliances with a matching system.
- All cut sur aces are to be sealed with a suitable sealant or protection against moisture.
- On tiled work sur aces, the joints in the area where the hob sits on the sur ace must be completely
illed with grout.
- On natural, arti icial stone, or ceramic tops, the snap action springs must be bonded in place.
- Ensure that the seal is correctly seated in the rame and that it is sea-ted against the work sur ace
without leaving any gaps. Additional silicon sealant must not be applied, this will make removal
more di icult in the event o the need or service.
- To remove the hob, it must be pressed out rom below.
Electrical connection
- Connect the wiring harness plugs with the respective sockets o the same colour o the built-in
oven or switch box.
C67600M and C88000M
This induction glass ceramic cooking zone can onl be combined with the following AEG units:
Competence E 8. . .
Competence E 6. . .
Competence E 4106-1
Competence S 8. . .

- 18 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Additional information for the ser ice
Cooktop assembl
- The cooktop assembly con orms to the system o the New Range, i.e. the cooktop rame and the
cooktop glass are two separate parts and not stuck with each other.
- A ter disassembling the cooktop take care that the 7-segment display and, with the sel -su icient
built-in cooktops, the control panel are not in the cooktop cover, but is clipped to the cooktop glass
rom below.
Cooktop technolog
- With the two old induction, the induction hot plates are ront right and le t, not laterally one a ter the
other as with the previous version. The induction module is a two old module.
- With the our old induction, the induction module consists o a block o our.
- With this new series o induction cooktops there are no test points to check the electronic in case
o a mal unction. That means, i the reason or a hot plate, which does not unction, is to be ound
in a mal unction o the electronic, the only solution is to exchange the module or, with sel -su icient
built-in cooktops, to exchange the control panel. The modules can also not be checked with the
help o a test routine.
Compatibilit
- The induction cooktops can only be combined with ranges which are equipped with an ERM (mo-
dular energy regulator), rom range series Compentence 2000 onward, classes Top and Com ort.
- Concerning the compatibility o the control lines, these are directly compatible rom Century
onward. With the previous range series Competence, the control line is equipped with an adaptor.

- 19 -
TSE-N 05.00 A. B. 599 50 82 27 EN
Cooktop assembl
4 Induction

- 20 -
TSE-N 05.00 A. B. 599 50 82 27 EN
