Electrolux EHH6540F8K User manual

EHI6540FOK EN HOB USER MANUAL 2
ET PLIIDIPLAAT KASUTUSJUHEND 20
FR TABLE DE CUISSON NOTICE D'UTILISATION 38

CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. PRODUCT DESCRIPTION................................................................................... 6
4. DAILY USE.......................................................................................................... 8
5. HINTS AND TIPS............................................................................................... 11
6. CARE AND CLEANING......................................................................................12
7. TROUBLESHOOTING........................................................................................13
8. INSTALLATION..................................................................................................15
9. TECHNICAL INFORMATION..............................................................................17
10. ENERGY EFFICIENCY..................................................................................... 18
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children.
•Keep children and pets away from the appliance when it
operates or when it cools down. Accessible parts are
hot.
•If the appliance has a child safety device, we
recommend you activate it.
•Cleaning and user maintenance shall not be made by
children without supervision.
•Children of less than 3 years should be kept away
unless continuously supervised.
1.2 General Safety
•The appliance and its accessible parts become hot
during use. Do not touch the heating elements.
•Do not operate the appliance by means of an external
timer or separate remote-control system.
•Unattended cooking on a hob with fat or oil can be
dangerous and may result in fire.
•Never try to extinguish a fire with water, but switch off
the appliance and then cover flame e.g. with a lid or a
fire blanket.
•Do not store items on the cooking surfaces.
ENGLISH 3

•Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can
get hot.
•Do not use a steam cleaner to clean the appliance.
•After use, switch off the hob element by its control and
do not rely on the pan detector.
•If the glass ceramic surface / glass surface is cracked,
switch off the appliance to avoid the possibility of
electric shock.
•If the supply cord is damaged, it must be replaced by
the manufacturer, an authorized Service or similarly
qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Keep the minimum distance from the
other appliances and units.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Seal the cut surfaces with a sealant to
prevent moisture to cause swelling.
• Protect the bottom of the appliance
from steam and moisture.
• Do not install the appliance adjacent to
a door or under a window. This
prevents hot cookware to fall from the
appliance when the door or the
window is opened.
• If the appliance is installed above
drawers make sure that the space,
between the bottom of the appliance
and the upper drawer, is sufficient for
air circulation.
• The bottom of the appliance can get
hot. Make sure to install a non-
combustile separation panel under the
appliance to prevent access to the
bottom.
• Make sure that the ventilation space of
2 mm, between the worktop and the
front of the below unit, is free. The
warranty does not cover damages
caused by the lack of an adequate
ventilation space.
2.2 Electrical Connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Before carrying out any operation make
sure that the appliance is disconnected
from the power supply.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Make sure the appliance is installed
correctly. Loose and incorrect
electricity mains cable or plug (if
applicable) can make the terminal
become too hot.
• Use the correct electricity mains cable.
• Do not let the electricity mains cable
tangle.
• Make sure that a shock protection is
installed.
• Use the strain relief clamp on the cable.
www.electrolux.com4

• Make sure the mains cable or plug (if
applicable) does not touch the hot
appliance or hot cookware, when you
connect the appliance to the near
sockets
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug (if applicable) or to the
mains cable. Contact our Authorised
Service Centre or an electrician to
change a damaged mains cable.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have an
isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation device
must have a contact opening width of
minimum 3 mm.
2.3 Use
WARNING!
Risk of injury, burns and
electrical shock.
• Remove all the packaging, labelling
and protective film (if applicable) before
first use.
• Use this appliance in a household
environment.
• Do not change the specification of this
appliance.
• Make sure that the ventilation openings
are not blocked.
• Do not let the appliance stay
unattended during operation.
• Set the cooking zone to “off” after each
use.
• Do not rely on the pan detector.
• Do not put cutlery or saucepan lids on
the cooking zones. They can become
hot.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
• If the surface of the appliance is
cracked, disconnect immediately the
appliance from the power supply. This
to prevent an electrical shock.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
• When you place food into hot oil, it
may splash.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• Do not keep hot cookware on the
control panel.
• Do not let cookware to boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones with
empty cookware or without cookware.
• Do not put aluminium foil on the
appliance.
• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches on the glass /
glass ceramic. Always lift these objects
up when you have to move them on
the cooking surface.
ENGLISH 5

• This appliance is for cooking purposes
only. It must not be used for other
purposes, for example room heating.
2.4 Care and cleaning
• Clean regularly the appliance to
prevent the deterioration of the surface
material.
• Deactivate the appliance and let it cool
down before you clean it.
• Disconnect the appliance from the
electrical supply before maintenance.
• Do not use water spray and steam to
clean the appliance.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use abrasive products, abrasive
cleaning pads, solvents or metal
objects.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Contact your municipal authority for
information on how to discard the
appliance correctly.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
2.6 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3. PRODUCT DESCRIPTION
3.1 Cooking surface layout
180 mm
145 mm 1
1
1 1
2
1Induction cooking zone
2Control panel
3.2 Control panel layout
51 2 3 64 7
9 811 10
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell
which functions operate.
www.electrolux.com6

Sen-
sor
field
Function Comment
1ON / OFF To activate and deactivate the hob.
2Lock / The Child Safety
Device To lock / unlock the control panel.
3STOP+GO To activate and deactivate the function.
4Bridge To activate and deactivate the function.
5- Heat setting display To show the heat setting.
6- Timer indicators of cook-
ing zones To show for which zone you set the time.
7- Timer display To show the time in minutes.
8- To select the cooking zone.
9 / - To increase or decrease the time.
10 Power function To activate and deactivate the function.
11 - Control bar To set a heat setting.
3.3 Heat setting displays
Display Description
The cooking zone is deactivated.
- The cooking zone operates.
STOP+GO function operates.
Automatic Heat Up function operates.
Power function operates.
+ digit There is a malfunction.
/ / OptiHeat Control (3 step Residual heat indicator): continue cook-
ing / keep warm / residual heat.
Lock / The Child Safety Device function operates.
Incorrect or too small cookware or no cookware on the cooking
zone.
Automatic Switch Off function operates.
ENGLISH 7

3.4 OptiHeat Control (3 step
Residual heat indicator)
WARNING!
/ / There is a risk of
burns from residual heat. The
indicator shows the level of
the residual heat.
The induction cooking zones make the
heat necessary for cooking process
directly in the bottom of the cookware.
The glass ceramic is heated by the heat of
the cookware.
4. DAILY USE
WARNING!
Refer to Safety chapters.
4.1 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
4.2 Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after
you activate the hob,
• you spill something or put something
on the control panel for more than 10
seconds (a pan, a cloth, etc.). An
acoustic signal sounds and the hob
deactivates. Remove the object or
clean the control panel.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking
zone cool down before you use the
hob again.
• you use incorrect cookware. The
symbol comes on and the cooking
zone deactivates automatically after 2
minutes.
• you do not deactivate a cooking zone
or change the heat setting. After some
time comes on and the hob
deactivates.
The relation between the heat setting
and the time after which the hob
deactivates:
Heat setting The hob deacti-
vates after
, 1 - 3 6 hours
Heat setting The hob deacti-
vates after
4 - 7 5 hours
8 - 9 4 hours
10 - 14 1.5 hour
4.3 The heat setting
To set or change the heat setting:
Touch the control bar at the correct heat
setting or move your finger along the
control bar until you reach the correct heat
setting.
4.4 Using the cooking zones
Put the cookware on the cross / square
which is on the surface that you cook.
Cover the cross / square fully. Induction
cooking zones adapt to the dimension of
the bottom of the cookware automatically.
You can cook with the large cookware on
two cooking zones at the same time.
4.5 Bridge function
This function connects two left side
cooking zones and they operate as one.
First set the heat setting for one of the left
side cooking zones.
www.electrolux.com8

To activate the function: touch . To
set or change the heat setting touch one
of the control sensors.
To deactivate the function: touch .
The cooking zones operate independently.
When you use only one cooking zone of
the pair we recommend that you use the
rear cooking zone. Also when you use
large cookware we recommend that you
put it near to the rear cooking zone.
4.6 Automatic Heat Up
If you activate this function you can get a
necessary heat setting in a shorter time.
The function sets the highest heat setting
for some time and then decreases to the
correct heat setting.
To activate the function the
cooking zone must be cold.
To activate the function for a cooking
zone: touch ( comes on).
Immediately touch the correct heat
setting. After 3 seconds comes on.
To deactivate the function: change the
heat setting.
4.7 Power function
This function makes more power available
to the induction cooking zones. The
function can be activated for the induction
cooking zone only for a limited period of
time. After this time the induction cooking
zone automatically sets back to the
highest heat setting.
Refer to “Technical
information” chapter.
To activate the function for a cooking
zone: touch . comes on.
To deactivate the function: change the
heat setting.
4.8 Timer
Count Down Timer
You can use this function to set how long
the cooking zone should operate for a
single cooking session.
First set the cooking zone then set the
function. You can set the heat setting
before or after you set the function.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of
the timer to set the time (00 - 99 minutes).
When the indicator of the cooking zone
starts to flash slowly the time counts
down.
To see the remaining time: set the
cooking zone with . The indicator of the
cooking zone starts to flash quickly. The
display shows the remaining time.
To change the time: set the cooking
zone with . Touch or .
To deactivate the function: set the
cooking zone with and touch . The
remaining time counts back to 00. The
indicator of the cooking zone goes out.
When the time comes to an
end, the sound operates and
00 flashes. The cooking zone
deactivates.
To stop the sound: touch .
CountUp Timer (The count up timer)
You can use this function to monitor how
long the cooking zone operates.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of
the timer. comes on. When the
indicator of the cooking zone starts to
flash slowly the time counts up. The
display switches between and counted
time (minutes).
To see how long the cooking zone
operates: set the cooking zone with .
The indicator of the cooking zone starts to
flash quickly. The display shows how long
the zone operates.
To deactivate the function: set the
cooking zone with and touch or .
ENGLISH 9

The indicator of the cooking zone goes
out.
Minute Minder
You can use this function as a Minute
Minder when the hob is activated and the
cooking zones do not operate (the heat
setting display shows ).
To activate the function: touch .
Touch or of the timer to set the
time. When the time comes to an end, the
sound operates and 00 flashes.
To stop the sound: touch .
The function has no effect on
the operation of the cooking
zones.
4.9 STOP+GO
This function sets all cooking zones that
operate to the lowest heat setting.
When the function operates, you cannot
change the heat setting.
The function does not stop the timer
functions.
To activate the function: touch .
comes on.
To deactivate the function: touch .
The previous heat setting comes on.
4.10 Lock
You can lock the control panel while
cooking zones operate. It prevents an
accidental change of the heat setting.
Set the heat setting first.
To activate the function: touch .
comes on for 4 seconds. The Timer stays
on.
To deactivate the function: touch .
The previous heat setting comes on.
When you deactivate the
hob, you also deactivate this
function.
4.11 The Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: activate the
hob with . Do not set the heat setting.
Touch for 4 seconds. comes on.
Deactivate the hob with .
To deactivate the function: activate the
hob with . Do not set the heat setting.
Touch for 4 seconds. comes on.
Deactivate the hob with .
To override the function for only one
cooking time: activate the hob with .
comes on. Touch for 4 seconds.
Set the heat setting in 10 seconds.
You can operate the hob. When you
deactivate the hob with the function
operates again.
4.12 OffSound Control
(Deactivation and activation of
the sounds)
Deactivate the hob. Touch for 3
seconds. The display comes on and goes
out. Touch for 3 seconds. or
comes on. Touch of the timer to
choose one of the following:
• - the sounds are off
• - the sounds are on
To confirm your selection wait until the
hob deactivates automatically.
When the function is set to you can
hear the sounds only when:
• you touch
• Minute Minder comes down
• Count Down Timer comes down
• you put something on the control
panel.
4.13 Power management
function
• Cooking zones are grouped according
to the location and number of the
phases in the hob. See the illustration.
www.electrolux.com10

• Each phase has a maximum electricity
loading of 3700 W.
• The function divides the power
between cooking zones connected to
the same phase.
• The function activates when the total
electricity loading of the cooking zones
connected to a single phase exceeds
3700 W.
• The function decreases the power to
the other cooking zones connected to
the same phase.
• The heat setting display of the reduced
zones changes between two levels.
5. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
5.1 Cookware
For induction cooking zones
a strong electro-magnetic
field creates the heat in the
cookware very quickly.
Use the induction cooking
zones with correct cookware.
Cookware material
•correct: cast iron, steel, enamelled
steel, stainless steel, the bottom made
of multi-layer (with correct mark from a
manufacturer).
•not correct: aluminium, copper,
brass, glass, ceramic, porcelain.
Cookware is correct for an induction
hob if:
• some water boils very quickly on a
zone set to the highest heat setting.
• a magnet pulls on to the bottom of the
cookware.
The bottom of the cookware
must be as thick and flat as
possible.
Cookware dimensions
Induction cooking zones adapt to the
dimension of the bottom of the cookware
automatically to some limit.
The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a smaller diameter than the
minimum receives only a part of the power
generated by the cooking zone.
Refer to “Technical
information” chapter.
5.2 The noises during operation
If you can hear:
• crack noise: cookware is made of
different materials (sandwich
construction).
• whistle sound: you the cooking zone
with high power level and the
cookware is made of different materials
(sandwich construction).
• humming: you use high power level.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not
refer to hob malfunction.
5.3 Öko Timer (Eco Timer)
To save energy, the heater of the cooking
zone deactivates before the count down
timer sounds. The difference in the
operation time depends on the heat
setting level and the length of the cooking
operation.
ENGLISH 11

5.4 Examples of cooking
applications
The relation between the heat setting and
the cooking zone consumption of power is
not linear. When you increase the heat
setting, it is not proportional to the
increase of the cooking zone consumption
of power. It means that the cooking zone
with the medium heat setting uses less
than a half of its power.
The data in the table is for
guidance only.
Heat setting Use to: Time
(min)
Hints
- 1 Keep cooked food warm. as nec-
essary Put a lid on the cookware.
1 - 3 Hollandaise sauce, melt: but-
ter, chocolate, gelatine. 5 - 25 Mix from time to time.
1 - 3 Solidify: fluffy omelettes,
baked eggs. 10 - 40 Cook with a lid on.
3 - 5 Simmer rice and milkbased
dishes, heating up ready-
cooked meals.
25 - 50 Add the minimum twice as
much liquid as rice, mix milk
dishes part procedure
through.
5 - 7 Steam vegetables, fish, meat. 20 - 45 Add some tablespoons of liq-
uid.
7 - 9 Steam potatoes. 20 - 60 Use max. ¼ l water for 750 g
of potatoes.
7 - 9 Cook larger quantities of food,
stews and soups. 60 - 150 Up to 3 l liquid plus ingredi- ents.
9 - 12 Gentle fry: escalope, veal cor-
don bleu, cutlets, rissoles,
sausages, liver, roux, eggs,
pancakes, doughnuts.
as nec-
essary Turn halfway through.
12 - 13 Heavy fry, hash browns, loin
steaks, steaks. 5 - 15 Turn halfway through.
14 Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. Power function is activated.
6. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
6.1 General information
• Clean the hob after each use.
• Always use cookware with clean
bottom.
• Scratches or dark stains on the surface
have no effect on how the hob
operates.
• Use a special cleaner applicable for the
surface of the hob.
• Use a special scraper for the glass.
www.electrolux.com12

6.2 Cleaning the hob
•Remove immediately: melted plastic,
plastic foil, and food with sugar. If not,
the dirt can cause damage to the hob.
Put the special scraper on the glass
surface at an acute angle and move
the blade on the surface.
•Remove when the hob is
sufficiently cool: limescale rings,
water rings, fat stains, shiny metallic
discoloration. Clean the hob with a
moist cloth and some detergent. After
cleaning, rub the hob dry with a soft
cloth.
7. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
7.1 What to do if...
Problem Possible cause Remedy
You cannot activate or op-
erate the hob. The hob is not connected to an electrical supply or it
is connected incorrectly.
Check if the hob is correctly
connected to the electrical
supply. Refer to the con-
nection diagram.
The fuse is released. Make sure that the fuse is
the cause of the malfunc-
tion. If the fuse releases
again and again, contact a
qualified electrician.
Activate the hob again and
set the heat setting in less
than 10 seconds.
You touched 2 or more
sensor fields at the same
time.
Touch only one sensor field.
STOP+GO function oper-
ates. Refer to "Daily use" chapter.
There is water or fat stains
on the control panel. Clean the control panel.
An acoustic signal sounds
and the hob deactivates.
An acoustic signal sounds
when the hob is deactiva-
ted.
You put something on one
or more sensor fields. Remove the object from the sensor fields.
The hob deactivates. You put something on the
sensor field .
Remove the object from the
sensor field.
Residual heat indicator
does not come on. The zone is not hot be- cause it operated only for a
short time.
If the zone operated suffi-
ciently long to be hot,
speak to an Authorised
Service Centre.
ENGLISH 13

Problem Possible cause Remedy
Automatic Heat Up function
does not operate. The zone is hot. Let the zone become suffi- ciently cool.
The highest heat setting is
set. The highest heat setting has the same power as the
function.
The heat setting changes
between two levels. Power management func- tion operates. Refer to "Daily use" chapter.
The sensor fields become
hot. The cookware is too large or you put it too near to the
controls.
Put large cookware on the
rear zones if possible.
There is no signal when you
touch the panel sensor
fields.
The signals are deactivated. Activate the signals.
Refer to "Daily use" chapter.
comes on. Automatic Switch Off oper-
ates. Deactivate the hob and ac- tivate it again.
comes on. The Child Safety Device or
the Lock function operates. Refer to "Daily use" chapter.
comes on. There is no cookware on
the zone. Put cookware on the zone.
The cookware is incorrect. Use the correct cookware.
Refer to “Hints and tips”
chapter.
The diameter of the bottom
of the cookware is too small
for the zone.
Use cookware with correct
dimensions.
Refer to “Technical informa-
tion” chapter.
The cookware does not
cover the cross / square. Cover the cross / square fully.
and a number come on. There is an error in the hob. Disconnect the hob from
the electrical supply for
some time. Disconnect the
fuse from the electrical sys-
tem of the house. Connect
it again. If comes on
again, speak to an Author-
ised Service Centre.
www.electrolux.com14

Problem Possible cause Remedy
comes on. There is an error in the hob
because a cookware boils
dry. Automatic Switch Off
and the overheating protec-
tion for the zones operate.
Deactivate the hob. Re-
move the hot cookware. Af-
ter approximately 30 sec-
onds, activate the zone
again. If the cookware was
the problem, the error mes-
sage goes out. Residual
heat indicator can stay on.
Let the cookware become
sufficiently cool. Check if
your cookware is compati-
ble with the hob.
Refer to “Hints and tips”
chapter.
7.2 If you cannot find a
solution...
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre. Give the
data from the rating plate. Give also three
digit letter code for the glass ceramic (it is
in the corner of the glass surface) and an
error message that comes on. Make sure,
you operated the hob correctly. If not the
servicing by a service technician or dealer
will not be free of charge, also during the
warranty period. The instructions about
the Service Centre and conditions of
guarantee are in the guarantee booklet.
8. INSTALLATION
WARNING!
Refer to Safety chapters.
8.1 Before the installation
Before you install the hob, write down the
information bellow from the rating plate.
The rating plate is on the bottom of the
hob.
Serial number ...........................
8.2 Built-in hobs
Only use the built-in hobs after you
assemble the hob into correct built-in units
and work surfaces that align to the
standards.
8.3 Connection cable
• The hob is supplied with a connection
cable.
• To replace the damaged mains cable
use the following (or higher) mains
cable type: H05BB-F Tmax 90°C.
Speak to your local Service Centre.
ENGLISH 15

8.4 Assembly
min.
50mm
min.
500mm
min.
2mm
min. 2 mm
AB
A
12 mm
28 mm
38 mm
B
57 mm
41 mm
31 mm
min
30 mm
min. 500 mm
< 20 mm
> 20 mm
min. 2 mm
AB
A
12 mm
28 mm
38 mm
B
57 mm
41 mm
31 mm
min. 500 mm
R 5mm
min.
55mm
560+1mm
490+1mm
min.
38 mm
min.
2 mm
www.electrolux.com16

min.
12 mm
min.
2 mm
8.5 Protection box If you use a protection box (an additional
accessory), the front airflow space of 2
mm and the protective floor directly below
the hob are not necessary. The protection
box accessory may not be available in
some countries. Please contact your local
supplier.
You can not use the
protection box if you install
the hob above an oven.
9. TECHNICAL INFORMATION
9.1 Rating plate
Modell EHI6540FOK PNC 949 596 155 00
Typ 58 GAD DC AU 220 - 240 V 50 - 60 Hz
Induction 7.4 kW Made in Germany
Ser.Nr. ................. 7.4 kW
ELECTROLUX
ENGLISH 17

9.2 Cooking zones specification
Cooking zone Nominal pow-
er (maximum
heat setting)
[W]
Power func-
tion [W]
Power func-
tion maximum
duration [min]
Cookware di-
ameter [mm]
Left front 2300 3200 10 125 - 210
Left rear 2300 3200 10 125 - 210
Right front 1400 2500 4 125 - 145
Right rear 1800 2800 10 145 - 180
The power of the cooking zones can be
different in some small range from the
data in the table. It changes with the
material and dimensions of the cookware.
For optimal cooking results use cookware
not larger than the diameter in the table.
10. ENERGY EFFICIENCY
10.1 Product information according to EU 66/2014
Model identification EHI6540FOK
Type of hob Built-In Hob
Number of cooking zones 4
Heating technology Induction
Diameter of circular cook-
ing zones (Ø) Left front Left rear
Right front
Right rear
21.0 cm
21.0 cm
14.5 cm
18.0 cm
Energy consumption per
cooking zone (EC electric
cooking)
Left front
Left rear
Right front
Right rear
168.6 Wh / kg
176.3 Wh / kg
178.1 Wh / kg
169.2 Wh / kg
Energy consumption of
the hob (EC electric hob) 173.1 Wh / kg
EN 60350-2 - Household electric cooking
appliances - Part 2: Hobs - Methods for
measuring performance
The energy measurements referring to the
cooking area are identified by the crosses
of the respective cooking zones.
10.2 Energy saving
You can save energy during everyday
cooking if you follow below hints.
• When you heat up water, use only the
amount you need.
• If it is possible, always put the lids on
the cookware.
• Before you activate the cooking zone
put the cookware on it.
• Put the smaller cookware on the
smaller cooking zones.
• Put the cookware directly in the centre
of the cooking zone.
• Use the residual heat to keep the food
warm or to melt it.
www.electrolux.com18

11. ENVIRONMENT CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable containers
to recycle it. Help protect the environment
and human health and to recycle waste of
electrical and electronic appliances. Do
not dispose appliances marked with the
symbol with the household waste.
Return the product to your local recycling
facility or contact your municipal office.
ENGLISH 19

SISUKORD
1. OHUTUSINFO.................................................................................................. 21
2. OHUTUSJUHISED........................................................................................... 22
3. SEADME KIRJELDUS......................................................................................24
4. IGAPÄEVANE KASUTAMINE.......................................................................... 26
5. VIHJEID JA NÄPUNÄITEID..............................................................................29
6. PUHASTUS JA HOOLDUS.............................................................................. 31
7. VEAOTSING.....................................................................................................31
8. PAIGALDAMINE...............................................................................................33
9. TEHNILISED ANDMED.................................................................................... 35
10. ENERGIATÕHUSUS...................................................................................... 36
SULLE MÕELDES
Täname teid selle Electroluxi seadme ostmise eest. Olete valinud toote, mille
loomisel on rakendatud pikaaegset asjatundlikku kogemust ja uuenduslikkust.
Nutika ja stiilse disaini kõrval ei ole unustatud ka teid. Ükskõik, millal te seda ka ei
kasuta – suurepärastes tulemustes võite te alati kindel olla.
Teretulemast Electroluxi.
Külastage meie veebisaiti:
Kasutusnõuanded, brošüürid, veaotsing, teave teeninduse kohta:
www.electrolux.com
Registreerige oma toode parema teeninduse saamiseks:
www.registerelectrolux.com
Ostke lisaseadmeid, tarvikuid ja originaalvaruosi:
www.electrolux.com/shop
KLIENDITEENINDUS
Soovitame alati kasutada originaalvaruosi.
Teenindusse pöördumisel peaksid teil olema varuks järgmised andmed. Mudel,
tootenumber (PNC), seerianumber.
Andmed leiate andmesildilt.
Hoiatus / oluline ohutusinfo
Üldine informatsioon ja nõuanded
Keskkonnateave
Jäetakse õigus teha muutusi.
www.electrolux.com20
