Electrolux EB4SL40SP User manual

EB4SL40CN
EB4SL40SP
EN Oven User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................3
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 7
4. OPERATING THE APPLIANCE......................................................................... 8
5. BEFORE FIRST USE......................................................................................... 9
6. DAILY USE......................................................................................................... 9
7. CLOCK FUNCTIONS....................................................................................... 15
8. USING THE ACCESSORIES........................................................................... 16
9. ADDITIONAL FUNCTIONS.............................................................................. 18
10. HINTS AND TIPS........................................................................................... 19
11. CARE AND CLEANING..................................................................................33
12. TROUBLESHOOTING....................................................................................35
13. ENERGY EFFICIENCY.................................................................................. 37
14. GUARANTEE ................................................................................................ 38
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2

1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
•Children of less than 3 years of age should be kept
away unless continuously supervised.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
•If the appliance has a child safety device, it should be
activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements.
ENGLISH 3

•Always use oven gloves to remove or put in
accessories or ovenware.
•Before carrying out any maintenance, disconnect the
appliance from the power supply.
•Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
•Use only the food sensor (core temperature sensor)
recommended for this appliance.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or units with
the same height.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
www.electrolux.com4

• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
ENGLISH 5

• If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance is in operation. Heat
and moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen lamp
used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
www.electrolux.com6

3. PRODUCT DESCRIPTION
3.1 General overview
1 2
4
3
5
6
7
8
1
2
3
4
1Control panel
2Display
3Socket for the food sensor
4Heating element
5Lamp
6Fan
7Shelf support, removable
8Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Food Sensor
To measure the temperature inside the
food.
ENGLISH 7

4. OPERATING THE APPLIANCE
4.1 Control panel
1 2 3 4 5 6
Function Comment
1On / Off To turn the appliance on and off.
2Lamp To turn the lamp on and off.
3Display Shows the current settings of the appliance.
4Rotary knob
To adjust the settings and navigate through the menu.
Press to turn the appliance on.
Hold the rotary knob to turn on the setting screen.
Hold and turn the rotary knob to navigate through the
menu.
Hold and press the rotary knob to confirm a setting or enter
the selected submenu.
To return to the previous menu find the option Back in the
menu list or confirm a selected setting.
5To turn on selected function.
6To turn off selected function.
4.2 Display
After turning on, the display shows the
heating function mode.
150°C
14:05
The display with maximum number of
functions set:
Options
Menu
25min
85 C
170 C
1h 15m
A B C D E F
A. Reminder
B. Up Timer
C. Heating function and temperature
D. Options or Time of Day
E. Duration time and End time of a
function or Food Sensor
F. Menu
www.electrolux.com8

5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning"
chapter.
Clean the oven and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
5.2 First Connection
After the first connection the software
version will appear for 7 seconds.
You have to set the language, the
Display Brightness and the Time of Day.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Heating Functions
Turning the heating functions on and off.
1. Turn on the oven.
2. Hold the rotary knob.
The last used function is underlined.
3. Press the rotary knob to enter the
submenu and turn it to select a
heating function.
4. Press the rotary knob to confirm.
5. Set the temperature and confirm.
6. Press . Food Sensor can be
plugged at any time before or during
cooking process. Some functions
contain a sequence of pop-ups.
Press the rotary knob to go to the
next pop-up. After the last
confirmation the function starts.
To turn off a function press .
The lamp may turn off
automatically at a
temperature below 60 °C
during some oven functions.
Heating Functions: Specials
Heating function Application
Slow Cooking To prepare tender, succulent roasts.
Keep Warm To keep food warm.
Plate Warming To preheat plates for serving.
Preserving To make vegetable preserves such as pickles.
ENGLISH 9

Heating function Application
Drying To dry sliced fruit, vegetables and mushrooms.
Dough Proving For controlled rising of yeast dough before bak‐
ing.
Defrost This function can be used for defrosting frozen
foods, such as vegetables and fruits. The de‐
frosting time depends on the amount and size
of the frozen food.
Bread Baking Use this function to prepare bread and bread
rolls with a very good professional-like result in
terms of crispiness, colour and crust gloss.
Heating functions: Standard
Heating function Application
True Fan Cooking To bake on up to two shelf positions at the
same time and to dry food. Set the temperature
20 - 40 °C lower than for the function: Conven‐
tional Cooking.
True Fan + Bottom To bake food on one shelf position for a more
intensive browning and a crispy bottom. Set
the temperature 20 - 40 °C lower than for the
function: Conventional Cooking.
Conventional Cooking
(Top / Bottom Heat)
To bake and roast food on one shelf position.
Bottom + Grill + Fan To make convenience food like e.g. french
fries, potato wedges or spring rolls crispy.
Grill To grill flat food and to toast bread.
Grill + Fan To roast larger meat joints or poultry with
bones on one shelf position. Also to make gra‐
tins and to brown.
Bottom Heat To bake cakes with crispy bottom and to pre‐
serve food.
www.electrolux.com10

Heating function Application
Moist Fan Baking This function is designed to save energy during
cooking. For more information refer to "Hints
and tips" chapter, Moist Fan Baking. The oven
door should be closed during cooking so that
the function is not interrupted and to ensure
that the oven operates with the highest energy
efficiency possible. When you use this function,
the temperature in the cavity may differ from
the set temperature. Due to the use of the re‐
sidual heat - the heating power may be re‐
duced. For general energy saving recommen‐
dations refer to: "Energy Efficiency" chapter,
Energy Saving.This function was used to com‐
ply with the energy efficiency class according
to EN 60350-1.
6.2 Menu - overview
Options
Menu
170 C
Menu
Menu item Application
Assisted Cooking Contains a list of automatic programmes.
Basic Settings Used to set the appliance configuration.
Submenu for: Basic Settings
Submenu Description
Child Lock When the Child Lock is on, the oven cannot be acti‐
vated accidentally. You can activate and deactivate
this function via Basic Setting Menu. Once activated,
Child Lock appears on the display when you turn on
the appliance. To enable the oven use, choose the
code letters with the rotary knob in the following or‐
der: A B C.
Fast Heat Up Decreases heat up time as a default. Note that it is
available only for some of the heating functions.
ENGLISH 11

Submenu Description
Heat + Hold Keeps the prepared food warm for 30 minutes after
a cooking is finished. To turn it off earlier press the
rotary knob. When this function is active the mes‐
sage "Keep warm started" appears on the display.
Note that it is available only for some of the heating
functions and if Duration is set.
Time Extension To extend predefined cooking time. Note that it is
available only for some of the heating functions.
Setup To set the oven configuration.
Service Shows the software version and configuration.
Submenu for: Setup
Submenu Description
Language Sets the language for the display.
Time of Day Sets the current time and date.
Key Tones Activates and deactivates the tone of the touch
fields. It is not possible to deactivate the tone of the
ON / OFF and STOP.
Alarm/Error Tones Activates and deactivates the alarm tones.
Buzzer Volume Adjusts the volume of press-tones and signals by
degrees.
Display Brightness Adjusts the display brightness by degrees.
Submenu for: Service
Submenu Description
DEMO Activation / deactivation code: 2468
Show Licenses Information about licenses.
Show Software Version Information about software version.
Factory Settings Reset to factory settings.
Submenu for: Assisted Cooking
Every dish in this submenu has a
proposed function and temperature.
Those parameters can be adjusted
manually according to the user's
preference.
For some of the dishes You can also
choose way of cooking:
• Weight Automatic
• Food Sensor
The level to which a dish is cooked:
• Rare or Less
• Medium
• Well Done or More
www.electrolux.com12

Food Category: Meat and Fish
Meat
Beef Sirloin
Roast
Meat Loaf
Scandinavi‐
an Beef
Pork Tenderloin Fresh
Smoked
Roast
Ham
Knuckle
Ribs
Veal Tenderloin
Roast
Knuckle
Lamb Roast
Saddle
Leg
Game Venison Saddle
Haunch
Hare Saddle
Leg
Poultry
Chicken Whole
Half
Legs
Wings
Duck
Goose
Turkey Whole:
Breast
Fish
Whole Fish Small
Medium
Large
Fish Bakes
Fish Fingers
Food Category: Side / Oven Dishes
Dish
Side Dishes French Fries
Croquettes
Wedges
Hash Browns
Oven Dishes Lasagne
Potato Gratin
Pasta Bake
Vegetables au
Gratin
Casserole, savou‐
ry
Casserole, vegeta‐
ble
Food Category: Savoury Baking
Dish
Pizza
Fresh Thin
Thick
Frozen Thin
Thick
Snacks
Chilled
Quiche Thin
Thick
ENGLISH 13

Dish
Bread
Fresh Baguette
Ciabatta
White
Bread
Dark Bread
Rye Bread
All Grain
Bread
Unleavened
Bread
Yeast Plait
Frozen Baguette
Bread
Pre-baked
Rolls
Fresh
Frozen
Pre-baked
Food Category: Desserts / Baking
Dish
Cake in Tin Almond
Cake
Apple Pie
Cheese
Cake
Apple
Cake, cov‐
ered
Short Pas‐
try Base
Sponge
Flan Base
Madeira
Cake
Sponge
Cake
Tarts
Dish
Cake on
Tray
Froz. Apple
Strudel
Brownies
Cheese
Cake
Christmas
Stollen
Fruit Flan Short Pas‐
try
Sponge
Dough
Yeast
Dough
Sponge
Cake
Sugar Cake
Swiss Roll
Swiss
Tarte,
sweet
Yeast Cake
Small Pas‐
try
Cakes,
small
Cream
Puffs
Eclairs
Macaroons
Muffins
Pastry
Stripes
Puff Pastry
Short Pas‐
try Biscuits
Casserole,
sweet
www.electrolux.com14

6.3 Options
Options
Menu
170 C
Options Description
Timer Settings Contains a list of clock functions.
Fast Heat Up To decrease heat up time in the currently
running heating function.
On / Off
Set + Go To set a function and turn it on later.
Once set, the message "Set&Go active"
appears on the display. Press Start to
turn it on. When this function is active the
message disappears from the display
and the oven starts to work. Note that it is
available only for some of the heating
functions and if Duration / End Time is
set.
6.4 Residual heat
When you turn off the oven, the display
shows the residual heat. You can use the
heat to keep the food warm.
7. CLOCK FUNCTIONS
7.1 Timer Settings
Clock function Application
Up Timer Automatically monitors how long the func‐
tion operates. The visibility of the Up Tim‐
er can be turned on and off.
Duration To set the length of an operation.1)
End Time To set the switch-off time for a heating
function. This option is available only
when the Duration is set. Use the func‐
tions Duration and End Time at the same
time to automatically turns on and off the
oven on a given time later. 1)
ENGLISH 15

Clock function Application
Reminder To set a countdown.1)
This function has no effect on the opera‐
tion of the oven.
Choose and set the time. When the
time ends the signal sounds. Press the ro‐
tary knob to stop the signal.
When the oven is turned off press the ro‐
tary knob to turn on this function.
1) Maximum 23 h 59 min
8. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
8.1 Food Sensor
Food Sensor measures temperature
inside the food. When the food is at the
set temperature, the appliance
deactivates.
There are two temperatures to be set:
• the oven temperature (minimum 120
°C),
• the food core temperature.
CAUTION!
Use only the accessory
supplied and the original
replacement parts.
Directions for the best results:
• Ingredients should be at room
temperature.
• The Food Sensor cannot be used for
liquid dishes.
• During cooking the Food Sensor must
remain in the dish and the plug in the
socket.
• Use recommended food core
temperature settings.
WARNING!
Refer to “Hints and tips”
chapter.
The appliance calculates an
approximate end of cooking
time. It depends on the
quantity of food, the set oven
function and temperature.
Food categories: meat, poultry
and fish
1. Activate the oven.
2. Insert the tip of the Food Sensor into
the centre of meat or fish, in the
thickest part if possible. Make sure
that at least 3/4 of the Food Sensor is
inside of the dish.
3. Put the plug of the Food Sensor into
the socket at the front of the oven.
www.electrolux.com16

The display shows: Food Sensor.
4. Set the core temperature.
5. Set a heating function and, if
necessary, the oven temperature.
When the dish reaches the set
temperature the signal sounds. The oven
turns off automatically.
6. Press the rotary knob to stop the
signal.
7. Remove the Food Sensor plug from
the socket and remove the dish from
the oven.
WARNING!
There is a risk of burns as
the Food Sensor becomes
hot. Be careful when you
unplug it and remove it from
the food.
Food category: casserole
1. Activate the oven.
2. Place half of the ingredients in a
baking dish.
3. Insert the tip of the Food Sensor
exactly in the centre of the casserole.
The Food Sensor should be
stabilized in one place during baking.
Use a solid ingredient to achieve
that. Use the rim of the baking dish to
support the silicone handle of the
Food Sensor. The tip of the Food
Sensor should not touch the bottom
of a baking dish.
4. Cover the Food Sensor with the
remaining ingredients.
5. Put the plug of the Food Sensor into
the socket at the front of the oven.
The display shows: Food Sensor.
6. Set the core temperature.
7. Set a heating function and, if
necessary, the oven temperature.
When the dish reaches the set
temperature, an acoustic signal sounds.
The oven turns off automatically.
8. Press the rotary knob to stop the
signal.
9. Remove the Food Sensor plug from
the socket and remove the dish from
the oven.
WARNING!
There is a risk of burns as
the Food Sensor becomes
hot. Be careful when you
unplug it and remove it from
the food.
ENGLISH 17

Changing the core temperature
You can change the core temperature
and the oven temperature at any time
during cooking.
1. Select on the display.
2. Turn the rotary knob to change the
temperature.
3. Press to confirm.
8.2 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
Baking tray/ Deep pan:
Push the baking tray / deep pan between
the guide bars of the shelf support.
Wire shelf and baking tray / deep pan
together:
Push the baking tray / deep pan between
the guide bars of the shelf support and
the wire shelf on the guide bars above.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
9. ADDITIONAL FUNCTIONS
9.1 Automatic Switch-off
For safety reasons the oven turns off
automatically after some time if a heating
function works and you do not change
any settings.
Temperature (°C) Switch-off time
(h)
30 - 115 12.5
120 - 195 8.5
www.electrolux.com18

Temperature (°C) Switch-off time
(h)
200 - 245 5.5
250 - maximum 1.5
The Automatic switch-off
does not work with the
functions: Light, Food
Sensor, Duration, End Time.
9.2 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
10. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
10.1 Advice for special heating
functions of the oven
Keep Warm
The function allows you to keep food
warm. The temperature is set
automatically to 80 °C.
Plate Warming
The function allows you to warm plates
and dishes before serving. The
temperature is set automatically to 70 °C.
Place plates and dishes in stacks evenly
on the wire shelf. Use the first shelf
position. After half of the warming time
switch their places.
Dough Proving
The function allows you to rise yeast
dough. Put the dough into a big dish and
cover it with a wet towel or plastic foil.
Set function: Dough Proving and the
cooking time.
10.2 Baking
• Use the lower temperature the first
time.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different
heights do not always brown equally.
There is no need to change the
temperature setting if an unequal
browning occurs. The differences
equalize during baking.
• Trays in the oven can twist during
baking. When the trays become cold
again, the distortions disappear.
10.3 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not browned suffi‐
ciently.
The shelf position is incor‐
rect.
Put the cake on a lower shelf.
ENGLISH 19

Baking results Possible cause Remedy
The cake sinks and
becomes soggy, lumpy
or streaky.
The oven temperature is
too high.
The next time you bake, set a
slightly lower oven temperature.
The baking time is too
short.
Set a longer baking time. You
cannot decrease baking times
by setting higher temperatures.
There is too much liquid in
the mixture.
Use less liquid. Be careful with
mixing times, especially if you
use a mixing machine.
The cake is too dry. The oven temperature is
too low.
The next time you bake, set a
higher oven temperature.
The baking time is too
long.
The next time you bake, set a
shorter baking time.
The cake browns un‐
evenly.
The oven temperature is
too high and the baking
time is too short.
Set a lower oven temperature
and a longer baking time.
The mixture is unevenly
distributed.
Spread the mixture evenly on
the baking tray.
The cake is not ready
in the baking time giv‐
en.
The oven temperature is
too low.
The next time you bake, set a
slightly higher oven tempera‐
ture.
10.4 Baking on one oven level
Baking in tins
Food Function Temper‐
ature
(°C)
Time (min) Shelf posi‐
tion
Ring cake or brioche True Fan
Cooking
150 - 160 50 - 70 1
Madeira cake / Fruit
cakes
True Fan
Cooking
140 - 160 70 - 90 1
Sponge cake / Sponge
cake
True Fan
Cooking
140 - 150 35 - 50 1
Sponge cake / Sponge
cake
Conventional
Cooking
160 35 - 50 1
Flan base - short pas‐
try1)
True Fan
Cooking
170 - 180 10 - 25 2
Flan base - sponge
mixture
True Fan
Cooking
150 - 170 20 - 25 2
www.electrolux.com20
