Electrolux EOB 966 User manual

1
GB
Electric ovens
INSTRUCTION BOOKLET
Please read this instruction booklet before using the appliance
Mod. EOB 966
35674-1301

2
Installation
 This oven must be installed by qualified
personnel to the relevant British Standards.
 This oven is heavy. Take care when moving it.
 Remove all packaging, both inside and outside
the oven, before using the oven.
 o not attempt to modify the oven in any way.
Child Safety
 This oven is designed to be operated by adults.
o not allow children to play near or with the
oven.
 The oven gets hot when it is in use. Children
should be kept away until it has cooled.
During Use
 This oven is intended for domestic cooking only.
It is not designed for commercial or industrial
purposes.
 Never line any part of the oven with aluminium
foil.
 o not allow heatproof cooking material, e.g.
roasting bags, to come into contact with oven
elements.
 Never place plastic or any other material which
may melt in or on the oven.
 o not place sealed cans or aerosols inside the
oven. They may explode if they are heated.
 o not hang towels, dishcloths or clothes from
the oven or its handle.
 o not use this oven if it is in contact with water
and never operate it with wet hands.
 Take great care when heating fats and oils as
they will ignite if they become too hot.
 Always use oven gloves to remove and replace
food in the oven.
 Ensure that all control knobs are in the OFF
position when not in use.
 o not leave cookware containing foodstuffs,
e.g. fat or oil in or on the oven in case it is
inadvertently switched ON.
 When using other electrical appliances, ensure
the cable does not come into contact with the
hot surfaces of the oven.
Maintenance and Cleaning
 Only clean this oven in accordance with the
instructions.
 The oven should be kept clean at all times. A
build-up of fats or other foodstuffs could result in
a fire, especially in the grill pan.
 Always allow the oven to cool down and switch
off the electrical supply before carrying out any
cleaning or maintenance work.
Service
 This oven should only be repaired or serviced by
an authorised Service Engineer and only genui-
ne approved spare parts should be used.
Environmental Information
 After installation, please dispose of the
packaging with due regard to safety and the
environment.
 When disposing of an old appliance, make it
unusable, by cutting off the cable. Remove any
door catches, to prevent small children being
trapped inside.
Important Safety Information
You MUST read these warnings carefully before installing or using the oven. If
you need assistance, contact our Customer Care De artment on 08705 950950
Kee this instruction book for future
reference and ensure it is assed on to
any new owner.

3
This appliance complies with the following
E.E.C. Directives:
* 73/23 - 90/683 (Low Voltage irective);
* 93/68 (General irectives);
* 89/336 (Electromagnetical Compatibility
irective) .
and subsequent modifications
For the User For the Installer
Contents
Important Safety Information 2
Description of the Appliance 4
Controls 5
Before the First Use 8
Using the Oven 8
Using the Fan Oven 0
Cooking Chart
Defrosting 3
Grilling 4
Cleaning the Oven 6
Something not working 8
Service and Spare Parts 9
Guarantee conditions 9
Technical Data 22
Electrical Connection 22
Building In 23
Oven Door Protection Device
All our appliances comply with the
European safety standards.
Nevertheless, in order to ensure the
highest safety level, and avoid small
children to be exposed to the heat
when the appliance is operated, it is
possible to fit a special protection
device to the oven door. This device
can be purchased in our Service
Force Centres, specifying the
relevant code (35791) and the
Product No. shown on the rating
plate.
The following symbols will be found in the text to
guide you throughout the Instructions:
Safety Instructions
Step by step instructions for an
operation
Hints and Tips
Environmental information
F
Guide to Use the instructions

4
Description of the Appliance
Accessories
Grill/
Roasting pan
Removable
handles
Anti-tip shelf (x 2)
Grill
trivet
Electronic
timer
Oven door
Thermostat
Control Light
Oven
Function
Control
Knob
Thermostat Control
Knob
Control Panel
Mains on
Light
Grill Element
Rating Plate

5
Controls
Oven Function Control Kno
Oven Light - The oven light will be on without
any cooking function.
Inner grill element only - can be used for
grilling small quantities.
ouble Grill - The full grill element will be on.
Thermal Grilling - This function offers an
alternative method of cooking food items,
normally associated with conventional
grilling. The grill element and the oven fan
operate together, circulating hot air around
the food.
Fan Oven cooking - This allows you to roast
or roast and bake simoultaneously using any
shelf, without flavour transference.
efrost Setting - This setting is intended to
assist in thawing of frozen food.
Thermostat Control Kno
Turn the thermostat control knob clockwise to
select temperatures between 50°C and 250°C
(MAX).
The Safety Thermostat
This oven is provided with a safety thermostat. In
case of malfunctioning of the main thermostat, and
consequent over-heating, the safety device will stop
the power supply to the appliance. If this happens,
call your local Service Force Centre. Under no
circumstances should you attempt to repair the
appliance yourself.
100
150
200
50
MAX

6
- +
- +
The electronic timer can indicate the time of day,
operate as a minute minder and automatically ope-
rate the oven.
Before the oven can be operated, the time of day
must be set on the electronic timer.
Please note that this is a 24 hour clock. For
example, 2pm is shown as 14:00.
In case of loss of power, all the settings (time of
day, set program or program in operation), will be
cancelled. When the power is restored, the
numbers on the display will flash, and the timer
has to be reset.
F
TO SET THE TIME OF DAY
Press buttons and , and at the same time
turn the time setting knob until the correct time of
day is displayed.
F
TO SET THE MINUTE MINDER
Press button and at the same time turn the
setting time knob until the duration time is displayed
(maximum 23 hours, 59 minutes).
Our diagram shows the timer set for 35 minutes.
After a few seconds the time of day will show in
the display.
To check the number of minutes remaining, press
the button. At the end of the timed period an
alarm will sound. To switch off the alarm press
button .
- +
A
U
T
O
A
U
T
O
Time
setting
Cookpot
symbol
Programming
controls
24 hour Clock and Timer
Auto
symbol
Minute minder
Cooking duration
End of cooking time
Manual function
Cookpot symbol - This will be displayed when
a program is in operation.
Auto symbol - This will be displayed when
the oven has been programmed for
automatic operation.
- + Time setting knob
A
U
T
O

7
- +
A
U
T
O
A
U
T
O
- +
A
U
T
O
A
U
T
O
F
TO SET THE TIMER TO
SWITCH OFF ONLY
This is useful if you want to begin cooking
immediately but have the oven switch off
automatically.
1. Set the oven function control knob and the
thermostat control knob on the required settings.
2. Place food in the oven.
3. Press button and, at the same time, turn
the time setting knob until the required cooking
duration is displayed.
Our diagram shows the timer set for 1 hour 10
minutes.
At the end of the cooking time the oven will switch
off, an alarm will sound. Turn the oven function and
thermostat control knob to zero. To switch off the
alarm press button .
F
TO SET THE TIMER TO SWITCH
THE OVEN ON AND OFF
1. Ensure the clock is showing the right time of
day.
2. Carry out steps 1, 2 and 3 as explained in "To
set the timer to switch off only".
3. Press button and at the same time turn the
time setting knob until the end cooking time is
displayed.
Our diagram shows the end cooking time set for
7:35 pm.
At the end of the cooking time turn the oven function
and thermostat control knob to zero.
F
TO CANCEL A PROGRAMME
1. Press button and, at the same time, turn
the time setting knob until the cooking duration
is set on "zero".
2. If the end cooking time has been set too, press
button and at the same time turn the time
setting knob until the end cooking time is set on
"zero".
- +
F
MANUAL FUNCTION
Press button to set the oven for manual function.

8
Before the First Use
Remove all ackaging, both inside and
outside the oven, before using the
appliance.
Before first use, the oven should be heated
without food. uring this time, an unpleasant
odour may be emitted. This is quite normal.
F1. Set the programmer to manual
function.
2. Switch the oven function control knob
to fan cooking .
3. Set the thermostat control knob to
MAX.
4. Open a window for ventilation.
5. Allow the oven to run empty for
approximately 45 minutes.
This procedure should be repeated with the grill
function for approximately 5-10 minutes.
Using the ven
Always cook with the oven door
closed.
 Stand clear when opening the drop
down oven door. Do not allow it to fall
open - support the door using the
door handle, until it is fully open.
 The oven has four shelf levels, and is
supplied with two shelves. The shelf
positions are counted from the
bottom of the oven as shown in the
diagram.
It is important that these shelves are
correctly positioned as shown in the
diagram.
 o not place cookware directly on
the oven base.
4
3
2
1
ANTI-TIP SHELF
metal tabs
The anti-tip shelf has four small metal tabs on its
frame to prevent it from sliding out from the shelf
supports.
FO 0336

9
Cookware
 Use any oven proof cookware which will
withstand temperatures of 250°C.
 Baking trays, oven dishes, etc. should not be
placed directly against the grid covering the fan
at the back of the oven, or placed on the oven
base.
 o not use baking trays larger than 30 cm x 35
cm (12 in x 14 in) as they will restrict the
circulation of heat and may affect performan-
ce.
The effects of dishes
on cooking results
ishes and tins vary in their thickness, conductivity,
colour, etc. which affects the way they transmit heat
to the food inside them.
AAluminium, earthenware, oven glassware and
bright shiny utensils reduce cooking and base
browning.
BEnamelled cast iron, anodized aluminium,
aluminium with non-stick interior and coloured
exterior and dark, heavy utensils increase
cooking and base browning.
Condensation and steam
When food is heated it produces steam in the same
way as a boiling kettle. The oven vents allow some
of this steam to escape. However, always stand
back from the oven when o ening the oven
door to allow any build up of steam or heat to
release.
If the steam comes into contact with a cool surface
on the outside of the oven, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not a fault with the oven.
To prevent discoloration, regularly wipe away
condensation and also soilage from surfaces.
Hints and Tips
Cooling fan
The cooling fan operates during cooking. Air is
expelled through vents between the oven door and
the control panel, as shown in the diagram.
The cooling fan may run on after the oven is
switched off to keep the controls cool. This is quite
normal.

10
Using the Fan ven
The air inside the oven is heated by the element
around the fan situated behind the back panel. The
fan circulates hot air to maintain an even tempera-
ture inside the oven.
The advantages of cooking with this function
are:
lFaster Preheating
As the fan oven quickly reaches temperature, it is
not usually necessary to preheat the oven although
you may find that you need to allow an extra 5-7
minutes on cooking times. For recipes which require
higher temperatures, best results are achieved if
the oven is preheated first, e.g. bread, pastries,
scones, souffles, etc.
lLower Tem eratures
Fan oven cooking generally requires lower
temperatures than conventional cooking.
Follow the temperatures recommended in the chart
at page 11 or remember to reduce temperatures by
about 20-25°C for your own recipes which use
conventional cooking.
lEven Heating for Baking
The fan oven has uniform heating on all runner
positions. This means that batches of the same
food can be cooked in the oven at the same time.
However, the top shelf may brown slightly quicker
that the lower one.
This is quite usual. There is no mixing of flavours
between dishes.
FHow to Use the Fan Oven
1. Turn the oven function control knob to .
2. Turn the thermostat control to the required
temperature.
THINGS TO NOTE
 The oven light will come on when the oven
function control knob is set.
 The oven fan will operate continually during
cooking.
 The thermostat control light will remain on until
the correct temperature is reached. It will then
cycle on and off to show the temperature is
being maintained.
FO 2079
