Electrolux EOB5417AO User manual

EOB5417AO
EOB5419AA
EOB5440AO
EOB5441AA
EN Oven User Manual

CONTENTS
1. SAFETY INFORMATION....................................................................................2
2. SAFETY INSTRUCTIONS..................................................................................4
3. PRODUCT DESCRIPTION................................................................................ 6
4. BEFORE FIRST USE......................................................................................... 7
5. DAILY USE......................................................................................................... 7
6. CLOCK FUNCTIONS......................................................................................... 9
7. USING THE ACCESSORIES........................................................................... 10
8. ADDITIONAL FUNCTIONS.............................................................................. 11
9. HINTS AND TIPS............................................................................................. 11
10. CARE AND CLEANING..................................................................................24
11. TROUBLESHOOTING....................................................................................26
12. ENERGY EFFICIENCY.................................................................................. 27
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can
be safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
www.electrolux.com2

responsible for any injuries or damages that are the
result of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children and dispose of
it appropriately.
•Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
•If the appliance has a child safety device, this should
be activated.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
1.2 General Safety
•Only a qualified person must install this appliance and
replace the cable.
•WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
•Always use oven gloves to remove or put in
accessories or ovenware.
•Before maintenance cut the power supply.
ENGLISH 3

•Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
•Do not use a steam cleaner to clean the appliance.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can
scratch the surface, which may result in shattering of
the glass.
•If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
•To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need to
be replaced, this must be carried out
by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
www.electrolux.com4

such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of this
appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with wet
hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and
air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration to
the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of the appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no
effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make
sure the door is never closed when
the appliance is in operation. Heat
and moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or
damage to the appliance.
ENGLISH 5

• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of detergent.
2.5 Internal light
• The type of light bulb or halogen lamp
used for this appliance is only for
household appliances. Do not use it
for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
2.7 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
3. PRODUCT DESCRIPTION
3.1 General overview
7
9
8
41 2 3 5 6
1
2
3
4
5
11
10
1Control panel
2Knob for the oven functions
3Power lamp / symbol
4Electronic programmer
5Knob for the temperature
6Temperature indicator / symbol
7Heating element
8Lamp
9Fan
10 Shelf support, removable
11 Shelf positions
www.electrolux.com6

3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
4. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions" chapter.
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and cleaning"
chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Retractable knobs
To use the appliance, press the control
knob. The control knob comes out.
5.2 Activating and deactivating
the appliance
It depends on the model if
your appliance has lamps,
knob symbols or
indicators:
• The lamp comes on when
the appliance operates.
• The symbol shows
whether the knob controls
the oven functions or the
temperature.
• The indicator comes on
when the oven heats up.
ENGLISH 7

1. Turn the knob for the oven functions
to select an oven function.
2. Turn the knob for the temperature to
select a temperature.
3. To deactivate the appliance turn the
knobs for the oven functions and
temperature to the off position.
5.3 Oven functions
Oven function Application
Off position The appliance is off.
Light To activate the lamp without a cooking function.
True Fan Cook‐
ing
To bake on up to three shelf positions at the same
time and to dry food. Set the temperature 20 - 40 °C
lower than for Top / Bottom Heat.
Pizza Setting To bake food on one shelf position for a more inten‐
sive browning and a crispy bottom. Set the tempera‐
ture 20 - 40 °C lower than for Top / Bottom Heat.
Top / Bottom
Heat
To bake and roast food on one shelf position.
Bottom Heat To bake cakes with crispy bottom and to preserve
food.
Defrost This function can be used for defrosting frozen
foods, such as vegetables and fruits. The defrosting
time depends on the amount and size of the frozen
food.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast
bread.
Turbo Grilling To roast larger meat joints or poultry with bones on
one shelf position. Also to make gratins and to
brown.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
www.electrolux.com8

5.4 Display
A B C
A. Function indicators
B. Time display
C. Function indicator
5.5 Buttons
Button Function Description
MINUS To set the time.
CLOCK To set a clock function.
PLUS To set the time.
6. CLOCK FUNCTIONS
6.1 Clock functions table
Clock function Application
TIME OF DAY To set, change or check the time of day.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates.
TIME DELAY To combine DURATION and END function.
MINUTE MIND‐
ER
To set countdown time. This function has no effect on
the operation of the appliance.
6.2 Setting and changing the
time
You must set the time before you
operate the oven.
The flashes when you connect the
appliance to the electrical supply, when
there was a power cut or when the timer
is not set.
Press the or to set the correct
time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
To change the time of day press
again and again until starts to flash.
6.3 Setting the DURATION
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
ENGLISH 9

3. Press or to set the DURATION
time.
The display shows .
4. When the time ends, flashes and
an acoustic signal sounds. The
appliance deactivates automatically.
5. Press any button to stop the acoustic
signal.
6. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
6.4 Setting the END
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the time.
The display shows .
4. When the time ends, flashes and
an acoustic signal sounds. Press any
button to stop the signal.
5. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
6. The appliance deactivates
automatically.
6.5 Setting the TIME DELAY
1. Set an oven function and
temperature.
2. Press again and again until
starts to flash.
3. Press or to set the time for
DURATION.
4. Press .
5. Press or to set the time for
END.
6. Press to confirm.
Appliance turns on automatically later on,
works for the set DURATION time and
stops at the set END time. At the set time
an acoustic signal sounds.
7. Turn the knob for the oven functions
and the knob for the temperature to
the off position.
8. The appliance deactivates
automatically.
6.6 Setting the MINUTE
MINDER
1. Press again and again until
starts to flash.
2. Press or to set the necessary
time.
The Minute Minder starts automatically
after 5 seconds.
3. When the set time ends, an acoustic
signal sounds. Press any button to
stop the acoustic signal.
4. Turn the knob for the oven functions
to the off position.
6.7 Cancelling the clock
functions
1. Press the again and again until
the necessary function indicator
starts to flash.
2. Press and hold .
The clock function goes out after some
seconds.
7. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
7.1 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
www.electrolux.com10

Deep pan:
Push the deep pan between the guide
bars of the shelf support.
Wire shelf and the deep pan together:
Push the deep pan between the guide
bars of the shelf support and the wire
shelf on the guide bars above and make
sure that the feet point down.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
8. ADDITIONAL FUNCTIONS
8.1 Cooling fan
When the appliance operates, the
cooling fan activates automatically to
keep the surfaces of the appliance cool.
If you deactivate the appliance, the
cooling fan can continue to operate until
the appliance cools down.
9. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
9.1 Inner side of the door
In some models, on the inner side of
the door you can find:
• the numbers of the shelf positions.
• information about the oven functions,
recommended shelf positions and
temperatures for typical dishes.
9.2 Baking
• Your oven may bake or roast
differently to the appliance you had
before. Adapt your usual settings
(temperature, cooking times) and
shelf positions to the values in the
tables.
• The manufacturer recommends that
you use the lower temperature the
first time.
ENGLISH 11

• If you cannot find the settings for a
special recipe, look for the one that is
almost the same.
• You can extend baking times by 10 –
15 minutes if you bake cakes on more
than one shelf position.
• Cakes and pastries at different
heights do not always brown equally
at first. If this occurs, do not change
the temperature setting. The
differences equalize during the baking
procedure.
• With longer baking times, you can
deactivate the oven approximately 10
minutes before the end of the baking
time and then use the residual heat.
When you cook frozen food, the trays in
the oven can twist during baking. When
the trays become cold again, the
distortions are gone.
9.3 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake is
not browned sufficiently.
The shelf position is incor‐
rect.
Put the cake on a lower
shelf.
The cake sinks and be‐
comes soggy, lumpy or
streaky.
The oven temperature is
too high.
The next time you bake,
set a slightly lower oven
temperature.
The cake sinks and be‐
comes soggy, lumpy or
streaky.
The baking time is too
short.
Set a longer baking time.
You cannot decrease
baking times by setting
higher temperatures.
The cake sinks and be‐
comes soggy, lumpy or
streaky.
There is too much liquid in
the mixture.
Use less liquid. Be careful
with mixing times, espe‐
cially if you use a mixing
machine.
The cake is too dry. The oven temperature is
too low.
The next time you bake,
set a higher oven tempera‐
ture.
The cake is too dry. The baking time is too
long.
The next time you bake,
set a shorter baking time.
The cake browns uneven‐
ly.
The oven temperature is
too high and the baking
time is too short.
Set a lower oven tempera‐
ture and a longer baking
time.
The cake browns uneven‐
ly.
The mixture is unevenly
distributed.
Spread the mixture evenly
on the baking tray.
The cake is not ready in
the baking time given.
The oven temperature is
too low.
The next time you bake,
set a slightly higher oven
temperature.
www.electrolux.com12

9.4 Baking on one level:
Baking in tins
Food Function Temperature
(°C)
Time (min) Shelf position
Ring cake /
Brioche
True Fan
Cooking
150 - 160 50 - 70 1
Madeira cake /
Fruit cakes
True Fan
Cooking
140 - 160 70 - 90 1
Fatless sponge
cake / Fatless
sponge cake
True Fan
Cooking
140 - 150 35 - 50 2
Fatless sponge
cake / Fatless
sponge cake
Top / Bottom
Heat
160 35 - 50 2
Flan base -
short pastry
True Fan
Cooking 170 - 1801) 10 - 25 2
Flan base -
sponge mixture
True Fan
Cooking
150 - 170 20 - 25 2
Apple pie / Ap‐
ple pie (2 tins
Ø20 cm, diago‐
nally off set)
True Fan
Cooking
160 60 - 90 2
Apple pie / Ap‐
ple pie (2 tins
Ø20 cm, diago‐
nally off set)
Top / Bottom
Heat
180 70 - 90 1
Cheesecake Top / Bottom
Heat
170 - 190 60 - 90 1
1) Preheat the oven.
Cakes / pastries / breads on baking trays
Food Function Temperature
(°C)
Time (min) Shelf position
Plaited bread /
Bread crown
Top / Bottom
Heat
170 - 190 30 - 40 3
Christmas stol‐
len
Top / Bottom
Heat 160 - 1801) 50 - 70 2
ENGLISH 13

Food Function Temperature
(°C)
Time (min) Shelf position
Bread (rye
bread):
1. First part of
baking pro‐
cedure.
2. Second
part of bak‐
ing proce‐
dure.
Top / Bottom
Heat 1. 2301)
2. 160 - 180
1. 20
2. 30 - 60
1
Cream puffs /
Eclairs
Top / Bottom
Heat 190 - 2101) 20 - 35 3
Swiss roll Top / Bottom
Heat 180 - 2001) 10 - 20 3
Cake with
crumble top‐
ping (dry)
True Fan Cook‐
ing
150 - 160 20 - 40 3
Buttered al‐
mond cake /
Sugar cakes
Top / Bottom
Heat 190 - 2101) 20 - 30 3
Fruit flans
(made with
yeast dough /
sponge mix‐
ture)2)
True Fan Cook‐
ing
150 35 - 55 3
Fruit flans
(made with
yeast dough /
sponge mix‐
ture)2)
Top / Bottom
Heat
170 35 - 55 3
Fruit flans
made with
short pastry
True Fan Cook‐
ing
160 - 170 40 - 80 3
Yeast cakes
with delicate
toppings (e.g.
quark, cream,
custard)
Top / Bottom
Heat 160 - 1801) 40 - 80 3
1) Preheat the oven.
2) Use a deep pan.
www.electrolux.com14

Biscuits
Food Function Temperature
(°C)
Time (min) Shelf position
Short pastry
biscuits
True Fan Cook‐
ing
150 - 160 10 - 20 3
Short bread /
Short bread /
Pastry stripes
True Fan Cook‐
ing
140 20 - 35 3
Short bread /
Short bread /
Pastry stripes
Top / Bottom
Heat 1601) 20 - 30 3
Biscuits made
with sponge
mixture
True Fan Cook‐
ing
150 - 160 15 - 20 3
Pastries made
with egg white /
Meringues
True Fan Cook‐
ing
80 - 100 120 - 150 3
Macaroons True Fan Cook‐
ing
100 - 120 30 - 50 3
Biscuits made
with yeast
dough
True Fan Cook‐
ing
150 - 160 20 - 40 3
Puff pastries True Fan Cook‐
ing 170 - 1801) 20 - 30 3
Rolls True Fan Cook‐
ing 1601) 10 - 25 3
Rolls Top / Bottom
Heat 190 - 2101) 10 - 25 3
Small cakes /
Small cakes
(20 per tray)
True Fan Cook‐
ing 1501) 20 - 35 3
Small cakes /
Small cakes
(20 per tray)
Top / Bottom
Heat 1701) 20 - 30 3
1) Preheat the oven.
9.5 Bakes and gratins
Food Function Temperature
(°C)
Time (min) Shelf position
Pasta bake Top / Bottom
Heat
180 - 200 45 - 60 1
ENGLISH 15

Food Function Temperature
(°C)
Time (min) Shelf position
Lasagne Top / Bottom
Heat
180 - 200 25 - 40 1
Vegetables au
gratin1)
Turbo Grilling 160 - 170 15 - 30 1
Baguettes top‐
ped with mel‐
ted cheese
True Fan Cook‐
ing
160 - 170 15 - 30 1
Sweet bakes Top / Bottom
Heat
180 - 200 40 - 60 1
Fish bakes Top / Bottom
Heat
180 - 200 30 - 60 1
Stuffed vegeta‐
bles
True Fan Cook‐
ing
160 - 170 30 - 60 1
1) Preheat the oven.
9.6 Multilevel Baking
Use the function True Fan Cooking.
Cakes / pastries / breads on baking trays
Food Temperature
(°C)
Time (min) Shelf position
2 positions 3 positions
Cream puffs /
Eclairs 160 - 1801) 25 - 45 1 / 4 -
Dry streusel
cake
150 - 160 30 - 45 1 / 4 -
1) Preheat the oven.
Biscuits / small cakes / small cakes / pastries / rolls
Food Temperature
(°C)
Time (min) Shelf position
2 positions 3 positions
Short pastry
biscuits
150 - 160 20 - 40 1 / 4 1 / 3 / 5
Short bread /
Short bread /
Pastry Stripes
140 25 - 45 1 / 4 1 / 3 / 5
Biscuits made
with sponge
mixture
160 - 170 25 - 40 1 / 4 -
www.electrolux.com16

Food Temperature
(°C)
Time (min) Shelf position
2 positions 3 positions
Biscuits made
with egg white,
meringues
80 - 100 130 - 170 1 / 4 -
Macaroons 100 - 120 40 - 80 1 / 4 -
Biscuits made
with yeast
dough
160 - 170 30 - 60 1 / 4 -
Puff pastries 170 - 1801) 30 - 50 1 / 4 -
Rolls 180 20 - 30 1 / 4 -
Small cakes /
Small cakes
(20 per tray)
1501) 23 - 40 1 / 4 -
1) Preheat the oven.
9.7 Pizza Setting
Food Temperature (°C) Time (min) Shelf position
Pizza (thin crust) 200 - 2301)2) 15 - 20 2
Pizza (with a lot of
topping)
180 - 200 20 - 30 2
Tarts 180 - 200 40 - 55 1
Spinach flan 160 - 180 45 - 60 1
Quiche Lorraine 170 - 190 45 - 55 1
Swiss Flan 170 - 190 45 - 55 1
Cheesecake 140 - 160 60 - 90 1
Apple cake, cov‐
ered
150 - 170 50 - 60 1
Vegetable pie 160 - 180 50 - 60 1
Unleavened bread 230 - 2501) 10 - 20 2
Puff pastry flan 160 - 1801) 45 - 55 2
Flammekuchen
(Pizza-like dish
from Alsace)
230 - 2501) 12 - 20 2
ENGLISH 17

Food Temperature (°C) Time (min) Shelf position
Piroggen (Russian
version of calzone) 180 - 2001) 15 - 25 2
1) Preheat the oven.
2) Use a deep pan.
9.8 Roasting
• Use heat-resistant ovenware to roast
(refer to the instructions of the
manufacturer).
• You can roast large roasting joints
directly in the deep pan (if present) or
on the wire shelf above the deep pan.
• Roast lean meats in the roasting tin
with the lid. This keeps the meat more
succulent.
• All types of meat that can be browned
or have crackling can be roasted in
the roasting tin without the lid.
• We recommend that you cook meat
and fish weighing 1 kg and above in
the appliance.
• To prevent the meat juices or fat from
burning onto the pan, put some liquid
into the deep pan.
• If necessary, turn the roast (after 1/2 -
2/3 of the cooking time).
• Baste large roasts and poultry with
their juices several times during
roasting. This gives better roasting
results.
• You can deactivate the appliance
approximately 10 minutes before the
end of the roasting time, and use the
residual heat.
9.9 Roasting tables
Beef
Food Quantity Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Pot roast 1 - 1.5 kg Top / Bot‐
tom Heat
230 120 - 150 1
Roast beef or
fillet: rare
per cm of
thickness
Turbo Grill‐
ing 190 - 2001) 5 - 6 1
Roast beef or
fillet: medium
per cm of
thickness
Turbo Grill‐
ing 180 - 1901) 6 - 8 1
Roast beef or
fillet: well done
per cm of
thickness
Turbo Grill‐
ing 170 - 1801) 8 - 10 1
1) Preheat the oven.
Pork
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Shoulder /
Neck / Ham
joint
1 - 1.5 Turbo Grill‐
ing
160 - 180 90 - 120 1
www.electrolux.com18

Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Chop / Spare
rib
1 - 1.5 Turbo Grill‐
ing
170 - 180 60 - 90 1
Meatloaf 0.75 - 1 Turbo Grill‐
ing
160 - 170 50 - 60 1
Pork knuckle
(precooked)
0.75 - 1 Turbo Grill‐
ing
150 - 170 90 - 120 1
Veal
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Roast veal 1 Turbo Grill‐
ing
160 - 180 90 - 120 1
Knuckle of
veal
1.5 - 2 Turbo Grill‐
ing
160 - 180 120 - 150 1
Lamb
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Leg of
lamb / Roast
lamb
1 - 1.5 Turbo Grill‐
ing
150 - 170 100 - 120 1
Saddle of
lamb
1 - 1.5 Turbo Grill‐
ing
160 - 180 40 - 60 1
Game
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Saddle / Leg
of hare
up to 1 Top / Bottom
Heat 2301) 30 - 40 1
Saddle of
venison
1.5 - 2 Top / Bottom
Heat
210 - 220 35 - 40 1
Haunch of
venison
1.5 - 2 Top / Bottom
Heat
180 - 200 60 - 90 1
1) Preheat the oven.
Poultry
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Poultry por‐
tions
0.2 - 0.25
each
Turbo Grill‐
ing
200 - 220 30 - 50 1
ENGLISH 19

Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Half chicken 0.4 - 0.5
each
Turbo Grill‐
ing
190 - 210 35 - 50 1
Chicken,
poulard
1 - 1.5 Turbo Grill‐
ing
190 - 210 50 - 70 1
Duck 1.5 - 2 Turbo Grill‐
ing
180 - 200 80 - 100 1
Goose 3.5 - 5 Turbo Grill‐
ing
160 - 180 120 - 180 1
Turkey 2.5 - 3.5 Turbo Grill‐
ing
160 - 180 120 - 150 1
Turkey 4 - 6 Turbo Grill‐
ing
140 - 160 150 - 240 1
Fish (steamed)
Food Quantity
(kg)
Function Tempera‐
ture (°C)
Time (min) Shelf posi‐
tion
Whole fish 1 - 1.5 Top / Bottom
Heat
210 - 220 40 - 60 1
9.10 Grilling
• Always grill with the maximum
temperature setting.
• Set the shelf into the shelf position as
recommended in the grilling table.
• Always set the pan to collect the fat
into the first shelf position.
• Grill only flat pieces of meat or fish.
• Always preheat the empty oven with
the grill functions for 5 minutes.
CAUTION!
Always grill with the oven
door closed.
Grilling
Food Temperature
(°C)
Time (min) Shelf position
1st side 2nd side
Roast beef 210 - 230 30 - 40 30 - 40 2
Filet of beef 230 20 - 30 20 - 30 3
Back of pork 210 - 230 30 - 40 30 - 40 2
Back of veal 210 - 230 30 - 40 30 - 40 2
Back of lamb 210 - 230 25 - 35 20 - 25 3
Whole Fish,
500 - 1000 g
210 - 230 15 - 30 15 - 30 3 / 4
www.electrolux.com20
