Electrolux EW27EW55G S User manual

Luxury-Glide™Oven Racks
With a ball bearing system, oven racks are
so smooth they extend effortlessly.
Sure-2-Fit™Capacity
Coordinate an entire meal – our oven features
4.2 cubic feet of cooking space with three
adjustable baking racks.
Baking Options
Features 7 cooking modes and 10 cooking options
including our exclusive Perfect Turkey™button
for large holiday meals. Perfect Convect3™Third
Element European Convection System features a
variable 2-speed fan for more even cooking.
Luxury-Design™Lighting
Our ramp-up designer halogen lighting is as
beautiful as it is functional and our Luxury-Hold™
oven door stays put at whatever angle you
place it.
Single Wall Ovens
EW27EW55G S, EW27EW55G W, EW27EW55G B
Featuring Wave-Touch™Electronic Controls
27" ELECTRIC SINGLE WALL OVENS
Configuration
Sabbath Mode (Star-K®Certified)
Control Panel Features
Wave-Touch™Electronic Oven Control
Keypad Entry of Time & Temperature
Electronic Clock & Timer
Temperature Display
Automatic Oven (Delay, Cook & Off)
Lockout
Automatic Oven Shutoff – 12 Hour
Programmable for °F or °C
Luxury-Design™Halogen Oven Light Touch Pad
Oven Features
Oven Cavity
Hidden Bake Element
Electric Bake Element – 1450 Watts
Six-Pass Broil Element – 3400 Watts
Convection Element – 2500 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3™with Variable 2-Speed Fan
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Convection Broil, Keep Warm, Slow Cook
Cooking Options –
Perfect Turkey™, Defrost, Dehydrate, Bread Proof,
My Favorites, Multi-Stage Cooking, Temperature Probe,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™LightingwithDual 40W Halogen Bulbs
Luxury-Glide™Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Luxury-Hold™Oven Door
Extra-Large Glass Window
Accessories
Porcelain Broiler Pan and Insert
3"-high Bottom Trim:
S – 903114-9020, W – 903114-9011, B – 903114-9010
Color/UPC(0-57112-)
Stainless Steel (S)
White (W)
Black (B)
Specifications
Oven Cavity Dimensions –
Height
Width
Depth
Overall Exterior Dimensions –
Height (Without 1" Bottom Trim)
Width
Depth (to Front Door Corner)
(with 90° Door Open)
Power Supply Connection Location
Connected Load (kW Rating) @ 240/208 Volts
Amps@240/208 Volts
Minimum Circuit Required (Amps)
Armored Electrical Cable
Approved for Under-Counter Installation*
Product Weight
Shipping Weight
*Single Wall Oven is approved to be used beneath Electrolux gas cooktop models EW30GC55G and
EW36GC55G; and Electrolux electric cooktop models EW30CC55G, EW36CC55G, EW30EC55G
and EW36EC55G.
NOTE: Always consult local and/ or national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
Single
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
3.5 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
7
10
Yes
2
1
Yes
Yes
Yes
Yes
Included
Optional
09704-6
09702-2
09703-9
16-1/2"
20-1/2"
18-1/32"
29"
27"
24-1/2"
44"
Left Bottom Rear
3.4/2.6
14.2/12.6
20
Included
Yes
150 Lbs.
168 Lbs.
electroluxappliances.com
Wall OvensWarmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsDishwashersRefrigerators
FreezersUnder Counter

Single Wall Ovens
EW27EW55G S, EW27EW55G W, EW27EW55G B
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EW27EW55G 01/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
* Critical dimension – MUST be applied
**For cutout height greater than 28
1
/
8 ", add
2"-wide wood shim of appropriate height to
each side of opening under oven side rails
3" max.
Electrical
junction
box location
2" min.
11/2"
min.
31"
suggested
distance
41/2"
min.
required
27 1/4"
min.
28 5/8"
max.
Full base
required
to support
150 lbs.
271/8"
min.
Bottom cutout
edge must be
finish cut
4" x 4"
opening
to route
armoured
cable
24 7/8"min.
25 1/4"max.
231/2"min.*
(critical
dimension)
2"-wide
wood spacers
(if needed)**
Bottom cutout
edge must be
finish cut
2" min.
245/8"
29"
(without
1"bottom
trim) Spacer
115/16"
Allow at least
21" clearance
for door depth
when open
24 1/2"
27"
273/16"
Power
supply
location
(left
bottom
rear)
27" Electric Single Wall Ovens Specifications
•
Product Weight – 150 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit fused
on both sides of line.
•
Connected Load (kW Rating) @ 240/208 Volts = 3.4/2.6kW
•
Amps @ 240/208 Volts =14.2/12.6 Amps
•
Recommended Circuit Breaker – 20 Amps
•
Always consult local and/or national electric codes.
•
Minimum 21" clearance for oven door depth when open.
•
Suggested distance from floor is 31". Minimum required distance is 4-1/2".
•
Minimum 23-1/2" deep cutout dimension is critical for proper installation,
to ensure that oven’s faceplate will fit flush against cabinet front.
•
For cutout height greater than 28-1/8", add a 2"-wide wood shim of
appropriate height to each side of opening under oven side rails.
•
Standard 1"-high Bottom Trim included.
•
To adapt Single Wall Oven to fit cutout height greater than 28-5/8",
optional 3"-high, Bottom Trim available.
•
Full oven base of solid plywood or similar material required, capable of
supporting 150 Lbs.
•
Base must be level and cabinet front must be square with finish-cut
bottom edge.
•
Single Wall Ovens are NOT approved to be used in stackable or
side-by-side installation.
•
Single Wall Ovens are approved to be used in under-counter installation.
•
Single Wall Ovens are approved to be used beneath Electrolux gas
cooktop models EW30GC55G and EW36GC55G; and electric cooktop
models EW30EC55G, EW36EC55G, EW30CC55G and EW36CC55G.
•
Single Wall Ovens are approved to be used in combination with any
Electrolux Warmer Drawer.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
3"-high Bottom Trim: S – (903114-9020), W – (903114-9011),
B – (903114-9010).
