Electrolux EW27EW65GB User manual

Luxury-Glide™Oven Racks
With a ball bearing system, oven racks are
so smooth they extend effortlessly.
Sure-2-Fit™Capacity
Coordinate an entire meal – our oven features
4.2 cubic feet of cooking space with three
adjustable baking racks.
Baking Options
Features 7 cooking modes and 10 cooking options
including our exclusive Perfect Turkey™button
for large holiday meals. Perfect Convect3™Third
Element European Convection System features a
variable 2-speed fan for more even cooking.
Luxury-Design™Lighting
Our ramp-up designer halogen lighting is as
beautiful as it is functional and our Luxury-Hold™
oven door stays put at whatever angle you
place it.
Double Wall Ovens
EW27EW65G S, EW27EW65G W, EW27EW65G B
Featuring Wave-Touch™Electronic Controls
27" ELECTRIC DOUBLE WALL OVENS
Configuration
Sabbath Mode (Star-K®Certified)
Control Panel Features
Wave-Touch™Electronic Oven Controls
Keypad Entry of Time & Temperature
Electronic Clock & Timer
Temperature Display
Toggle Control
Automatic Oven (Delay, Cook & Off)
Lockout
Automatic Oven Shutoff – 12 Hour
Programmable for °F or °C
Luxury-Design™Halogen Oven Light Touch Pad
Oven Features
Oven Cavity (both ovens)
Hidden Bake Element
Electric Bake Element 1450 Watts
Six-Pass Broil Element 3400 Watts
Convection Element – 2500 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3™with Variable 2-Speed Fans
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Convection Broil, Keep Warm, Slow Cook
Cooking Options –
Perfect Turkey™, Defrost, Dehydrate, Bread Proof,
My Favorites, Multi-Stage Cooking, Temperature Probe,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™LightingwithDual 40W Halogen Bulbs
Luxury-Glide™Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Luxury-Hold™Oven Doors
Extra-Large Glass Windows
Accessories
Porcelain Broiler Pan and Insert
3"-high Bottom Trim:
S – 903114-9020, W – 903114-9011, B – 903114-9010
Color/UPC(0-57112-)
Stainless Steel (S)
White (W)
Black (B)
Specifications
Oven Cavity Dimensions –
Height
Width
Depth
Overall Exterior Dimensions –
Height (Without 1" Bottom Trim)
Width
Depth (to Front Door Corner)
(with 90° Door Open)
Power Supply Connection Location
Connected Load (kW Rating) @ 240/208 Volts
Amps@240/208 Volts
Minimum Circuit Required (Amps)
Armored Electrical Cable
Product Weight
Shipping Weight
NOTE: Always consult local and/ or national electric codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
Double
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
3.5 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
7
10
Yes
2
1
Yes
Yes
Yes
Yes
Included
Optional
09710-7
09708-4
09709-1
16-1/2"
20-1/2"
18-1/32"
50-7/16"
27"
24-1/2"
42-1/4"
Left Bottom Rear
6.8/5.1
28.0/25.0
30
Included
300 Lbs.
320 Lbs.
electroluxappliances.com
Wall OvensWarmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsDishwashersRefrigerators
FreezersUnder Counter

Double Wall Ovens
EW27EW65G S, EW27EW65G W, EW27EW65G B
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EW27EW65G 01/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
3" max.
Electrical
junction
box location
4" x 4"
opening
to route
armoured
cable
271/8"
min.
11/2"
min.
111/2"
suggested
distance
41/2"
min.
required
487/8"
min.
497/8"
max. Full base
required
to support
300 lbs.
* Critical dimension – MUST be applied
**For cutout height greater than 49
1
/
2 ", add
2"-wide wood shim of appropriate height to
each side of opening under oven side rails
2"-wide
wood spacers
(if needed)**
Bottom cutout
edge must be
finish cut
24 7/8"min.
25 1/4"max.
231/2"min.*
(critical
dimension)
2" min.
485/8"
245/8"
Spacers
Allow at least
21" clearance
for door depth
when open
24 1/2"
27"
Power
supply
location
(left
bottom
rear)
507/16"
(without
1"bottom
trim)
115/16"
27" Electric Double Wall Oven Specifications
•
Product Weight – 300 Lbs.
•
Single phase 3- or 4-wire cable, 120/240 or 120/208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit fused
on both sides of line.
•
Connected Load (kW Rating) @ 240/208 Volts = 6.8/5.1kW
•
Amps @ 240/208 Volts = 28.0/25.0 Amps
•
Recommended Circuit Breaker – 30 Amps
•
Always consult local and/or national electric codes.
•
Minimum 21" clearance for oven door depth when open.
•
Suggested distance from floor is 11-1/2". Minimum required distance
is 4-1/2".
•
Minimum 23-1/2" deep cutout dimension is critical for proper installation,
to ensure that oven’s faceplate will fit flush against cabinet front.
•
For cutout height greater than 49-1/2", add a 2"-wide wood shim of
appropriate height to each side of opening under oven side rails.
•
Standard 1"-high Bottom Trim included.
•
To adapt Double Wall Oven to fit cutout height greater than 49-7/8",
optional 3"-high, Bottom Trim available.
•
Full oven base of solid plywood or similar material required, capable of
supporting 300 Lbs.
•
Base must be level and cabinet front must be square with finish-cut
bottom edge.
•
Double Wall Ovens are NOT approved to be used in stackable or
side-by-side installation.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
3"-high Bottom Trim: S – (903114-9020), W – (903114-9011),
B – (903114-9010).
