Electrolux ETB2302J-A User manual

ETB2302J-A
ETB2502J-A
ETB2802J-A
ETB3400K-A
ETB3440K-A
ETB3460K-A
ETB3700K-A
ETB3740K-A
ETB3760K-A
User ManualRefrigeration
EN 2
ETB2302J-H
ETB2502J-H
ETB2802J-H
ETB3400K-H
ETB3440K-H
ETB3460K-H
ETB3700K-H
ETB3740K-H
ETB3760K-H
EBB2802K-A
EBB3402K-A
EBB3442K-A
EBB3462K-A
EBB3702K-A
EBB3742K-A
EBB3762K-A
EBB2802K-H
EBB3402K-H
EBB3442K-H
EBB3462K-H
EBB3702K-H
EBB3742K-H
EBB3762K-H

CONTENTS
WE’RE THINKING OF YOU
CUSTOMER CARE AND SERVICE
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.electrolux.com/productregistration
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
Thank you for choosing this Electrolux product. We have created it to give you
impeccable performance for many years, with innovative technologies that help make
life simpler features you might not find on ordinary appliance. Please spend a few
minutes reading to get the very best from it.
Visit our website to:
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Subject to change without notice.
Warning / Caution-Safety information.
General information and tips.
Environmental information.
................................................................................................ 3
............................................................................ 5
....................................................................... 24
.................................................................................. 25
.............................................................................................. 28
............................................................................ 29
1. SAFETY INFORMATION
2. DESCRIPTION OF THE APPLIANCE
3. CONTROL PANEL
......................................................................................................... 19
4. INSTALLING YOUR NEW APPLIANCE
5. USING YOUR REFRIGERATOR
6. AUTOMATIC ICE MAKER
............................................................................................... 30
7. CLEANING YOUR REFRIGERATOR
8. FOOD STORAGE GUIDE
.................................................................................................... 31
........................................................................................................................... 33
9. TROUBLESHOOTING
10. NOISES

SAFETY INFORMATION
1.
WARNING
Note: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your customer care
centre. The manufacturer will not accept liability,
should these instructions or any other safety
instructions incorporated in this book be ignored.
• It is essential the power point is
properly earthed to ground. Consult a
qualified electrician if you are unsure.
• Do not use electrical appliances
inside the food storage compartments
of the appliance, unless they are of
the type recommended by the
manufacturer.
• Unplug the refrigerator before
cleaning or moving it to avoid electric
shock.
• Never unplug the refrigerator by
pulling the electrical cord as this may
damage it. Grip the plug firmly and
pull straight out.
• If the power cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard
• Don’t use a steam cleaner. If live
components come into contact with
condensing steam, they may
short-circuit or cause an electric
shock.
• Do not store explosive substances
such as aerosol canswhit a
flammable propellant this appliance.
If pressurised aerosol containers bear
the word ‘flammable’ and/or a small
flame symbol, do not store them
inside any refrigerator or freezer.
If you do so you may cause an
explosion.
• Do not damage the refrigerant circuit.
• This appliance contains insulation
formed with flammable blowing
gases. Avoid safety hazards by
carefully disposing of this appliance.
• If you wish to discard this refrigerator,
please contact your local authorities
and ask for the correct method of
disposal.
• When you dispose of your old
refrigerators and freezers, remove
any doors. Children can suffocate if
they get trapped inside.
R600a refrigerant warning
This appliance contains flammable
R600a refrigerant. Avoid safety hazards
by carefully installing, handling,
servicing and disposing of this
appliance.
• Ensure that the tubing of the
refrigerant circuit is not damaged
during transportation and installation.
• Leaking refrigerant may cause eye
injuries or ignite.
• The room for installing appliance
must be at least 1m
3
per 8g of
refrigerant. The amount of refrigerant
in the appliance can be found on the
rating plate inside the appliance.
• If you are unsure of the refrigerant
check the rating plate inside the
refrigerator compartment.
• It is hazardous for anyone other than
an Authorised Service Person to
service this appliance. In Queensland
Australia the Authorisation Service
Person MUST hold a Gas Work
Authorisation for hydrocarbon
refrigerants to carry out servicing or
repairs which involve the removal of
covers.
• Keep ventilation openings in the
appliance enclosure or in the built-in
structure, clear of obstruction.
• Do not use mechanical devices or
other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.

WARNING
Stable Footing
When your refrigerator is in place, you
need to stabilise it. Lift the front of the
refrigerator to take the weight off each
stability foot and make small quarter
turns to each foot until it is in firm
contact with the floor. If you intend to
move the refrigerator, remember to
wind up each foot so that you can
move it freely. Repeat the process of
the foot adjustment once you have
settled on the new location of the
refrigerator.
GENERAL WARNINGS
Read the following carefully to avoid
damage or injury.
It is important to use your refrigerator
safely. Check these safety points
before using your refrigerator.
• The appliance must be plugged into
its own dedicated electrical outlet.
• The plug must be accessible when
the refrigerator is in position.
• It is essential the powerpoint is
properly earthed to ground. Consult a
qualified electrician if you are unsure.
• Don’t use extension cords or adapter
plugs with this refrigerator.
• If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
• Unplug the appliance before cleaning
and before changing the light bulb
(when fitted) to avoid electric shock.
• Never unplug the refrigerator by
pulling the electrical cord as this may
damage it. Grip the plug firmly and
pull straight out.
Side View
Stabilising foot
wound down
• Choose a location for your
refrigerator that isn’t too cold. The
ambient room temperature should be
above 10°C.
• Stand your refrigerator in a dry place
avoid areas of high moisture or
humidity.
• Don’t put the refrigerator in frosty or
unprotected areas like a garage or on
the verandah.
• Don’t plug your refrigerator into a
timer fitted to the powerpoint.
• Do not put the refrigerator in direct
sunlight, near stoves, fires or heaters.
• Do not put the refrigerator on an
uneven surface.
• Do not store flammable materials on
or under the appliance, e.g. aerosols.
• Do not store explosive substances
such as aerosol cans with a flamma-
ble propellant in this appliance.
• Never store fizzy drinks in the freezer
compartment.
• Never try to repair the refrigerator
yourself, only use a qualified or
authorised service person for repairs.
• Never use electric heaters or dryers
to defrost the freezer because you
can receive an electric shock
• When transporting and installing the
refrigerator, care should be taken to
ensure that no parts of the refrigerat-
ing circuit are damaged.
• Keep ventilation openings in the
appliance enclosure or in the built-in
structure clear of obstruction.
• When installed correctly, your
refrigerator should:
– Have adequate space at the back
and sides for air circulation.
– Be vertically aligned to the
surrouning cupboards.
– Have doors that will self-close
from a partially open position.
NOTE: You must read these warnings carefully
before installing or using the refrigerator. If you
need assistance, contact your Customer Care
Department. The manufacturer will not accept
liability, should these instructions or any other
safety instructions incorporated in this book be
ignored.

2. DESCRIPTION OF THE APPLIANCE
2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
• ETB2302J-A
• ETB2302J-H
• ETB2502J-A
• ETB2502J-H
• ETB2802J-A
• ETB2802J-H
The details of the refrigerator feature:
Doors Slide Control Refrigerator
Door Handles Humidity Slide
Ice Twist & Serve Crisper
Feet
Slide Control Freezer Temp.
GasketsFreezer Shelf
Door Bins
TasteSeal Room
Multi Flow
Refrigerator Light
FlexStor Rails
Shelves
Deodoriser Cover Refrigerator
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Egg Tray
FlexStor Bins
Bottle Bins
ETB2802 illustrated
TOP MOUNT REFRIGERATOR FEATURES

2
1
3
4
5
6
7
8
9
10
11
12
13
14
16
17
15
TOP MOUNT REFRIGERATOR FEATURES
The details of the refrigerator feature:
DoorCrisper
Door Handles Feet
Ice Twist & Serve Gaskets
Door Bins Shallow
Slide Control Freezer Temp.
Egg TrayFreezer Shelf
Door Bins Upper
TasteSeal Room
Multi Flow
Metal Cover
Bottle Bins
Shelves
Auto Humidity Control
ETB3400 illustrated
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
• ETB3400K-A
• ETB3400K-H

2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
18
19
16
TOP MOUNT REFRIGERATOR FEATURES
ETB3440 illustrated
17
The details of the refrigerator feature:
DoorAuto Humidity Control
Door Handles Crisper
Water Dispenser Feet
Gaskets
Ice Twist & Serve
Door Bins ShallowSlide Control Freezer Temp.
Water Tank
Freezer Shelf
TasteSeal Room
Multi Flow
Egg Tray
Metal Cover
Shelves
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Door Bin Upper
Bottle Bins
• ETB3440K-A
• ETB3440K-H

2
1
3
4
6
7
8
9
10
5
11
12
13
14
15
18
17
19
16
• ETB3460K-A
• ETB3460K-H
TOP MOUNT REFRIGERATOR FEATURES
ETB3460 illustrated
The details of the refrigerator feature:
DoorAuto Humidity Control
Door Handles Crisper
Water Dispenser Feet
Gaskets
Auto Ice Maker
Door Bins ShallowSlide Control Freezer Temp.
Water Tank
Freezer Shelf
TasteSeal Room
Multi Flow
Egg Tray
Metal Cover
Shelves
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Door Bin Upper
Bottle Bins

ETB3700 illustrated
2
1
3
4
5
6
7
8
9
10
11
12
13
14
16
17
15
TOP MOUNT REFRIGERATOR FEATURES
The details of the refrigerator feature:
DoorCrisper
Door Handles Feet
Ice Twist & Serve Gaskets
Door Bins Shallow
Slide Control Freezer Temp.
Egg TrayFreezer Shelf
Door Bins Upper
TasteSeal Room
Multi Flow
Metal Cover
Bottle Bins
Shelves
Auto Humidity Control
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
• ETB3700K-A
• ETB3700K-H

2
1
3
4
5
6
7
8
9
10
11
12
13
14
15
18
19
16
17
ETB3740 illustrated
TOP MOUNT REFRIGERATOR FEATURES
The details of the refrigerator feature:
DoorAuto Humidity Control
Door Handles Crisper
Water Dispenser Feet
Gaskets
Ice Twist & Serve
Door Bins Shallow
Slide Control Freezer Temp.
Water Tank
Freezer Shelf
TasteSeal Room
Multi Flow
Egg Tray
Metal Cover
Shelves
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 Door Bin Upper
• ETB3740K-A
• ETB3740K-H
19 Bottle Bins

2
1
3
4
6
7
8
9
10
5
11
12
13
14
15
18
17
19
16
TOP MOUNT REFRIGERATOR FEATURES
ETB3760 illustrated
The details of the refrigerator feature:
DoorAuto Humidity Control
Door Handles Crisper
Water Dispenser Feet
Gaskets
Auto Ice Maker
Door Bins ShallowSlide Control Freezer Temp.
Water Tank
Freezer Shelf
TasteSeal Room
Multi Flow
Egg Tray
Metal Cover
Shelves
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Door Bin Upper
Bottle Bins
• ETB3760K-A
• ETB3760K-H

EBB2802 illustrated
• EBB2802K-A
• EBB2802K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
1
3
5
6
7
8
9
10
11
12
13
4
14
15
16
17
18
19
2
The details of the refrigerator feature:
DoorIce Twist & Serve
Door Handles Freezer Shelf
Multi Flow Freezer Crisper
Feet
Refrigerator Light
GasketsShelves
FlexStor Rails
Slide Control Refrigerator Temp.
Slide Control Freezer Temp.
Humidity Slide
FlexStor Bins
Crisper
TasteSeal Room
Features may vary depending on model. Not all models will have features listed.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Egg Tray
Bottle Bins

2
1
3
4
6
7
8
9
10
11
12
5
13
14
15
16
17
18
• EBB3402K-A
• EBB3402K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3402 illustrated
DoorFreezer Shelf
Door Handles Freezer Drawer Lower
Multi Flow Feet
Gaskets
Shelves
Door Bin DairyMetal Cover
Door Bin Upper
Slide Control Freezer Temp.
Auto Humidity Control
Crisper
Egg Tray
TasteSeal Room
Ice Twist & Serve
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
18 Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.
16

3
1
2
4
10
8
9
11
12
14
5
15
6
13
16
17
18
19
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3442 illustrated
7
DoorIce Twist & Serve
Water Dispenser Drawer meat
Door Handles Drawer Middle
Freezer Crisper
Multi Flow
FeetShelves
Gaskets
Metal Cover
Slide Control Freezer Temp.
Auto Humidity Control
Egg Tray
Crisper
TasteSeal Room
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Water Tank
Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.
• EBB3442K-A
• EBB3442K-H

3
1
2
4
10
8
9
11
12
14
5
15
6
13
7
16
17
18
19
• EBB3462K-A
• EBB3462K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3462 illustrated
DoorAuto Ice Maker
Water Dispenser Drawer Meat Box
Door Handles Ice Bin Large
Freezer Crisper
Multi Flow
FeetShelves
Gaskets
Metal Cover
Slide Control Freezer Temp.
Auto Humidity Control
Egg Tray
Crisper
TasteSeal Room
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Water Tank
Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.

2
1
3
4
6
7
8
9
10
11
12
5
13
14
15
16
17
18
• EBB3702K-A
• EBB3702K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3702 illustrated
DoorFreezer Shelf
Door Handles Freezer Drawer Lower
Multi Flow Feet
Gaskets
Shelves
Door Bin DairyMetal Cover
Door Bin Upper
Slide Control Freezer
Auto Humidity Control
Crisper
Egg Tray
TasteSeal Room
Ice Twist & Serve
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.

3
1
2
4
10
8
9
11
12
14
5
15
6
13
16
18
19
20
17
• EBB3742K-A
• EBB3742K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3742 illustrated
7
DoorIce Twist & Serve
Water Dispenser Freezer Drawer Meat
Door Handles Freezer Middle
Freezer Drawer Lower
Multi Flow
FeetShelves
Gaskets
Metal Cover
Slide Control Freezer Temp.
Auto Humidity Control
Door Bin Dairy
Crisper
TasteSeal Room
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Egg Tray
Water Tank
Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.

• EBB3762K-H
BUTTOM MOUNT REFRIGERATOR FEATURES
EBB3762K illustrated
3
1
2
4
10
8
9
11
12
14
6
15
7
13
16
18
19
20
5
DoorAuto Ice Maker
Water Dispenser Drawer Meat
Door Handles Bin Ice Large
Freezer Drawer Lower
Multi Flow
FeetShelves
Gaskets
Metal Cover
Slide Control Freezer Temp.
Auto Humidity Control
Egg Tray
Crisper
TasteSeal Room
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Egg Tray
Water Tank
Bottle Bins
The details of the refrigerator feature:
Features may vary depending on model. Not all models will have features listed.
17

DESCRIPTION OPERATION / PRIMARY FUNCTION
CONTROL PANEL3.
3.1 TEMPERATURE CONTROL
7 5 3 1
Top mount freezer Freezer temperature adjustment.
- Select the refrigerator control.
- Slide the control to the left to set it to colder (No.7).
- Slide the control to the right to set less cold (No.1).
Buttom mount freezer Refrigerator temperature adjustment.
- Select the refrigerator control.
- Slide the control up to set it to colder (No.5).
- Slide the control down to set less cold (No.1).
Refrigerator Freezer
Freezer temperature adjustment.
- Select the refrigerator control.
- Slide the control up to set it to colder (No.7).
- Slide the control down to set less cold (No.1).
Setting the freezer temperature to colder
is not recommended for normal or very
hot climate condition as this will limit the
cooling capacity to other sections of the
refrigerator. In very cold climate the
freezer will need to be set colder.
When you first turn on the refrigerator, set both the refrigerator and freezer temperature
control to normal. Please refer to the below section for information on adjusting refrigerator
and freezer temperature.
When you set a temperature, you set an average temperature for the whole refrigerator
cabinet.
Checking the softness of ice cream is a good indication that your freezer is the right
temperature, while checking the temperature of water kept in the refrigerator is a good
way of checking the temperature of the food compartment.
Temperatures inside each compartment may vary, depending on how much food you
store and where you place it.
High or low room temperature may also affect the actual temperature inside the
refrigerator.
When you change the temperature settings, make small adjustments and wait 24 hours
before assessing whether you need to make any further changes.
Recommended Freezer Setting
Room Temp. Setting
Below 15°
Above 15°
7
5
Only install refrigerator indoors where
the room temperature is above 10°

3.2 ABOUT THE USER INTERFACE
Refrigerator temperature scale icons
Temperature adjust
Refrigerator temperature
scale icons
•Indicates the temperature setting of the refrigerator
compartment.
Temperature adjust Temperature Control
•Touch the ‘TEMP’ button to awaken control.
•Touch the ‘TEMP’ button to decrease the refrigerator
temperature. There are 5 temperature settings indicated
by the illumination sequence on the display. Once the
coldest temperature is reached the display will return to
the warmest setting with the next press.
DESCRIPTION OPERATION / PRIMARY FUNCTION
ETB3400K-A
ETB3400K-H
●
●
ETB3440K-A
ETB3440K-H
●
●
ETB3700K-A
ETB3700K-H
●
●
ETB3740K-A
ETB3740K-H
●
●
EBB3702K-A
EBB3702K-H
●
●
EBB3742K-A
EBB3742K-H
●
●
EBB3402K-A
EBB3402K-H
●
●
EBB3442K-A
EBB3442K-H
●
●
