Electrolux EW23CS85KS User guide

23 CU. FT. COUNTER-DEPTH REFRIGERATORS
Capacities
Total Capacity
Fresh Food Volume
Freezer Volume
Total Shelf Area
Fresh Food Shelf Area
Freezer Shelf Area
Exterior
Signature Soft-Arc Door and Handle Design
Electronic Controls
Hidden Hinge Door Design
Ice / Water Dispenser
Perfect Set®Temperature Control System and Display
Crushed / Cubes / Water
Air and Water Filter Indicator / Reset
Fast Ice™/ Fast Freeze™
Lock / Dispenser Light Control
Fresh Food Conveniences
PureAdvantage®Water & Ice
PureAdvantage®Air Filtration
Water Filter Location
Temp Alarm System
Door Ajar Alarm / Power Failure Alarm
Glass Shelves
Dual Humidity-Controlled Upper Crisper
Humidity-Controlled Lower Crisper
Perfect Temp®Drawer
Chill Zone™Drawer
Wine and Beverage Mat
Clear Gallon Door Bins
Clear 2-Liter Door Bins
Condiment Bin
Perfect Bin™Door Storage
Dairy Compartment with Clear Cover
Tall Bottle Retainers
Clear In-Door Can Racks (Holds 6 Cans Each)
Luxury-Design®LED Ramp-Up Multilevel
Freezer Conveniences
Automatic Ice Maker with Ice Server
Glass Shelves
Sliding Full-Width Freezer Baskets
Sliding Half-Width Freezer Baskets
Clear Fixed Door Bins
Tilt-Out Wire Door Racks
Ice Cream Shelf
Soft Freeze™Bin
Pizza Shelf
Luxury-Design®LED Ramp-Up Multilevel
Additional Features
ENERGY STAR®
Sabbath Mode (Star-K®Certified)
Specifications
Color –
Stainless Steel
Product Dimensions –
Height (with Hinges and 3/8" Rollers)
Cabinet Width / Door Width
Depth (to Center of Arc)
(with 90° Door Open)
Power Supply Connection Location
Water Inlet Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts‡
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
‡An electrical supply with grounded three-prong receptacle is required. The power supply circuit must
be installed in accordance with current edition of National Electrical Code (NFPA 70) and local codes
& ordinances.
NOTE: Always consult local and national electric & plumbing codes. Refer to Product Installation Guide
for detailed installation instructions on the web at electroluxappliances.com.
Specifications subject to change.
22.6 Cu. Ft.
13.97 Cu. Ft.
8.59 Cu. Ft.
21.56 Sq. Ft.
15.60 Sq. Ft.
5.96 Sq. Ft.
Yes
Wave-Touch®
Yes
Yes
Yes
Yes / Yes / Yes
Yes
Yes / Yes
Yes / Yes
Yes
Yes
Right Rear
Yes
Yes / Yes
3 Luxury-Design®Lift-Off
Luxury-Close™
Luxury-Close™
Luxury-Close™
Yes
1 Adjustable
1
Yes
2
Yes
Yes
2
1 Luxury-Glide®/ 1 Standard
1
3
Yes
Yes
Yes
Yes
Yes
S
69-1/2"
35-5/8" / 36"
28-3/16"
45"
Right Bottom Rear
Left Bottom Rear
120V / 60 Hz / 15 or 20A
1.02
15
325 Lbs.
Perfect Temp®Drawer
Features nine preset selections including
White / Sparkling Wine, Fish / Shellfish, Snacks
and Chilled Beer, plus three customizable
“My Favorites,” giving you an array of choices
to store or serve whatever you want at the
ideal temperature.
Luxury-Glide®Crispers
Drawers smoothly glide out and keep produce
fresh with adjustable humidity control and minimal
temperature variation.
Wave-Touch®Controls
One simple touch and the control panel activates.
After you make your choices, options will fade
away, returning to an uncluttered display.
9"-Tall Water / Ice Dispenser
Our tall water and ice dispenser is specially
designed to accommodate a variety of large
containers, from a 16-ounce tumbler to a pitcher
or a coffee carafe.
Counter-Depth Refrigerator
EW23CS85K S
Featuring Wave-Touch®Electronic Controls
electroluxappliances.com

Counter-Depth Refrigerator
EW23CS85K S
Electrolux Major Appliances, N.A.
USA •10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •electroluxappliances.com
CANADA •5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •electroluxappliances.ca
EW23CS85K 09/12 © 2012 Electrolux Home Products, Inc.
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Counter-Depth Refrigerator Specifications
Product Weight – 315 Lbs.
•
An electrical supply with grounded three-prong receptacle is required. The
•
power supply circuit must be installed in accordance with current edition
of National Electrical Code (NFPA 70) and local codes & ordinances.
Voltage Rating – 120V / 60 Hz / 15 or 20 Amps
•
Connected Load (kW Rating) @ 120 Volts = 1.02 kW
•
Amps @ 120 Volts = 8.5 Amps
•
Always consult local and national electric & plumbing codes.
•
Floor should be level surface of hard material, capable of supporting fully
•
loaded refrigerator.
When installing refrigerator adjacent to wall, cabinet or other appliance
•
that extends beyond front edge of unit, 20" minimum clearance
recommended to allow for optimum 120° to 180° door swing, providing
complete drawer / crisper access and removal. (Absolute 4-1/2"
minimum clearance will ONLY allow for 90° door swing which will provide
drawer / crisper access with restricted removal.)
To ensure optimum performance, avoid installing in direct sunlight or close
•
proximity to range, dishwasher or other heat source.
For proper ventilation, front grille MUST remain unobstructed.
•
Recess electrical outlet when possible.
•
Water recess on rear wall recommended to prevent water line damage.
•
Water Pressure – Cold water line must provide between 30 and 100
•
pounds per square inch (psi).
Copper tubing with 1/4" O.D. recommended for water supply line with
•
length equal to distance from rear of unit to household water supply line
plus 7 additional feet. Optional Water Supply Installation Kits available.
Adjustable front rollers to assist with door alignment.
•
“Built-In Look” Specifications
Minimum opening of 70-1/4" H x 36" W x 25" D required to allow for ease
•
of installation, proper air circulation, and plumbing / electrical connections.
Remove all wall / floor molding prior to installation.
•
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Counterdepth Refrigerator
EW23CS85K

General Installation Guidelines
For Installation with Side-by-Side Refrigerator
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•10200 David Taylor Drive •Charlotte, NC 28262 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
INSTGDLNS_SSR EL 02/12 © 2012 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at electroluxappliances.com.
Top
Front
Front
Top
