Electrolux DFKTWC75GS User manual

Use & Care Guide
Installation Instructions
Vent Hood
316495007-09/2007

2

3
Finding Information
Purchase date
Electrolux model number
Electrolux serial number (see picture for location)
Please read and save this guide
Thank you for choosing Electrolux, the new premium brand in home appliances. This Use & Care Guide
is part of our commitment to customer satisfaction and product quality throughout the service life of your
new appliance.
We view your purchase as the beginning of a relationship. To ensure our ability to continue serving you,
please use this page to record important product information.
Keep a record for quick reference
NOTE
Registering your product with Electrolux enhances
our ability to serve you. You can register online at
www.electroluxusa.com or by dropping your
Product Registration Card in the mail.
Questions?
For toll-free telephone support in the U.S. and Canada:
1-877-4ELECTROLUX (1-877-435-3287)
For online support and Internet product information visit http://www.electroluxusa.com
Table of contents
Finding information ................................................ 3
SAFETY .............................................................. 4
Verify package contents............................................6
Installation ........................................................... 7
• Install the ductwork .............................................................. 7
• Wiring.................................................................................8
• Install mounting bracket ....................................................... 9
• Install flue mounting bracket ................................................ 9
• Prepare the hood ................................................................ 10
• Install the hood ................................................................... 12
• Install filters.......................................................................14
Maintenance ....................................................... 15
• Grease filters ....................................................................... 15
• Non-Ducted recirculation filters.......................................... 15
• Hood cleaning .................................................................... 15
Operation ........................................................... 16
• Controls.............................................................................16
• Halogen bulbs....................................................................17
• Fuse replacement...............................................................17
Warranty information..............................................18
©2007 Electrolux Home Products, Inc. All rights reserved. Printed in Italy

4Safety
Important Safety Instructions
Read all instructions before using this
appliance.
Save these instructions for future
reference.
Do not attempt to install or operate your
appliance until you have read the safety
precautions in this manual. Safety items
throughout this manual are labeled with a
WARNING or CAUTION based on the risk type.
This symbol alerts you to
situations that may cause
serious body harm,
death or property
damage.
This symbol alerts you to
situations that may cause
bodily injury or property
damage.
INTENDED FOR DOMESTIC COOKING
ONLY
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK,ORINJURY TOPERSONS,OBSERVE THE
FOLLOWING:
1. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer at the address or telephone number
listed in the warranty.
2. Before servicing or cleaning unit, switch power off
at service panel and lock service panel to prevent
power from being switched on accidentally. When
theservicedisconnectingmeanscannotbelocked,
securely fasten a prominent warning device, such
as a tag, to the service panel.
3. Installationworkandelectrical wiring must be done
by a qualified person(s) in accordance with all ap-
plicable codes and standards, including fire-rated
constructioncodes and standards.
4. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of
fuelburningequipmenttopreventbackdrafting. Fol-
low the heating equipment manufacturer’s guide-
linesandsafetystandardssuchasthose published
bytheNationalFireProtectionAssociation(NFPA),
and the American Society for Heating, Refrigera-
tionandAirConditioning Engineers(ASHRAE),and
the local code authorities.
5. When cutting or drilling into wall or ceiling, do not
damageelectrical wiring andother hidden utilities.
6. Ductedfansmustalwaysbevented totheoutdoors.
7. Do not use this unit with any separate solid-state
speedcontrol device.
8. Toreducethe risk of fire, useonly metal ductwork.
9. This unit must be grounded.
TOREDUCETHERISKOF ARANGETOPGREASE
FIRE:
A.Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low
or medium settings.
B.Alwaysturn hood ONwhencooking at highheat or
whenflambeingfood(i.e.CrepesSuzette,Cherries
Jubilee,Peppercorn Beef Flambe’).
C.Cleanventilatingfansfrequently.Greaseshould not
be allowed to accumulate on fan or filter.
D.Use proper pan size. Always use cookware
appropriate for the size of the surface element.

5
Safety
TO REDUCE THE RISK OF INJURY TO PERSONS
IN THE EVENT OF A RANGE TOP GREASE FIRE,
OBSERVETHEFOLLOWING:*
1. SMOTHERFLAMESwith a close-fittinglid, cookie
sheet, or metal tray, then turn off the burner. BE
CAREFUL TO PREVENT BURNS. If the flames
donotgooutimmediately,EVACUATEAND CALL
THEFIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - You may be
burned.
3. DONOTUSEWATER, including wetdishcloths or
towels - violent steam explosion will result.
4. Use an extinguisher ONLY if:
A.You know you have a Class ABC extinguisher
and you already know how to operate it.
B.Thefireissmalland contained in theareawhere
it started.
C.The fire department is being called.
D.You can fight the fire with your back to an exit.
* Based on “Kitchen Fire Safety Tips” published
by NFPA.
1. To reduce risk of fire and to properly exhaust air,
be sure to duct air outside. Do not vent exhaust
airintospaceswithinwallsorceilingsorintoattics,
crawlspaces, or garages.
2. Take care when using cleaning agents or
detergents.
3. Avoid using food products that produce flames
undertheRangeHood.
4. For general ventilating use only. Do not use to
exhaust hazardous or explosive materials and
vapors.
5. Toavoidmotorbearing damage andnoisyand/or
unbalanced impellers, keep drywall spray,
construction dust, etc. off power unit.
6. Yourhoodmotorhasathermaloverloadwhichwill
automaticallyshutoffthemotorifitbecomesover-
heated.The motor willrestart when itcoolsdown.
Ifthe motor continues toshut off andrestart, have
thehood serviced.
7. Forbestcaptureof cooking impurities,the bottom
of the hood should be a minimum of 24" and a
maximum of 30" above the cooking surface.
8. Two installers are recommended because of the
large size and weight of this hood.
9. This product is equipped with a thermostat which
maystartblower automatically. Toreducethe risk
ofinjuryandtopreventpowerfrombeingswitched
on accidentally, switch power off at service panel
and lock or tag service panel.
10.Please read specification label on product for
furtherinformationandrequirements.
AUTOMATICALLYOPERATEDDEVICE.
TOREDUCETHERISKOFINJURY,DISCONNECT
FROM POWER SUPPLY BEFORE SERVICING.
THE UNIT IS EQUIPPED WITH AN INTEGRAL
DISCONNECTINGSWITCHLOCATEDINSIDETHE
BLOWERHOUSING.
INTEGRAL DISCONNECTING SWITCH

6
Unpack hood and check contents.
Youshould receive:
1- Hood
1 - Decorative Flue Assembly
1 - Parts Bag containing:
1 - Mounting Bracket
1- Discharge Collar
1 - Flue Mounting Bracket
6 - Mounting Screws (4,8 x 38mm Pan Head)
7 - Mounting Screws (3,9 x 9,5mm Pan Head)
2 - Mounting Screws (3.9 x 6mm Flat Head)
6 - Drywall Anchors
2 - Grease Filters
1 - Installation Instructions
1-Warranty Card
MOUNTING
BRACKET
DISCHARGE
COLLAR
FLUE MOUNTING
BRACKET
6 MOUNTING SCREWS
(4,8 x 38mm Pan Head) 6 DRYWALL
ANCHORS
7 MOUNTING
SCREWS (3,9 x
9,5mm Pan Head)
DECORATIVE
FLUE
2 MOUNTING SCREWS
(3.9 x 6mm Flat Head)
Verify package contents
GREASE
FILTERS

7
Installation
1. Decide where the ductwork will run between the
hoodand the outside.
2. A straight, short duct run will allow the hood to
perform most efficiently.
3. Longductruns, elbows, andtransitionswill reduce
the performance of the hood. Use as few of them
aspossible.Largerductingmay berequiredforbest
performancewith longer ductruns.
4. Install a roof or wall cap. Connect round metal
ductwork to cap and work back towards hood
location. Use duct tape to seal the joints between
ductwork sections.
5. Nevermakethesizeor areaoftheductworksmaller
than the size that originates at the hood.
6. Bigger ductwork is better.
7. Keep duct lenght less than 50 linear feet.
8. Minimize use of elbows and transitions (4 or less).
9. Always separate 90 degree elbows with at least 2
feet of straight ductwork.
10. Place transitions at least 1 foot from the hood
outlet.
To reduce the risk of fire, use only metal
ductwork.
ROOF CAP
ROUND DUCT
DECORATIVE
FLUE
HOOD
WALL
CAP
ROUND
ELBOW
24” TO 30” ABOVE
COOKING SURFACE 6”
ADAPTER
Install the ductwork

8Installation
Wiring
GROUNDINGINSTRUCTIONS
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electriccurrent.
This appliance is equipped with a cord having a
groundingwirewithagrounding plug.
Theplugmustbepluggedintoanoutlet that isproperly
installedandgrounded.
This range hood must be properly grounded.
The unit should be installed by a qualified
electrician in accordance with all applicable
nationalandlocalelectricalcodes.
Improper grounding can result in a risk of
electric shock.
Consult a qualified electrician if the grounding
instructionsarenotcompletelyunderstood,or if doubt
exists as to whether the appliance is properly
grounded.
Do not use an extension cord.
If the power supply cord is too short, have a qualified
electrician install an outlet near the appliance.
Settheelectricalpowersupplywithinthespacecovered
by the decorative flues.
Position the power socket at a maximum distance of
33-7/16” (85 cm) from where the lead exits from the
hood(seeillustrationalongside).
Make sure this does not interfere with the bracket
fasteningareaorwiththedecorativeflue(wheretheflue
touches the wall).
Fit the plug into the power socket.
33-7/16"
(85cm)
max

9
Installation
Install mounting bracket
FRAMING BEHIND DRYWALL
37"= bottom of hood 24" above cooktop
43"= bottom of hood 30" above cooktop
37” to 43” above cooktop
1. Constructwoodwallframing that is flushwithinte-
rior surface of wall studs.
Makesure:
a) the framing is centered over installation loca-
tion.
b) the heightoftheframingwillallowthemounting
bracket tobe securedto theframing withinthe
dimensionsshown.
2. After wall surface is finished, secure mounting
bracket to framing using dimensions shown.
FLUE MOUNTING BRACKET
10-5/8”
(270.4 mm)
3.9 x 6 mm
FLAT HEAD BRACKET SCREWS
Install flue mounting bracket
DUCTEDANDNON-DUCTED
1. Assemble the flue mounting bracket, adjusting
outside width as shown.
2. Carefullycenterthemountingbracketdirectlyover
therangehoodlocation.
3. Securethebracketassemblytotheceilingusing(2)
4.8x38mmmountingscrews and drywallanchors.
Make sure the bracket is pushed into the corner,
tightagainst the wall and centered over the hood.

10 Installation
Prepare the hood
NOTE
Onstainlesssteel hoods, carefullyremovetheplastic protective filmfromallexterior surfaces ofthe
hood and decorative flues, prior to final installation.
1. Removethepolystyreneblockandthetape(Fig.1).
2. The back plate shown in Fig. 2 must be removed:
removethe (4) screws of theback plate,operating
from the inside of the hood (Fig. 3).
3. Remove the tape on the electrical system plate;
place the electrical system plate on the hood
(protect surface from electrical system plate using
cardboardprotection). Fig. 4.
4. Remove the (2) screws of the back plate (Fig. 5)
and discard the back plate.
FIG. 4
ELECTRICAL SYSTEM PLATE
PROTECTION
FIG. 1
FIG. 2
FIG. 3
FIG. 5
POLYSTYRENE BLOCK
TAPE
BACK PLATE
