Electrolux DI 8610 User manual

DI 8610
CHDI 8610
Cooker Hood
Operating and Installation Instructions

55
Printedonrecycledpaper
AEG-puttingwordsintoaction
Contents
Safety warnings 56
FortheUser 56
FortheInstaller 56
Description of the Appliance 58
Extractorversion 58
RecirculationVersion 58
Hood Operation 59
Controldeviceforgreaseandcharcoalfilters 60
GreasefilterLED(D) 60
CharcoalfilterLED(E) 60
Resettingthesaturationindicator 60
Maintenance and care 61
Cleaningthehood 61
Metalgreasefilter 61
Removingthemetalgreasefilter 61
Charcoalfilter 62
Changingthelightbulb 63
What to do if 64
Special accessories 65
Technicalassistanceservice 65
Technical Specifications 66
Mountingaccessoriesincluded 66
Electrical connection 67
Safetywarningsfortheelectrician 67
Installation 68

56
Safety warnings
For the User
•Thecookerhoodisdesignedtoextractunpleasantodoursfromthekitchen,itwillnot
extractsteam.
•Alwayscoverlightedelements,topreventexcessheatfromdamagingtheappliance.
Inthecaseofoil,gasandcoalfiredcookersitisessentialtoavoidopenflames.
•Also,whenfrying,keepthedeepfryingpanonthecookertop/cookerundercareful
control.
•Thehotoilinthefryingpanmightigniteduetooverheating.
•Theriskofself-ignitionincreaseswhentheoilbeingusedisdirty.
•Itisextremelyimportanttonotethatoverheatingcancauseafire.
•Never carry out any flambécooking under the hood.
•Always disconnect the unit from the power supply before carrying out any
work on the hood, including replacing the light bulb (take the cartridge fuse
outofthefuseholderorswitchofftheautomaticcircuitbreaker).
•It is very important to clean the hood and replace the filter at the
recommended intervals. Failure to do so could cause grease deposits to
build up, resulting in a fire hazard.
For the Installer
•Whenusedasanextractorunit,thehoodmustbefittedwitha 150mmdiameterhose.
Shouldtherealreadybeapipeofdiameter125mmthatductstotheoutsidethrough
thewallsorroof,itispossibletousethe150/125mmreductionflangeprovided.In
thiscasethehoodwillbeslightlynoisier.
•When installing the hood, make sure you respect the following minimum
distance from the top edge of the cooking hob/ring surfaces:
electric cookers 600mm
gas cookers 650mm
coal and oil cookers 700mmmin.
•ThenationalStandardonfuel-burningsystemsspecifiesamaximumdepressionof
0.04mbarinsuchrooms.
•Theairoutletmustnotbeconnectedtochimneyfluesorcombustiongasducts.The
airoutletmustundernocircumstancesbeconnectedtoventilationductsforroomsin
whichfuel-burningappliancesareinstalled.
•Theairoutletinstallationmustcomplywiththeregulationslaiddownbytherelevant
authorities.
•Whentheunitisusedinitsextractorversion,asufficientlylargeventilationholemust
beprovided,withdimensionsthatareapproximatelythesameastheoutlethole.
•Nationalandregionalbuildingregulationsimposeanumberofrestrictionsonusing
hoodsandfuel-burningappliancesconnectedtoachimney,suchascoaloroilroom-

57
heatersandgasfires,inthesameroom.
•Hoodscanonlybeusedsafelywithappliancesconnectedtoachimneyiftheroom
and/orflat(air/environmentcombination)isventilatedfromoutsideusingasuitable
ventilationholeapproximately500-600cm2 largetoavoidthepossibilityofa
depressionbeingcreatedduringoperationofthehood.
•Ifyouhaveanydoubts,contacttherelevantcontrollingauthorityorbuilding
inspector’soffice.
•Sincetheruleforroomswithfuelburningappliancesis“outletholeofthesamesizeas
theventilationhole”,aholeof500-600cm2,whichistosayalargerhole,could
reducetheperformanceoftheextractorhood.
•Ifthehoodisusedinitsfilteringfunction,itwilloperatesimplyandsafelyintheabove
conditionswithouttheneedforanyoftheaforementionedmeasures.
•Whenthehoodisusedinitsextractorfunction,thefollowingrulesmustbefollowedto
obtainoptimaloperation:
—shortandstraightoutlethose
—keepbendsinoutlethosetoaminimum
—neverinstallthehoseswithanacuteangle,theymustalwaysfollowagentlecurve.
—keepthehoseaslargeaspossible(preferablythesamediameterastheoutlet
hole).
•Failuretoobservethesebasicinstructionswilldrasticallyreducetheperformanceand
increasethenoiselevelsoftheextractorhood.

58
Description of the Appliance
•Thehoodissuppliedasanextractorunitandcanalsobeusedwithafilteringfunction
byfittingonecharcoalfilter(specialaccessory).
•YouwillneedanoriginalAEGcharcoalfilterforthisfunction(Availablefromyourlocal
AEGServiceForceCentre).
Extractor version
•Theairisdischargedtotheoutsidethrougha
pipe,whichmustbefittedtoconnectionflange
A. Fig. 1.
•Inordertoobtainthebestperformancethe
hoseshouldhaveadiameterequaltotheoutlet
hole.
Fortheextractorversionthispipemusthavea
diameterof150mm.
Shouldtherealreadybeapipeofdiameter
125mmthatductstotheoutsidethroughthe
wallsorroof,itispossibletousethe150/125
mmreductionflangeprovided.Inthiscasethe
hoodwillbeslightlynoisier. Fig. 1
A
Recirculation Version
•Theairisfilteredthroughanactivatedcharcoalfilterandreturnedtothekitchen
throughthetopgrilloftheoutletpipe.
•YouwillneedanoriginalAEGcharcoalfilterfortherecirculationfunction.(Available
fromyourlocalServiceForceCentre).
•Fixthedeflectorusing4screwsØ3.5x6.5mm.Fig.2.
F
Fig. 2

59
Hood Operation
•Bestresultsareobtainedbyusingalowspeedfornormalconditionsandahigh
speedwhenodoursaremoreconcentrated.
Turnthehoodonafewminutesbeforeyoustartcooking,youwillthengetanunder
pressureinthekitchen.Thehoodshouldbeleftonaftercookingforabout15minutes
oruntilalltheodourshavedisappeared.
Thecontrolswitchesarelocatedontheunit’sfrontpanel:
A- Mainswitch,hoodoff.
B- Startandchoiceofmotorspeed1-2-3-1-2.........
C- Indicatesspeed1(LED).
D- Indicatesspeed2 andsaturationofthegreasefilter(LED)
E- Indicatesspeed3andsaturationofthecharcoalfilter(LED) (flashingLED)
F- IndicatesIntensivespeed(LED).
G- Intensivespeedon/off.TheIntensivespeedrunsfor5minutes:
IfthehoodisonwhentheIntensivespeedisactivated,thehoodrevertsto
previousspeedafter5minutes.
IfthehoodisoffwhentheIntensivespeedisactivated,thehoodwillbeturnedoff
after5minutes.
TointerrupttheIntensivespeed,pressbuttonAorB.
H- LightOFF
I- LightON
Shouldthehoodorthecontrolsfailtooperate:disconnectthepowersupplyforatleast5
seconds,thenturnthehoodbackonagain.
Correct ventilation
Ifthecookerhoodistoworkcorrectlytheremustbeanunderpressureinthekitchen.
Itisimportanttokeepthekitchenwindowsclosedandhaveawindowinanadjacent
roomopen.
Important
Thisisnotapplicableforrecirculation.Greatcaremustbetakenifthehoodisusedat
thesametimeasaburnerorfireplace(e.g.gas,diesel,coalorwoodheaters,water
heaters,etc.),asthehoodwillexpelairwhichisrequiredbytheseotherappliances.
Inthissituation,ensurethatawindowisopen.Thenegativepressureintheroom
mustnotexceed0,04mbartopreventfumesbeingdrawnbackintotheroombythe
cookerhood.
ABCDEFGH I

60
Control device for grease and charcoal filters
Thishoodisfittedwithadevicethatsignalswhenitisnecessarytocleanthegreasefilter
orthecharcoalfilter(inthecaseofrecirculationversionwithcharcoalfilter).
Ondelivery,thehoodisnotsuppliedwithancharcoalfilter,sothesaturationindicatorwill
bedisabled.
Ifthehoodistobeusedwithacharcoalfilter,thesaturation
indicatorlightmustbeenabledasfollows:
PressbuttonsBandGsimultaneouslyandholdthemfor3seconds. Atfirstonlythe
greasefilterLEDDwilllightup,butwhenthecharcoalfilterLEDElightsupthesaturation
indicatorwillbeenabled.
Todisableit:PressbuttonsBandGagainsimultaneouslyandhold
themfor3seconds,untilthecharcoalfilterLEDgoesout.
Grease filter LED (D)
LEDDwillstarttoflashwhenitistimetocleanthegreasefilter.
Cleaningwillbenecessaryafter40workinghours. Alwayscomplywiththemaintenance
instructionsforthegreasefilter.
Charcoal filter LED (E)
ThecharcoalfilterLEDEwillstarttoflashwhenthecharcoalfilterneedstobereplaced.
Thisoperationisnecessaryafterapproximately160workinghours.
Resetting the saturation indicator
Aftercleaningorreplacingthefilters,pressbuttonAfor3secondsuntilthegreasefilter
LEDDorthecharcoalfilterLEDEstopsflashing.

61
Maintenance and care
•The hood must always be disconnected from the electricity supply before
beginning any maintenance work.
Cleaning the hood
•Cleantheoutsideofthehoodusingadampclothandamilddetergent.
•Neverusecorrosive,abrasiveorflammablecleaningproducts.
•Neverinsertpointedobjectsinthemotor’sprotectivegrid.
•Washtheoutsidesurfacesusingadelicatedetergentsolution.Neverusecaustic
detergentsorabrasivebrushesorpowders.
•Onlyevercleantheswitchpanelandfiltergrilleusingadampclothanddelicate
detergents.
•Itisextremelyimportanttocleantheunitandchangethefiltersattherecommended
intervals.Failuretodosowillcausegreasedepositstobuildupthatcouldconstitutea
firehazard.
Metal grease filter
•Thepurposeofthegreasefiltersistoabsorb
greaseparticleswhichformduringcooking
anditmustalwaysbeused,eitherinthe
externalextractionorinternalrecycling
function.
Attention:themetalgreasefiltersmustbe
removedandwashed,eitherbyhandorinthe
dishwasher,everyfourweeks.
Removing the metal grease
filter
•First,pushthemetalgreasefilterstop
backwards,thenextractthefilter,pullingdownwards.Fig.3.
Hand washing
•Soakgreasefiltersforaboutonehourinhotwaterwithagrease-looseningcleaner,
thenrinseoffthoroughlywithhotwater.Repeattheprocessifnecessary.Refitthe
greasefilterswhentheyaredry.
Dishwasher
•Placegreasefiltersinthedishwasher.Selectthemostpowerfulwashingprogramme
andhighesttemperature,atleast65°C.Repeattheprocess.Refitthegreasefilters
when they are dry.
Whenwashingthemetalgreasefilterinthedishwasheraslightdiscolourationofthe
filtercanoccur,thisdoesnothaveanyimpactonitsperformance.
Fig. 3

62
Charcoal filter
•Thecharcoalfiltershouldonlybeusedifyouwanttousethehoodintherecirculation
function.
•TodothisyouwillneedanoriginalAEGcharcoalfilter(availablefromyourlocal
ServiceForceCentre).
•Cleaning/replacing the charcoal filter for UK
Thecharcoalfilterscannotbecleaned,werecommendthattheyshouldbereplaced
approximatelyeverythreemonthsormoreoftenifthehoodisusedformorethan
threehoursperday.
•Cleaning/replacing the carbon filter not for UK
Unlikeothercarbonfilters,theLONGLIFEcarbonfiltercanbecleanedand
reactivated.Atnormalusethefiltershouldbecleanedeverysecondmonth(when
usingthehood2,5hoursperday,inavarage).Thebestwaytocleanthefilterisin
thedishwasher.Usenormaldetergentandchoosethehighesttemperature(65ºC).
Washthefilterseparatelysothatnofoodpartsgetsstuckonthefilterandlatercauses
badodours.Toreactivatethecarbon,thefiltershouldbedriedinanovenfor10
minuteswithatemperatureofmaximum100ºC.
Afterapproximatelythreeyearsofuse,thecarbonfiltershouldbereplacedwitha
new,astheodourreductioncapacitywillbereduced.
•Fitting
Removetheframeiwhichsupportsthefilterhbyunscrewing itfromthehoodg
(Fig.4). Insertthecharcoalfilterinsidetheframeandputallpartsbackintheirplace.
•Toremove proceedinthereverseorder.
•Alwaysspecifythehoodmodelcodenumberandserialnumberwhenordering
replacementfilters.Thisinformationisshownontheregistrationplatelocatedonthe
insideoftheunit.
•ThecharcoalfiltercanbeorderedfromyourlocalAEGServiceForceCentre.
Fig. 4
i
g
h

63
Warning
•Failuretoobservetheinstructionsoncleaningtheunitandchangingthefilterscould
causeafirehazard.Youarethereforestronglyrecommendedtofollowthese
instructions.
•Themanufacturerdeclinesallresponsibilityforanydamagetothemotororanyfire
damagelinkedtoinappropriatemaintenanceorfailuretoobservetheabovesafety
recommendations.
Changing the light bulb
•Disconnectthecookerhoodfromthemainssupply.
•Removethe lamp cover,use ascrewdriverasalever. Fig. 5.
•Replacetheoldbulbwithanewoneofthesametype.
•Refitthelampcover.
•Ifthelightdoesnotcomeon,makesurethebulbhasbeeninsertedincorrectlybefore
contactingyourlocalAEGServiceForceCentre.
Fig. 5

64
What to do if
Ifyourappliancefailstoworkproperlypleasecarryoutthefollowingchecks.
Symptom Solution
Thecookerhoodwillnotstart... Check that:
Thehoodisconnectedto
theelectricitysupply.
Checkthatafanspeedhas
beenselected
Thecookerhoodisnotworking Checkthat:
effectively.. Thefanspeedissethigh
enoughforthetask.
Thegreasefiltersareclean.
Thekitchenisadequatelyventedtoallow
theentryoffreshair.
Ifsetupforrecirculation,checkthatthe
charcoalfilterisstilleffective.
Ifsetupforextraction,checkthattheducting
andoutletsarenotblocked.
Thecookerhoodhas Thesafetycut-outdevicehasbeentripped.
switchedoffduringoperation... Turnoffthehobandthenwaitforthedevice
toreset.
Ifthehoodhasbeeninstalledbelowthe
heightsindicatedintheinstallation
instructionsthemotorwillcut-outfrequently
whichwilldamagethehood.
Ifafterallthesechecks,theproblempersists,contactyourlocalServiceForceCentre,
quotingthemodelandserialnumber.
Pleasenotethatitwillbenecessarytoprovideproofofpurchaseforanyin-guarantee
servicecalls.
In-guaranteecustomersshouldensurethattheabovecheckshavebeenmadeasthe
engineerwillmakeachargeifthefaultisnotamechanicalorelectricalbreakdown.

65
Technical assistance service (not for UK)
Youarewelcometotelephoneourtechnicalassistanceservice(seelistoftechnical
assistancecentres)wheneveryouneedinformationorintheunlikelyeventofafault.
Whencalling,pleasebereadytospecify:
1. The model code number
2. The serial number (E-Nr.)
3. The manufacturing number (F-Nr.)
This information is shown on the registration plate inside the unit behind the
greasefilter.
Wereservetherighttochangespecificationsandcoloursasaresultofourpolicyof
continuingtechnologicaldevelopment.
Service and spare parts for UK
Intheeventofyourappliancerequiringservice,orifyouwishtopurchasespareparts,
contactyourlocalAEGServiceForceCentrebytelephoning:08705929929
YourcallwillbeautomaticallyroutedtotheServiceCentrecoveringyourpostcode
area.FortheaddressofyourlocalServiceForceCentreandfurtherinformationabout
ServiceForce,pleasevisitthewebsiteatwww.serviceforce.co.uk
Pleaseensurethatyouhavereadthesection„Whattodoif....“astheengineerwillmake
achargeifthefaultisnotamechanicalorelectricalbreakdowneventheapplianceis
under warranty. Please note that proof of purchase is required for in-guarantee
servicecalls.
Help us to help you
Pleasedetermineyourtypeofenquirybeforewritingortelephoning.
Whenyoucontactusweneedtoknow:
•Yourname
•Addressandpostcode
•Telephonenumber
•Clearandconcisedetailsofthefault
•Nameandmodeloftheappliance*
•Enumber*
*Thisinformationcanbefoundontheratingplate,whichcanbeseenwhenthegrease
filtersareremoved.
Special accessories*
CharcoalfilterKF20 E-Nr. 942120 600
*NotavailableinUK,pleasecontactyourlocalServiceForceCentre.

66
Technical Specifications
Dimensions:
HeightxWidthxDepth(incm) 80-106,5 x 100 x 65
Maximum absorbed power: 250W
Motorabsorption: 1 x170W
Lighting: 4x20W
Lengthofthecable: 150cm
Mounting accessories included
1ReductionflangeØ150-125
1Deflector
6Wood-screws6x70mm
6WallplugsØ10mm
10Nuts
8Metal-screw3x9mm
14Metal-screw4x8mm
10Metal-screw4x7mm

67
Electrical connection (not for UK)
Safety warnings for the electrician
Beforeconnectingtheappliancetothepowersupply,checkthatthevoltageindicatedon
theratingplatecorrespondstothemainspowersupplyavailable. Appliancesfittedwitha
plugcanbeconnectedtoanystandardpowersocketwithineasyaccess.
Shoulditbenecessarytoprovideafixedconnection,thehoodmustonlybeinstalledby
anelectricianauthorisedbythelocalelectricityboard.Wheninstalling,anomnipolar
disconnectorwithadistanceofatleast3mmbetweencontactsmustbeprovided.
Electrical connection
220-240V–bymeansoffixedpowercablewithplug.
(Fixedconnectionoftheappliancemustonlybecarriedoutbyanauthorisedelectrician.)
Electrical connection for UK only
Safety warnings for the electrician
Theelectricoutletshouldbeplacedonthewallinsidethechimney.Thehoodhasa
powercable,150cm,withearthconnectionandtheratedvoltageis220-240V.
Connectthehoodtothemainssupplyviaadoublepoleswitch
whichhas3mmminimumseparationbetweenthecontacts.
Theswitchmustbeaccessibleatalltimes.
ThefollowingisvalidintheUnitedKingdomonly:
- thewirewhichiscolouredgreenandyellowmustbeconnectedtotheterminalwhich
ismarkedwiththeletterEorbytheearthsymbol( ),orcolouredgreenorgreen
andyellow;
- thewirewhichiscolouredbluemustbeconnectedtotheterminalwhichismarked
withtheletterNorcolouredblack,-
- thewirewhichiscolouredbrownmustbeconnectedtotheterminalwhichismarked
withtheletterLorcolouredred.

68
Installation - Fig. 6-7-8
Expansionplugsareprovidedtosecurethehoodtomosttypesofceilings.However,a
qualifiedtechnicianmustverifysuitabilityofthematerialsinaccordancewiththetypeof
ceiling.Theceilingmustbestrongenoughtotaketheweightofthehood.
Duringelectricalconnectionensurethepowersupplyisdisconnectedatthedomestic
mainsswitch.
•Adjustextensionofthehoodsupportstructure,asthefinalheightofthehooddepends
onthis,andrememberthatwithinstallationcompletedthehoodmustbeatleast60cm
abovethehobtopforelectriccookersand75cmforgasormixedfuelcookers.
•Fixthetwosectionsofthestructureusing8screws(2).
•Placetheceilingholediagramdirectlyabovethehobtop(3-thecentreofthe
diagrammustmatchthecentreofthehobtopandtheedgesmustbeparalleltothe
sidesofthehobtop–thesideofthediagramwiththewordingFRONTcorresponds
tothecontrolpanelside). Preparetheelectricalconnection.
•Drillasshown(6holesfor6wallplugs–4plugsforfixture),screwtheouterscrews
leavingaspaceofabout1cm.betweenthescrewheadandtheceiling(4).
•Fitanexhaustpipeinsidethesupport(5)andconnectittothemotorcompartment
connectionring(exhaustpipeandfixingbracketsarenotsupplied).
•Hooktheframeontothe4screws(6-seealsostep4).
CAUTION!Thesideofthesupportwithconnectionboxcorrespondstothesideofthe
controlpanelwithhoodassembled.
•Tightenthe4screws(7).
•Insertandtightenanother2screwsintheremainingfreeholes(8)forsecurefixing.
•Carryouttheelectricalconnection(9)tothemainspowersupply,onlyturnonthe
powersupplyuponcompletionofassembly.
•Hookthehoodontothesupport(10),ensuringitfitsproperly–tohookthehoodonto
thesupportpartiallytighten4screws(seealsostep12).
•Securethehoodtothesupportusingtwoscrews(11);thiswillalsohelpcentrethe
twosections.
•Tightenthe4screwssecuringthesupporttothehood(12).

69
2a
3
4
4
4
4
44
6
6
7
7
7
7
8
8
2a
5
7
9
10
10
10 10
11
11
14,5
273
273
244
214
190
6
12
2b
2b
Fig. 6

70
•Forextractorversions(13A),connecttheotherendoftheexhaustpipetotheflue.
Forfilterversions(13F),fitdeflectorFtothesupportandsecureittothebracket
suppliedusing4screws,thenconnecttheexhaustpipetotheconnectionringlocated
onthedeflector.
•Fitthenutswithfixinghooks(14)suppliedinsidethetopandbottomsectionsofthe
fluesattherectangularslots.Atotalof10nutsmustbefitted.
•Jointhetwotopsectionsofthefluetocoverthesupport(15)sothatoneoftheslotson
thesectionsissituatedonthesamesideofthecontrolpanelandtheotheronthe
oppositeside.Screwthetwosectionstogetherwith4screws(2eachside-seethe
plandiagramforjoiningthetwosections).
•Fixthetopflueassemblytothesupport,neartheceiling,withtwoscrews(16-one
eachside).
•Carryoutelectricalconnectionofcontrolpanelandbulbs(17).
•Jointhetwobottomsectionsofthefluecoveringthesupport(18) using6screws(3
eachside,seetheplandiagramforjoiningthetwosections).
•Insertthebottomsectionoftheflueinitsseatsothatitcompletelycoversthemotor
compartmentandelectricalconnectionbox,thenensureitfrominsidethehoodusing
twoscrews(19).
•Applythe2tabs(20-supplied)tocoverthefixingpointsofthebottomflue
(CAUTION!THEBOTTOMFLUETABSARETHENARROWER AND
SHALLOWERONES).
Thewideranddeepertabsarethoseusedforthetopflue,andmustbecuttosize.
•Turnthemainspoweronagainatthecentralelectricalpanelandcheckforcorrect
hoodoperation.

71
15
15
15
15
15
16
16
15
15
13F
F
13A
15
14
Fig. 7

72
19
18
18
18
18
18
18
18
18
18 18
M
X
17
17
19
20
X
20
Fig. 8

LI1R5C
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nürnberg
http://www.aeg.hausgeraete.de
http://www.aeg.co.uk
© Copyright by AEG
