80 electrolux laundry electrolux laundry 81
Modern life is hectic.
How will you get time for all the things you enjoy doing?
At Electrolux we have the solution if time is your problem.
Our washing machines are there to make your life easier
so that you will get time for the things you really want to
do. We were thinking of you when we made them.
Time Manager - puts you in control of your time.
or those of you who are looking to control more of your
time, we have the Time Manager washing machine. This
function allows you to decide the time your wash takes,
not the machine. The large LCD display informs you how
your clothes can be washed. Just select the temperature
and you choose the time and press start. We were
thinking it really is that easy!
We offer a wide range of washing machines to meet all
your needs and requirements. All models have a smart
design and a large porthole door with wider opening for
easy unloading. The wash capacity is 6kg (4kg for drying
programmes).
Tailored programmes
It is important to tailor the wash programmes to your
needs, so our washing machines or washer dryers are the
ideal choice. These models have 1200rpm-1400rpm spin
speeds and Direct Spray wash technology which showers
clothes for a more economical wash whilst giving an A+
rated wash performance.
The push buttons make it easy to select the options you
require. Spin reduction and rinse hold both help to reduce
creasing, making ironing easier. Pre-wash, quick wash or
intensive wash can be selected depending upon how
soiled the garments are.
A further time saving feature
To save you even more time, when you want to wash and
dry a half load, we have included a “wash-to-dry” facility.
Simply select the programme required, set the drying
time, press the on button and relax. You’re free to do
whatever you want until your clothes are ready to put
away, clean and dry.
Do your laundry the easy way.
ully integrated laundry appliances are the finishing touch for your
kitchen, discreetly hiding an important appliance behind a furniture door.
You can choose between a washing machine or if space saving is
important to you, a combined washer dryer.
There is so much to do. There are families, friends and career.
There are movies, theatres, concerts and art galleries. Or perhaps
you are into reading books, or visiting the gym.

82 electrolux laundry electrolux laundry 83
Time Manager
function
500/1400rpm
spin
Quick, prewash
and intensive
wash options
Q
Large washing
capacity
EWG14750W
ully integrated 1400rpm spin electronic washing machine
Laund y featu es:
• Extra large washing capacity, 6kg - to meet your wash requirements
• Time Manager function - puts you in control of your time
• 500/1400rpm spin - the selected wash programme gives the optimum
spin speed for the load
• Quick, prewash and intensive wash options - depending how soiled
the garments are
• ully integrated design - appliance blends into kitchen design behind
cabinet door
• Direct spray wash technology - excellent washing performance using
less detergent, energy and water
• Spin reduction option - your choice of 500/700/900/1400rpm
• Rinse hold option - helps to reduce creasing
• Internal self clean filter
• Electronic controls with large LCD display - helps you plan your time
• Delay start option - set the machine to start when it suits you
• Large porthole with wide door opening - for easy loading
• Carboran tub - reduces noise even at high spin speeds
• Water connection - cold fill
• Energy rating:
A+AB
Time Manager
function
500/1400rpm
spin
Quick, prewash
and intensive
wash options
Q
Large washing
capacity
EWG14440W
ully integrated 1400rpm spin electronic washing machine
Laund y featu es:
• Large washing capacity, 5kg - to meet your wash requirements
• Time Manager function - puts you in control of your time
• 500/1400rpm spin - the selected wash programme gives the optimum
spin speed for the load
• Quick, prewash and intensive wash options - depending how soiled
the garments are
• ully integrated design - appliance blends into kitchen design behind
cabinet door
• Aqualux - for great wash results
• Rinse hold option - helps to reduce creasing
• Internal self clean filter
• luff filter above the plinth - easy access for cleaning
• Electronic controls with LCD display - helps you plan your time
• Delay start option - set the machine to start when it suits you
• Large porthole with wide door opening - for easy loading
• Carboran tub - reduces noise even at high spin speeds
• Water connection - cold fill
• Energy rating:
AAB
5kg
1400
1400 6kg

84 electrolux laundry electrolux laundry 85
EWX14450W
ully integrated 1400rpm spin electronic washer dryer
Laund y featu es:
• Extra large washing capacity, 6kg - to meet your wash requirements,
4kg drying capacity
• Time Manager function - puts you in control of your time
• 500/1400rpm spin - the selected wash programme gives the optimum
spin speed for the load
• Quick, prewash and intensive wash options - depending how soiled the
garments are
• ully integrated design - appliance blends into kitchen design behind
cabinet door
• Aqualux - for great wash results
• Spin reduction button - for more flexibility
• Half load “wash-to-dry” facility - for convenience and ideal for rainy days
• Rinse hold option - helps to reduce creasing
• Internal self clean filter
• Electronic controls with LCD display - helps you plan your time
• Delay start option - set the machine to start when it suits you
• Large porthole with wide door opening - for easy loading
• Carboran tub - reduces noise even at high spin speeds
• Detergent recovery system uses detergent more effectively - wasting less
• Combined washing machine and tumble dryer to maximise use of
space in your kitchen
• Condenser dryer, no venting required
• Water connection - cold fill
• Energy rating:
BA
Time Manager
function
500/1400rpm
spin
Quick, prewash
and intensive
wash options
Q
Large washing
capacity
1400 6kg
EWX12550W
ully integrated 1200rpm spin electronic washer dryer
Laund y featu es:
• Extra large washing capacity, 6kg - to meet your wash requirements,
4kg drying capacity
• Time Manager function - puts you in control of your time
• 500/1200rpm spin - the selected wash programme gives the optimum
spin speed for the load
• Quick, prewash and intensive wash options - depending how soiled the
garments are
• ully integrated design - appliance blends into kitchen design behind
cabinet door
• Direct spray wash technology - excellent washing performance using
less detergent, energy and water
• Spin reduction button - for more flexibility
• Half load “wash-to-dry” facility - for convenience and ideal for rainy days
• Rinse hold option - helps to reduce creasing
• Internal self clean filter
• Electronic controls with LCD display - helps you plan your time
• Delay start option - set the machine to start when it suits you
• Large porthole with wide door opening - for easy loading
• Carboran tub - reduces noise even at high spin speeds
• Detergent recovery system uses detergent more effectively - wasting less
• Combined washing machine and tumble dryer to maximise use of
space in your kitchen
• Condenser dryer, no venting required
• Water connection - cold fill
• Energy rating:
CA
Time Manager
function
500/1200rpm
spin
Quick, prewash
and intensive
wash options
Q
Large washing
capacity
1200 6kg
EWG12450W
ully integrated 1200rpm spin electronic washing machine
Laund y featu es:
• Extra large washing capacity, 6kg - to meet your wash requirements
• Time Manager function - puts you in control of your time
• 500/1200rpm spin - the selected wash programme gives the optimum
spin speed for the load
• Quick, prewash and intensive wash options - depending how soiled
the garments are
• ully integrated design - appliance blends into kitchen design behind
cabinet door
• Aqualux - for great wash results
• Spin reduction option - your choice of 500/700/900/1200rpm
• Rinse hold option - helps to reduce creasing
• luff filter above the plinth - easy access for cleaning
• Electronic controls with LCD display - helps you plan your time
• Delay start option - set the machine to start when it suits you
• Large porthole with wide door opening - for easy loading
• Carboran tub - reduces noise even at high spin speeds
• Water connection - cold fill
• Energy rating:
A+AB
Time Manager
function
500/1200rpm
spin
Quick, prewash
and intensive
wash options
Q
Large washing
capacity
1200 6kg

86 electrolux cooking electrolux cooking 87
Single ovens All our stainless steel ovens are now anti-fingerprint. (1) F = Fast rill (2) Pyroluxe cleaning: 5.0kWh
Model EOC69400X EOB98000X EOB66714X EOC68000X EOB67000X EOB63100X/K
Fuel Electric Electric Electric Electric Electric Electric
Steam Side opening
Oven Functions (s = secondary, m = main)
Ultrafan fan operated cooking •• ••••
Turbo-grilling •• •••
Conventional cooking •• ••••
Pizza setting •• •••
Fan controlled defrosting •• ••••
Keep warm •• ••
Full width/dual circuit electric grill(1) •• ••••
Economy electric grill •• ••••
Base heat finishing and reheating •• ••••
Top heat •
Cycloheat gas
as grill
Steam cooking (100) •
Steam cooking (25/75) •
Steam cooking (50/50) •
Oven features
Oven door(s) (Q=quadruple T=triple, D=double) QT T QQT
Interior lights (Watts) 2x65 2x50 25 40 40 25
Interior lights (Position) Back + side Back + side Back
Light bar •• ••••
Baking chart •••••
Rotary controls •
Pop in - pop out controls ••
Touch control •• ••
Set timer •
Digital display •• ••
Digital temperature control •• •••
Compact hinge •• •••
Cooling fan •• ••••
Smell filter •••
Easy installation - side handles and stability feet •• ••••
Programmer
Fully programmable analogue timer
Fully programmable electronic timer •• •••
Mechanical minute minder
Electronic minute minder •••••
Digital controls with menu guided cooking •• ••
Cleaning
Pyroluxe oven cleaning(2) ••
Catalytic lining/liners •••
Diamond glazed enamel interior •
Fold down grill ••••
Removable inner door glasses •• ••••
Equipment Supplied
Telescopic runners •••
Chrome grid runners •• •
Chrome auto-stop non-tip shelves •• ••••
rill/Meat pan •• ••••
Dripping pan •• ••••
Meat probe •• •
Internal Oven Dim. (s=secondary, m=main)
Volume (usage) litres 51 50 54 51 51 51
Height (mm) 310 310 335 310 310 310
Width (mm) 405 400 395 405 405 405
Depth (mm) 410 407 410 410 410 410
Energy Information
Oven temperature range (°C) 30-300 30-300 50-276 30-300 30-300 50-276
Energy class AA AAAA
Energy consumption static (kWh) 0.91 1.19 0.79 0.89 0.79 0.79
Energy consumption fan (kWh) 0.79 0.79 0.79 0.79 0.79 0.79
Energy consumption steam (kWh) 0.79
Standby power (W) 1 1.4 11 1
Electrical connection
Connected load (kW) 3.5 3.5 2.5 3.5 3.5 3
Fuse rating (A) 16 16 13 16 16 13
Oven/ rill power (max) (kW) 3.5/2.9 3.5/2.9 2.5/1.7 3.5/2.9 3.5/2.9 3.0/2.9
Safety and interference suppression
Low Voltage Directive (LVD) •• ••••
Electromagnetic Compatibility (EMC) •• ••••
Literature supplied
Operation and installation instructions •• ••••
Appliance Dimensions
Height (mm - A) 594 594 590 594 594 594
Width (mm - B) 594 594 594 594 594 594
Depth (mm - C) 567 567 560 567 567 567
Net weight (Kg) 40 49 31.2 41.5 34 32.5
Aperture Dimensions
Height (In-column) (mm - D) 590 590 580 590 590 590
Height (Under-counter) (mm - E) 593
Width (mm - F) 560 560 560 560 560 560
Depth (mm - ) 550 550 550 550 550 550
Packaging Dimensions
Height (mm) 700 690 660 700 700 700
Width (mm) 660 660 630 660 660 660
Depth (mm) 705 700 670 705 705 705
ross weight (Kg) 44 53 32.7 45.5 38 35.5
Colour options
Stainless steel •• • •••
White
Brown
Black •
Model EOB63000X/W
EOB53000X/W/B/K EOB51001X/K/W EOG10000X
Fuel Electric Electric Electric as
Oven Functions (s = secondary, m = main)
Ultrafan fan operated cooking •••
Turbo-grilling •
Conventional cooking
Pizza setting
Fan controlled defrosting •••
Keep warm
Full width/dual circuit electric grill(1) ••
Economy electric grill ••
Base heat finishing and reheating
Top heat
Cycloheat gas
as grill •
Steam cooking (100)
Steam cooking (25/75)
Steam cooking (50/50)
Oven features
Oven door(s) (Q=quadruple T=triple, D=double) TDDD
Interior lights (Watts) 25 25 15 2.5
Interior lights (Position) Back Back
Light bar
Baking chart •
Rotary controls ••••
Pop in - pop out controls
Touch control
Set timer ••
Digital display
Digital temperature control
Compact hinge ••••
Cooling fan ••••
Smell filter
Easy installation - side handles •••
Programmer
Fully programmable analogue timer
Fully programmable electronic timer
Mechanical minute minder ••
Electronic minute minder ••
Digital controls with menu guided cooking
Cleaning
Pyroluxe oven cleaning(2)
Catalytic lining/liners
Diamond glazed enamel interior ••••
Fold down grill ••••
Removable inner door glasses •••
Equipment Supplied
Telescopic runners
Chrome grid runners ••
Chrome auto-stop non-tip shelves •••
rill/Meat pan ••
Dripping pan •••
Meat probe
Internal Oven Dim. (s=secondary, m=main)
Volume (usage) litres 51 51 53 62
Height (mm) 310 310 335 302
Width (mm) 405 405 395 465
Depth (mm) 410 410 410 437
Energy Information
Oven temperature range (°C) 50-276 50-275 50-275 50-275
Energy class AAA
Energy consumption static (kWh) 0.79 0.79 0.79
Energy consumption fan (kWh) 0.79 0.79 0.79
Energy consumption steam (kWh)
Standby power (W) 11
Electrical connection
Connected load (kW) 332.075 1.7*
Fuse rating (A) 13 13 13 3*
Oven/ rill power (max) (kW) 3.0/2.9 3.0/2.9 2.075/1.65 2.7*
Safety and interference suppression
Low Voltage Directive (LVD) ••••
Electromagnetic Compatibility (EMC) ••••
Literature supplied
Operation and installation instructions ••••
Appliance Dimensions
Height (mm - A) 594 594 590 597
Width (mm - B) 594 594 594 596
Depth (mm - C) 567 567 560 565
Net weight (Kg) 34 30 31.0 32.1
Aperture Dimensions
Height (In-column) (mm - D) 590 590 593 580
Height (Under-counter) (mm - E) 593
Width (mm - F) 560 560 560 560
Depth (mm - ) 550 550 550 550
Packaging Dimensions
Height (mm) 700 700 660 660
Width (mm) 660 660 630 660
Depth (mm) 705 705 670 630
ross weight (Kg) 38 34 32.5 33.6
Colour options
Stainless steel ••••
White •••
Brown •
Black ••
* Relates to gas connection.
