Electrolux EW 560F User manual

WASHING MACHINE
EW 560 F
EW 660 F
EWF 861
fkpqor`qflk _llhibq
NQTNSRQMM
GB
TH
VIET
ID

2
Contents
Washing hints 9
Sorting the laundry 9
Temperatures 9
Before loading the laundry 9
Maximum loads 9
Laundry weights 9
Removing stains 9
Detergents and additives 10
Operating sequence 11-12
International wash code symbols 13
Washing programmes 14-15
Maintenance 16
Door seal 16
Bodywork 16
Detergent dispenser drawer 16
Drain pump 16-17
Water inlet filter 17
Emergency emptying out 17
Frost precautions 17
Something not working? 18-19
Warnings 3-4
Disposal 4
Tips for environmental protection 4
Technical specifications 4
Installation 5
Unpacking 5
Positioning 5
Water inlet 5
Water drainage 6
Electrical connection 6
Your new washing machine 7
Description of the appliance 7
Detergent dispenser drawer 7
Use 8
Control panel 8
Controls 8
Dear customer,
Please read these operating instructions carefully
and pay particular attention to the safety notes
indicated in the first pages. We recommend that you
keep this instruction booklet for future reference and
pass it on to any future owners.
The symbols you will see on some paragraphs of this booklet have the following meaning:
The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly
important for your safety or correct functioning of the appliance.
The information marked with this symbol provides additional instructions and practical tips on the use of
the appliance.
Tips and information about economical and ecological use of the machine are marked with this symbol.
Our contribution to the protection of the
environment: we use environmentally
friendly paper.
Transport damages
When unpacking the appliance, check that it is not
damaged. If in doubt, do not use it and contact the
Service Centre.

ENGLISH
3
Installation
• All internal packing must be removed before using
the appliance. Serious damage may be caused to
the machine or adjacent furniture if the protective
transit devices are not removed or are not
completely removed. Refer to the relevant
paragraph in the instruction book.
• Any electrical work required to install this appliance
must be carried out by a qualified electrician.
• Any plumbing work required to install this
appliance must be carried out by a qualified
plumber.
• After having installed the machine, check that it is
not standing on its electrical supply cable.
• If the appliance is placed on a carpeted floor,
ensure that air can circulate freely between the
feet and the floor.
Use
• This appliance is designed for domestic use. It
must not be used for purposes other than those for
which it was designed.
• Only wash fabrics which are designed to be
machine washed. Follow the instructions on each
garment label.
• Do not overload the appliance. Follow the
instructions in the instruction book.
• Make sure that all pockets are empty. Objects such
as coins, safety pins, pins and screws can cause
extensive damage.
• Do not machine wash garments saturated with
petroleum, methylated spirits, trichlorethylene, etc.
If such fluids have been used to remove stains
prior to washing, wait until they have completely
evaporated from the fabric before placing
garments in the appliance.
• Place small items such as socks, belts, etc. in a
cloth bag or pillowcase to prevent them getting
trapped between the drum and the tub.
Warnings
• Use only the recommended quantities of fabric
softener. An excessive amount could damage the
laundry.
• Leave the porthole door slightly ajar when the
appliance is not in use. This preserves the door
seal and prevents the formation of musty smells.
• Always check that water has emptied out before
opening the door. If not, drain the water following
the instructions in the instruction book.
• Always unplug the appliance and shut the water
tap after use.
General safety
• Repairs to the machine must be carried out only by
qualified personnel. Repairs carried out by
inexperienced persons could cause serious
danger. Contact your local Service Centre.
• Never pull the power supply cable to remove the
plug from the socket; always take hold of the plug
itself.
• During high temperature wash programmes the
door glass may get hot. Do not touch it!
Child safety
• Children are often not aware of how dangerous
electrical appliances can be. When the machine is
working, children should be carefully supervised
and not be allowed to play with the appliance.
• The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children - danger
of suffocation! Keep them out of children’s reach.
• Keep all detergents in a safe place out of children’s
reach.
• Make sure that children or pets do not climb into
the drum.
• When the appliance is to be scrapped, cut off the
electrical supply cable and destroy the plug with
the remaining cable. Disable the door catch in
order to prevent children from becoming trapped
inside while playing.
The following warnings are provided in the interests of overall safety. You must read them carefully before
installing or using the appliance.

4
EW560F EW660F EWF861
DIMENSIONS Height 85 cm 85 cm 85 cm
Width 60 cm 60 cm 60 cm
Depth 60 cm 60 cm 60 cm
MAXIMUM LOAD Cotton 5.5.kg 5.5.kg 6 .kg
Synthetics 2.5 kg 2.5 kg 2.5 kg
Delicates 2.5 kg 2.5 kg 2.5 kg
Woollens 10kg 10kg 10kg
SPIN SPEED 550 rpm max. 650 rpm max. 850 rpm max.
POWER SUPPLY VOLTAGE/FREQUENCY 220-240 V/50 Hz 220-240 V/50 Hz 220-240 V/50 Hz
TOTAL POWER ABSORBED 2200 W 2200 W 2200 W
MINIMUM FUSE PROTECTION 10 A 10 A 10 A
WATER PRESSURE Minimum 500kPa 500kPa 500kPa
Maximum 800 kPa 800 kPa 800 kPa
This appliance complies with the following EEC Directives:
73/23/EEC of 19/02/73 relating to low voltage
89/336/EEC of 03/05/89 relating to electromagnetic compatibility.
Technical specifications
Disposal
Tips for environmental protection
Packaging materials
The materials marked with the symbol are
recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of
them properly in appropriate collection containers.
Machine
Use authorised disposal sites for your old appliance.
Help to keep your country tidy!
To save water, energy and to help protect the
environment, we recommend that you follow these
tips:
• Normally soiled laundry may be washed without
prewashing in order to save detergent, water and
time (the environment is protected too!).
• The machine works more economically if it is fully
loaded.
• With adequate pre-treatment, stains and limited
soiling can be removed; the laundry can then be
washed at a lower temperature.
• Measure out detergent according to the water
hardness, the degree of soiling and the quantity of
laundry being washed.

5
Unpacking
All transit bolts and packing must be
removed before using the appliance.
You are advised to keep all transit devices so that they
can be refitted if the machine ever has to be transported
again.
1. Using a spanner, unscrew and remove the two
rear bottom screws. Slide out the two plastic pins.
Lay the machine on its back, taking care not to
squash the hoses. This can be avoided by placing
one of the corner packing pieces between the
machine and the floor
2. Remove the polystyrene block(s) from the bottom
of the machine and release the two plastic bags.
3. Very carefully slide out the left polythene bag,
removing it towards the right and then
downwards.
4. Very carefully slide out the right polythene bag,
removing it towards the left and then upwards.
Remove the bottom cover placed into the drum of
your appliance, lay it’s hook as the arrow ’A’
indicates and push the top of the cover to seal it
closed
Important: You can find more detailed instructions
regarding the bottom cover assembling in it’s relative
bag.
5. Set the machine upright and remove the
remaining rear screw. Slide out the relevant pin.
6. Plug all the holes with the plugs which you will
find in the envelope containing the instruction
manual.
Positioning
Install the machine on a flat hard floor.
Make sure that air circulation around the machine
is not impeded by carpets, rugs etc. Check that
the machine does not touch the wall or cupboard
units. Carefully level by screwing the adjustable
feet in or out. Never place cardboard, wood or
similar materials under the machine to
compensate for any unevenness in the floor.
Water inlet
Connect the water inlet hose to a tap with 3/4” BSP
thread.
Use the hose supplied with the washing machine.
DO NOT USE OLD HOSES.
The other end of the inlet hose which connects to the
machine can be turned in any direction. Simply
loosen the fitting, rotate the hose and retighten the
fitting, making sure there are no water leaks.
P1051
Installation
P1128
P0002
P1088
P1129
P0001
P1123
2
3
1
P1126
P1127
P0021

6
The inlet hose must not be lengthened. If it is too
short and you do not wish to move the tap, you will
have to purchase a new, longer hose specially
designed for this type of use.
Water drainage
The end of the drain hose can be positioned in three
ways:
Hooked over the edge of a sink using the plastic
hose guide supplied with the machine. In this
case, make sure the end cannot come unhooked
when the machine is emptying.
This could be done by tying it to the tap with a piece
of string or attaching it to the wall.
In a sink drain pipe branch. This branch must be
above the trap so that the bend is at least 60 cm
above the ground.
Directly into a drain pipe at a height of not less
than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain pipe
must be larger than the outside diameter of the drain
hose.
The drain hose must not be kinked. Run it along the
floor; only the part near the drainage point must be
raised.
For the correct functioning of the machine the
drain hose must remain hooked on the proper
support piece situated on the top part of back
side of the appliance
P0023
P0022
Electrical connection
This machine is designed to operate on a 220-240 V,
single-phase, 50 Hz supply.
Check that your domestic electrical installation can
take the maximum load required (2.2 kW), also
taking into account any other appliances in use.
Connect the machine to an earthed socket.
The manufacturer declines any responsibility
for damage or injury through failure to comply
with the above safety precaution.
Should the appliance power supply cable
need to be replaced, this must be carried out
by our Service Centre.
Important!
When the appliance is installed the power supply
cable must be easily accessible.

7
Your new washing machine
This new machine meets all modern needs for effective treatment of laundry with low water, energy and
detergent consumption.
•The temperature selector dial will allow you to choose the most suitable temperature for your laundry.
• The automatic cooling of the washing water from 95° to 60°C before draining will prevent old drain pipes
from being deformed and will reduce thermal shock to fabrics, helping to prevent creasing.
•The special wool programme with its new delicate wash system treats your woollens with extreme care.
•The unbalance control device ensures the machine is stable during the spin.
•The ECO valve allows total use of detergent and reduces water consumption so saving energy.
1 Detergent dispenser drawer
2 Programme chart
3 Control panel
4 Door handle
5 Drain pump
6 Adjustable feet
Detergent dispenser drawer
Prewash
Main wash
Fabric softener, starch
Description of the appliance
On-Off Spin
Suppress. Rinse
Hold
Quick
Half
13
4
5
6
2
TEMPERATURE PROGRAMMES
EW 560 F
Whi es wi h prewash
Whi es
Coloureds
Wool
B
A
B
C
D
60°- 95°
60°- 95°
30°- 60°
F
J
H
K
L
M
30°- 60°
30°- 60°
- 40°
N
- 40°
30°- 40°
Syn he ics
Syn he ics wi h prewash
Color save
Quick cycle
Drain
Rinses
Delica es
Shor spin
Co ons Syn he ics and special
Fas spin
Rinses
30°- 40°
GP
C0069
ENGLISH

8
Use
Control panel
1 Detergent dispenser drawer and
programme chart
2 Mains-on light
This light comes on when the On-Off button is
pressed, and goes out when it is pressed again.
3 On-Off button
Press this button to start the machine. The same
button is used to switch the machine off.
Before selecting a programme or changing an
ongoing programme the machine must be
switched off by depressing the On-Off button.
4 Spin Suppress. button
Select this button when you have to wash particulary
delicate cotton or linen items in order to exclude all
the spinning phases.
5 Quick Half button
Select this button to reduce water consumption on
the rinse cycle when washing a smaller load of
cottons (maximum load size = 2,5 kg).
6 Rinse Hold button
Press this button to make the machine stop with
water in the drum after the cotton, synthetic or
delicate wash cycles.
This prevents any creasing which may occur if the
clothes are left damp in the drum. When it is
convenient for you to empty the machine, simply
press this button again so that the machine can
proceed to drain the water, or select the programme
N (short spin).
If this button is not activated, the washing
programmes will end with a spin.
7 Temperature selector dial
Turn this dial to select the washing temperature.
Position = cold wash.
8 Programme selector dial
To select the required programme, turn this dial
clockwise until the programme letter is exactly
opposite the pointer.
Before selecting a programme or changing a
programme in progress the machine must be
switched off by depressing ON-OFF button.

ENGLISH
9
Washing hints
Sorting the laundry
Follow the wash code symbols on each garment
label and the manufacturer’s washing instructions.
Sort the laundry as follows:
whites, coloureds, synthetics, delicates, woollens.
Temperatures
95° for normally soiled white cottons and linen
(e.g. tea cloths, towels, tablecloths,
sheets...)
60° for normally soiled, colour fast garments
(e.g. shirts, night dresses, pyjamas....) in
linen, cotton or synthetic fibres and for
lightly soiled white cotton (e.g. underwear).
(cold)for delicate items (e.g. net curtains), mixed
30°-40° laundry including synthetic fibres and
woollens.
Before loading the laundry
Never wash whites and coloureds together. Whites
may lose their “whiteness” in the wash.
New coloured items may run in the first wash; they
should therefore be washed separately the first time.
Make sure that no metal objects are left in the
laundry (e.g. hair clips, safety pins, pins).
Button up pillowcases, close zip fasteners, hooks
and poppers. Tie any belts or long tapes.
Remove persistent stains before washing. Rub
particularly soiled areas with a special detergent or
detergent paste.
Treat curtains with special care. Remove hooks or tie
them up in a bag or net.
Maximum loads
Recommended loads are indicated in the
programme charts.
General rules:
Cotton, linen: drum full but not too tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more than
one third full.
Washing a maximum load makes the most efficient
use of water and energy.
For heavily soiled laundry, reduce the load size.
Laundry weights
The following weights are indicative:
bathrobe 1200 g
napkin 100 g
quilt cover 700 g
sheet 500 g
pillow case 200 g
tablecloth 250 g
towelling towel 200 g
tea cloth 100 g
night dress 200 g
ladies’ briefs 100 g
man’s work shirt 600 g
man’s shirt 200 g
man’s pyjamas 500 g
blouse 100 g
men’s underpants 100 g
Removing stains
Stubborn stains may not be removed by just water
and detergent. It is therefore advisable to treat them
prior to washing.
Blood: treat fresh stains with cold water. For dried
stains, soak overnight in water with a special
detergent then rub in the soap and water.
Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab the
stain; treat several times.
Dried grease stains: moisten with turpentine, lay
the garment on a soft surface and dab the stain with
the fingertips and a cotton cloth.
Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with rust
stains which are not recent since the cellulose
structure will already have been damaged and the
fabric tends to hole.
Mould stains: treat with bleach, rinse well (whites
and fast coloureds only).
Grass: soap lightly and treat with bleach (whites and
fast coloureds only).
Ball point pen and glue: moisten with acetone (*),
lay the garment on a soft cloth and dab the stain.
Lipstick: moisten with acetone as above, then treat
stains with methylated spirits. Remove any residual
marks from white fabrics with bleach.
Red wine: soak in water and detergent, rinse and
treat with acetic or citric acid, then rinse. Treat any

Quantity of detergent to be used
The type and quantity of detergent will depend on
the type of fabric, load size, degree of soiling and
hardness of the water used.
Water hardness is classified in so-called “degrees” of
hardness. Information on hardness of the water in
your area can be obtained from the relevant water
supply company, or from your local authority.
Follow the product manufacturers’ instructions on
quantities to use.
Use less detergent if:
– you are washing a small load,
– the laundry is lightly soiled,
– large amounts of foam form during washing.
residual marks with bleach.
Ink: depending on the type of ink, moisten the fabric
first with acetone (*), then with acetic acid; treat any
residual marks on white fabrics with bleach and then
rinse thoroughly.
Tar stains: first treat with stain remover, methylated
spirits or benzine, then rub with detergent paste.
(*) do not use acetone on artificial silk.
Detergents and additives
Good washing results also depend on the choice of
detergent and use of the correct quantities to avoid
waste and protect the environment. Although
biodegradable, detergents contain substances
which, in large quantities, can upset the delicate
balance of nature.
The choice of detergent will depend on the type of
fabric (delicates, woollens, cottons, etc.), the colour,
washing temperature and degree of soiling.
Only frontload washer detergent should be used in
this appliance:
– powder detergents for all types of fabric,
– powder detergents for delicate fabrics (60°C max)
and woollens,
– liquid detergents, preferably for low temperature
wash programmes (60°C max) for all types of
fabric, or special for woollens only.
The detergent and any additives must be placed in
the appropriate compartments of the dispenser
drawer before starting the wash programme.
If using concentrated powder or liquid detergents, a
programme without prewash must be selected.
The washing machine incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.
Pour liquid detergent into the dispenser drawer
compartment marked just before starting the
programme.
Any fabric softener or starching additives must be
poured into the compartment marked before
starting the wash programme.
Follow the product manufacturer’s recommendations
on quantities to use and do not exceed the «MAX»
mark in the detergent dispenser drawer.
10

ENGLISH
11
4. Select the desired option(s)
Depress one or more buttons depending on the
selected programme.
5. Select the temperature
Turn the dial to the required setting.
6. Select the programme and start
the machine
Turn the programme selector dial clockwise to the
required programme and press the On-Off button :
the mains on light comes on and the machine starts
to operate.
P0080S
On-Off
M0046
B
M0045
95
Spin
Suppress. Rinse
Hold
Quick
Half
Operating sequence
Before the first wash we recommend that you pour 2
litres of water into the main wash compartment
of the detergent drawer in order to activate the
ECO valve. Then run a cotton cycle at 60°C, with the
machine empty, in order to remove any
manufacturing residue from the drum and tub.
Pour half a measure of detergent into the main wash
compartment and start up the machine.
1. Place the laundry in the drum
Open the door.
Place the laundry in the drum, one item at a time,
shaking them out as much as possible.
Close the door.
2. Measure out the detergent
Pull out the dispenser drawer until it stops. Measure
out the amount of detergent recommended by the
manufacturer in a graduated cup and pour it into the
main wash compartment .
If you wish to carry out the prewash, pour detergent
into the appropriate compartment marked .
3. Measure out the additive
If required, pour fabric softener into the compartment
marked , without exceeding the «MAX» mark.
C0071
C0070
P0004

12
7. At the end of the programme
The machine stops automatically.
If you have selected the Rinse Hold button or the
Spin Suppress. one, the machine will stop with the
water left in the tub, to prevent the fabric from
creasing. To drain the water release the same
button. To drain and spin, select programme N (short
spin).
Depress the On-Off button again to switch the
machine off. The mains on light goes out.
Wait one or two minutes before opening the door to
give the electric locking mechanism time to release
it.
Remove the laundry.
Turn the drum by hand to make sure it is completely
empty, so as to avoid any forgotten items being
damaged in a subsequent wash (e.g. shrinking) or
their colour running into a load of whites.
Release any buttons which have been pressed.
Turn the water tap off and unplug the machine.
Leave the door ajar to air the machine.

ENGLISH
13
International wash code symbols
These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.
Energetic wash
Delicate wash
Max. wash
temperature
95°C
Max. wash
temperature
60°C
Max. wash
temperature
40°C
Max. wash
temperature
30°C
Hand wash Do not
wash
at all
Bleaching Bleach in cold water Do not bleach
Ironing Hot iron
max 200°C
Warm iron
max 150°C
Lukewarm iron
max 110°C
Do not iron
Dry cleaning Dry cleaning
in all solvents
Dry cleaning in
perchlorethylene,
petrol, pure alcohol,
R 111 & R 113
Dry cleaning
in petrol,
pure alcohol
and R 113
Do not
dry clean
Drying Flat On the line On clothes
hanger
Tumble dry
high
temperature
low
temperature
Do not
tumble dry
95
60
60
40
40
40
30
30

14
Programme table
The temperatures indicated are the optimum temperatures for each programme and depend on the type of
laundry and degree of soiling.
Important!
• Programme Bbegins with a short drain, then the programme selector dial advances automatically to the water
filling position.
• We suggest you not to switch the appliance off and on during its operation. This would modify the memorised
programme in progress with unsatisfactory washing results.
Washing programmes for cotton and linen
Programme
A
B
B
C
Color save
D
Quick Cycle
F
Rinses
G
Fast spin
60°-95°
60°-95°
30°-60°
30°-40°
30°-40°
COLD
Temp. Fabrics Additional
functions
Prewash at 40°C
Wash at 60°-95°C
4 rinses
Long spin
Wash at 60°-95°C
4 rinses
Long spin
Wash at 30°-60°C
4 rinses
Long spin
Wash at 30°-40°C
4 rinses
Long spin
Wash at 30°-40°C
4 rinses
Long spin
4 rinses with additive if
required
Long spin
Drain and long spin
Programme
description
WHITES WITH PREWASH, for
example work garments, sheets,
household linen, underwear, towels
WHITES WITHOUT PREWASH,
for example household linen,
sheets, shirts, underwear
COLOUREDS WITHOUT
PREWASH, for example shirts,
blouses, terry cloths, underwear
Cotton and linen with delicate
colours
This programme can be used for
lightly soiled items.
This programme can be used for
rinsing hand washed garments
Separate spin for cotton and linen
Spin Suppress.
Quick Half
Spin Suppress.
Quick Half
Spin Suppress.
Quick Half
Spin Suppress.
Quick Half
Spin Suppress.
Quick Half
Spin Suppress.
Quick Half

ENGLISH
15
Programme table
Washing programmes for synthetics, mixed fabrics, delicates and wool
Programme
SYNTHETICS WITH PREWASH, for
example underwear, coloured items,
shirts, blouses
SYNTHETICS WITHOUT PRE-
WASH, for example shirts, blouses,
mixed fabrics
DELICATES, for example curtains
WOOL
Special programme for garments
bearing the “Pure new wool, non-
shrink, machine washable” label
This programme can be used for
rinsing hand washed garments
Separate spin for synthetics,
delicates and wool
For emptying out the water of the last
rinse of the programmes with Rinse
Hold option.
H
J
K
L
Wool
M
Rinses
N
Short spin
P
Drain
30°-60°
30°-60°
-40°
-40°
COLD
COLD
Temp. Fabrics Additional
functions
Prewash at 40°C
Wash at 30°-60°C
3 rinses
Short spin
Wash at 30°-60°C
3 rinses
Short spin
Wash at -40°C
3 rinses
Short spin
Wash at -40°C
3 rinses
Short spin
3 rinses with additive if
required
Short spin
Drain and short spin
Water drainage
Programme description
Rinse Hold
Rinse Hold
Rinse Hold
Rinse Hold
Rinse Hold
The temperatures indicated are the optimum temperatures for each programme and depend on the type of
laundry and degree of soiling.
Important!
• Programme Jfor synthetics and Lfor wool begin with a short drain, then the programme selector dial
advances automatically to the water filling position.
• We suggest you not to switch the appliance off and on during its operation. This would modify the memorised
programme in progress with unsatisfactory washing results.

16
Maintenance
1. Bodywork
Clean the outside of the machine with soap and
water only. Rinse with clean water and dry with a soft
cloth.
Important: do not use methylated spirits, solvents or
similar products to clean the bodywork.
2. Door seal
Check from time to time the door seal and remove
any objects that are trapped in the rubber fold.
3. Detergent dispenser drawer
After a while, detergents and fabric softeners leave
deposits in the drawer.
Clean the drawer from time to time by rinsing it under
a running tap. To remove the drawer from the
machine, press the button in the rear left-hand
corner.
To facilitate cleaning, the top part of the additive
compartments can be removed.
C0073
C0072
P1050
Detergent can also accumulate inside the drawer
recess: clean it with an old toothbrush. Refit the
drawer after cleaning.
4. Drain pump
The pump should be inspected if
• the machine does not empty and/or spin
• the machine makes an unusual noise during
draining due to objects such as safety pins, coins
etc. blocking the pump.
Proceed as follows:
• Disconnect the appliance.
• If necessary wait until the water has cooled down.
• Open the pump door.
• Place a container close to the pump to collect any
spillage.
• Release the emergency emptying hose, place it in
the container and remove its cap.
• When no more water comes out, unscrew the drain
filter and remove. Always keep a rag nearby to dry
up spillage of water when removing the filter.
P1115
P1114
P0038

ENGLISH
17
6.Emergency emptying out
If the water is not discharged, proceed as follows to
empty out the machine:
• pull out the plug from the power socket;
• close the water tap;
• if necessary, wait until the water has cooled down;
• open the the pump door;
• place a bowl on the floor and place the end of the
emergency emptying hose into the bowl. Remove
its cap. The water should drain by gravity into the
bowl. Whe the bowl is full, put the cap back on the
hose. Empty the bowl. Repeat the procedure until
water stops flowing out;
• clean the pump if necessary as previously
described;
• replace the emergency emptying hose in its seat
after having plugged it;
• screw the pump again and close the door.
7.Frost precautions
If the machine is installed in a place where the
temperature could drop below 0°C, proceed as
follows:
• Remove the plug from the socket.
• Close the water tap and unscrew the water inlet
hose from the tap.
• Place the end of the emergency emptying hose
and that of the inlet hose in a bowl placed on the
floor and let water drain out.
• Screw the water inlet hose back on and reposition
the emergency emptying hose after having put the
cap on again.
By doing this, any water remaining in the machine is
removed, avoiding the formation of ice and,
consequently, breakage of the affected parts.
When you use the machine again, make sure that
the ambient temperature is above 0°C.
Important!
Every time you drain the water through the
emergency emptying hose you must pour 2 litres of
water into the main wash compartment of the
detergent drawer and then run the drain programme.
This will activate the ECO valve avoiding that part of
the detergent remains unused at next washing.
• Remove any objects from the pump impeller by
rotating it.
• Put the cap back on the emergency emptying hose
and place the latter back in its seat.
• Screw the pump fully in.
• Close the pump door.
5.Water inlet filter
If you notice that the machine is taking longer to fill,
check that the filter in the water inlet hose is not
blocked.
Turn off the water tap.
Unscrew the hose from the tap.
Clean the filter with a stiff brush.
Screw the hose back onto the tap.
P1090
P1117
132991220.qxd 29/09/2003 15:48 Pagina 17 (Nero/Process Black pellicola)

18
Something not working?
Problem Possible cause
• The machine does not start up: • The door is not firmly closed.
• The machine is not plugged in or there is no power
at the socket.
• The main fuse has blown.
• The programme selector dial is not positioned
correctly.
• The On-Off button has not been depressed.
• The machine does not fill: • The water tap is closed.
• The inlet hose is squashed or kinked.
• The filter in the inlet hose is blocked.
• The door is not properly closed.
• The machine fills then empties
immediately:
• The end of the drain hose is too low. Refer to
relevant paragraph in “water drainage” section.
• The machine does not empty
and/or does not spin:
• The drain hose is squashed or kinked.
• The Rinse Hold option has been selected.
• The Spin Suppress. option has been selected.
• The drain pump is clogged.
• There is water on the floor: • Too much detergent or unsuitable detergent
(creates too much foam) has been used.
• Check whether there are any leaks from one of the
inlet hose fittings. It is not always easy to see this
as the water runs down the hose; check to see if it
is damp.
• The drain hose is damaged.
• The cap on the emergency emptying hose has not
been replaced after cleaning the filter.
• Unsatisfactory washing results: • Too little detergent or unsuitable detergent has
been used.
• Stubborn stains have not been treated prior to
washing.
• The correct temperature was not selected.
• Excessive laundry load.
• The machine vibrates or is
noisy:
• The transit bolts and packing have not been
removed.
• The support feet have not been adjusted.
• The laundry is not evenly distributed in the drum.
• Maybe there is very little laundry in the drum.
• The door will not open: • The programme is still running.
• The door lock has not been released.
• There is water in the drum.
Problems which you can resolve yourself.

ENGLISH
19
If you are unable to identify or solve the problem,
contact our service centre. Before telephoning, make
a note of the model, serial number and purchase
date of your machine: the Service Centre will require
this information.
Mod. ..........
Prod. No. ...........
Ser. No. .........
Mod. ..........
Prod. No. ...........
Ser. No. .........
P0042 BD
P1035UK
Water is not
visible in the machine. The machine,
which is the result of modern technology, runs
in a very economical way with low water
consum tion. Performance is
nevertheless excellent.
Problem Possible cause
• Spinning starts late or the
laundry is not spun enough:
• The electronic unbalance detection device has cut
in because the laundry is not evenly distributed in
the drum. The laundry is redistributed by reverse
rotation of the drum. This may happen several
times before the unbalance disappears and normal
spinning can resume. If, after 20 minutes, the
laundry is still not evenly distributed in the drum,
the machine will not spin. If at the end of the
programme the laundry is not spun enough,
redistribute the load manually and select the spin
programme.
The machine makes an unusual
noise. The machine is fitted with a commutator
motor which im roves machine
erformance.
P1034UK

The Electrolux Group. The world’s No. 1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor
use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing
machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14
billion in more than 150 countries around the world.
