TSE-P 04.00 EB 1/50 599 34 22-16
SERVICE MANUAL
WASHING
ELECTROLUX ZANUSSI S.p.A.
Corso Lino Zanussi,30 Publication no.
I - 33080 PORCIA /PN (ITALY) 599 34 22-16
Tel [phone]
Fax [phone]
TSE-P
Edition: 04.2000
EN/SERVICE/EB
“NEAT”
WASHING MACHINES
WITH EWM2000
ELECTRONIC CONTROL
Production: Porcia/PN (IT)

TSE-P 04.00 EB 2/50 599 34 22-16
CONTENTS
GENERAL CHARACTERISTICS .............................................................. page 3/50
CONTROL PANEL .................................................................................... page 4/50
Operation of the buttons............................................................................. page 5/50
Display........................................................................................................ page 10/50
WASHING PROGRAMMES ...................................................................... page 12/50
Programme table legend............................................................................ page 12/50
60º cotton cycle (AC motor) ....................................................................... page 14/50
60º cotton cycle (DC motor) ....................................................................... page 15/50
60º synthetics cycle.................................................................................... page 16/50
40º handwash cycle.................................................................................... page 17/50
"FUCS" (Fast Unbalance Control System)................................................. page 18/50
Spin cycles ................................................................................................. page 20/50
STRUCTURAL CHARACTERISTICS ....................................................... page 23/50
Hydraulic circuit.......................................................................................... page 24/50
TECHNICAL CHARACTERISTICS........................................................... page 25/50
EWM2000 electronic control unit................................................................ page 25/50
Microprocessor memory............................................................................. page 26/50
Electronic pressure switch.......................................................................... page 27/50
Instantaneous door safety device............................................................... page 28/50
Detergent dispenser................................................................................... page 29/50
Power supply to motor................................................................................ page 31/50
AC/DC converter ........................................................................................ page 31/50
Recirculation pump..................................................................................... page 32/50
Heating....................................................................................................... page 32/50
Drain pump................................................................................................. page 32/50
DIAGNOSTIC AND CONFIGURATION SYSTEMS.................................. page 33/50
Access to the diagnostics and configuration systems................................ page 33/50
Diagnostics system .................................................................................... page 34/50
Display board diagnostics .......................................................................... page 35/50
Diagnostics cycle........................................................................................ page 36/50
Alarms ........................................................................................................ page 37/50
Reading the last alarm ............................................................................... page 38/50
Alarm codes................................................................................................ page 39/50
Cancelling the last alarm condition............................................................. page 43/50
Configuration of the main PCB................................................................... page 44/50
Configuration code ..................................................................................... page 45/50
Examples of configuration.......................................................................... page 46/50
Exiting the diagnostics/configuration system ............................................. page 47/50
BASIC CIRCUIT DIAGRAMS.................................................................... page 48/50

TSE-P 04.00 EB 3/50 599 34 22-16
GENERAL CHARACTERISTICS
Design: The cabinet is completely new, and is distinguished by the rounded front panel.
Inclined tub and bellows seal: The tub and the bellows seal are inclined at an angle of
approximately 20°. The capacity of the drum is 46 litres (G20).
Large porthole door: The porthole door is larger than that fitted to current models, and can be
opened to an angle of 180º.
The combination of an inclined tub and a larger porthole door makes introduction and removal of the
washing easier; in addition, the washing load is more visible to the user.
“INPUT” control panel: Simplifies programme selection.
EWM2000 electronic control unit: Provides excellent washing efficiency.
JETSYSTEM washing
Spin speeds up to 1.600 rpm

TSE-P 04.00 EB 4/50 599 34 22-16
CONTROL PANEL
The control panel fitted to the appliance may be different depending on:
Þthe control/display board (2 versions)
Þthe different design of the panel (on the number of buttons, LEDs)
Þthe different configuration of the buttons
1. “FABRICS” button
2. “TEMPERATURE” button
3. “SPIN” button
4. “OPTIONS” button
5. “OPTIONS” button
6. “OPTIONS” button
7. “START/PAUSE” button
8. “SKIP/RESET” button
9. “DELAYED START” button
10. Programme phase indicator LEDs
11. Display window
12. ON/OFF button
13. Pilot lamp

TSE-P 04.00 EB 5/50 599 34 22-16
1. “FABRICS” button
Press this button to select the washing programme suitable for the
fabrics to be washed.
The LED corresponding to the selected washing programme lights.
The machine proposes the standard programme for the type of fabric
selected; a temperature and the maximum spin speed for the selected
programme are displayed, as well as the normal soiling level.
However, these parameters can be modified by pressing the
corresponding buttons. The display will also show the duration of the
selected programme, which is calculated according to the maximum
load for each type of fabric, and the START/PAUSE LED begins to
flash.
The type of fabric can be modified at any time during the washing cycle; in this case, the phase currently
being performed will restart from the beginning.
The table below shows the options that the user can select for each model.
LED Type A Type B Type C
L1 Cotton Cotton Cotton
L2 Synthetics Synthetics Synthetics
L3 Delicate fabrics Delicate fabrics Delicate fabrics
L4 Wool Hand wash Wool
L5 Hand wash Mini ------
Hand wash
If this programme is selected (certain models only), the washing cycle will be especially delicate, and can be
used for fabrics labelled “Hand Wash”.
2. “TEMPERATURE” button
If a temperature different from the standard temperature proposed by
the appliance is desired, press this button repeatedly to increase of
decrease the temperature. The corresponding LED will light.
The maximum temperature is 90°C for cotton, 60°C for synthetics,
40°C for delicate fabrics, wool and hand washing.
The temperature button is effective only after the type of fabric has
been selected.
The temperature can be modified at any time during the washing cycle
(“START/PAUSE”); in this case, the phase will restart from the
beginning.
LED Type A Type B Type C
L6 90º C 90º C 90º C
L7 60º C 60º C 60º C
L8 40º C 50º C 50º C
L9 30º C 30º C 40º C
L10 Cold wash Cold wash 30º C

TSE-P 04.00 EB 6/50 599 34 22-16
3. “SPINNING” button
Press this button to reduce the speed of the intermediate and final
spin cycles as shown in the table below. This button is effective
only after the type of fabric has been selected; the spin speed can
be modified until the end of the rinses.
LED11 LED12 LED13 LED14 LED15
1600 900 700 500
1600 1200 900 700
1500 900 700 500
1500 1200 900 700
1400 900 700 500
1400 1200 900 700
1300 900 700 500
1300 1200 900 700
1200 900 700 500
1100 900 700 500
1000 900 700 500
900 700 600 500
NO SPIN
or
RINSE HOLD
In COTTON cycles, the spin cycle cannot be excluded.
In COTTON cycles, this option also modifies the structure of the rinsing phases according to the
speed of the intermediate spin:
Intermediate spin
(rpm) Traditional washing Jetsystem washing
1st rinse 2nd rinse Last rinse 1st rinse 2nd rinse Last rinse
<850 TR2 TR2 TR2 TR2 TR2 TR2
850-950 TR1 TR2 TR2 TE TR2 TR2
1000-1150 TR1 TR1 TR2 TE TE TR2
>1150 TR1 TR1 TR1 TE TE TE
TR2 Traditional rinse at second level
TR1 Traditional rinse at first level
TE "total exchange" (virtual tank) jetsystem rinse

TSE-P 04.00 EB 7/50 599 34 22-16
4,5,6“OPTIONS” buttons
The number and type of OPTIONS buttons vary according to the
model. All OPTIONS buttons are effective during the programme
selection phase, but only after the type of fabric has been selected.
After the “START/PAUSE” button has been pressed, the options can
generally be selected up until the start of the phase whose parameters
are to be modified.
“RINSE HOLD” button
The RINSE HOLD button is effective during the entire duration of the programme.
This function can be selected in COTTON, SYNTHETICS, DELICATE FABRICS and WOOL cycles; in
certain models, it is combined with the SPIN button.
When this option is selected, the appliance will not drain the tub at the end of the final rinse (in order to
prevent creasing the fabrics). At the end of the cycle, the LED corresponding to the START/PAUSE button
(and, where applicable, the phase indicator LED) will begin to flash to indicate to the user that the water in
the tub must be drained.
The following options can be selected to complete the programme:
Þdrain and spin: Press START/PAUSE. The appliance will drain the tub and then perform a spin cycle at
the maximum speed for the programme previously selected.
Þselect a spin speed using the SPIN button and then press START/PAUSE.
Þdrain only: Press SKIP/RESET once, until the DRAIN pilot lamp lights, then press START/PAUSE.
If the RINSE HOLD option is selected in a COTTON cycle, the water fill for the final rinse will take place at a
higher level.
“PRE-WASH” button
This option adds a pre-wash phase at the beginning of the cycle. The PRE-WASH option can be selected
only during the programme selection phase, and is not available in WOOL cycles.
The PRE-WASH option cannot be selected together with the STAINS or SOAK options.
“SOAK” button
This option can be selected in COTTON, SYNTHETICS and DELICATE FABRICS cycles (but only in the
programme selection phase), and adds a pre-wash at the beginning of the cycle.
30 minutes after the start of the cycle, the water is drained and the appliance passes to the subsequent
phase.
The DELAYED START button (if featured) can be used to select a SOAK time from 1 hour to 24 hours. The
delay time will be shown in hours in the display window during the selection phase; after the cycle has been
started, the delayed-start countdown will be shown in hours until it falls below 10 hours, after which the time
will be shown in hours and minutes. At the end of the SOAK phase, the water is drained from the tub and the
washing programme starts.
The SOAK option cannot be selected together with the STAINS and PRE-WASH options.
“STAINS” button
The STAINS option can be selected in COTTON, SYNTHETICS and DELICATE FABRICS cycles with
temperatures of 40°C or higher, and can also be selected during the washing phase.
This option adds the STAINS phase, in which special additives are introduced into the tub from the pre-wash
compartment after the BIO phase with heating to 40°C, and an additional 10 minutes of motor movement.
The STAINS option cannot be selected together with the PRE-WASH/SOAK, INTENSIVE and QUICK
/DAILY options.

TSE-P 04.00 EB 8/50 599 34 22-16
“INTENSIVE” / “HEAVY SOIL” button
This option can be selected during the entire duration of the washing programme, and is available only in
cycles for COTTON and SYNTHETICS.
This option increases the phases of drum movement after the heating phases.
The INTENSIVE / HEAVY SOIL option cannot be selected together with the STAINS, QUICK CYCLE and
ECONOMY options.
“QUICK CYCLE - LIGHT SOIL” / “DAILY” button
This option can be selected during the entire duration of the wash programme, and is available in cycles for
COTTON, SYNTHETICS and DELICATE FABRICS: it reduces the duration of the cycle.
When this option is selected in COTTON cycles, it modifies the rinse sequence as well as reducing the
times: one rinse is eliminated, and the water fill level in the remaining rinses is increased.
The QUICK CYCLE - LIGHT SOIL” / DAILY option cannot be selected together with the STAINS,
INTENSIVE and ECONOMY options.
“LEVEL OF SOILING” button
This option can be selected during the entire duration of the washing programme.
The standard programme is set for NORMAL soiling. By pressing this button, the level of soiling can be
modified:
ÞHEAVY (this option can be selected only in cycles for COTTON and SYNTHETICS).
LIGHT - QUICK CYCLE (this option can be selected only in cycles for COTTON, SYNTHETICS and
DELICATE FABRICS).
The functions of these options are as described for the corresponding individual buttons.
“ECONOMY” button
This option can also be selected during the washing cycle, and is available only in cycles for COTTON and
SYNTHETICS with temperatures of 40°C or higher.
The ECONOMY option reduces the temperature of the programme and increases the drum movement
phases after the heating phases.
The ECONOMY option cannot be selected together with the INTENSIVE/HEAVY AND LIGHT SOILING and
QUICK CYCLE / DAILY options.
"BIO" button
This option can be selected only after selecting the type of fabric, and can also be selected during the
washing phase. The BIO option can be selected only in cycles for COTTON and SYNTHETICS with
temperatures of 40°C or higher.
The BIO option adds a 10-minute phase of motor movement after heating to 40°C, and is designed to
activate the enzymes contained in the detergent.
“EXTRA RINSE” button
The EXTRA RINSE option can be selected at any time up to the end of the washing phase, and adds one
rinse phase in cycles for COTTON, SYNTHETICS and DELICATES.

TSE-P 04.00 EB 9/50 599 34 22-16
7. “START/PAUSE” button
START: After selecting the programme and the desired options, press the
START button to start the programme. The LED positioned above
the button will cease flashing and remain lit. If a delayed start time
has been selected, the countdown will commence; the countdown
will be shown on the display.
PAUSE: When the button is pressed again, the programme currently being
performed is interrupted. The LED above the button will start to
flash. When the cycle is paused, the door LED switches off and the
door can be opened on condition that:
- the machine is not performing a heating phase
- the water level is not high
- the drum is not in movement
When the appliance is paused, the programmes can be modified as follows:
→The structure can be changed or the programme cancelled (SKIP/RESET button). In this case,
the water (and detergent) will not be drained and the new cycle will begin with water in the tub.
If it is preferred to restart the new cycle without saving water and detergent, it is necessary first
to select a drain phase and then the new programme.
→The FABRICS and the TEMPERATURES can be modified only during the washing phase; in
this case, the cycle will be restarted from the beginning.
→The SPIN can be modified before the start of the final spin cycle.
→All the cycle OPTIONS can be modified before the commencement of the phase to be modified.
To re-start the programme, press the button again.
DRAIN and SPIN: after programmes with the RINSE HOLD option.
8. “SKIP/RESET” button
Thus button performs two functions:
Cancels the programme: Press the button until the cycle LEDs switch off. The display will show three
flashing hyphens.
Selects special programmes: In the programme selection and execution phases, this button can be used
to cancel certain phases of the programme so that the appliance effectively
performs a special cycle. In the programme execution phase, the appliance must
be paused.
The cycle normally performed by the appliance consists of the following phases:
Wash - Rinses - Spins
ÞWhen the button is pressed once: Rinses - Spins.
ÞWhen the button is pressed twice: Spin
ÞWhen the button is pressed three times: Drain.
ÞWhen the button is pressed four times: Cancel programme.
If the PRE-WASH option is selected, it can be cancelled by pressing this button, so that the appliance
performs the wash only.

TSE-P 04.00 EB 10/50 599 34 22-16
9. “DELAYED START” button
This button can be used to delay the start of the programme for up to 24
hours. The selected delay time is shown on the display for approximately 5
seconds, after which the duration of the programme is displayed.
The DELAYED START option must be selected after selecting the
programme and before pressing START/PAUSE.
The delay countdown is decremented at intervals of one hour, and is shown
on the display.
To modify or cancel the delayed-start time:
- press START/PAUSE to set the appliance to PAUSE.
- press the DELAYED START button until the display shows the new delay time or 0h.
- press START/PAUSE again.
The porthole door remains locked during the entire delayed-start period (the door pilot lamp lights).
If it is necessary to open the porthole door, set the appliance to PAUSE mode. After re-closing the door,
press START/PAUSE.
If the SOAK option has been selected, the delay time becomes the soak time.
10. Programme phase LEDs
When the programme has been selected, the LEDs corresponding to the various phases in the programme
light. When the programme starts, only the LED corresponding to the current phase remains lit.
LED Colour Models with
display Models without display
L26 Green -- Prewash
L27 Green Prewash Wash
L28 Green Wash Rinses
L29 Green Rinses Rinse Hold
L30 Green Spin Spin
L31 Green Drain Drain
L32 Orange -- Filter Clogged
L33 Green -- End
11. Display
The display shows the following information:
ÞThree flashing hyphens: when a programme is cancelled by
pressing the SKIP/RESET button. The hyphens will also be
displayed when the ON/OFF button is pressed to switch the
appliance on, but only if the cycle selected previously has been
cancelled.
ÞThe duration of the washing programme is displayed when the
programme has been selected. This time corresponds to the time
necessary for the maximum wash load.
When the programme is started (i.e. after pressing
START/PAUSE), the time is decremented at intervals of one
minute.

TSE-P 04.00 EB 11/50 599 34 22-16
ÞRinse hold: the appliance stops with water in the tub at the end of
programmes for which the RINSE HOLD option has been selected; the
display shows a zero (fixed, not flashing).
ÞEnd of cycle: indicated by a zero (flashing) and, at the same time,
the door pilot lamp switches off. The zero re-appears when the
appliance is switched on again, if the previous programme has not
been cancelled. It may occur, when the appliance is switched on for
the first time, that a flashing zero is shown on the display and the
acoustic signals are activated. This is due to the fact that the machine
has performed a washing cycle during testing in the factory which has
not been cancelled on completion.
ÞDelayed start, which is selected using the DELAYED START button.
The countdown starts when the START/PAUSE button is pressed,
and is decremented at intervals of one hour.
ÞAn incorrect option selection is signalled by Err on the display if the
function selected is not compatible with the programme. The buzzer
also sounds when an incorrect option is selected.
ÞAn alarm code indicates a machine malfunction.
12. ON/OFF button
Press the ON/OFF button to switch the appliance ON. The display shows three flashing hyphens or a
flashing zero. Press the same button to switch the appliance OFF.
The ON/OFF button is an individual pushbutton, and is not part of the display board.
EXCLUSION OF THE BUZZER AT THE END OF THE PROGRAMME
By pressing the "TEMPERATURE" and "SPIN"
buttons at the same time (or the temperature button
with button 4) it is possible to disactivate the buzzer
sound which indicates the end of the programme; by
repeating this operation the buzzer will be activated
again.
This function is always available and is memorized
until it is modified.

TSE-P 04.00 EB 12/50 599 34 22-16
WASHING PROGRAMMES (SEQUENCE CHARTS)
KEY TO PROGRAMMES
Description
Calibration Drain sub-phase for calibration of the electronic pressure switch
Levels
WC Level of water in the tub
RPC Control level for circulation pump
DPC Control level for drain pump
MC Control level for motor
Pumps
OFF Pump off
ON Pump on
LEV Pump on from one level of pressure switch
Water inlet valves
ELV2 Prewash
ELV3 Wash
ELV2 ELV3 Prewash + wash = softener
Refilling
NR Normal refilling
VT "Total exchange" refilling (virtual tank)
WL Electronic pressure switch
AB Safety pressure switch
Dis Level control disabled
En Level control enabled
Movement (motor)
OFF Motor stopped
ON Motor in operation
LEV Level movement Time
Tout Maximum time (timeout)
Motor movement
Code Pause (sec) Movement (sec) Speed (rpm)
D_MOV 12 4 55
E_MOV 31055
E1_MOV 41275
SE_MOV 4 24 55/40
N_MOV 8855
PWL1_MOV 40 1 35
PWL3_MOV 12 1 35
SPARE_MOV 31040
PWL4_MOV 57 1 35
COLD_MOV 41240
CR3_MOV Single-direction movement 80
DLD_MOV Single-direction movement 40

TSE-P 04.00 EB 13/50 599 34 22-16
SE Movement:
VT movement during rinses in "jetsystem total exchange" COTTON programmes (virtual tank):
During these phases, in which the motor rotates at high speed, if the electronic pressure switch detects that
the water in the tub falls below a certain level, the following operations are performed:
spin at 470 rpm (VT_MOV_CODE) to remove the water from the fabrics and therefore to increase the
level in the tub.
5 seconds pause, during which the level is again checked and, if necessary, the solenoid valve is
activated in order to load water until the level is correct.
energetic movement (E) (with the circulation pump in operation).
These operations may be repeated up to a maximum of three times for each rinse.
The parameters of the different programmes (levels, movements) vary according to the motor power supply
system of the different models:
AC motor
DC motor

TSE-P 04.00 EB 14/50 599 34 22-16
Cotton 60 JETSYSTEM - AC motor (G46l, intermediate spin 850 - 1000)
Levels (mm H20) Movement RefillingStep
n.° PHASE Description wc rpc dpc mc Rec. pump Drain pump Water inlet valves type code type wl ab Temp.
°C Time Time to end
1WASH CALIBRATION 35/15 35/15 35/15 35/15 OFF ON OFF Motor Stopped NR Dis Dis Tout 10' 0.00.20
2 WATER LOAD 50/15 OFF ELV2 En Tout 15' 0.01.40
3 MOVEMENT ON PWL3_MOV 1' 0.01.00
4 WATER LOAD 55/30 LEV ELV3 DLD_MOV Tout 15' 0.01.40
5 MOVEMENT 45/15 45/15 LEV COLD_MOV 4' 0.04.00
6 MOVEMENT OFF E_MOV 3' 0.03.00
7 HEATING 35/15 35/15 SPARE_MOV En 40 Tout 40' 0.06.40
8 HEAT+MOVEMENT OFF ON Dis Dis 56 2' 0.02.00
9 HEATING LEV En En 56 Tout 40' 0.07.00
10 MOVEMENT ON ON Dis Dis 2' 0.02.00
11 HEAT+MOVEMENT OFF 56 2' 0.02.00
12 HEATING LEV En En 56 Tout 40' 0.03.00
13 MOVEMENT ON ON SE_MOV Dis Dis 18' 0.18.00
14 MOVEMENT N_MOV 4' 0.04.00
15 MOVEMENT SE_MOV 18' 0.18.00
16 MOVEMENT OFF OFF Motor Stopped 22'' 0.00.20
17 WATER DRAIN Lev ON D_MOV Tout 10' 0.00.20
18 SPINNING ON IMP6 Tout 20' 0.09.00
19 1st RINSE MOVEMENT OFF ON CR3_MOV 5'' 0.00.10
20 WATER LOAD 75/20 LEV En Tout 15' 0.01.40
21 MOVEMENT 35/25 ON E_MOV VT 4' 0.05.30
22 MOVEMENT E1_MOV NR Dis 2' 0.02.00
23 WATER DRAIN OFF Lev D_MOV Tout 10' 0.00.20
24 SPINNING ON IMP6_RINSE Tout 20' 0.05.00
25 2nd RINSE MOVEMENT 35/15 OFF ON CR3_MOV 5'' 0.00.10
26 WATER LOAD 75/20 LEV En Tout 15' 0.01.40
27 MOVEMENT 35/25 ON E_MOV VT 4' 0.05.30
28 MOVEMENT E1_MOV NR Dis 2' 0.02.00
29 WATER DRAIN OFF Lev D_MOV Tout 10' 0.00.20
30 SPINNING ON IMP6_RINSE Tout 20' 0.05.00
31 3rd RINSE MOVEMENT 35/15 OFF ON CR3_MOV 5'' 0.00.10
32 (softener) WATER LOAD 100/80 LEV ELV2 ELV3 N_MOV En Tout 15' 0.01.40
33 MOVEMENT 100/80 6' 0.06.00
34 MOVEMENT OFF OFF Motor Stopped Dis 22'' 0.00.20
35 SPINNING WATER DRAIN 35/15 35/15 Lev ON D_MOV Tout 10' 0.00.20
36 SPINNING ON IMPCF_01_AC Tout 20' 0.07.00
37 MOVEMENT OFF N_MOV 2' 0.02.00

TSE-P 04.00 EB 15/50 599 34 22-16
Cotton 60 JETSYSTEM - DC motor (G46l - intermediate spin 850 1000)
Levels (mm H20) Movement RefillingStep
n.° PHASE Description wc rpc dpc mc Rec. pump Drain pump Water inlet valves type code type wl ab Temp.
°C Time Time to end
1WASH CALIBRATION 15/5 15/5 15/5 15/5 OFF ON OFF Motor Stopped NR Dis Dis Tout 10' 0.00.20
2 WATER LOAD 45/15 OFF ELV2 En Tout 15' 0.01.40
3 MOVEMENT ON PWL3_MOV 1' 0.01.00
4 WATER LOAD 55/30 LEV ELV3 DLD_MOV Tout 15' 0.01.40
5 MOVEMENT 45/15 45/15 LEV COLD_MOV 4' 0.04.00
6 MOVEMENT OFF E_MOV 3' 0.03.00
7 HEATING 15/5 15/5 SPARE_MOV En 40 Tout 40' 0.05.50
8 HEAT+MOV OFF ON Dis Dis 58 2' 0.02.00
9 HEATING LEV En En 58 Tout 40' 0.06.20
10 MOVEMENT ON ON Dis Dis 2' 0.02.00
11 HEAT+MOV OFF 58 2' 0.02.00
12 HEATING LEV En En 58 Tout 40' 0.02.20
13 MOVEMENT ON SE_MOV Dis Dis 12' 0.12.00
14 MOVEMENT N_MOV 4' 0.04.00
15 MOVEMENT SE_MOV 14' 0.14.00
16 MOVEMENT OFF OFF Motor Stopped 22'' 0.00.20
17 WATER DRAIN Lev ON D_MOV Tout 10' 0.00.20
18 SPINNING ON IMP6 Tout 20' 0.09.00
19 1st RINSE MOVEMENT OFF ON CR3_MOV 5'' 0.00.10
20 WATER LOAD 75/20 LEV En Tout 15' 0.01.40
21 MOVEMENT 25/15 ON E_MOV VT 5' 0.06.30
22 MOVEMENT E1_MOV NR Dis 3' 0.03.00
23 WATER DRAIN OFF Lev D_MOV Tout 10' 0.00.20
24 SPINNING ON IMP6_RINSE Tout 20' 0.05.00
25 2nd RINSE MOVEMENT 15/5 OFF ON CR3_MOV 5'' 0.00.10
26 WATER LOAD 75/20 LEV En Tout 15' 0.01.40
27 MOVEMENT 25/15 ON E_MOV VT 5' 0.06.30
28 MOVEMENT E1_MOV NR Dis 3' 0.03.00
29 WATER DRAIN OFF Lev D_MOV Tout 10' 0.00.20
30 SPINNING ON IMP6_RINSE Tout 20' 0.05.00
31 3rd RINSE MOVEMENT 15/5 OFF ON CR3_MOV 5'' 0.00.10
32 (softener) WATER LOAD 95/20 ELV2 ELV3 N_MOV En Tout 15' 0.01.40
33 MOVEMENT 95/20 11' 0.11.00
34 MOVEMENT OFF OFF Motor Stopped Dis 22'' 0.00.20
35 SPINNING WATER DRAIN Lev ON D_MOV Tout 10' 0.00.20
36 SPINNING 15/5 15/5 ON IMPCF_01_DC Tout 20' 0.09.00
37 MOVEMENT OFF N_MOV 2' 0.02.00

TSE-P 04.00 EB 16/50 599 34 22-16
Synthetics 60 JETSYSTEM (G46l)
Levels (mm H20) Movement RefillingStep
n.° PHASE Description wc rpc dpc mc Rec. pump Drain pump Water inlet valves type code type wl ab Temp.
°C Time Time to end
1WASH CALIBRATION 35/15 * 35/15 * 35/15* 35/15* OFF ON OFF Motor Stopped NR Dis Dis Tout 10' 0.00.00
2 WATER LOAD 50/15 ** OFF ELV2 En Tout 15' 0.01.40
3 MOVEMENT ON PWL3_MOV 1' 0.01.00
4 WATER LOAD 100/65 LEV ELV3 OFF Motor Stopped Tout 15' 0.01.40
5 MOVEMENT LEV N_MOV 7' 0.07.00
6 HEATING 100/65 ON E_MOV En 39 Tout 40' 0.10.50
7 MOVEMENT LEV 8' 0.08.00
8 HEATING ON 55 Tout 40' 0.09.40
9 MOVEMENT LEV 8' 0.08.00
10 HEATING ON 55 Tout 40' 0.00.00
11 MOVEMENT LEV 8' 0.08.00
12 WATER LOAD 175/90 ON N_MOV Dis Tout 1' 0.01.00
13 MOVEMENT Dis 2' 0.02.00
14 MOVEMENT OFF OFF Motor Stopped 22'' 0.00.20
15 WATER DRAIN Lev ON E_MOV Tout 10' 0.00.20
16 TIME WATER DRAIN ON 2' 0.02.00
17 1st RINSE MOVEMENT 35/15 * 35/15 * OFF OFF Motor Stopped 5'' 0.00.10
18 WATER LOAD 175/90 LEV En Tout 15' 0.01.40
19 MOVEMENT ON N_MOV 2' 0.02.00
20 WATER DRAIN OFF Lev E_MOV Dis Tout 10' 0.00.20
21 TIME WATER DRAIN ON 2' 0.02.00
22 2nd RINSE MOVEMENT 35/15 OFF OFF Motor Stopped 5'' 0.00.10
23 WATER LOAD 175/90 LEV En Tout 15' 0.01.40
24 MOVEMENT LEV ON N_MOV 2' 0.02.00
25 WATER DRAIN OFF Lev E_MOV Dis Tout 10' 0.00.20
26 SPINNING ON IMP_C0 Tout 20' 0.03.00
27 3rd RINSE MOVEMENT 35/15 * OFF OFF Motor Stopped 5'' 0.00.10
28 (softener) WATER LOAD 175/90 LEV ELV2 ELV3 En Tout 15' 0.01.40
29 MOVEMENT ON N_MOV 5' 0.05.00
30 MOVEMENT OFF OFF Motor Stopped Dis 22'' 0.00.20
31 SPINNING WATER DRAIN 35/15 * Lev ON D_MOV Tout 10' 0.00.20
32 SPINNING ON IMP5 Tout 20' 0.02.00
*DC motor: 15/5
** DC motor: 45/15

TSE-P 04.00 EB 17/50 599 34 22-16
Handwash 40 JETSYSTEM (G46l)
Levels (mm H20) Movement RefillingStep
n.° PHASE Description Wc rpc dpc mc Rec. pump Drain pump Water inlet valves type code type wl ab Temp.
°C Time Time to end
1WASH CALIBRATION 35/15 * 35/15* 35/15* 35/15* OFF ON OFF Motor Stopped NR Dis Dis Tout 10' 0.00.00
2 WATER LOAD 50/15 ** OFF ELV2 En Tout 15' 0.01.10
3 MOVEMENT ON PWL3_MOV 1' 0.01.00
4 WATER LOAD 115/50 LEV ELV3 OFF Motor Stopped Tout 15' 0.01.10
5 MOVEMENT LEV PWL1_MOV 4' 0.04.00
6 HEATING ON En 29 Tout 40' 0.08.00
7 MOVEMENT LEV 2' 0.02.00
8 HEAT+MOV 37 14' 0.14.00
9 MOVEMENT OFF OFF Motor Stopped Dis Dis 22'' 0.00.20
10 WATER DRAIN Lev Tout 10' 0.00.20
11 TIME WATER DRAIN ON 1' 0.01.30
12 1st RINSE MOVEMENT 35/15 * OFF OFF Motor Stopped 5'' 0.00.10
13 WATER LOAD 175/90 LEV En Tout 15' 0.01.10
14 MOVEMENT ON PWL3_MOV 3' 0.03.00
15 WATER DRAIN OFF Lev OFF Motor Stopped Dis Tout 10' 0.00.20
16 TIME WATER DRAIN ON 1' 0.01.30
17 2nd RINSE MOVEMENT 35/15 * OFF OFF Motor Stopped 5'' 0.00.10
18 WATER LOAD 175/90 LEV En Tout 15' 0.01.10
19 MOVEMENT ON PWL1_MOV 3' 0.03.00
20 WATER DRAIN OFF Lev OFF Motor Stopped Dis Tout 10' 0.00.20
21 TIME WATER DRAIN ON 1' 0.01.30
22 3rd RINSE MOVEMENT 35/15 * OFF OFF Motor Stopped 5'' 0.00.10
23 (softener) WATER LOAD 175/90 LEV ELV2 ELV3 En Tout 15' 0.01.10
24 MOVEMENT ON PWL1_MOV 5' 0.05.00
25 MOVEMENT OFF OFF Motor Stopped Dis 22'' 0.00.20
26 SPINNING WATER DRAIN 35/15 * Lev OFF Motor Stopped Tout 10' 0.00.20
27 SPINNING ON ON IMP4 Tout 20' 0.01.00
*DC motor: 15/5
** DC motor: 45/15

TSE-P 04.00 EB 18/50 599 34 22-16
“FUCS” (Fast Unbalance Control System)
The control procedure for unbalanced loads is performed dynamically, before each spin cycle, as follows:
The phase begins at a speed of 55 rpm; the speed can never fall below this threshold, otherwise the
check is repeated.
At intervals of 400 ms, the balance is calculated and compared with predetermined limits. If the value is
less than the lower limit, the speed of the drum is increased by 2 rpm; if the value is higher, the speed of
the drum is reduced by 2 rpm. The reduction in the speed of the drum distributes the washing correctly;
this procedure is repeated until the wash load is completely balanced.
Correct balancing of the wash load is achieved at a speed of 115 rpm, after which the spin cycle begins.
The Unbalancing Control function takes place in three steps:
Step 1: The first phase has a preset unbalancing threshold: if correct balancing is achieved, the appliance
performs the spin cycle. If not, after a maximum of 60 seconds, a spin pulse at 470 rpm is
performed and the function passes to step 2.
Step 2: In the second phase, the unbalancing threshold is variable: if correct balancing is not achieved
within 180 seconds, the function passes to step 3.
Step 3: The third phase has a preset unbalancing threshold: if correct balancing is not achieved within 60
seconds, the spin cycle is performed at a lower speed. In this case, spinning may also start at 85
rpm.
If the unbalancing value remains excessive, the spin cycle is skipped.
Anti-foam control function
If the pressure switch detects an anti-foam level (i.e. excessive foam) at the beginning of the spin cycle, the
spin is interrupted and the appliance resumes operation from the second phase of the unbalancing control
procedure.
EXAMPLES OF OPERATION OF THE UNBALANCING CONTROL FUNCTION:
Load correctly balanced
A: low speed
B: FUCS phase 1
C: normal spin

TSE-P 04.00 EB 19/50 599 34 22-16
Load balanced after few attempts:
A: low speed
B: FUCS phase 1
C: normal spin
Load balanced after second phase:
A: low speed
B: FUCS phase 1 with pulse at 470 rpm
C: low speed
D: FUCS phase 2
E: normal spin
Load balanced after second phase and anti-foam
control function:
A: low speed
B: FUCS phase 1 with pulse at 470 rpm
C: low speed
D: FUCS phase 2
E: spin with anti-foam function
F: low speed
G: FUCS phase 3
H: normal spin
Load slightly unbalanced after third phase:
A: low speed
B: FUCS phase 1 with pulse at 470 rpm
C: low speed
D: FUCS phase 2
E: FUCS phase 3
F: reduced-speed spin
Load unbalanced after third phase:
A: low speed
B: FUCS phase 1 with pulse at 470 rpm
C: low speed
D: FUCS phase 2
E: FUCS phase 3
F: the spin phase is skipped and the appliance
passes to the subsequent phase

TSE-P 04.00 EB 20/50 599 34 22-16
SPIN CYCLES
IMP_C0 spin: pre-wash - COTTONS and SYNTHETICS, penultimate rinse - SYNTHETICS
IMP5 spin: final - SYNTHETICS
IMP7 spin: final - DELICATE FABRICS
