Electrolux PW9 User manual

438 9065-31/EN
2010.06.02
Operating manual
Washer extractors
PW9
Type W3...
Operating manual in original language

3
Contents
Contents
Safety Precautions....................................................................................... 5
General......................................................................................................... 7
Program buttons...................................................................................... 7
Option buttons......................................................................................... 8
Start-button ............................................................................................. 8
Detergent container................................................................................. 8
Display information.................................................................................. 9
Error code.............................................................................................. 10
Wash program ....................................................................................... 11
Program 4G01 ....................................................................................... 11
Wash program description .................................................................... 12
Error codes................................................................................................. 15
Coin meter.................................................................................................. 17
Price programming................................................................................ 17
Maintenance............................................................................................... 19
The manufacturer reserves the right to make changes in design
and materials specifications.

5
Safety Precautions
All external equipment which is connected to the machine must be CE/EMC-approved
and connected using an approved shielded cable.
Safety Precautions
The machine is only intended for water-wash use.
Do not allow minors to use the machine.
Do not hose down the machine with water.
The machine's door lock must under no circumstances be bypassed.
If the machine develops a fault, this must be reported to the person in charge as soon
as possible. This is important both for your safety and that of others.
The machine is not intended to be used by people (including minors) with reduced
physical or mental capacity or lack of experience and knowledge. Such people must
be instructed in the use of the machine by a person who has responsibility for their
safety. Minors must be supervised to ensure that they do not play with the machine.
In order to prevent damage to the electronics (and other parts) that may occur as the
result of condensation, the machine should be placed in room temperature for 24 hours
before being used for the first time.

7
1
6293
6294
6295
6296
6297
6298
2
3
4
5
6
1
2
3
4
5
6
General
General
Program buttons
90°C White.
60°C Colour.
40°C Colour.
60°C Synthetics.
40°C Synthetics.
30°C Delicate.

8
6300
6299
7
8
9
1
2
3
4
10
6229
6433
Option buttons
"Light soiled"
Reduce the temperature and program time.
"Pre-wash"
Adds a pre-wash and one rinse, longer wash
time. Can be used together with program 1-5
(see page 3).
Start-button
• START:
Press button to start a program.
• RAPID ADVANCE:
To get Rapid Advance function, keep the
button pressed as long as requested.
Detergent container
Compartment 1 – Pre-wash, powder or liquid
detergent
Compartment 2 – Main wash, powder detergent
Compartment 3 – Liquid softener
Compartment 4 – Main wash, liquid detergent
and bleach agent (liquid)
General
7
8
9
10

9
11
3141
13
12
2253
3141
General
Display information
• The clock symbol and two figures are now lit
in the display. The two figures show the time
remaining until the end of the wash.
The two time figures are not displayed im-
mediately after installation. The relevant
program has to have been used at least once
before the remaining time is displayed.
• Immediately after starting, the colon “:” flas-
hes in the display. This means that as long as
it is flashing, a new program can be selected
(without losing anything). You still have the
opportunity to change your mind if you have
chosen the wrong program.
• Press PAUSE/START.
• Select new program
• If the new program is more expensive than
the one you have paid for, the difference ap-
pears in the display. Insert more coins until 00
appears in the display (coin meter machines
only).
• Press START again once the new program
has been selected.
• The temperature now appears in the display.
For coin meter machines, the price for the se-
lected program is displayed. Insert coins/tokens
corresponding to the displayed value.
11
12
13

10
14
2243 A
Error code
Error code can be shown in the display. For
further information, see separate chapter.
14
General

11
1
6291
Wash program
Wash program
Program 4G01
The wash programs are designed for cotton and synthetic textiles. You can
wash normal household textiles and also textiles from hotels, restaurants
and many other professional businesses.
• Press the button for the program required.
• Press the button for option "Pre-wash" or "Light soiled".
• Add correct amount of detergent(s) and fabric softener as indicated in
program table.
• If coin operated, insert correct amount of coins/tokens.
• Press START-button.
1

12
Pre-wash Main wash Rinses Final Detergent
extraction compartment No.
– 80°C 3 6 min 3 and 2 or 4
– 75°C 3 4 min 3 and 2 or 4
30°C 85°C 4 6 min 1, 3 and 2 or 4
– 55°C 3 6 min 3 and 2 or 4
– 55°C 3 4 min 3 and 2 or 4
30°C 60°C 4 6 min 1, 3 and 2 or 4
– 40°C 3 6 min 3 and 2 or 4
– 40°C 3 4 min 3 and 2 or 4
30°C 40°C 4 6 min 1, 3 and 2 or 4
– 55°C 3 2 min 3 and 2 or 4
– 55°C 3 2 min 3 and 2 or 4
30°C 60°C 3 2 min 1, 3 and 2 or 4
Wash program description
4G01
Wash program

13
Pre-wash Main wash Rinses Final Detergent
extraction compartment No.
– 40°C 3 2 min 3 and 2 or 4
– 40°C 3 2 min 3 and 2 or 4
30°C 40°C 3 2 min 1, 3 and 2 or 4
– 30°C 3 1.5 min 3 and 2 or 4
– 30°C 2 1.5 min 3 and 2 or 4
Wash program description
4G01
Wash program

15
2243 A
1
Error code Cause/Action
01E Acknowledgement signal for water level not received within time
allowed.
02E Door status acknowledgement signal not received during program
operation.
03E Door lock acknowledgement signal not received within time
allowed.
07E Water level above parameter set for safety, during program.
10E Water level is above parameter set (10 scale units) after water
discharge.
For other error messages or repeated messages, contact service.
Error codes
If the power supply to the machine should be
cut while it is working, the programmer has a
memory which stores the program at least one
minute.
The machine will restart automatically once the
power supply is restored.
When error code occur a new start attempt can
be made directly by activate the START-button.
Resetting the wash program and error code, in
order to choose a new wash program, can be
done by pressing the START-button min.
10 seconds.
Error codes
1

17
1
5750
2
2273
3
6292
Coin meter
Coin meter
Price programming
• Press the relevant program selection button.
When programming washing programs with
options, press the relevant program selection
button + option button.
• Keep the price programming button activated.
(The button is located in the space for the
coin box.)
00 now appears in the display and the ‘coin’
is lit.
• Enter the price using the numerical button
functions (max. 3 figures).
• Release the price programming button.
This procedure is then repeated for all programs.
2
1
3

19
Maintenance
Maintenance
Daily
• Cleanthedoorsealfromdetergentresidue.
• Makesurethedoorisnotleaking.
• Cleanthedetergentsupplyboxandwipeoffthemachinewithadamp
rag.
• Makesurethedrainvalveisnotleaking.
• Startthemachineandmakesurethedoorislockedduringtheprogram.
Rapidadvancetheprogramtostopandmakesurethedoorcannotbe
openeduntilaftertheprogramiscomplete.
Every month
• Checkthatvalves,hosesandconnectionsarenotleaking.
• Removeanylintfromthedrainconnection,jointsinthedrainpipe,etc.
Every third month
Whenchemicalshavecollectedontheedgesofthepanels:
• Turnoffpowertomachine.
• Turnoffthewatersupplyandreleasethepressurefromtheinlethoses.
• Removethewaterinlethosesfromthebackofthemachineandclean
orchangetheinletlter.
• Cleanthedetergentsupplyboxthoroughly.
• Takeoffthetopandfrontmachinepanels.
• Washawaydetergentandotherchemicalsfromthepanelstostopthem
rusting.
• Makesuretherearenoleaksinsidethemachine.Repairasnecessary.
• Cleanthesealaroundthedoor.
• Retthetopandfrontpanels.
• Deliming.Useaprogramwithhightemperatureandaddadeliming
agent,e.g.citricacid.
