Electrolux W4240H User manual

PROFESSIONAL LAUNDRY
W4240H W4300H
27/60 33/75
240/8.5 300/10.6
795 / 31 5/16 795 / 31 5/16
890 820
350 300
19.4 19.4
x x
x x
36 38
293+13 / 77.4+3.4 388+19 / 102.5+5
0.5 0.45
Clarus Control
Compass Control
Washer extractors
W4240H, W4300H
Features and benefits
• High extraction force for efficient dewatering
• Available with two types of program controls:
Compass Control with:
– Large display and one dial for easy program selection
– Language selection
– Two Quick Start buttons for frequently used wash programs
– Wash program packages optimized on Economy,
Performance and Time
Clarus Control with:
– Fully programmable microprocessor
– All relevant wash parameters can be programmed
– Programming from key pad or downloading via memory card
• AWS – Automatic Weighing System:
– The machine weighs the linen and adjusts the amount of water
and energy according to the load. This leads to considerable
savings in case the machine is not fully loaded
• Extremely low water and energy consumption – see table below
• Four compartment soap box for manual dosing of powder or liquid
detergent
• Stainless steel front panel and grey side panels
• Large door opening for easy loading/unloading
• Low noise level, for pleasant working environment
• SuperBalanceTM guarantees the correct extraction force
Main options
• Automatic liquid detergent supply
(optional I/O board for Compass Control)
• IS – Integrated Saving – actual load will be shown in the display
(Clarus Control only)
• Stainless steel side panel (Clarus Control only)
• Connection to payment system or coin meter
(Compass Control only)
Certified in accordance with ISO 9001 and ISO 14001 and approved IP 24D. Certified in accordance with UL/ETL standards.
Main specifications
Max. capacity kg/lb
Drum, volume litre/ft3
diameter ø mm/inch
Extraction rpm
G-factor
Heating alternatives, electricity kW
steam
non-heated
Consumption data ”WARM” * (3S03)
Total time min
Water consumption (cold+hot) litre/gallon
Energy consumption (motor) kWh
* Water temperature 59°F cold water and 149°F hot water.
®
®

G
F
L
N
K
O
P
M
I
H
3
2
1
4
5
6
5378
D
A
C
8
9
7
5377
5379
B
E
5
Share more of our thinking at www.electrolux.com
W4240H W4300H
20.9(63) 19.4(63)
3.0(15) 2.1(15)
3.0(15) 2.1(15)
3/4 3/4
30-90 30-90
60/15 60/15
75/3 75/3
170/45 170/45
1/2 1/2
7-40 7-40
5 5
14.8 13.7
5.2 ± 1.0 6.2 ± 1.3
1158 ± 221 1390 ± 280
78 76
67 69
85 83
5 5
400/882 556/1226
448/988 575/1268
1.79/63.2 2.1/74.2
x x
x x
x x
x x
1020 / 40 3/16 1020 / 40 3/16
915 / 36 1060 / 41 3/4
1445 / 56 7/8 1445 / 56 7/8
500 / 19 11/16 500 / 19 11/16
955 / 37 5/8 1135 / 44 11/16
1155 / 45 1/2 1155 / 45 1/2
100 / 3 15/16 100 / 3 15/16
1360 / 53 9/16 1360 / 53 9/16
215 / 8 7/16 215 / 8 7/16
1320 / 51 15/16 1320 / 51 15/16
300 / 11 13/16 300 / 11 13/16
380 / 14 15/16 380 / 14 15/16
100 / 3 5/6 100 / 3 5/6
360 / 14 3/16 360 / 14 3/16
510 / 20 1/16 335 / 13 3/16
www.electroluxusa.com/laundrysystems
Front
Right side
Rear side
Art. No. 438901958/2012.04.26 We reserve the right to alter specifications without notice.
Electrical connections*
Heating Voltage
El. 208-240V 3AC 60 Hz kW(A)
Steam 208-240V 1AC 60 Hz kW(A)
or 100-120V 1AC 60 Hz kW(A)
non-heated
Water and steam connection
Water valves inch
Water pressure psi
Capacity at 45 psi l/min / gallon/min
Drain valve ø mm/inch
Draining capacity l/min / gallon/min
Steam valve inch
Steam pressure psi
Liquid detergent supplies
Floor requirements
Frequency of the dynamic force Hz
Floor load at max extraction kN
lbs force
Sound levels
Sound pressure level** dB(A)
Sound power level (IEC 60704-2-4)
wash dB(A)
extraction dB(A)
Heat emission
% of installed power, max
Shipping data
Weight net, kg/lbs
crated, kg/lbs
Shipping volume m3/ft3
Accessories
Steel base frame
Water re-use tank (Clarus Control)
Hose kits for water or steam
Fluff collector
Dimensions in mm/inch
A Width
B Depth
C Height
D
E
F
G
H
I
K
L
M
N
O
P
1 Electrical connections
2 Cold water
3 Hot water
4 Steam connection
5 Drain
6 Liquid supply connections
7 Control panel
8 Soap box
9 Door opening ø 435 mm / 17 1/8 inch
* Other voltages available, see installation manual.
** Approx. value at operators position in a mid-size laundry room.
