Eliet GZC 750 User manual

GZC 750
GZC 1000
MANUAL

2
English
You will find information about the actual use and maintenance of the machine.
Read it carefully and keep it in a safe place.
Please also keep your purchasing invoice or the proof of receipt together with
this booklet.
Register your purchase online at www.eliet.eu
© ELIET
Copyright 2009 ELIET. All right reserved. All textual material, drawings, figures, diagrams, graphs, etc., included in this ELIET
booklet are protected by copyright and also by other intellectual property rights. Nothing from this information may be copied
for commercial goals or distributed and/or changed or reposted for other goals. Content has been included at specifiec places in
this ELIET manual of which the copyright is the exclusive property of their respective owners.

3
English
1. Introduction
1.1 Read this operating manual carefully
ELIET machines are designed for safe and reliable use if they are operated in accordance with
the instructions provided. Carefully read these operating instructions before using the machine.
Failure to do so may result in personal injury or damage to the equipment.
1.2 Identification data – ELIET SEEDER GZC750 - 1000
Write the identification data of your machine in the text boxes::
Engine :
Stock no :
Serial no :
Year of manufacture :
2. Warranty
2.1 Warranty card
In order to avail of the warranty, please fill out the warranty card
and send it to the address below within one month after purchase:
European customers : ELIET EUROPE NV/SA US customers : ELIET USA Inc.
Diesveldstraat 2 3361 Stafford street (office B) - USA
8553 Otegem - Belgium 15204 Pittsburgh (PA) - USA
T([phone] - F([phone] T412 367 5185 - F412 774 1970
www.eliet.eu www.elietusa.com
Read the warranty conditions on the attached warranty card.
Also register your product online on www.eliet.eu.

4
English
3. Welcome
Welcome to the family of ELIET users.
We thank you for the trust that you have placed in ELIET and we are convinced that you have
purchased the very best machine. The operating life of your ELIET machine depends on how you
care for your machine. This manual and the motor manual included will help you on your way.
Strict adherence to the instructions and suggestions in these manuals will guarantee optimum
performance of your ELIET machine for a very long time.
Read this manual carefully before operating the machine. This will prevent incorrect operation of
the machine.
For your own safety, please observe the safety instructions specified in the relevant chapter. Even
if you are thoroughly familiar with operating such equipment, it is still advisable to read these
pages carefully.
All ELIET equipment and machines are continually being updated and improved and therefore
the specification of your machine may differ slightly in terms of shape, technology and acces-
sories. The descriptions and technical data in this manual are accurate at the time of printing.
Certain illustrations and descriptions may not be applicable to your specific machine, but instead
relate to a different version of the machine. For this reason, discrepancies or deviations in the
texts and illustrations in this manual cannot give rise to any claims, as you may well understand.
Should you have any questions not fully addressed in this manual, please contact your ELIET
dealer.
ELIET AT YOUR SERVICE
ELIET EUROPE NV/SA ELIET USA
GMT + 1 : GMT - 6
opening hours: 8 to 12 and from 13 to 18 opening hours: 8 AM to 6 PM
T (+32) (0)56 77 70 88 - F (+32) (0)56 77 52 13 T 412 367 5185 - F 412 774 1970
[e-mail] [e-mail]
www.eliet.eu www.elietmachines.com

5
English
4. Table of contents
1. Introduction............................................................................................................................3
1.1 Read this operating manual carefully.............................................................................................3
1.2 Identification data – ELIET SEEDER GZC750 - 1000......................................... 3
2. Warranty ................................................................................................................................3
2.1 Warranty card ......................................................................................................................................3
3. Welcome .................................................................................................................................4
4. Table of contents...................................................................................................................5
5. Safety symbols......................................................................................................................7
5.1 For your information..........................................................................................................................7
5.2 Caution.................................................................................................................................................7
5.3 Warning................................................................................................................................................7
6. Most important parts ...........................................................................................................8
6.1 Overall view..........................................................................................................................................8
6.2 Steering ...............................................................................................................................................10
6.3 Engines ................................................................................................................................................10
7. Safety instructions ...............................................................................................................12
7.1 Safety messages:.................................................................................................................................12
7.2 Safety features ..................................................................................................................................14
7.3 Safety instructions ............................................................................................................................15
7.3.1 General safety instructions......................................................................................................15
7.3.2 Careful and proper use............................................................................................................15
7.3.3 Operator’s responsibilities......................................................................................................17
7.3.4 Personal Protective Equipment (PPE) .................................................................................18
7.3.5 Ergonomics.................................................................................................................................18
7.3.6 Danger zone...............................................................................................................................19
7.3.7 Periodic maintenance...............................................................................................................20
7.3.8 Limits of the machine..............................................................................................................20
7.3.9 In harmony with nature...........................................................................................................21
8. Dealer’s duties .....................................................................................................................22
9. Operating instructions ........................................................................................................24
9.1 Preliminary checks ............................................................................................................................24
9.2 Characteristics of the work area....................................................................................................24
9.3 Preparation of the work area .........................................................................................................25
9.4 Preparation of the machine ...........................................................................................................27
9.4.1 Setting the machine..................................................................................................................27
9.4.2 Refuelling ...................................................................................................................................32
9.5 Starting the petrol engine...............................................................................................................33
9.6 Operating the machine ....................................................................................................................36
9.6.1 Riding the machine ...................................................................................................................36
9.6.2 Planning and determining the track and the work pattern. ..........................................40
9.6.3 Crumbling and levelling..........................................................................................................40
9.6.4 Sowing, raking and pressing.................................................................................................42

6
English
6
9.7 Placing and removing the seed reservoir ....................................................................................44
9.8 Cleaning the machine.......................................................................................................................45
9.9 Fault diagnosis...................................................................................................................................47
9.9.1 The engine fails to start after idle periods: .........................................................................47
9.9.2 Engine shuts off during operation.......................................................................................48
9.9.3 Loss of seed during transport ...............................................................................................49
9.9.4 Irregular sowing pattern.........................................................................................................50
9.9.5 The worked surface shows a trail of damage. ...................................................................50
9.9.6 Dead man’s handle too tight..................................................................................................51
10. Transporting the machine ..................................................................................................52
11. Maintenance ..........................................................................................................................56
11.1 General..................................................................................................................................................56
11.2 Maintenance schedule......................................................................................................................57
11.3 Engine maintenance.........................................................................................................................58
11.3.1 Cleaning the air filter................................................................................................................58
11.3.2 Changing the air filter.............................................................................................................59
11.3.3 Oil level check ...........................................................................................................................60
11.3.4 Changing the oil .......................................................................................................................61
11.3.5 Checking and/or changing the spark plug .........................................................................62
11.4 Machine maintenance ......................................................................................................................63
11.4.1 Visual check................................................................................................................................63
11.4.2 General lubrication treatment ..............................................................................................64
11.4.2.1 Hinges and ball joints......................................................................................................65
11.4.2.2 Grease nipples ...............................................................................................................68
11.4.2.3 Bearings............................................................................................................................69
11.4.2.4 Lubricating the chain and chain wheels ..................................................................70
11.4.2.5 Friction surfaces ............................................................................................................71
11.4.3 Belt tension check and adjustment .....................................................................................73
11.4.4 Belt replacement......................................................................................................................75
11.4.5 Replacing the belt tensioning roller ....................................................................................77
11.4.6 Chain tightening.......................................................................................................................78
11.4.7 Replacing the vibrating harrows...........................................................................................80
11.4.8 Checking level and refilling hydrostatic oil........................................................................80
12. Storing the machine............................................................................................................81
13. Equipment specifications ...................................................................................................82
14. Declaration of conformity CE.............................................................................................83
15. Appendices ...........................................................................................................................84
15.1 Removing the protective covers ....................................................................................................84
15.2 Risk analyses.....................................................................................................................................85
15.3 Seeding diagram...............................................................................................................................87
15.4 List with torque values ...................................................................................................................88
16. Warranty conditions............................................................................................................89

7
English
7
5. Safety symbols
In the operating manual, a number of symbols are used to provide additional information and
warn of any dangers.
5.1 For your information
For your information:
This symbol is used to draw your attention to specific information and/or ac-
tions, or it is used to indicate where you can find additional information relating
to the topic.
5.2 Caution
Caution:
This symbol suggests safe practices. The purpose is to prevent incorrect opera-
tion that could result in personal injury or damage to the machine.
5.3 Warning
Warning:
This notice warns you about any extreme dangers of which you must be aware
in these specific circumstances. So for the sake of your own safety, remain alert
at all times.

8
n
m
o
l
k
j
o
n
m
l
k
j
English
6. Most important parts
To fully understand the content of this operating manual you need to be fully conversant with the
terminology used for the descriptions. This chapter refers to a broad range of machine parts and
identifies their names. We recommend that you take the time to study the machine prior to its
use for a better understanding of the descriptions provided in this operating manual.
6.1 Overall view
Essential machine parts:
1. Steering
2. Seed reservoir
3. Depth control harrow
4. Protective transmission covers
5. Levering point
6. Lever (un)couple rotary drum
seed reservoir
1. Front weights
2. Blast bumper
3. Frame
4. Engine
5. Hydrostatic pump (on the fig.
the protective cover has been
removed)
6. Anchoring points (4x) during
transportation

9
p
o
nm
l
j
k
English
Bottom view:
1. Crumble rollers front (left and
right)
2. Hydrostatic engines (left and
right)
3. Harrow
4. Seed reservoir
5. Crumble roller back
6. Drainage cap hydrostatic oil
Top view:
(without protective covers and frame seed reservoir):
1. Rotary drum seed reservoir
2. Steering
3. Belt transmissions
• engine – hydrostatic pump
• engine – aandrijfas schudeggen
4. Reservoir hydrostatic oil
5. Return filter
6. Oil filler cap (hydrostatic)
7. Hydrostatic pump

10
nm
o
l
k
j
English
6.2 Steering
For your information:
If the terms for back,
front, left, and right are used,
in the manual, then this is always
viewed from the perspective of the
operator directing the machine.
1. Gear shift hydrostatic engine (proportionally
controlled)
2. Dead man’s handle (start movement)
3. Lever Vibrating harrow
• Stop
• Slow speed/mode
• High speed/mode
4. Hour meter
5. Throttle lever engine
6. Operation of the seed container (open & close)
6.3 Engines
• GZC750 – B&S Vanguard (6,5 HP)
Front
Back
Left
Right

11
English
• GZC1000 – Honda GX270 (9 HP)
1. Petrol tank
2. Fuel cap
3. Oil filler cap (front side)
4. Oil drainage cap (backside)
5. Spark plug
6. Air filter
7. Exhaust
8. Ventilation grid
9. Contact lock
10. Starter cable
For your information:
Your authorised ELIET dealer is at your service for any maintenance or advice,
ensuring that your ELIET machine always remains in perfect condition. You
can contact him/her for original ELIET parts and lubricants at any time.
These service parts are manufactured according to the same strict rules and
craftsmanship as the original equipment.
For your information:
Chapter 11 contains an overview of the maintenance requirements for this
machine and advises you on maintenance requiring the assistance of an
authorised dealer.
Caution:
For your own safety, only original ELIET parts may be mounted onto this ELIET
machine.

12
English
7. Safety instructions
7.1 Safety messages:
For your information:
The safety stickers are applied to the machine in clearly visible places. Take
notice of the warning messages on these stickers prior to using the machine.
This sticker is affixed to the cover of the drive shaft
of the vibrating harrows. A central spot on the
machine, in remains visible for the operator.
The first part shows icons that summarise the general safety instructions:
1. Before operating the machine the manual should be read and understood.
2. Suitable safety clothing (safety goggles, gloves, ear protection) must be worn whenever and
wherever it is required.
3. Working with or performing maintenance on the machine poses the risk of cuts to the hands.
Be attentive and cautious.
The second part of the sticker reminds bystanders to observe a 10 m safe distance when
approaching the machine.
The third part of the sticker reminds the operator that the motor must be turned off and the
spark plug cap removed before starting maintenance on the machine.
This sticker has stock no.: BQ 505 010 171
Some general safety symbols are affixed
to the handlebar. Prior to operating the
machine, make sure to put on suitable
protective clothing (gloves, ear protection
and goggles) and read the manual.

13
English
A safety sticker applied to the cover of the belt
drive warns that no work must be done without the
cover in place. Working without the cover poses the
immediate risk of clothes or limbs getting caught in
the drive and being cut off.
This sticker carries stock code BQ 505 010 130.
The sticker is located to the left of the frame, near
the vibrating harrows. The sticker points at the
danger of cuts when reaching hands or limbs into the
relevant zone. This sticker carries stock code BQ 505
010 070.
Identification sticker
This sticker is attached to the right hand side of the
machine body. It contains the machine’s identification
Model
Model no.
Serial no.
Year of manufacture
Engine
Capacity
Weight
Guaranteed A-weighted sound power Lw(A):
This sticker also contains the manufacturer’s
data. The CE label confirms that the machine is in
compliance with the applicable European machine
directive.
This label is applied to the right hand side of the
machine body. The figures on it represent the
guaranteed sound power levels (LwA) produced by
the machine under normal operating circumstances.
(Stock no. BQ 505 112 098)
Caution:
Safety stickers that as a result of use or cleaning are either damaged, have been
removed or become illegible must be replaced immediately. Stickers can be
obtained from any authorised ELIET dealer.

14
English
7.2 Safety features
The All-in-oneTM control lever (AIOC):
The machine is dangerous for the operator while driving it. This
handle serves to operate the belt drive towards the hydrostatic
pump. If there is no propulsion on the hydrostatic pump, the oil flow
to the wheel engines drops as well.
Letting go of the handle interrupts all drives and the machine will
come to a halt.
Protective covers:
All moving parts are safely shielded by several protective covers.
1. Protective cover of the steering mechanism.
2. Protective cover Motor transmission
3. Protective cover Drive shaft vibrating
harrows
4. Cover of the reduction gearbox of the
vibrating harrows
5. Protective cover Chain transmission
• Front roller - rear roller
• Rotating drum
6. Protective cover Hydrostatic pump
Sturdy construction: the robust construction is testimony to the sustainability of the machines
and offers a guarantee for the operator’s safety under unforeseen circumstances.
Front weights provide for a passive safety feature. They protect the
operator against too much strain (and avoid back problems) in lifting the
handlebar while taking a bend.
The ergonomic handlebar is height-adjustable, allowing it to be set in the
most ergonomic position for the user. In addition, the machine is equipped
with an Intuitive Steering SystemTM, making its operation easy and
natural

15
English
7.3 Safety instructions
7.3.1 General safety instructions
• The Owner Manual must stay with the unit during its complete service life. It serves as a refer-
ence for the user, and enables the machine to be used and maintained in accordance with the
correct instructions. Always refer to this instruction manual if you have any doubts about an
action that you are about to perform.
• Always observe the applicable regulations of the Labour Inspectorate to avoid accidents.
• If the instructions stated in this manual are not clear to you, do not hesitate to contact your
Eliet dealer for further explanation. The help desk at NV ELIET is at your service to answer all
of your questions. (EU [phone] - USA 412 367 5185 ). (servic[email protected])
• Under no conditions whatsoever may the original design of the machine be modified without
explicit and written consent of ELIET NV.
• Always observe all safety instructions when using this ELIET machine ! Carefully read all the
instructions relating to the operation of the machine. They are important for your own per-
sonal safety.
• Be sure to read the chapter which is intended for the dealer (see § 8. Dealer’s duties) and
verify whether the machine was delivered in accordance with the instructions.
• Get advice from the dealer or another professional when purchasing the machine
For your information:
Also read the safety instructions in the HONDA engine manual. It contains useful
tips about proper use and maintenance of the engine.
• Read and observe all safety messages stickered onto the machine (read § 7.1 for information
about the locations of the stickers)
7.3.2 Careful and proper use
• The purpose of the machine is to level the surface and seeding a new lawn. The machine
combines four separate operations:
Crumbling:
• Shattering clods
• Flattening the roughly prepared surface
Levelling:
• Irregularities are being removed
• The vibrating harrows loosen the structure of the top layer and distribute the soil evenly over
the work width. Foreign objects (stones, sticks, metal wire or other debris) that might surface
can be removed manually by the operator.

16
English
• Levelling the top layer
Seeding:
• Evenly scattering lawn seed.
• Raking in the seed (slow vibrating mode), principally breaking up the sowing lines and covering
the seeds under a thin layer of soil. This protects the seed from the wind and makes them less
visible to birds.
Rolling:
• Pressing down the terrain to make sure that the sown grass seeds are well embedded in the
soil.
• Nevertheless, the soil still remains sufficiently loose to quickly absorb moisture after rain.
The moisture level in this secure habitat below the top layer is ideal for the seed, which will
germinate faster as a result.
Caution:
The machine may be used only on terrain that has been cleared of vegetation
and that has undergone ground preparation.
Caution:
This machine is not a bulldozer or earthworks machine and must be used only
for the above-described purpose.
• Seeding is a physical effort that requires the operator to be concentrated. It is therefore
advisable to take sufficient breaks as well as adequate food and drink.
• It is unsafe for persons with heart problems and/or balance disturbances to operate the
machine.
• Think about what you are doing at every manoeuvre. Do not be tempted to let routine dull
your attention. Never act impulsively or on reflex.
• Despite the extensive safety features, do not seek out dangerous situations (read an indicative
list of risks in appendix B1).
)
Warning:
Most accidents are the result of carelessness or reckless behaviour.
• Never use the machine on sites that do not comply with the soil characteristics (read § 9.2 Site
characteristics).
• Always operate the machine in a forward direction. This provides the best overview of the work
area.

17
English
• Never work when light intensity is below 500 Lux.
• Never use the machine as a means of transporting people or loads, except to carry the
operator on the specially provided foot board (available under number MA 016 001 003).
• Thoroughly inspect the area where the machine is to be used. Remove roots, stones, sticks,
textile, steel wires and other debris. Also pay attention to any superficial cabling or conduits
(electric cables, water, etc.).
• Be alert! When hitting a stone or hard object - stop the machine immediately and remove the
object before continuing.
• Don’t forget to switch of the vibrating harrows and place them in the uppermost position when
driving the machine to the work area.
• Choose an obstacle-free access route towards the terrain. Selecting the right route will reduce
the risk of damage to terraces, pavements, platforms, walkways, etc.
• ELIET cannot be held liable for damage to property.
• Avoid inhaling the machine’s exhaust fumes. Exhaust fumes contain toxins, which can
lead to poisoning and result in death. Consequently, the engine may never run in a closed
environment for more than 30 seconds.
7.3.3 Operator’s responsibilities
• The operator of this machine is assumed mature enough and with enough common sense to
make decisions by himself.
• All persons using the machine are assumed to be fully conversant with the safety instructions.
The operator is fully liable for the use of the machine in regard to himself and to third parties.
• The machine may not be operated by minors. This does not apply to youths over 16 who are
learning to operate the machine under the supervision of an experienced operator.
• Children and animals must be kept outside the machine’s danger zone. A minimum distance of
10 meters must be observed.
• ELIET advises against lending the machine to others, but if this should occur, it should only be
lent to persons who are familiar it. Always make sure that the user is aware of the potential
hazards and ensure that he/she reads the manual before using the machine. (Appendix B1
contains a list of indicative dangers.)
• This machine must only be operated by persons who are well-rested and in a good physical
condition. Take a rest if you become tired while operating the machine.
• Do not operate the machine after alcohol or hallucinogenic drug use.
Warning:
One moment of thoughtlessness or carelessness can lead to life long regret.

18
English
7.3.4 Personal Protective Equipment (PPE)
• Although the risk of personal injury is limited with this ELIET seeder, the operator’s feet are
most vulnerable. Sturdy closed shoes with a steel top are highly recommended.
• The person operating this machine must wear suitable clothing, i.e. covering the entire body.
• Do not wear loose fitting clothing (a shawl, for instance, is a potential hazard)
• Long hair must be contained using a cap or a headband, or worn in a ponytail.
• For protection of the most sensitive senses, ELIET recommends hearing protection.
• Be extra alert when wearing hearing protection: it can impair the ability to hear warning
sounds (such as yelling, signal tones, etc.). With this in mind, ELIET strongly advices against
hearing protection with a built-in music player.
• As indicated on the safety sticker on the machine, the operator must wear safety gloves and
safety goggles in addition to hearing protection.
• Working the soil can cause a large amount of dust, especially under warm and dry weather
circumstances. ELIET recommends using a dust mask if your respiratory airways become agi-
tated as a result (masks should comply with the 89/686/EEC standard).
For your information:
The operator of the machine can reduce the risk of injury by wearing the proper
personal protection equipment.
7.3.5 Ergonomics
• For optimum use, the rear end of the machine will have to be lifted regularly when turning.
This is necessary because the rear roller is fabricated as one piece and spans the entire width
of the machine. The roller is propelled laterally by a chain that is connected to the left front
roller and as such, does not have a separate differential.
Therefore, it is important to take into account the following points:
o Place the handlebar at the correct height (read § 9.4.1.3)
o Be sure to wear shoes with a sole that provide sufficient grip.
o Hold the handlebar with both hands.
o While lifting, keep your back straight, also your lower back, and tighten the muscles of your
arms such that the strength comes from your legs, not from your back.
o Bend your knees to let your upper legs do most of the work.
o If you need to turn, pivot your feet instead of twisting at the waist.

19
3 m
3 m
3 m
English
For your information :
Front weights for the machine are available from your ELIET dealer. ELIET
recommends their use: they serve as counterweights and make lifting the rear of
the machine easier. A maximum of four weights of 20 kg each can be mounted
at the front. Each operator will use the number of weights that matches their
desired comfort level.
• The seed reservoir can hold approximately 61 L (GZC 750) or 93 L (GZC 100) of grass seed.
Choosing seed bags of equally large volume for filling the seed reservoir will prevent back
problems caused by lifting the bags.
7.3.6 Danger zone
The image below shows the position of the operator and the machine’s danger zone.
• For safety’s sake, the operator should never allow bystanders within the danger zone which
stretches up to 3 m around the machine during work.
• Do not take risks! If someone enters the machine’s danger zone, immediately stop the machine
by releasing the dead man’s handle and switch off the vibrating harrow via the handle on the
handlebar.
• Once the motor is running, the operator must focus his full attention on operating the
machine.
• Shut off the engine when leaving the machine unattended. Turn the motor switch to the OFF
position.
Operator
Operator
Operator

20
English
7.3.7 Periodic maintenance
For your information:
For your own safety and in the interest of preserving the life of the machine, this
machine should undergo regular maintenance.
• Periodic maintenance is essential. Strictly follow the maintenance schedule in this operating
manual (see §11.2).
• The maintenance meter helps you to monitor the number of operating hours .
• Inspect the machine prior to every job. (Read § 9.1 and §11.4.1). Any defects must be repaired
immediately.
• Always make sure the motor is switched off before performing repairs or maintenance. Always
wait until all moving parts have come to a full stop before performing any action whatsoever.
• If parts must be replaced as a result of wear or failure, you must always turn to your author-
ised ELIET dealer for original replacement parts. This is of key importance for your own safety.
Warning:
Repairs, maintenance and cleaning must only be performed with the engine
disengaged and the spark plug cap decoupled.
7.3.8 Limits of the machine
• The work depth of the vibrating harrows can be adjusted from +10 mm to -40 mm (the lower
part of the rollers being the point of reference). The real work depth will be lower because the
machine will sink into the soil somewhat.
For your information :
The work depth depends on the surface and on the wear of the teeth.
• The combined lawn seeder should not be used at low temperatures or under frosty
circumstances.
• Do not use the machine on dried-out soil.
• The machine weighs (*) 385 kg (GZC750) / 415 kg (GZC1000). Please take this into account
when transporting the machine as well as when loading or unloading.
• The width of any passage should measure at least: 820 mm (GZC750) / 1140 mm (GZC1000).
• The tread width of the hind roller is: 710 mm (GZC750) / 1030 mm (GZC1000).
• The maximum ground clearance in transport mode is 10 mm (with the vibrating harrows in the
