EliteProAV Insta-DE2 Series User manual

Rev. 122716 DR 1 www.eliteproav.com
Insta-DE2 Series
Dry-Erase Front Projection Screen Film
User’s Guide
Thank you for choosing the Insta-DE2 Series dry-erase whiteboard projection screen! Please read through
this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life.
Precautionary Notes:
Before using the dry-erase function of your whiteboard screen, please make note of the following
instructions to properly maintain and clean your dry-erase surface projection screen. (These Whiteboard
cleaning tips are just as relevant with any dry-erase writing surface as they are with our Whiteboard-
Projection Screens.)
1. Only use a high density foam eraser when removing dry-erase markings from the Whiteboard
screen.
2. Do not use abrasive erasers as these may scratch the surface of the screen.
3. Never spray the whiteboard cleaner solution onto the surface while marker writing is present and
then attempt to use a high density foam eraser to remove. This will only smear the dry-erase
marker ink making the surface more difficult to clean and will likely ruin the foam eraser.
4. If there are any dry-erase markings left behind even after attempting to remove them using our
high density erasers, spray our whiteboard cleaning solution directly onto the screen surface and
use only a soft microfiber cloth to wipe-down and clean the area.
For a video demonstration, please visit: http://www.elitescreens.com/whiteboardscreen-cleaning
If replacement cleaning accessories are needed, please visit the Whiteboard cleaning accessories section of
our website at http://www.elitescreens.com/clean-whiteboard
Product Features:
Award winning and GREENGUARD certified VersaWhite material.
1.1 gain with 180 degree wide viewing angle.
Special anti-scratch layer to ensure long use as a
dry-erase/projection screen.
Application Advantages:
Instantly converts flat surfaces/walls into a dry-erase whiteboard projection screen.
Includes adhesive black velveteen border to enhance contrast and overall appearance.
Perfect dry-erase and projection solution for today's short throw projectors.
Ideal and effective instructional presentation tool in the classroom, boardroom, and training
facilities.

Rev. 122716 DR 2 www.eliteproav.com
Product Specifications:
What’s in the package?
Please make sure all parts listed below are included.
Notes: For best results and maximum product longevity, O NLY use a high density whiteboard Eraser.
a. b. c. d. e. f.
g. h.
Tools required (not included)
Specifications:
Color display
White
Thickness
2.1mm
Material composition
High molecular weight copolymer
of Terephthalic acid ethyl esters
Weight
1m2/377g
Temperature
At room temperature
Gain
1.1
Viewing Angle
180∘
Parts List
QTY
a. Insta-DE2 Screen Material Film Roll
1
b. Self-stick cradle
1
c. Whiteboard pens
2
d. High density eraser
2
e. double-sided tape
1
f. Black velvet border adhesive strip roll
1
g. smoothing tool
1
h. Powder compound
1-3
Model
Number
1 bag
(25g)
2 bags
(50g)
3 bags
(75g)
IWB86VW2
X
IWB97XW2
X
IWB105HW2
X
IWB4.2x10W2
X
IWB4.2x20W2
X
IWB4.2x30W2
X
IWB114XW2
X
IWB5x10W2
X
IWB5x20W2
X
IWB5X30W2
X
Carpenter's Pencil
Measuring Tape
Shop Towels
Roller cover and frame
Paint Tray
150 grit sandpaper
Dust Mask
Safety Goggles
R-35 Primer

Rev. 041217 DR 3 www.eliteproav.com
Preparing the installation surface:
The Insta-DE 2 product is to be solely installed on flat surfaces. Prepare the flat wall/surface by
cleaning the entire area. Do not install if any imperfections are found on the surface such as drilled
holes, glue/tape residue, dents, etc. We recommend sanding the area first to make sure you have a
clean flat and smooth surface. Failure to remove such imperfections can damage the product. The
dry erase function of this product requires a smooth writeable surface and EliteProAV is not
responsible should these instructions are not be properly followed.
Take the Insta-DE 2 film out of the package, unroll it on a clean surface and lay it on its front side.
Before applying the Insta-DE 2, the application surface must be dry, clean, smooth, and structurally
sound.
1. Clean the surface to remove any dirt, grease, and wax.
2. Fill any depressions or holes with a drywall compound
3. Use sandpaper to smooth any bumps and blemishes. Sand until the surface is completely flat.
4. Level-5 finish to the surface and apply one coat of Professional R-35 primer.
The warranty of this product will be voided if any bubbling occurs due to the use of an after-
market spray adhesive or if the screen was applied on to a textured wall.
Installation:
We strongly recommend two or more people for this installation.
1. Smoothen the entire surface of the wall with sandpaper.
2. Clean the entire surface with a wet sponge or lint-free towel to remove any dust left from sanding the
wall.
3. Measure and draw line around the screen installation area.
4. Apply the included double-sided tap over the line. Do not remote the top film of the tape
5. Pour an entire powder bag into a paint bucket filled with 27 oz. of room temperature water and stir
until all lumps are gone and the compound has a syrup texture. This will make the mixture into an
adhesive compound for sticking the film to the wall.
Note: Once the compound has been mixed, it must be applied within 4 hours to ensure a sealed installation
of the Insta-DE2 to the wall. Use one bag for every 27 oz. of water.
Wall

Rev. 041217 DR 4 www.eliteproav.com
6. Pour the mixture into a paint tray and dip the roller.
7. Evenly apply a thin coat of adhesive to the surface with a paint roller.
8. Wait for adhesive to dry.
9. Sand the surface until no adhesive residue remains.
10. Apply one coat of Professional R-35 Primer (do not allow it to dry) and immediately apply the
Insta-DE2 to the wall.
11. Unroll the Insta-DE2 on to the wall lining it up with the drawn line from Step 3.
Note 1: Each side of the material is labeled FRONT/BACK
Note 2: Do not allow the material to wrinkle or crease to avoid permanent damage.
12. Flatten the surface with a flexible wall smoothing tool in a 45 degree angle to avoid scratching the
surface.
13. Lift edges and smoothen out any remaining air bubbles.
Caution:
The smoothing tool’s edge is sharp. Carefully scrape the screen when removing air bubbles to avoid scratching
the surface.
14. Peel off the top layer of the double-sided tape and flatten the screen’s edges with the smoothing tool.
15. Use a soft damp towel or sponge to clean entire surface.
Tip:
In rare instances, High indoor temperature will cause the surface to expand and produce bubbles.
Because the back of the Insta-DE 2 is very smooth, the glue does not easily stick to the wall by itself. For
this reason a coating of R-35 primer has to be applied to the wall.
Use a sharp utility knife to cut a small hole in the center of the bubble. Inject some Professional R-35
primer with a syringe and smooth out the Insta-DE 2 screen surface with a smoothing tool.

Rev. 041217 DR 5 www.eliteproav.com
Adhesive black velvet border installation:
1. Measure the top/bottom and left/right sides of the Insta-DE2 screen to obtain the required length of
the velvet border you will need to use for bordering your screen.
2. Peel a small portion off of the velvet border and place it about half an inch over the white area of the
screen. Continue to peel off and roll out the remainder of the velvet border until you have reached
the end and cut the edge.
Note: For best results we recommend cutting the edge in a 45° angle.
3. Repeat the process for the remainder of the sides until all sides are bordered as shown below.
4. Allow the compound to dry for approximately 24 hours before using the dry-erase feature of the Insta-
DE2. Use only the included erasers to remove and erase dry-erase markings. For a deep clean, we
recommend using a non-alcohol based dry-erase board cleaner with a soft microfiber cloth.
Elite offers a replacement kit (part number ZER3) which includes:
1 x bottle of 8.45 oz cleaning solution
1 x microfiber cloth
2 x high density foam erasers
2 x sets of dry-erase markers (4 total)
Contact your reseller or visit shop.elitescreens.com for pricing and purchase.
Safety Precautions:
A. Avoid using sharp objects directly on the screen which can result in permanently damaging the
product and voiding your warranty.
B. Creases or wrinkles caused by improper installation are not removable.

Rev. 041217 DR 6 www.eliteproav.com
Below are sample pictures of improper installations.
The above pictures are the result of improper installations.
The surface to which you are installing this material to should be perfectly smooth. If in case the surface is
uneven, it is recommended to place a smooth board over the desired space of the install first. This will
eliminate any bubbling of the material over time.

Rev. 041217 DR 7 www.eliteproav.com
Dimensions Table:
Model Number Diag. Size View Area (HxW) View Height (A) View Width (B) Thickness (C)
Unit: Inches
IWB5x40W2
5'x40'
60.2"x480.0"
60.2
480.0
0.008
IWB5x50W2
5'x50'
60.2"x600.0"
60.2
600.0
0.008
IWB5x60W2
5'x60'
60.2"x720.0"
60.2
720.0
0.008
Unit: mm
IWB5x40W2
5'x40'
60.2"x480.0"
1529
12192
0.2
IWB5x50W2
5'x50'
60.2"x600.0"
1529
15240
0.2
IWB5x60W2
5'x60'
60.2"x720.0"
1529
18288
0.2
For more information, technical support or your local EliteProAV contact,
please visit www.eliteproav.com
Note: Data Error ±1"
