Eljer 091-2190 User manual

Eljer, Inc. 4/07
3.23
Toilets
Patriot 14” Rough-In Toilets
VITREOUS CHINA
1.6 Gallons (6 Liters) of Water Per Flush
Available in Elongated-Rim or Plain-Rim
Close-Coupled, Two-Piece Toilet
Siphon Vortex Bowl with Shelf-Top Tank
Fully Glazed 2" Trapway
14" Rough-In
091-2190 Vitreous China, Two-Piece, Plain-Rim
Toilet, 14" Rough-In, Includes (131-2120)
Bowl and (141-2190) Tank - 77 lbs.
Cubes 4.76
091-2195 Vitreous China, Two-Piece, Elongated-Rim
Toilet, 14" Rough-In, Includes (131-2125)
Bowl and (141-2190) Tank - 80 lbs.,
Cubes 4.84
Component Parts:
131-2120 Plain-Rim Bowl - 40 lbs., Cubes 2.80
131-2125 Elongated Bowl - 43 lbs., Cubes 2.92
141-2190 14” Rough-In Tank - 37 lbs., Cubes 1.91
151-1190 Tank Lid Only for 14" Rough Tank - 16 lbs.
Optional Tank:
141-2195 Tank 14” Rough with Right-Hand
Chrome Flush Actuator - 37 lbs.,
Cubes 1.92
Flush Actuators:
495-2120-00 White (Standard on White Tanks)
495-2120-82 Natural (Standard on Natural Tanks)
495-2120-96 Biscuit (Standard on Biscuit Tanks)
495-2121-00 Polished Chrome (Furnished with Colors
Other Than White, Natural, and Biscuit)
495-2121-04 Polished Brass (Optional)
495-2121-25 Brushed Nickel (Optional)
495-2121-35 Oil-Rubbed Bronze (Optional)
495-2742-00 Polished Chrome for Right-Hand
Actuator Tank
Recommended Toilet Seats:
124-0240 Premium Solid Plastic Seat and Cover -
Plain-Rim
124-0245 Premium Solid Plastic Seat and Cover -
Elongated-Rim
CSA Certified
Patriot Elongated-Rim Toilet, 14” Rough-In (091-2195)
Note: Dimensions May Vary +/- 1/2" and are Subject to
Change or Cancellation
Eljer assumes no responsibility or liability for local or
state regulations which deviate from national standards.
It shall be the responsibility of the installer to comply
with local codes and standards prior to installation of
any Eljer product.
Dimensions for Location of Supply are Suggested
E-Force
Gravity Flushing System
by Eljer
www.eljer.com
Plain-Rim Elongated-Rim
Water Surface 8-1/4" x 8-3/4" 9" x 8-3/4"
(210mm x 222mm) (229mm x 222mm)
Trap Size 2" (51mm) 2" (51mm)
Trap Seal 2-3/8" (60mm) 2-1/2" (64mm)
ALL FIXTURE DIMENSIONS ARE NOMINAL AND MAY VARY WITHIN THE RANGE OF
TOLERANCES ESTABLISHED BY ASME/ANSI STANDARDS, A112.19.2M. ALL
MEASUREMENTS SHOWN ARE SUBJECT TO CHANGE OR CANCELLATION.
DIMENSIONS IN PARENTHESES ARE IN MILLIMETERS 25.4 mm = 1 INCH.
