Elk Products ELK-319HRR Instruction sheet

ELK-319HRR Heat & Rate of Rise Sensor
Description
The ELK-319HRR is a Supervised, Wireless Heat Sensor. It
uses a solid-state thermistor to sample and trigger an event
at a selectable setpoint of either 135 or 200 degrees F. It can
also trigger an event if the temperature rises 12 degrees F or
more during a one (1) minute time period.
When an event is triggered the sensor transmits an alarm (trip)
signal to the panel. Additionally transmitted signals include:
tamper, hourly supervisory, and low battery (as needed). The
sensor is powered by a single 3V lithium battery which can
provide up to 10 years of life.
This sensor is compatible with Elk’s 319MHz Receivers/Panels
as well as many other panels that operate on the 319.5MHz
Frequency and adhere to the ITI/Interlogix protocol.
Specications
RF frequency: 319.5 MHz
Supervision
Interval: 62 - 68 minutes
Compatibility: ELK-319 Receivers/Panels & other panels
that operate on the 319.5MHz Freq. and
adhere to the ITI/Interlogix protocol
Battery type: One (1) 3VDC lithium battery (Panasonic or
Varta Model CR123) Exp. Battery life 10 yrs
Rate of Rise
Rating: 12° to 15°F (6.7° to 8.3°C)
UL max.
Ambient ceiling: 100°F/150°F (37.8°C/65.6°C
Maximum
UL Spacing: 50ft (15.2m) x 50ft (15.2m)
Storage
Temp Range: -30 to 167°F (-34 to 75°C)
Relative
Humidity: 0 to 95% non-condensing
Dimensions 2.29” Dia. x 1.28” H (58.25mm x 32.4mm)
Programming (Enrollment)
The following is a general guideline for programming (enrolling)
a sensor into the receiver or panel. For more extensive
instructions please refer to the receiver or panel instructions.
1. Place the panel into the Program mode.
2. Proceed to the WIRELESS SETUP menu.
3. Select the appropriate zone/sensor location number.
4. When prompted by the panel to trip the sensor for learning:
• Remove the battery pull tab which will power up the sensor
• The panel should acknowledge the sensor has been learned
by keypad display and/or audio alert (depending on the
panel). If enrollment fails try pressing and releasing the
tamper plunger. In some cases it may be necessary to
remove and reinstall the batteries.
5. Repeat the above process for any additional wireless
sensors. Proceed to the zone programming to assign each
sensor’s zone denition.
6. Exit programming mode when nished.
Installation Guidelines
• Operation should be tested from the desired location to
make certain it can be received by the panel before drilling
any holes or permanently mounting the sensor
• Mounting this sensor on metal can negatively a󰀨ect the
transmitting range.
• Install the sensor within 100 ft. of the receiver or panel.
• Heat sensors such as this are recommended for areas
like garages, kitchens, attics, utility & equipment closets or
places where a smoke detector is not advisable.
• Avoid areas that may experience extreme or rapid increasing
temperatures such as near: replaces, stoves, heaters, etc.
• Mount this sensor on ceilings at least 4 inches away from
any wall. If placed on a wall the sensor must be within 6
inches of the ceiling.
• If using the 135°F setting make sure the ceiling location
does not exceed this temperature.
TM Interlogix is a registered trademark belonging to United Technologies.
Setup
The sensor can be setup to detect a xed temperature of either
Low (135°F) or High (200°F).
Use the jumper to select Low or Hi.
Fixed Temperature
Low = 135°F
High = 200°F
Note: If no jumper is installed
the sensor will be set to 200°F.

Elk Products, Inc.- 3266 Hwy 70 - Connelly Springs, NC 28612 http://www.elkproducts.com 1/3/2020
FCC AND IC COMPLIANCE STATEMENT:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o󰀨 and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di󰀨erent from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Cet appareil est conforme avec Industrie Canada exempts de
licence standard RSS (s). Son fonctionnement est soumis aux
deux conditions suivantes: (1) cet appareil ne doit pas provoquer
d’interférences et (2) cet appareil doit accepter toute interférence,
y compris celles pouvant causer un mauvais fonctionnement de
l’appareil.
In accordance with FCC requirements of human exposure to radio
frequency elds, the radiating element shall be installed such that
a minimum separation distance of 20 cm is maintained from the
general population.
FCC ID: 2ABBZ-RF-ROR
IC: 11817A-RFROR
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation. Changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This Class B digital apparatus complies with Canadian ICES-3B.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Limited Warranty
THIS WIRELESS SENSOR IS WARRANTED TO BE FREE FROM
DEFECTS AND WORKMANSHIP FOR A PERIOD OF 2 YEARS
FROM DATE OF MANUFACTURE EXCLUDING BATTERIES.
BATTERIES USED WITH WIRELESS DEVICES ARE NOT
WARRANTED.
MANUFACTURER HEREBY DISCLAIMS ANY AND ALL OTHER
WARRANTIESAND REPRESENTATIONS, WHETHER EXPRESS,
IMPLIED, STATUTORY OR OTHERWISE INCLUDING (BUT NOT
LIMITED TO) ANY WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE WITH RESPECT
TO THESE PRODUCTS AND ANY RELATED SOFTWARE.
MANUFACTURER FURTHER DISCLAIMS ANY OTHER IMPLIED
WARRANTY UNDER THE UNIFORM COMPUTER INFORMATION
TRANSACTIONS ACT OR SIMILAR LAW AS ENACTED BY
ANY STATE. (USA only) SOME STATES DO NOT ALLOW THE
EXCLUSION OF IMPLIED WARRANTIES, SO THE ABOVE
EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER LEGAL RIGHTS THAT VARY FROM STATE TO STATE.
MANUFACTURER MAKES NO REPRESENTATION, WARRANTY,
COVENANT OR PROMISE THAT ITS ALARM PRODUCTS
AND/OR RELATED SOFTWARE (I) WILL NOT BE HACKED,
COMPROMISED AND/OR CIRCUMVENTED; (II) WILL PREVENT,
OR PROVIDE ADEQUATE WARNING OR PROTECTION FROM,
BREAK-INS, BURGLARY, ROBBERY, FIRE; OR (III) WILL WORK
PROPERLY IN ALL ENVIRONMENTS & APPLICATIONS.
NOTE: Elk Products is not responsible for any changes
or modications not expressly approved by the party
responsible for compliance. Such modications could
void the user’s authority to operate the equipment.
Testing this Fire Sensor
All wireless sensors be tested after installation and
programming.
1. Contact the Alarm Monitoring Center and place the account
in test prior to testing this sensor.
2. Place the tip of a strong magnet against the small mark
(resembles a ngernail) on the outer front face of the sensor
and hold in place for at least 15 seconds.
3. The Control Panel Fire Alarm should activate and sound.
4. Silence and reset the Alarm.
Battery Replacement
Low Battery trouble will be transmitted when the sensor battery
needs to be replaced.
NOTE: Replace the 3V lithium battery within 7 days
following a low battery trouble indication.
• Twist the sensor counterclockwise to remove it from the
mounting base.
• Turn the sensor over and remove the old battery.
• Observe polarity on the battery and the holder and
carefully Insert the new battery into the sensor.
CAUTION: Use only approved 3.0V Lithium Battery
Panasonic or Varta model CR123
