Elmdene PSUIR Series User manual

1
Technical Support: [phone] (option 3) PAK200526 01B ©2016 ELMDENE INTERNATIONAL LTD
PSUIR-xx
PSU Interface Relay
M
odels
:
PSUIR-12 PSUIR-24
12Vdc Version 24Vdc Version
F EATURES
-Available in 12Vdc or 24Vdc models
-Multiple Trigger configurations
-N/O and N/C changeover contacts
-Contact rating: 10A @ 12Vdc
-LED indication when ‘Relay Energised’
-Low current consumption
-Standalone device - retrofit into any
boxed 12Vdc or 24Vdc PSU
PERATI N
This device provides the functionality to control the output of a PSU by the means of either a Volt Free
contact (N/O or N/C) or a low voltage signal (12Vdc/24Vdc), as shown in the block diagram below:
Typical Applications
•Access Control Systems where power is required to be removed from the system devices (i.e. door
locks) in the event of a Fire Alarm activation. Note: For BS7273-4 compliance, it is necessary to use the
device in ‘Volta e tri er’ mode, to provide fail safe operation under open and short circuit conditions.
•Any system that requires remote control of a Power Supply output (turn on or off) in response to real
time events.
Elmdene International Ltd Tel: [phone]
3 Keel Close, Interchange Park, Fax: [phone]
Portsmouth, Hampshire, PO3 5QD, UK  Web: www.elmdene.co.uk
PSU
(12 or 24Vdc)
Trigger I/P
(Contact or Voltage)
12 or 24
V
dc
(Un
-
switched)
12 or 24
V
dc
(Switched On/Off - Trigger controlled)

2
Technical Support: [phone] (option 3) PAK200526 01B ©2016 ELMDENE INTERNATIONAL LTD
C NNECTI NS
I/P: + +12Vdc or +24Vdc from PSU O/P
- 0V from PSU O/P
O/P: + Auxiliary +Vdc un-switched PSU O/P
- 0V output to load (Common 0v for NO, NC & Aux)
NO Normally Open relay output (see chart below)
NC Normally Closed relay output (see chart below)
Trigger: + Trigger I/P from control device (+VE or Contact)
- Trigger I/P from control device (0V or Contact)
Warning: This unit is NOT suitable for switching 240Vac. Mains loa s.
Trigger & Jumper Configurations
The device has 3 modes of operation set by the onboard jumpers:
•Contact Mode (Normally Open) - Jumper across: 2 & 3
•Contact Mode (Normally Closed) - Jumpers across: 1 & 2 and 3 & 4
•Voltage Mode - Jumper across: 3 & 4
Table 1 defines the output state of the N.O and N.C contacts with respect to Mode selected and Trigger inputs.
Note: Trigger Input terminals + and - are only polarity conscious when used in Voltage mode
Table 1 Trigger
Select Jumper(s) Trigger + & -
utput
N. N.C LED
Contact
Mode
N. 2 & 3
open
no output
+12/24V
OFF
closed
+12/24V
no output
ON
N.C 1 & 2
3 & 4
open
+12/24V
no output
ON
closed
no output
+12/24V
OFF
Voltage
Mode +VE 3 & 4
removed
no output
+12/24V
O
FF
applied
+12/24V
no output
ON
1
2
3
4
Trigger
Select
NO
NC
+V
E
Jumper Settings for Trigger Selection
Mode:
Link Pins:
2&3
1&2
3&4
3&4

3
Technical Support: [phone] (option 3) PAK200526 01B ©2016 ELMDENE INTERNATIONAL LTD
Typical Setup:
I NSTALLATI N AND S ET -U P
Note: Ensure all power is removed while connections are made to the device.
1. Ensure PSU voltage matches the PSU Relay Interface rating (12Vdc or 24Vdc).
2. Set jumpers to required Trigger method.
3. Mount PSU Interface Relay using self-adhesive mounting feet supplied.
4. Make required connections.
5. Apply power and test relay operation by using the appropriate Trigger selected.
M AINTENANCE
There is no regular maintenance required of this device.
In th
e
example
above
, power
to the
l
ock is removed
when
the
24Vdc
signal from the
Fire Alarm
Panel is
disconnected (BS7273-4 Compliant).
}
PSU Interface Relay
PSUIR-12
1
2
3
4
+
V
dc
0V
dc
To Access Control Lock
+Vdc
0Vdc
Input
From
PSU
Trigger Select set to
Voltage Mode: (Jumpers 3&4)
N
NC
+
+
Switche +V c O/P
Trigger
I/P
+
(Un-switched)
(Un
-
switched)
Fire
+ 24V -
Aux
Fire Panel
F
ault

4
Technical Support: [phone] (option 3) PAK200526 01B ©2016 ELMDENE INTERNATIONAL LTD
D ISP SAL F P R DUCT AT E ND F L IFE
This product falls within the scope of EU Directives 2012/19/EU Waste Electrical and Electronic Equipment
(WEEE). At the end of life, the product must be separated from the domestic waste stream and disposed via
an appropriate approved WEEE disposal route in accordance with all national and local regulations.
For more information see: www.recyclethis.info
S PECIFICATI N
Operating Voltage: 12Vdc: 11Vdc to 14Vdc
24Vdc: 20Vdc to 28Vdc
Current: Maximum 30mA @ 12.0Vdc (with relay energised)
Switching Load: 10A @ 12Vdc
Dimensions: L60xW51xH23 (mm)
C MPLIANCE
This product meets the essential requirements of the following EU Directives:
EMC: 2014/30/EU
RoHS2: 2011/65/EU
WEEE: 2012/19/EU
Packa in supplied with this product may be recycled.
Please dispose of packa in accordin ly.
