ELNet Pico 5 User manual

ElNet Pico 5/60
Energy Powermeter
Rev 1.3

2
Table of Contents
CHAPTER 1 ─ INTRODUCTION .......................................5
1.1 About the ElNet Pico Powermete .......................5
1.2 How to use this manual ...........................................6
1.3 Safety Information...................................................7
1.4 Warranty ..................................................................8
1.5 Your comments are welcome.................................10
1.6 Disclaimer...............................................................11
CHAPTER 2 —INSTALLATION......................................12
2.1 Contents of packaging...........................................13
2.2 Mechanical mounting............................................14
2.3 Wiring Schematics.................................................15
2.4 Connections............................................................17
2.5 Manufacturing Data..............................................20
CHAPTER 3 —USING ElNet Pico Powermeter...........21
3.1 Front Panel.............................................................21
3.2 Control Buttons......................................................22
CHAPTER 4 - NECESSARY ElNet Pico SETTINGS....23
4.1 Settings for Current Transformer ........................24
4.2 Phase Order Check................................................25

3
4.3 Time Settings..........................................................27
4.4 Date Settings...........................................................28
4.5 Filter Settings.........................................................29
CHAPTER 5 —Text Panel Displays..................................30
5.1 Current...................................................................30
5.2 Current in Neurtal Line ........................................31
5.3 Voltage ....................................................................31
5.4 Active Power (P) ....................................................32
5.5 Reactive Power (Q)................................................34
5.6 Apparent Power (S) ...............................................35
5.7 Total Power Factor and for each Phase................36
5.8 Frequency...............................................................36
5.9 Active Energy.........................................................37
5.10 Reactive Energy..................................................38
5.11 Apparent Energy ................................................38
5.12 T.O.U Energy ......................................................39
CHAPTER 6 —COMMUNICATION................................42
6.1 MODBUS Framing................................................42
6.1.1 RTU Transmission Mode....................................42
6.1.2 The RTU Frame Format ....................................43
6.1.3 Address Field.......................................................44

4
6.1.4 Function Field.....................................................44
6.1.5 Data Field............................................................45
6.1.6 Check Field..........................................................45
6.2 Registers for ElNet Pico Multimeter....................45
6.2.1 Registers addresess............................................47
6.3 Communication Connections................................47
6.4 Communication Settings .......................................47
6.4.1 Communication Address ....................................48
6.4.2 Baud Rate............................................................48
6.4.3 Parity ...................................................................48
6.5 Communication Set Up .........................................49
6.5.1 Address Set Up....................................................49
6.5.2 Baud Rate Set Up................................................50
6.5.3 Parity Set Up.......................................................51
6.5.4 Stop Bit Set Up....................................................51
6.6 Communication with UniArt Software................52
Table 6.4 Function Codes ...................................................54
CHAPTER 7 —Specifications...........................................55

5
CHAPTER 1 ─ INTRODUCTION
1.1 About the ElNet Pico Powermete
Large consumers of electricity e.g. factories, hotels, hospitals,
municipalities, need to know the history of their consumption and
the quality and the values of the power supply. Details such as
Voltage, Current, Power Factor, Hertz, Neutral Current, Energy
consumption can be displayed by the ElNet Pico Energy
Powermeter .
An additional feature of the Multimeter is the ability to measure
THD –Total Harmonic Distortion. Part of the Electricity Supply
Authority’s bill reflects poor or good Harmonics in the
consumer’s system, therefore it is in his interest to monitor
Harmonics and try to improve it.
The ElNet Pico Energy Powermeter is a compact, multi
functional, three-phase Powermeter simple to install and is
especially designed to integrate into Building Management
Systems. It requires no special mounting and is ideally suited for
mounting on DIN rail of any standard electrical panel.
The Configuration and Setup is menu driven, with password
protection.
Communication with external devices is simple and is based on
standard known protocol.
Each ElNet Pico Energy Powermeter is carefully and
meticulously manufactured using quality components and the
latest production methods. Before leaving the factory each
ElNet Pico Energy Powermeter is calibrated and is sent
to the customer accompanied by the test certificate and Certificate
of Compliance (C.O.C).

6
1.2 How to use this manual
We at CONTROL APPLICATIONS Ltd, envisage this manual to
be used by three types of people, i.e. the Installation Technician,
the Senior Electrical Engineer and the end User. For this reason
this manual is divided into chapters for ease of reference by each
of these different people. There could be a situation where two of
the above mentioned tasks can be combined, or in a rare instance
one person could handle all three tasks.
CHAPTER 1, Introduction, describes the ElNet Pico
Powermeter , its potential users, the readings it can provide and
some of its features in brief.
CHAPTER 2, Installation, provides detailed instructions for
unpacking, mechanical mounting, and electrical wiring up
instructions for the Installation Technician.
CHAPTER 3, Using the ElNet Pico Powermeter, describes
in detail front Panel, the functions of the control buttons, and the
Lock Utility.
CHAPTER 4, Parameter Configuration & Settings explains in
detail the minimum parameters settings needed by the Senior
Electrical Engineer to set up and configure the ElNet Pico
Energy Powermeter.

7
CHAPTER 5, Front Panel Displays, is an easy to follow step-by-
step guide to obtain readings and tables.
CHAPTER 6, Communications provides details about the
Communication capabilities of the ElNet Pico Energy
Powermeter, and how to Set Up.
CHAPTER 7, Specifications, is a detailed list of specifications of
the ElNet Pico Energy Powermeter.
1.3 Safety Information
The purpose of this manual is to help you. Please read the
instructions carefully before performing any installation and note
any precautions.
Ensure that all incoming AC power and other
power sources are turned off before
performing any work on the ElNet Pico
Energy Powermeter. Failure to do so may
result in serious or even fatal injury and/or
equipment damage.
If the ElNet Pico Energy Powermeter
is damaged in any way do NOT connect it to
any power source.
WARNING!

8
To prevent a potential fire or shock hazard,
never expose the ElNet Pico Energy
Powermeter to rain or moisture.
Keep the surrounding area free of dirt and
clutter especially metal objects. Good
housekeeping pays.
Inspect the cables periodically for cracks,
kinks or any other signs of wear.
Keep children away.
Do not pull the cords.
Users should stay alert and not approach the
terminals of the ElNet Pico Energy
Powermeter while tired or under the
influence of alcohol, medicines or any other
chemical substance that would tend to make a
person drowsy.
Above all use common sense at all times.
1.4 Warranty
CONTROL APPLICATIONS Ltd provides a 12- Month warranty
against faulty workmanship or components from date of dispatch
under the condition that the product was properly installed and
used.
CONTROL APPLICATIONS Ltd does not accept liability for any
damage that may be caused by natural disasters (such as floods,
fire, earthquake, lightening etc.).
CONTROLAPPLICATIONS Ltd does not accept liability for any
damage that may be caused by malfunction of the ElNet Pico
Energy Powermeter.

9
CONTROLAPPLICATIONS Ltd will advise the customer on the
proper installation and use of the ElNet Pico Energy
Powermeter , but will not accept any responsibility that the
instrument is suitable for the application for which it was
originally purchased.
This warranty may become void if the Installation, Parameter
Configuration & Setting Instructions are not carried out according
to the instructions set out by CONTROLAPPLICATIONS Ltd.
The ElNet Pico Energy Powermeter has no user serviceable
parts and should be opened and serviced by a duly qualified
authorized representative only. The sensitive electronics
could become damaged if exposed to a static environment. This
action would void the warranty.
This warranty is limited to the repair and/or replacement at
CONTROL APPLICATION Ltd sole discretion of the defective
product during the warranty period. Repaired or replaced products
are warranted for ninety (90) days from the date of repair or
replacement, or for the remainder of the original product’s
warranty period, whichever is longer.
CONTROL APPLICATIONS Ltd is always at your service to
advise the customer on any problem that may be encountered
regarding any installation, operation, parameter & configuration
settings or maintenance.

10
1.5 Your comments are welcome
CONTROLAPPLICATIONS Ltd. sincerely thanks you for
choosing our ElNet Pico Energy Powermeter . We are
confident that it will provide you with many years of trouble free
service and give you all the power and energy information and
history that you expected from the instrument when you bought it.
While every effort was made to keep the information as reliable,
helpful, accurate and up to date as possible, all possible
contingencies cannot be covered. Technical or typographical
errors could occur, and we would be happy to receive any
comments, criticisms or notifications of any such errors from you,
our valued customer.
Address: Control Applications ltd
24A HaBarzel St.
Tel-Aviv 69710
Israel
Tel: [phone]
Fax: [phone]
Electronic Address: [e-mail]

11
1.6 Disclaimer
Information in this User Manual is subject to change without
notice and does not represent a commitment on the part of
CONTROLAPPLICATIONS Ltd.
CONTROL APPLICATIONS Ltd supplies this User Manual as is
without warranty of any kind; either expressed or implied, and
reserves the right to make improvements and/or changes in the
manual or the product at any time.
While it is the intention of CONTROL APPLICATIONS Ltd to
supply the customer with accurate and reliable information in this
User Manual, CONTROL APPLICATIONS Ltd assumes no
responsibility for its use, or for any infringement of rights of the
fourth parties which may result from its use.
This User Manual could contain technical or typographical errors
and changes are periodically made to the information herein;
these changes may be incorporated in new editions of the
publication.

12
CHAPTER 2 —INSTALLATION
In this Chapter you will find the information and instructions that
the Installation Technician needs to mount and connect the
ElNet Pico Energy Powermeter.
During operation, hazardous voltages are
present in connecting cables and terminal
blocks.
Fully qualified personnel must do all work.
Failure to follow this rule may result in
serious or even fatal injury to personnel
and/or damage to equipment.
Refer to Section 1.3 Safety information before
carrying out any installation.
Read this manual thoroughly and make sure
you understand the contents before
connecting the ElNet Pico Energy
Powermeter to any power source.
WARNING!

13
2.1 Contents of packaging
To unpack the Elnet Pico Energy Powermeter
The Elnet Pico Energy Powermeter is packed and shipped
in a carton approximately 19x11x6.5 cm.
Before opening the package, ensure the area, clean and dry.
Without using any sharp instruments, carefully open the carton of
the Elnet Pico Energy Powermeter.
Please check the contents of the carton, it should contain:
1. New ElNet Pico Energy Powermeter.
2. ElNet Pico wiring diagram.
3. Test Certificate and Certificate of Compliance. (C.O.C)
4. 3 Current Transformers. (in case of Pico 60 only)

14
2.2 Mechanical mounting
To Mount the ElNet Pico Energy Powermeter
The ElNet Pico Energy Powermeter is manufactured with a
standard DIN rail mounting. To mount, simply choose a suitable
location and click into position.
Figure 2.1 Din Rail Mounting Diagram
Do not mount the ElNet Pico Energy
Powermeter too close to any main electrical
conductors
Allow sufficient space to carry out
maintenance to the ElNet Pico Energy
Powermeter
NOTE!
!

15
2.3 Wiring Schematics
To wire up the ElNet Pico 5 Energy Powermeter
Figure 2.2 Schematic Wiring Diagram

16
To wire up the ElNet Pico 60 Energy Powermeter
Figure 2.2 Schematic 60A Wiring Diagram

17
2.4 Connections
To connect the ElNet Energy Powermeter
All Connections are made via terminal connector plugs (Voltage
input, Power Supply, etc.).
Recommended max. tightening torque for the connector screws is
0.5 Nm.
The CT cores of the ElNet Energy Powermeter are located
internally in the instrument and the lead from the leg of the
external Current Transformer must be connected to the correct
terminal connector in order to maintain the correct direction.
NOTE!
Ensure all the connections to the leads of the current
transformer wiring is secure and there is no mechanical
strain on the wire
Connect the lead from side “L” to the terminal connector L at the
relevant phase, than connect the lead from side “K” to the
terminal connector K at the same phase, of the ElNet Energy
Powermeter.

18
WARNING!
WARNING
Never allow an open circuit between the two Current
Transformer leads.
Repeat the procedure for Line 2 and Line 3.
Connect the rest of the connections to the ElNet Pico Energy
Powermeter by means of terminal connector plugs.
The Front Panel (See Figure 2.3)has all connections printed and
is simple to follow. (See table 2.1 for connections).
Figure 2.4 Front Panel

19
Pin
Designation
Description
Remarks
L1
Line1 Supplied Voltage
Through a 6Amp fuse
L2
Line2 Supplied Voltage
Through a 6Amp fuse
L3
Line3 Supplied Voltage
Through a 6Amp fuse
N
Neutral
Measurement neutral Line
I1L
From Current
Transformer Lon Line1
Note the correct direction to
insert the lead
I1K
From Current
Transformer Kon
Line1
Note the correct direction to
insert the lead
I2L
From Current
Transformer Lon Line2
Note the correct direction to
insert the lead
I2K
From Current
Transformer Kon
Line2
Note the correct direction to
insert the lead
I3L
From Current
Transformer Lon Line3
Note the correct direction to
insert the lead
I3K
From Current
Transformer Kon
Line3
Note the correct direction to
insert the lead
RS485 -
RS485 Comm. (-) Line
RS485 +
RS485 Comm. (+) Line
Table 2.1 Front Panel connections

20
2.5 Manufacturing Data.
2.5.1 From the main menu, use the buttons to scroll to
Config menu and press “Enter”.
2.5.2 In the "PassWord…" menu use the buttons to change
the password to 1 and press “Enter”.
2.5.3 The Configuration menu will appear, use the buttons
to scroll to Information menu and press “Enter”.
2.5.4 The manufacturing Data will appear, use buttons to
scroll between the data, when finished press “Back”.
Number
Screen
Description
1
EDt
Production date of software operating system
2
Ver
Bios Revision
3
ID
Unique identifying number
Table 2.2 Production Data
C o n f i g
