Elnur Gabarron ECOMBI PROSSH Operation instructions

USER OPERATING INSTRUCTIONS
SMART STORAGE HEATER
ECOMBI PROSSH
MODELS
PROSSH158
PROSSH208
PROSSH308
PROSSH408
Please read these instructions carefully before installing or using this appliance for the first time.

1
INDEX
1. –IMPORTANT INFORMATION...................................................................................................................................2
2. - OPERATING INSTRUCTIONS..................................................................................................................................3
2.1. General information..................................................................................................................................................3
2.2. Commissioning...........................................................................................................................................................4
3.- ADVANCED SETTINGS ...............................................................................................................................................5
3.1. Operating mode.........................................................................................................................................................5
3.2. Date and time.............................................................................................................................................................6
3.3. Programme Settings..................................................................................................................................................6
3.4. Charge setting ............................................................................................................................................................9
3.5. Advanced settings....................................................................................................................................................10
3.6. Emitter Mode ...........................................................................................................................................................11
4.- REMOTE OPERATION USING THE G-CONTROL HUB.................................................................................12
5.- TROUBLESHOOTING ................................................................................................................................................12
6.- CLEANING MAINTENANCE INSTRUCTIONS...................................................................................................13
7.- MAIN COMPONENTS LIST.......................................................................................................................................13
8.- THECNICHAL FEATURES..........................................................................................................................................13

2
1. –IMPORTANT INFORMATION
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire,
electric shock, and injury to persons, including the following:
•Keep combustible materials, such as
furniture, pillows, bedding, papers, clothes,
etc. and curtains at least a foot (30cm) from
the front, sides and rear of the heater. It is
essential that the indicated minimum
clearances are maintained.
•CAUTION —Some parts of this product can become
very hot and cause burns. Particular attention must be
given where children and vulnerable people are
present.
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children
must not play with the appliance. Cleaning and user maintenance must not be made by children without
supervision.
•Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has
been placed or installed in its intended normal operating position and they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user
maintenance.
•Children of less than 3 years should be kept away unless continuously supervised.
•Do not operate any heater after it malfunctions. Disconnect power at service panel and have heater
inspected by a reputable electrician before reusing. To disconnect heater, turn controls to off, and turn off
power to heater circuit at main disconnect panel.
•Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an
electric shock or fire or damage the heater.
•Do not use this heater to dry clothes. To prevent a possible fire, do not block air intakes or exhaust in any
manner. Air inlets and outlets provide proper operation of the appliance and prevent its overheating. DO
NOT cover air inlet and outlet grills.
•A heater has hot and arcing or sparking parts inside. Do not use in areas where gasoline, paint, or
flammable vapors or liquids are used or stored. The use of these heaters is forbidden in any area where
there is a presence of gases, explosives or inflammable objects. Never open a charged heater.
•SAVE THESE INSTRUCTIONS. This guide must be kept and given to any new user. Use this heater
only as described in this manual. Any other use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The warranty of the heater will not cover any damage caused by non
observance of any of these instructions.
•Do not use this heater outdoors.
WARNING: In order to avoid overheating do not cover the heater.
WARNING: In order to avoid overheating do not cover the heater.

3
2. - OPERATING INSTRUCTIONS
2.1. General information
CAUTION: DO NOT USE THIS HEATER TO DRY CLOTHES. Do not cover this heater at any time.
CONNECTION / DISCONNECTION
Power switch. All models are equipped with a switch on the back
side panel. It is used to connect and disconnect ECOMBI PROSSH.
KEYBOARD:
Keep pressed the button to access the advanced configuration. Press this button to go back in the different menus.
Press the button to confirm values in the different menus.
Press the key to increase the displayed value or to advance through the different options available.
Press the key to decrease the displayed value or to move through the different options available.
ON/OFF
Once the heater is connected to a main supply you can turn the heater ON by switching the main ON/OFF switch positioned at
the rear right side of the heater as shown above.
BACKLIGHT
Pressing any button, the display will illuminate with a soft white colour. After certain time if no buttons are pressed the display
backlight will turn off.
Buttons only will respond when the backlight is on.
KEYBOARD LOCK
During any operation mode, it is possible to lock the keyboard by holding and simultaneously for 5 seconds. A pop-up
window will confirm the keyboard lock.
To unlock the keyboard, press and simultaneously for 5 seconds. A pop-up window will confirm the keyboard unlock.

4
2.2. Commissioning
An easy installation wizard is programmed in ECOMBI PROSSH electronic control. Follow the start wizard instructions when
turning your ECOMBI PROSSH on for the first time or after resetting it to the factory settings.
START WIZARD - INITIAL SETTINGS.
The ECOMBI PROSSH electronic control will guide you through the commissioning of the unit. The steps to follow are:
a. Select language. Confirm the language in the storage heater electronic control.
b. Date & Time. Check and confirm that the default date & time in the unit is correct. If not, please change it.
c. Charging periods. 2 different charging periods can be set in ECOMBI PROSSH. Set Charging Periods 1 & 2 according to your
electricity low tariff hours.
By default, ECOMBI PROSSH is set to an 7 hours charging period, from 00:00 to 07:00 hours. If this charging time matches your
electricity low tariff hours, you do not need to make any changes in the unit configuration. Otherwise, you can change charging
Periods 1 and 2 to match your electricity tariff.
d. Temperature setting. This is the last step of the start wizard. Select and confirm the room set temperature of your choice.
With the help of the start wizard, you will set you ECOMBI PROSSH storage heater for an autonomous operation. It will charge
and store the heat during the charging hours set in c.Charging Periods and it will adjust the charge level and consumption
according to the set temperature of your choice.
An incorrect time, charging periods or set temperatures configuration, might result in a high cost of the electricity bill.
i
i

5
3.- ADVANCED SETTINGS
With the general settings menu, you can make additional changes and adjustments in device start-up and operation. To access the
settings menu of the device, press and hold the button for 5 seconds in the home screen of any operating mode of the device
with the screen lit. The following screen appears:
Use or to move up and down. Confirm with to enter
the desired setting.
3.1. Operating mode
Scroll down to Operating Mode and press to access the operating mode selection menu. A new screen will appear with the
selectable operating modes:
-Basic mode or 24-hour temperature mode: The storage heater retains the setpoint temperature for 24 hours. In this
mode, the device automatically regulates and adjusts its charge day by day in order to maintain the temperature selected
with minimum expense. To change the basic mode setpoint temperature value, simply press or when the device
is operating in this mode until the desired temperature is displayed. The setpoint temperature and the charge level are
displayed on the screen in this mode.
ADJUST SETPOINT TEMPERATURE
-Weekly programme: The setpoint temperature varies in accordance with the weekly programme set in the unit. 3
temperature levels (Comfort, Eco and Frost Protection) can be selected for each time interval (1 hour) in order to adjust
the temperature of the room to the habits and needs of the different users. You can alter the setpoint temperature of each
of the 3 temperature levels (See section 3.3.1 Temperatures. Edit Programme) as well as the corresponding temperature
level at each hour of the week. (See section 3.3.2 Weekly programme. Edit programme). The horizontal temperature
display for the 24 hours of the current day appears on the screen together with the setpoint temperature of the current
period.
-Off: The storage heater does not retain any temperature or follow any programming, as it retains the time setting previously
set. The compensation element will be activated if the room temperature is below the Frost Protection in order to prevent
freezing. The set point temperature (3ºC) and the Frost Protection message appear on the screen.

6
3.2. Date and time
You can see the device time at any time in the top left corner of the screen. The date can be seen in the “Date and Time” menu.
To change the time or the date, access the advanced settings menu by pressing for 5 seconds and
then access the “Date and Time” menu. The Date and Time menu will allow you to change the following
values:
-Date: Use or to select the desired day/month/year. Confirm with .
-Time: Use or to select the desired hour/minute. Confirm with .
-Date format:Use or to select the desired format. Confirm with .
-Time format:Use or to select the desired format. Confirm with .
If the device is connected to a G Control hub, the time setting is overridden and the hub time is set automatically. In this case, the
time set menu will not be accessible.
The ECOMBI PROSSH automatically changes the time from wintertime to summertime and vice-versa, even if it is not connected to
the G Control hub, provided that the Automatic Time Change parameter is activated. (Activated by factory setting).
3.3. Programme Settings
This menu will only be accessible when the device is operating in the operating mode Weekly Programme. In this menu, you
can change the comfort, eco and frost protection temperatures and select or change the existing weekly programming.
To do this, access the advanced settings menu by pressing for 5 seconds and then go into the “Programme settings”menu.
3.3.1. Temperatures. Programme Settings
You can change the setpoint temperature value of the 3 temperature levels used in the Programme Mode (Comfort, Eco and Frost
Protection) at any time.
To do this, access the “Temperatures” menu and change “Comfort”, “Eco” or “Frost Protection” as you wish. Press to exit the
home menu.
It is possible to change the setpoint temperature temporarily in the home screen during the current period of the programme mode.
You can do this by simply pressing the or buttons. The temporary change is retained until the next change of programmed period.
i
i
i

7
3.3.2. Weekly Programme. Programme Settings.
In the “Weekly Programme” menu you can select from one of the 3 predefined programmes or you
can edit the existing programme from the “Weekly Programme” menu in order to set a customised
programme.
3.3.2.1. PREDEFINED PROGRAMMES
In this section you have the option of selecting one of the 3 operating programmes preset in the device.
Programme 1 (At home)
Monday to Sunday:
•00:00 - 07:00 Eco ( )
•07:00 - 22:00 Comfort ( )
•22:00 - 00:00 Eco ( )
Programme 2 (Work M-F)
Monday to Friday:
•00:00 - 07:00 Eco ( )
•07:00 - 08:00 Comfort ( )
•08:00 - 17:00 Eco ( )
•17:00 - 22:00 Comfort ( )
•22:00 - 00:00 Eco ( )
Saturdays and Sundays:
•00:00 - 07:00 Eco ( )
•07:00 - 22.00 Comfort ( )
•22.30 - 00:00 Eco ( )
Programme 3 (Office hours)
Monday to Sunday:
•00:00 - 07:00 Eco ( )
•07:00 - 18:00 Comfort ( )
•18:00 - 00:00 Eco ( )
3.3.2.2. WEEKLY PROGRAMME:
If you do not want to use any of the factory preset programmes, you can set a customised programme from the “Weekly
Programme”menu.

8
To do this, scroll down to the day that you want to programme and press . Select “Edit” and press to programme the
day selected.
The first segment of the day of the week corresponding to the period 00:00 →01:00 starts to flash. The bar diagram at the top
part of the screen represents the temperature levels programmed for each hourly period of the day
in question.
-3 bars represent the hourly period with comfort temperature programmed. ( )
-2 bars represent the hourly period with eco temperature programmed. ( )
-1 bar represents the hourly period with frost protection temperature programmed. ( )
By pressing you can select the desired temperature level for the current hourly period: Frost Protection , Economy
or Comfort .
Press to go to the next hour. When you have set the different hourly periods for the day selected, press and the
setting for this day will be recorded.
COPY THE DAILY PROGRAMME, GO TO THE NEXT DAY
You can copy the programme of the current day to the other days of the week. To do this, scroll down to the day that you
want to copy. Press and select “Copy”.
Select the days you want to copy the programme to.
Scroll down to “Save”, press and the copy of the programme will have finalised.
If you want this setting to be stored as a preset programme, select “Save” in the next screen.
Press and a new preset programme will be generated with the name USER, which you can see and select at any time in the
“Preset Programmes” menu.
ECOMBI PROSSH will not charge at intervals set to Frost Protection . It is recommended to reserve this temperature level solely
for complete days on which you do not require heating.
i

9
3.4. Charge setting
The Charge Setting menu allows you to change the factory preset charging period of your storage heater to match the off-peak
period of your hourly tariff, as well as the days of the week on which you need the storage heater to charge. The standard factory
preset period is 00:00 to 07:00 and the charge is active every day of the week.
3.4.1 Charging periods
Go into the “Charging Periods” menu if you want to change the charging periods for your device.
2 charging periods are selected in ECOMBI PROSSH.
-1st charging period: Factory setting of 00:00 to 07:00.
-2nd charging period: (Factory disabled, 00:00 to 00:00).
The factory setting for both periods can be changed as you wish. Enter the period that you want to alter and change the start and
end time to adapt to your tariff.
3.4.2 Charging days in the week
It is possible to select the days of the week on which the ECOMBI PROSSH heater will charge and those on which it will not.
Access the “Charging Days” menu and select the days on which you want the storage heater to charge.
If a day of the week is selected as a non-charging day, the ECOMBI PROSSH heater automatically sets the Frost Protection setpoint
for this day in the Programme mode and automatically assigns this temperature to the 24 hours of the non-charging day in the Basic mode.
3.4.3 Initial charge
The initial factory setting charge is 100%. It is the charge value of the device at the start of an extended period of inactivity or from
its installation. Subsequently, during its operation, the device self-regulates the day-to-day level of charge so that it operates
efficiently in accordance with energy needs.
To change the charge percentage, from the “Initial Charge” menu, go into “Edit”, select the desired charge value and select “Save”.
If the balancing heating element is disabled, ECOMBI PROSSH will not automatically calculate the day-to-day charge and will always
retain the maximum charge value that has been set in the initial charging parameter as the target charge.
i
i

10
3.5. Advanced settings
With the advanced settings menu, you can change general settings in the device, as well as its advanced operating settings. To
access the advanced settings menu, press for 5 seconds and then select the “Advanced” menu. The Advanced Settings menu
comprises the following parts:
•General settings.
•Operating settings.
•Reset.
•Parameters (Reserved for installer and factory settings. Any change can alter the behaviour of the
device).
3.5.1 General settings
-LANGUAGE: Select the language that you want.
-UNITS: Choose between “Celsius” and “Fahrenheit”, according to the temperature unit that you want.
-AUTOMATIC TIME CHANGE: Activate or disable the automatic time change, from winter to summer and vice-
versa.
-AMPLIFIER: Activate or disable the sound of the keystrokes on the keyboard.
-SCREEN:
oTime on: selects the time it takes for the display to turn off after you stop using
the keyboard.
oBrightness activated: selects the percentage of brightness when the screen is on.
oBrightness disabled: selects the percentage of brightness when the screen is off.
oStyle: select the screen design style.
▪Light B/W: white background and black letters.
▪Dark B/W: black background and white letters.
▪Colour: Home screen with coloured icons.
3.5.2 Operating settings
-BLANCING HEATING ELEMENT:
oStatus: Balancing heating element active or inactive.
oMaximum peak times: Maximum operating time of the balancing heating element during tariff on-peak
periods. Set this value to “0” to disable the operation of the balancing heating element in tariff on-peak
periods; in this case the charge correction will not work and the same level of charge will apply to every
day.
-FROST PROTECTION: Activate or disable the frost protection mode if the device is operating in Off mode.
-OVERLOAD PROTECTION: Protection against excessive temperature whilst charging. Degrees above the comfort
setpoint at which the storage heater stops charging. (Selectable values 0,1,2,3,4 and 5).

11
-CONTROL TYPE: Select the temperature control type. A PID device with default settings programmed is
recommended.
-OPEN WINDOW DETECTION: Activates when open windows detected (On/Off).
-INTELLIGENT START-UP: Adaptable start-up activation (On/Off).
-COMPENSATION: Correction of room temperature (Values from -5ºC to 5ºC).
3.5.3 Reset and default factory settings
You can reset the unit and restore factory setting configuration.
Default Values
Parameter
Sun: Comfort temperature
21ºC
Moon: Economic temperature
18ºC
Frost protection temperature
3ºC
UP01: Initial % of storage charge
100%
UP02: Starting time off peak period 1
00:00
UP03: Ending time off peak period 1
07:00
UP04: Starting time off peak period 2
00:00
UP05: Ending time off peak period 2
00:00
UP06: Charging days of the week
Charging 7 days of the
week.
UP07: Ambient sensor Offset
0ºC
UP08: Max. Balancing element –working period
16 hours
UP09: Overtemperature protection
2ºC
UP10: Temperature Unit
ºC
UP11: Open Window Detection Function
Off
UP12: Adaptive Start Control
Off
UP13: Kind of temperature control
PID
Incorrect time settings, erroneous programming of the reduced rate time and too high temperature settings may result in a high cost
of your electricity bill.
3.6. Emitter Mode
This operation mode is used when it is necessary to heat the room temporarily and there is no need for storage heating. To set
this mode, turn off the unit by pressing the main switch on the back-side panel and keep pressed at the same time you turn
on the unit by pressing the main switch until the message 19.0E is displayed on the display.
-Emitter mode is a temporary operation mode. You cannot access from this mode to general setting menu,
operation mode menu or any other settings.
-Use and to modify the set-point temperature for this operation mode. The unit will turn on the
balancing heating element if required in order to provide instantaneus heat to the room.
-The unit will not charge within this mode.
To exit emitter mode and go back to the commom operation mode, just turn off and turn on the unit again by pressing the main
switch on the back-side panel.
i

12
4.- REMOTE OPERATION USING THE G-CONTROL HUB
It is possible to control the full operation of the unit remotely with the Elnur Gabarron Wifi Control app or the app-web
(https://remotecontrol.elnur.es). The unit must be connected to a G-Control Hub connected to the internet to use this feature.
To associate the ECOMBI PROSSH unit to the G-Control Hub, follow the instructions of the installation wizard of the app.
-Open the application and login with your user and password.
-Access the heating menu in the top menu in the app.
-Press the button (+) and select the type of heater that you are going to connect (Storage heater).
-Press Start Search and follow the instructions of the installation wizard.
When required, keep pressed button during 3 seconds until the symbol is displayed in the storage heater display.
You can control now and adjust the settings of your storage heater using the Elnur Gabarron Wifi Control app or the app-web
https://remotecontrol.elnur.es.
5.- TROUBLESHOOTING
ECOMBI PROSSH does not
heat.
Please check it is connected and switched on.
Make sure the device is not covered or the lower air inlets are not obstructed. The LR safety limit
may be activated; in this case it is necessary to reset it manually. Please contact technician.
ECOMBI PROSSH does not
reach set up temperature
Make sure that adequate temperature is selected.
Make sure the storage heater is sized correctly for heat loss.
Error messages in display
Please contact technician.
ECOMBI PROSSH does not
communicate with the G
Control Hub.
Check the unit is associated, the symbol must be shown on the display.
For distances greater than 30 metros and 2-3 walls, associate first the closest units. Each unit can
work as signal extender.
If symbol is flashing, check the G Control Hub connexion to the network, and if any other device
in the RF Net that could be working as signal extender has been removed.

13
6.- CLEANING MAINTENANCE INSTRUCTIONS
Before cleaning, make sure the power has been turned off at the circuit breaker panel and that the heating element of the heater
is cool.
Occasionally, clean dust with a dry, soft cloth. Do not use any solvent or abrasive product for cleaning.
When the Heating season is finished, please disconnect the device by turning off the power switch located at the right back of
the unit or at the circuit breaker.
Any other servicing should be performed by an authorized technician.
ECOMBI PROSSH has been manufactured under a fully assured quality system and using environmentally friendly processes. Once its
useful life is finished please take the device to a recycling depot so that its components can be recycled in an appropriate way.
7.- MAIN COMPONENTS LIST
Storage Heating Element (All except PROSSH158)
Ref. 15190091
Power PCB & Fixing Bracket
Ref. 15191890
Storage Heating Element (PROSSH158)
Ref. 15190875
Keyboard PCB PROSSH
Ref. 15192680
450W Balancing Heating Element (PROSSH158)
Ref. 15190105
PT1000 Core Sensor
Ref. 15192140
600W Balancing Heating Element (PROSSH208)
Ref. 15190110
Room Sensor
Ref. 46102195
900W Balancing Heating Element (PROSSH308)
Ref. 15190120
110ºC Balancing Element Limiter
Ref. 15190725
1200W Balancing Heating Element (PROSSH408)
Ref. 15190130
135ºC Cut Out Manually Limiter
Ref. 10190460
Switch
Ref. 15190055
8.- THECNICHAL FEATURES
Storage heater elements and balancing heating element will never operate at the same time.
i
i
PROSSH158
PROSSH208
PROSSH308
PROSSH408
Connection
230 - 240V ~
230 - 240V ~
230 - 240V ~
230 - 240V ~
Balancing Element Output
450/490W
600/653W
900/980W
1200/1307W
Insulation
Class I
Class I
Class I
Class I
Length
55cm
66cm
89cm
111cm
Height
73cm
73cm
73cm
73cm
Depth
18cm
18cm
18cm
18cm
Weight
59kg
77kg
112kg
147kg
Number of bricks
4
8
12
16
Brick Package
11072
11016
11016
11016
Storage Heater Output
975/1062W
1300/1415W
1950/2123W
2600/2831W
Charge Period
7.6 –7h
7.6 –7h
7.6 –7h
7.6 –7h
Charging
7.4 kWh
9.9 kWh
14.9 kWh
19.8 kWh
The symbol on the product or in its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the shop where you
purchased the product. These instructions are only valid in the EU member states.

14
NOTES
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………
…………………………………………………………………………………………………

As a part of the policy of continuous product improvement Elnur UK Ltd. reserves the right to alter specifications without notice.
ELNUR UK Ltd.
Unit 1, Brown Street North
Leigh, Lancashire. WN7 1BU
Telephone:
[phone]
www.elnur.co.uk
[email protected]
15190045 R1.1
