Eloflex H User manual

INSTRUCTION MANUAL
FOR USE, DRIVING AND SAFETY
Read this documentation before using your Eloflex
to make sure that you use it in a manner that is safe, and which does not harm you,
your environment or your power wheelchair.
Eloflex
H

2
Thanks and good luck!
Thank you for choosing an Eloflex as your power wheelchair. It means a lot to us because
our vision is to make people’s everyday life a little easier and to give people with disabilities
a greater freedom. We hope you experience both with the help of your Eloflex.
We believe that you will enjoy much of your new power wheelchair. This manual contains
important information on safety, use and care. We encourage you to read through this
entire documentation before using your Eloflex for the first time. We also suggest that
you train to run your Eloflex on a secluded, open and level surface before using it in
other contexts. Eloflex power wheelchair is designed for users with many different needs.
Decide whether Eloflex is suitable for the user is always taken by the ordinator or dealer
together with the user himself. Eloflex accepts no responsibility for cases where the power
wheelchair is not adapted to the user’s needs.
An Eloflex should primarily be used in its standard design. If the power wheelchair has
to be adapted or altered in any way, it must only be carried out by your assistant center
or by Eloflex. Please note that damages and faults caused by non-compliance with the
operating instructions or due to poor maintenance are not covered by the warranty.
Good luck and great joy with your Eloflex.
Drive carefully!
Content Page
Intended use 3
Folding 4-5
Install the joystick 6
Fold down the joystick 6
Charging instructions 7
Manual driving 7
Adjust the armrests 8
Footrest 8
Driving Handle 9
Anti-tip device 9
Page
Seat Belt 9
Adjustment of Lumbar Support 10
Adjust the back 10
Adjust the Locking Mechanism 11
Transport and storage 11
Joystick 12
Navigate the menus 13
Driving 14-15
Safety 16-17
Technical specifications 18
Contact 18

3
Type classification and intended use
Eloflex power wheelchairs have been developed for people
who have difficulty walking or cannot walk at all, but who
have vision ability, physical ability and mental ability to control
a power wheelchair.
The Eloflex power wheelchair is sufficiently compact and
flexible for indoor use, but the chair is also suitable for
outdoor use. The chapter ”Technical data” at the back of this
document contains information on speed, turning radius,
range, maximum lifting capacity and maximum weight for
the user and so on. We encourage you to read all safety
information in the chapter ”Safety” in this document.
Eloflex is tested and approved according to EN12184: 2014
- class B (indoor and outdoor use). Eloflex is also approved
according to ISO-7176, IEC60601 and the batteries are
approved according to UN38.3.
Eloflex power wheelchairs meet the applicable requirements
of the MDR 2017/745.
Class 1 conformity assessment / CE marking has been
issued in accordance with Annex VIII Chapter III of MDR
2017/745. Conformity assessment procedure: Annex II and
Annex III of MDR 2017/745.The CE marking will be void if you
use replacement components or accessories that have not
been approved for this product.
Needs
The purpose of an Eloflex power wheelchair is to
compensate for an injury or disability, which is why it is
recommended in the following circumstances:
• If the user has the inability to walk or very limited ability
to walk, which makes it difficult to move in his / her own
home.
• If there is a need to leave the home to get out or to visit
places that are normally visited in order to carry out
everyday affairs.
• When the user has difficulty getting to, or performing work
or activities because of his / her mobility disabilities.It is
advisable to use Eloflex power wheelchairs both indoors
and outdoors, if it is not possible to use hand-operated
wheelchairs due to mobility problems, but it is still possible
to properly handle power wheelchairs.
Accessories
Chargers and bag with simpler tools are available when
delivered in the storage bag under the seat.
Utility
Only use the Eloflex power wheelchair when fully functional.
Otherwise you put yourself and others at risk. The following
list does not include all possible situations. It describes only
certain situations that may affect the usability of the power
wheelchair.
• Do not use the power wheelchair if the batteries are
defective or deformed
• Do not use the power wheelchair if the engine is jerky or
makes abnormal noise
• Do not use the power wheelchair if the brake function
appears to be wrong
• If your tires are worn, contact your assistant center or
dealer
• If you notice any damage to the seat belt, armrest, seat,
backrest, joystick or other part of the chair, contact your
assistant center or dealer.
• If you notice any damage to the electrical system (cables,
batteries, chargers, etc.), please contact your assistant
center or dealer
Manufacturer’s warranty
The Eloflex warranty replaces parts that are broken, the
damage must not be caused by the user. The warranties do
not cover damage caused by external circumstances such
as theft, abuse, misuse, lightning, or modification.
Life span
The estimated lifetime of an Eloflex is 5 years. However, the
life of the product is largely affected by how it is used and
managed. An Eloflex can have a much longer life if you take
care of it in a good way and only use it in line with the
information in this document.
Safety regulations and risks
PLEASE READ THE SAFETY INSTRUCTIONS FROM THE
PAGE 14 BEFORE YOU USE YOUR ELOFLEX.
Intended use

4
Folding
Fold up
1. Stand the folded chair upright and
unfold the footrest. Image 1.
2. Grip the handle at the back of
the backrest and pull backward.
Simultaneously, hold onto the seat
cushion with one hand. Image 2.
3. Close the locking latch. Image 3.
4. Extend the tipping guards by
pressing the button and then
swinging out the tipping guard.
Image 4.
5. Raise the armrests to the desired
height. Image 5.
3
IMPORTANT!
It is very important
that you close the lock
before using
the power wheelchair.
5
4
Fold out
Push
1
2
”Click”

5
Fold in
Push
Folding
1
Collapse
1. Lower the armrests. Image 1.
2. Fold in the tipping guards by
pressing the button and then
swinging them inward. Image 2.
3. Open the locking latch. Image 3.
4. Grip the handle at the back of
the backrest and push forward.
Simultaneously, hold onto the seat
cushion with one hand. Image 4.
5. Fold in the footrest. Image 5.
Learn more…
… about adjusting the
armrests on page 8.
5
4
2 3

6
Fold down the joystick
The smart joystick mount allows the
user to quickly lower the joystick without
removing it. This means that you get
closer to the edge of the table, which
gives a better sitting position.
1. Lift the lock lever to release the joystick.
2. Gently pull the joystick forward.Then let
the joystick hang straight down.
Install the joystick
Step 1
Mount the joystick in the tube under the
armrest and tighten the screw in the
desired position.
Step 2
Assemble the cable connectors and
gently rotate until the pins enter the
holes and the grooves in the two
connectors engage. Then screw the
sleeves together on each contact.
IMPORTANT!
Be careful not to
damageor bend the
pins in the connector.

7
Manual driving
Turn off the power wheelchair with the
joystick. Then push the red levers on
the motors (see picture) to disconnect
the magnetic brakes. In this position,
the chair can be rolled manually.
Note! If the user uses the chair without
assistance, the magnetic lock of the
chair must always be switched on.
ON OFF
IMPORTANT!
NEVER connect
the charger directly
to the battery.
This is how you charge
Start by turning off your Eloflex (all lights
on the joystick should be off). Connect
the charger to the socket on the front
of the joystick. Make sure that the
contacts’ position matches each other.
Then plug the charger’s power cable
into a wall outlet.
Charging is indicated by a lamp on the
charger. Red lamp means that charging
is in progress. After about three
hours, the batteries are charged at 90
percent. The chair can now be used
again.
After about 5-8 hours, the light on
the charger becomes green and the
batteries are fully charged. During
charging, the charger itself becomes
warm, and this is normal. Charging
instructions should take place for about
Charging instructions
five hours when the bar on the battery
indicator at the joystick has dropped
three lines.
The batteries will not be damaged by
maintenance charges but for maximum
battery lifespan we recommend that
you disconnect the charger when the
batteries are fully charged. Charging
the batteries can be done down to
-10 degrees. When charging in lower
temperatures, the batteries will not get
fully charged.
If your Eloflex is used in minus degrees,
the mileage is affected. For example,
at -10 degrees, the mileage can be
reduced by up to 50 %.

8
For optimal seating comfort, you can
adjust the height of the armrests.
1. First release the lock by lifting the
lock lever.
2. Then raise or lower the armrests to
the desired height.
3. Lower the locking lever.
Adjust the armrests
For easier entry and exit, the footrest can be folded up as shown down below.
Footrest
TIP!
It’s also possible to
completely remove the
armrests for easier getting
in and out.

9
Anti-tip device
You can fold in the tipping guards when
folding the chair and during transport.
1. Press the button
2. Fold in the tipping guard.
NOTE! The anti-tip devices must
always be extended when using
the chair.
Seat Belt
For safe driving, we recommend always
using the seat belt when operating the
chair.
Driving Handle
The driving handle is used for manually
pushing the chair. The driving handle
can be folded up when not in use.

10
Fold up the trim of the back by pulling
it. Tighten the Velcro straps for a
comfortable sitting position. Then fold
the trim down and press lightly so that
it gets stuck in the Velcro strips.
Model H is equipped with a convenient
lumbar support for optimal seating
comfort. To adjust the lumbar support,
follow these steps:
1. Lift the front of the backrest.
2. Loosen or tighten the lumbar
support using the Velcro fastener to
your desired level of support.
3. If you do not want any lumbar
support, remove the entire lumbar
support.
Adjustment of Lumbar Support
Adjust the back

11
• To lift the chair, it is recommended
that the chair is first folded.
• A folded chair can be put in the
luggage of a car or set in a wardrobe.
• If the chair is not to be used for
a while, we recommend that the
batteries be fully charged before the
chair is set aside.
• The chair should be stored indoors in
frost-free, dry and ventilated areas.
Storage temperature 0-30 degrees.
• When transporting by bus or by
handicap transportation, the Eloflex
must be attached to the fastening
points shown in the pictures at the
bottom. Note that Eloflex is not tested
as a car seat. We therefore always
recommend that the user moves
over to the car’s own seats.
Transport and storage
Adjustment of the Locking Mechanism
It’s important that the locking
mechanism on your Eloflex chair moves
with resistance when pulled up and
down. It should be difficult enough to
stay in an upright position on its own.
This is crucial to ensure that the locking
mechanism remains securely in its
locked position even when the springs
are compressed.
To make the locking mechanism move
with more resistance, you only need
to tighten the fastener with the two
hex screws that secure the locking
mechanism in place.
It’s important
that the locking
mechanism
moves with
resistance up
and down to prevent it from
opening when using the chair.
• When transporting by flight, please
check with your airway company.
Eloflex follows the recommendation
of IATA.

12
Power on and off
LCD
Multifunctional buttons
Horn
USB connector
Joystick
Speed indicator: All lines
white = maximum speed.
Trip meter: This shows the
distance you have driven
and the current speed.
Battery control: How
much power is left in the
batteries is indicated.
When the batteries are fully
charged, all bars are white.
As the batteries run down,
the lines go out in turn.
Charge when three bars
have gone out.
1
2
TIP:
Use the USB connector
on the underside of the
joystick to charge
your mobile phone.
Reduce/increase speed
Joystick
On/Off light
1
1
13
3
Charger input
Light
Joystick: Controls the
chair’s speed and direction.
Power on and off:
Press to turn your Eloflex on
and off.
Horn: Press to call attention.
Increase speed: Press to
increase the chair’s maximum
speed.
Reduce speed:
Press to reduce the chair’s
maximum speed.
On/off light: Press to turn the
light on or off.
2
2
2

13
Navigate the menus
Language
Speed unit
Volume
Return Enter
Function list
Change settings
You can change the chair's settings such as language, horn
volume and measurement units.
1. To enter the settings, press the right multifunction button. A list
of multiple choice options will then open.
2. In the multi-choice list, scroll up and down with the speed
buttons.
3. Select function with the right multifunction button (Enter) or go
back one step with the left multifunction button (Return).
1
1
2
3

14
DRIVING
There is a risk of injury by tipping the wheelchair.
• Only drive in inclines that do not exceed the
maximum allowable slope
• Always use anti-tippers when traveling with Eloflex
• Driving downhill should always be done at a lower
speed
• Avoid areas where there is a risk of icy or slippery
surfaces
• Never try to drive up or down stairs with your
power wheelchair
• Never drive over obstacles higher than the
recommended maximum height
• Avoid rapid movements with the joystick and
sudden changes in driving direction while driving
Risk of being stuck in remote places.
• A user with greatly reduced mobility should not
drive longer distances outdoors alone
Risk of injury if one foot slips off the footrest and falls
under the powered wheelchair while driving.
• Always place your feet in the middle of the footrest
while driving
Risk of injury if you collide with other objects in narrow
passages.
• Drive through narrow passages with the lowest
speed and greatest attention
There is a risk that the wheelchair will tip over if the anti-tip
devices are removed, damaged or mounted at a position that
deviates from the standard mounting.
• The anti-tip devices must always be mounted
when the power wheelchair is used
• The anti-tip devices only work on a solid surface.
On soft surfaces such as lawns and snow, the
anti-tip device can lose its effect. Therefore, drive
extremely carefully on soft surfaces.
Safety instructions when driving

15
Driving
Read
The user must read these safety and driving
instructions before using the Eloflex power
wheelchair.
Practice
Practice makes perfect. Train to drive your Eloflex together
with an assistant by starting on an open plan surface,
preferably outdoors, before using your power wheelchair
among other people, in stores or restaurants etc.
Move forward by moving the joystick slowly forward.
Stop by releasing the joystick.
Reverse
Reverse by moving the joystick slowly backwards.
To stop, release the joystick. Remember to always look
backwards before you start reversing to be sure that no
person or thing is in the way.
Spin
Spin by moving the joystick gently sideways. Take care so
nothing is in the way of the sides when you spin.
Turn
Turn as you drive by gently moving the joystick sideways in
the same direction you want to turn. Always lower the speed
when turning.
Obstacle
Practice avoiding and passing obstacles. Move the joystick
sideways while driving forward to avoid obstacles. Remember
to lower the speed as you approach obstacles.
Fast driving
Fast driving: Press the joystick in the forward position if you
want to drive fast. Remember to retract the joystick and lower
the speed as soon as you feel insecure, whether you are
turning or approaching an obstacle
Run over obstacles
Drive slowly to the obstacle and make sure the front wheels
are in the direction of travel. Then move the joystick slowly
forward while leaning backwards to drive over the obstacles
Eloflex is tested and approved for obstacles up to a maximum
of 6 cm.
Run on slope
Try driving straight up or down for an inclined surface. Lean
slightly forward as you drive up, and backwards as you drive
down, to maintain the center of gravity. Avoid driving sideways
if possible and compensate for any side slope by leaning in
the opposite direction. Always drive slowly on slopes. Avoid
surfaces that tilt more than 9 degrees.
Elevators
Remember to check the width of the elevator door and how
quickly the door is closed before you enter the lift. Keep in
mind that you may have to reverse out of the lift if it is not
large enough to allow you to turn around
Driving on the road
Drive primarily on sidewalks, walkways and cycle paths and,
ultimately, on busy roadways with your Eloflex.
Cross the roadway
if possible, always choose to cross the road at a pedestrian
crossing. Pay attention to intersecting cars. Use chamfered
part of the pavement if available.
Avoid curbs higher than 6 cm.

16
SAFETY
There is a risk of personal injury if the power wheelchair
is used for purposes other than those described in this
document.
• Use the power wheelchair only according to the
instructions in this manual (see above, chapter
”Type classification and intended use”)
There is a risk of personal injury if the power wheelchair is
used for reduced driving ability.
• Do not use the wheelchair when your driving
skills are impaired due to, for example, illness,
medication or alcohol.
There is a risk of injury if the power wheelchair is involuntarily
moved.
• Switch off the wheelchair before boarding and
exiting or if there is a risk that you, another person
or an object could come in contact with the
joystick.
• When the motors are disengaged, the brakes
do not work. Therefore, the wheelchair must
only be pushed on flat ground, never on slopes.
Never leave the wheelchair in or near slopes with
disengaged motors.
There is a risk of personal injury if the powered wheelchair is
switched off during travel with, for example, the on / off button
or by tearing off a cable, as it stops with a hard jerk.
• Release the joystick when braking in an
emergency. Then the wheelchair stops
automatically.
There is a risk of injury due to falls from the wheelchair
• Do not move forward, do not bend forward
between the knees and do not lean over the
wheelchair edge, for example to reach objects.
• Always use a seat belt and re-adjust it before each
trip.
• Drive as close to the new seat as possible when
transferring to another seat. There is a risk of
personal injury if the maximum permissible load is
exceeded.
• Observe the maximum permissible load (see
chapter ”Technical data” at the back of this
document).
• The power wheelchair may only be used by
a single person. Never use the wheelchair to
transport more than one person at a time.
There is a risk of personal injury and damage to the
wheelchair if the lock is released when folding is not properly
clamped when the power wheelchair is used.
• If the power wheelchair’s lock has not clicked into
place properly, the chair can suddenly collapse
when used, which can cause you to fall out of the
wheelchair.
• Always ensure that the locking hook is in a correct
position before using the power wheelchair. There
is a risk of personal injury and crushing damage
when folding the wheelchair.
• Always fold and raise the power wheelchair as
described in the operating instructions.
• Pay attention so that none or nothing is squeezed
when folding and unfolding.
There is a risk of personal injury and damage to the
wheelchair if it is used in damp areas.
• The power wheelchair must not be used during
showering.
• The power wheelchair must not be used when
bathing.
General safety instructions

17
Safety
Crossing railway tracks
Always cross the railway track straight from the front, never
obliquely from the side. Never cross the railway tracks alone,
always have someone with you who can help you.
Sharp edges
Be careful when driving on steep slopes, as the chair is likely
to break. Eloflex is tested and approved for gradient with a
maximum of 9 degrees. Always have someone with you who
can help you.
High edges
Be careful when driving up or out for an edge. Eloflex is tested
and approved for edges up to a maximum of 6 cm. Always
have someone with you who can help you.
Transfer
We recommend that you always have someone who can
help you with transfers to and from your Eloflex. Always turn
off the power before starting the movement. Always lift up the
armrests and footrest before moving to make getting in and
out of the chair easier.
Don’r repair on your own
Never try to repair a broken power wheelchair on your own.
If you try to repair the chair yourself, the warranty does not
apply. Always turn to Eloflex or to the shop or assistant center
that sold / prescribed the chair. Never modify your power
wheelchair on your own.
No toy
Never allow children who do not normally use an power
wheelchair to sit on or use your Eloflex
Cleaning
Never clean your Eloflex with running water. Only wipe it with a
damp cloth. If your Eloflex is slow to fold up and together, you
can lubricate the joints with oil or silicone spray
Beware of heat
Never leave your Eloflex in direct sunlight or near a heat
source as the batteries may be damaged. Never be near
open fire with your Eloflex. You can use your Eloflex from -10
degrees up to +45 degrees. At freezing temperatures, the
range can be affected.
Storage
Keep your Eloflex out of the reach of children when not in use.
The chair should be stored indoors in frost-free, dry and
ventilated areas. Storage temperature 0-30 degrees.
The charger
The charger must never be covered when used to charge
your Eloflex. The charger becomes hot and there is a risk of
accident or injury.
Batteries
Never store the batteries in direct sunlight or in a location that
can reach below zero temperatures. The batteries should be
stored in a dry and ventilated place.

18
© Copyright Eloflex
This document contains copyrighted information and may
not be copied or reproduced in whole or in part without the
written permission of Eloflex. Eloflex is reserved for any
typographical errors in this document and we reserve the
right to product changes.
Contact Eloflex
If you have any questions or need help, please contact your
help center or dealer. If you want direct contact with us, you
will find contact information on our website, www.eloflex.eu.
Eloflex
Hammarbacken 4B
191 49 Sollentuna
SWEDEN
Teknisk data
2021-05-08
Version 2.0
Sungo Europe B.V.
Olympisch Stadion 24, 1076DE
Amsterdam, Netherlands
SRN:NL-AR-000000247
Kunshan Aoshida Electric Technology Co., Ltd
No. 108 Matang Road, Penglang Town, Development Zone, Kunshan City, Jiangsu
MODEL H
Weight 43 kg without batteries
Total weight 49,5 kg including batteries
Range 40 km
Max load 200 kg
Speed 8 km/h
Motor 2 x brushless motors
Motor effect 2 x 400 Watt
Battery 2 x Litium ION 20AH/24V
Battery effect 2 x 480 Wh
Charging time 3 hours
Turning radiation 99 cm
Wheels Front 9” air, rear 13” air
Seat height 54 cm
Seat width 51 (56, 61) cm
Seat depth 51 cm
Backrest Adjustable
Size 103x66x115 cm
Size folded 83x66x45 cm
