Sunrise Medical Quickie Q200 R User manual

Supplier: This manual must be given to the user of this
wheelchair.
User: Before using this wheelchair read this entire
manual and save for future reference.
QUICKIE Q200 R
General Manual
Instructions for Use
Instructions for Use
P/N 253470 Rev. B
P/N 253470 Rev. B
Distribuidor: Este manual debe ser entregado el usuario de
esta silla de ruedas.
Usuario: Antes de usar esta silla de ruedas, lea este manual
en su totalidad y guárdelo para futura referencia.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español y francés
está disponible en formato PDF en nuestra página en Internet: www.SunriseMedical.com. Ingrese a la
página del producto específico para descargar el manual, o comuníquese con el proveedor autorizado
de Sunrise Medical.
Au Fournisseur: Ce manuel doit être remis à l’utilisateur de ce
fauteuil roulant.
Utilisateur: Avant d’utiliser ce fauteuil roulant, lisez l’intégralité
de manuel et conserver pour référence future.
Chaque fauteuil est livré avec un manuel d’instructions en anglais. Les versions en espagnol et en
français sont à votre disposition en format PDF sur le site : www.SunriseMedical.com. Veuillez vous rendre
à la page de votre produit pour télécharger le manuel dans la langue souhaitée, ou contactez un
fournisseur agréé Sunrise Medical.
Owner’s Manual
Owner’s Manual
Manual de
Manual de
Instrucciones
Instrucciones
Manuel
Manuel
d ’instructions
d ’instructions
Quickie Q200 R
Quickie Q200 R
Quickie Q200 R
®®
®®
®®
®®

Quickie®Q200®R General Manual
253470 Rev. B 2
I. INTRODUCTION
SUNRISE MEDICAL LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your questions
or comments about this manual, the safety and reliability of your chair, and the
service you receive from your Sunrise dealer. Please feel free to write or call us at
the address and telephone number below:
SUNRISE MEDICAL (US) LLC
Customer Service Department
2842 N. Business Park Avenue
Fresno, CA 93727 USA
[phone]
Please register your wheelchair, and let us know if you change your address. This
will allow us to keep you up to date with information about safety, new products,
and options to increase your use and enjoyment of the wheelchair.
You can also register your wheelchair at:
www.SunriseMedical.com/register
FOR ANSWERS TO YOUR QUESTIONS
Your authorized dealer knows your wheelchair best, and can answer most of your
questions about chair safety, use, and maintenance.
For future reference, please ll in the following:
Dealer: ______________________________________________________
Address: _____________________________________________________
Telephone: __________________________________________________
Serial #: ____________________ Date/Purchased: _______________
ADDITIONAL INFORMATION YOU SHOULD KNOW
No component of this chair was made with Natural Rubber Latex.
www.SunriseMedical.com/register
DISPOSAL AND RECYCLING INFORMATION
When this product reaches the end of its life, please take it to an
approved collection or recycling point designated by your local or state
government. This product is manufactured using a variety of materials.
Your product should not be disposed of as ordinary household waste. You should dispose
of your product properly, according to local laws and regulations. Most materials that are
used in the construction of this product are fully recyclable. The separate collection and
recycling of your product at the time of disposal will help conserve natural resources and
ensure that it is disposed in a manner that protects the environment.
Ensure you are the legal owner of the product prior to arranging for the product disposal
in accordance with the above recommendations.

Quickie®Q200®R General Manual
253470 Rev. B3
II. TABLE OF CONTENTS
I. INTRODUCTION.......................................................................................2
II. TABLE OF CONTENTS............................................................................3
1.0 USER INFORMATION...............................................................................4
1.1 This user manual................................................................................4
1.2 For further information..................................................................4
1.3 Symbols used in this manual.........................................................4
2.0 SAFETY .............................................................................................................5
2.1 Symbols and labels used on the product................................5
2.2 Safety: Temperature.........................................................................5
2.3 Safety: Moving parts.........................................................................5
2.4 Safety: Electromagnetic radiation...............................................5
2.5 Safety: Choking hazard ...................................................................6
2.6 Safety: Using a (vehicle mounted) wheelchair lift................6
2.7 Safety: Accessory trays...................................................................6
2.8 Safety: Lifting the wheelchair .......................................................6
2.9 Safety: Stability....................................................................................6
3.0 INTENDED USE OF THE WHEELCHAIR
3.1 Area of application: the user........................................................7
3.2 Area of application: the user environment ............................8
4.0 SETTING UP THE WHEELCHAIR......................................................9
4.1 Seating system ....................................................................................9
4.2 Seat height............................................................................................9
4.3 Center of gravity ...............................................................................9
4.4 Controller height and depth ........................................................9
4.5 Control system program ...............................................................9
4.6 Check after setup and /or adjustment of wheelchair........9
5.0 USING THE WHEELCHAIR...................................................................10
5.1 Checking wheelchair before use.................................................10
5.2 Making a transfer...............................................................................10
5.3 Driving the wheelchair....................................................................10
5.4 Curves....................................................................................................11
5.5 Breaking and Emergency stop .....................................................11
5.6 Driving on a slope.............................................................................11
5.7 Obstacles and curbs.........................................................................12
5.8 Pushing the wheelchair...................................................................13
5.9 (Powered) seating options ............................................................14
6.0 BATTERIES, CHARGING AND RANGE..........................................15
6.1 Batteries ................................................................................................15
6.2 Charging batteries.............................................................................16
6.3 The range of your vehicle..............................................................16
6.4 Replacing batteries............................................................................17
6.5 Disconnecting batteries for air transport...............................17
7.0 TRANSPORTATION ..................................................................................18
7.1 Transport of the wheelchair in a car........................................18
7.2 The wheelchair as a passenger seat..........................................19
7.3 Special transit requirements.........................................................20
7.4 General transport warnings .........................................................20
8.0 MAINTENANCE AND CLEANING...................................................21
8.1 Maintenance ........................................................................................21
8.2 Wheels and tires maintenance....................................................23
8.3 Lighting maintenance .......................................................................24
8.4 Cleaning and disinfection ...............................................................24
8.5 Medium to long term storage .....................................................24
9.0 TROUBLE SHOOTING ............................................................................25
10.0 TECHNICAL SPECIFICATIONS: APPLICABLE NORMS /
STANDARDS .................................................................................................26
11.0 SUNRISE LIMITED WARRANTY.........................................................27

Quickie®Q200®R General Manual
253470 Rev. B 4
1.0 USER INFORMATION
If you are visually impaired,
this document can be viewed
in PDF format at
www.SunriseMedical.com
1.0 User information
Congratulations on choosing a Sunrise Medical wheelchair. Our high quality mobility products are designed
to enhance your independence and make your everyday life easier.
As a part of our ongoing product improvement initiative, Sunrise Medical reserves the right to change
specications and design without notice. Further, not all features and options oered are compatible with all
congurations of the wheelchair.
All dimensions are approximate and may be subject to change. The intended lifetime of the wheelchair is ve
(5) years. Please DO NOT use or t any third party components to the wheelchair unless they are ocially
approved by Sunrise Medical.
1.1 This user manual
This user manual will help you to use and maintain your wheelchair safely. This entire user manual for this
wheelchair consists of four booklets:
• The general wheelchair user manual (this booklet)
• The user manual for the seating system
• The user manual for the controller
• The user manual for the battery charger
When necessary, this general user manual refers to other manuals as shown below:
Seating system: Refers to the user manual for the seating system.
Controller: Refers to the user manual for the controller.
Battery charger: Refers to the user manual for the battery charger.
Do not use your wheelchair until this entire manual (all booklets) has been read and
understood!
If one of the user manuals was not included with your wheelchair, please contact your Sunrise Medical
authorized dealer immediately.
1.2 For further information
Please contact your local Sunrise Medical authorized dealer if you have any questions regarding the use,
maintenance, or safety of your wheelchair. In case there is no authorized dealer in your area or you have any
questions, contact Sunrise Medical either in writing or by telephone. For information about product safety
notices and product recalls, go to www.SunriseMedical.com
1.3 Symbols used in this manual
DANGER!
Potential risk of serious injury or death
WARNING!
Potential risk of injury
CAUTION!
Potential damage to equipment
NOTE:
General user advice
Not following these instructions may result in physical injury, damage to the product, or damage to the
environment!

Quickie®Q200®R General Manual
253470 Rev. B5
2.0 SAFETY
Follow the instructions carefully next to these warning symbols! Not paying careful attention to these
instructions could result in physical injury or damage to the wheelchair or the environment. Wherever
possible, safety information is provided in the relevant chapter.
2.1 Symbols and labels used on the product
The signs, symbols, and instructions axed to the wheelchair comprise part of the safety facilities. They
must never be covered or removed. They must remain present and clearly legible throughout the entire
lifespan of the wheelchair.
Replace or repair all illegible or damaged signs, symbols, and instructions immediately. Please contact your
Sunrise Medical authorized dealer for assistance.
Fig. 2.1: Chair serial number: located on right side of the base on the bottom front of the battery box.
Fig. 2.2: Transit xation point.
Fig. 2.3: Warning – Danger of nger entrapment (pinch point).
Fig. 2.4: Warning – Maximum user weight for the wheelchair.
Fig. 2.5: Location of Motor Serial Number Label.
Fig. 2.6: Warning – Hot Label on Motor.
2.2 Safety: Temperature
WARNING!
1. Avoid physical contact with the wheelchair’s motors at all times. Motors are continuously in motion
during use and can reach high temperatures. After use, the motors will cool down slowly. Physical
contact could cause burns. Allow the motors after using at least 30 minutes to cool down.
2. If you do not use the wheelchair, ensure that it is not exposed to direct sunlight for lengthy periods of
time. Certain parts of the wheelchair, such as the seat, the back, and the armrests can become hot if
they have been exposed to full sunlight for too long. This may cause burns or allergic reactions to the
skin.
2.3 Safety: Moving parts
DANGER!
A wheelchair has moving and rotating parts. Contact with moving parts may result in serious physical injury
or damage to the wheelchair. Contact with the moving parts of the wheelchair should be avoided (Fig. 2.7).
• Wheels (turning and caster)
• Powered tilt in space adjustment
• Swing-away bracket of the controller
• Power elevating leg rests
2.4 Safety: Electromagnetic radiation
CAUTION!
The standard version of your electric wheelchair has been tested on the applicable requirements with
respect to electromagnetic radiation (EMC requirements). In spite of these tests:
It cannot be excluded that electromagnetic radiation may have an inuence on the wheelchair. For example:
• Mobile telephones
• Large-scale medical apparatus
• Other sources of electromagnetic radiation
It cannot be excluded that the wheelchair may interfere with electromagnetic elds. For example:
• Shop doors
• Burglar alarm systems in shops
• Garage door openers
In the unlikely event that such problems do occur, we request that you notify your Sunrise Medical
authorized dealer immediately.
DANGER!
1. When operating two-way radio, walkie-talkies, C.B. radio, Amateur radio, public mobile radio, and
other powerful transmitting devices the wheelchair should be brought to a halt and turned o.
2. The operation of cordless, mobile telephones, and cell phones including hands-free devices is
permitted, but if abnormal operation of the wheelchair is encountered then the chair must be brought
immediately to a halt and turned o.
Controller: Refers to the user manual for the controller.
Fig. 2.3
Fig. 2.4
Fig. 2.2
Fig. 2.7
Fig. 2.6
Fig. 2.5
Fig. 2.1
