ELTRONIKA ELT-865 User manual

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
1
ELT-865 Terminal
User Manual
Date: 20 Jun 2013
Powered by

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
2
Contents
1Overview........................................................................................................................................4
2References......................................................................................................................................4
3Trademarks.....................................................................................................................................5
4Package ..........................................................................................................................................6
4.1 Box ..........................................................................................................................................6
4.2 Complete package contents .....................................................................................................7
5General presentation ......................................................................................................................8
5.1 Description ..............................................................................................................................8
5.2 External connections ...............................................................................................................9
5.2.1 Interfaces and connectors.................................................................................................9
5.2.2 Power supply connector .................................................................................................11
5.2.3 Audio Input/Output ........................................................................................................12
5.2.4 SIM card holder .............................................................................................................12
5.3 Product sticker.......................................................................................................................13
6Basic features and services ..........................................................................................................14
7Using the modem .........................................................................................................................15
7.1 Setting up the modem............................................................................................................15
7.2 Mounting the modem ............................................................................................................18
7.2.1 On DIN bus ....................................................................................................................18
7.2.2 On the wall .....................................................................................................................18
7.3 Checking the communication with the modem.....................................................................19
7.4 Python scripts ........................................................................................................................20
7.4.1 Downloading script ........................................................................................................20
7.4.2 Script execution..............................................................................................................21
7.5 Status of the modem (LEDs).................................................................................................22
7.6 Disabling and enabling echo function ...................................................................................22
7.7 Verifying the strength of received signal...............................................................................23
7.8 PIN code status......................................................................................................................23
7.9 Network registration..............................................................................................................24
7.9.1 GSM network registration..............................................................................................24
7.9.2 GPRS network registration ............................................................................................25
7.10 AT commands summary ....................................................................................................26
8Troubleshooting ...........................................................................................................................27
8.1 No connection/communication with the modem...................................................................27

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
3
8.2 Receiving ERROR message..................................................................................................27
8.3 Receiving NO CARRIER message .......................................................................................28
9Technical characteristics ..............................................................................................................29
9.1 Mechanical characteristic ......................................................................................................29
9.1.1 Housing description (dimensioning diagram)................................................................29
9.2 Electrical characteristic .........................................................................................................30
9.2.1 Power supply..................................................................................................................30
9.2.2 RF characteristics...........................................................................................................30
9.3 Environmental characteristic.................................................................................................31
10 Architecture..................................................................................................................................31
11 Safety recommendations ..............................................................................................................33
11.1 General Safety .......................................................................................................................33
11.2 Care and Maintenance...........................................................................................................34
11.3 Responsibility........................................................................................................................34
12 Accessories...................................................................................................................................35
12.1 Accessories critical for using modem................................................................................35
12.2 Additional accessories .......................................................................................................36
13 On-line support ............................................................................................................................37

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
4
1 Overview
The ELT-865 Terminal is the complete modem solution for wireless m2m
applications. Based on the Telit GL865 module, it is available as DUAL or QUAD band
version and offers high level GSM/GPRS features in compact aluminium housing with all
the standardized interfaces. Together with its small size and wide supply voltage range,
makes it easy to integrate into all kinds of machines.
The ELT-865 Terminal enabling voice, data, SMS and fax communication is a
universal solution for all low-volume M2M and mobile data applications including metering,
traffic systems, transportation and logistics, security, vending machines, and facility
management.
Device can be controlled by standard AT commands or by customer's application
inside (embedded Python Script Interpreter), thus making it the smallest, complete SMT
platform for m2m solutions.
This document contains full ELT-865 modem description and gives information about
installation and using it.
2 References
[1] Telit_AT_Commands_Reference_Guide.pdf
[2] Telit_GL865-DUAL/QUAD_Hardware_User_Guide.pdf
[3] Telit_Modules_Software_User_Guide.pdf
[4] Telit_GL865-DUAL/QUAD_Product_Description.pdf
[5] Telit_Easy_Script_Python.pdf
[6] http://www.telit.com/en/products/gsm-gprs.php?p_id=12&p_ac=show&p=93
[7] http://www.python.org/

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
5
3 Trademarks
TELIT and the Stylized T Logo are registered in Trademark Office. All other product or ser-
vice names are the property of their respective owners.
Copyright © Telit Communications S.p.A. 2011.

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
6
4 Package
4.1 Box
the product is packed in the original box.
We can find product sticker on the box. It matches modems sticker that is placed on the
device. This proves that your modem is original product. More information about stickers in
chapter 5.3 Product sticker.

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
7
4.2 Complete package contents
Complete package contains:
•ELT-865 terminal (item A)
•DIN handle (item B)
•wall handles (items C)
•antenna GSM (via SMA) (item D)
•CD with software (item E)
•RS232 cable (item F)

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
8
5 General presentation
5.1 Description
LEDs
SMA
connector
SIM card
holder ejector
EIA574 (RS-232)
DE9 D-sub socket
Power supply
GPRS
GSM
PWR
Audio
Input/Output
Extractable
SIM card
holder

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
9
5.2 External connections
5.2.1 Interfaces and connectors
5.2.1.1 Antenna connector
SMA antenna input is used to connect external GSM antenna. To establish
connection with GSM network an external antenna must be used. Type of antenna depends
on GSM coverage. In good circumstances (level of received signal is high) use antenna
which is attached in the package. If range of GSM is low or none, an outdoor or indoor (for
instance in place where GSM range is sufficient) antenna should be used.
Note: If there is no antenna connected to SMA connector, the connection with GSM
network is impossible.
SMA connector
for antenna

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
10
5.2.1.2 RS-232 Interface (EIA574)
ELT-865 terminal is equipped with RS-232 interface (as shown below). DE9 DSUB
socket is connected via voltage level translator circuit to GL865 UART.
Table of RS-232 DB9 pins:
Pin No.
Name
Dir
Description
1
DCD
IN
Data Carrier Detect. Raised by DCE when modem synchronized.
2
RD
IN
Receive Data (a.k.a RxD, Rx). Arriving data from DCE.
3
TD
OUT
Transmit Data (a.k.a TxD, Tx). Sending data from DTE.
4
DTR
OUT
Data Terminal Ready. Raised by DTE when powered on. In auto-answer mode
raised only when RI arrives from DCE.
5
SGND
-
Ground
6
DSR
IN
Data Set Ready. Raised by DCE to indicate ready.
7
RTS
OUT
Request To Send. Raised by DTE when it wishes to send. Expects CTS from
DCE.
8
CTS
IN
Clear To Send. Raised by DCE in response to RTS from DTE.
9
RI
IN
Ring Indicator. Set when incoming ring detected - used for auto-answer
application. DTE raised DTR to answer.
DE-9 (EIA/TIA 574)
Looking into female connector
EIA574 (RS-232)
DE9 D-sub socket
Female connector

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
11
5.2.2 Power supply connector
The power supply connector is a 2-pin connector for external DC power supply
connection, which can handle voltage from range 5..30 V DC, 2.5 W max. continuous
power.
No.
Singal
I/O
Description
+
V+BATTERY
I
5..30V DC
-
GND
-
Ground
Attention!
An attempt to power terminal from DC source outside of 5..30V range may result in physical
destruction of the device.
Power supply
connector 3,5mm

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
12
5.2.3 Audio Input/Output
The ELT-865 modem is equipped with audio interface, which can be used for
transmitting voice communication while calling. To use this interface plug the HandsFree
headphones into it. The Audio I/O is shown in the picture below.
5.2.4 SIM card holder
SIM card holder is placed in front of ELT-865 terminal (as shown below) and is
accessible externally. To insert SIM card into the holder press the yellow button, eject the
little drawer, place there Your SIM card and insert drawer into the modem (You will hear
click). To operate the module in a GSM network, it is necessary to insert a SIM card
obtained from the network operator.
Extractable SIM
card holder
SIM card holder
ejector
Audio Input/Output
Interface

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
13
5.3 Product sticker
Product stickers are on the modem and on the box of the product.
A production sticker includes the following information:
•Product serial number (IMEI)
•the CE marking
•the 15-digit bar code
•the model signature (ELT-865)

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
14
6 Basic features and services
Basic features and available services for ELT-865 are contained in table below.
Feature/service
Description
Standard
Supported Bands:
•GSM Quad-band
•850/900/1800/1900MHz
Physical:
•83 x 72 x 25 mm
•Weight 151g
GPRS
Multi-slot class 10 (4 Down; 2 Up; 5 Total)
Max BR Downlink 85.6 Kbps
Coding Scheme CS1-CS4
Interfaces
Connectors
•Single 70 pin board to board
•RF MMCX
SIM Card
•3.0V / 1.8V
•STK 3.1
Connectivity
•UART: BR from 300 bps to 115.2 Kbps
Auto BR
SMS
•MO / MT Text and PDU mode
•Cell broadcast
Audio
•Telephony
•Digital audio
•Differential analog audio lines
•Vocoders HR/FR/EFR/AMR
•DTMF support
•Audio control: echo suppression; noise suppression; side tone; gain control
GSM supplementary
services
•USSD phase II
•Call forwarding
•Call hold; waiting; multiparty
•Call diverting
•Missed call indicator
•AOC
•Call barring
CSD
•Max BR 14.4 Kbps
Power supply
5V – 30V DC

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
15
7 Using the modem
7.1 Setting up the modem
To set up the modem, do the following steps:
•Eject SIM card holder using yellow button and pull out the drawer.
•Insert Your SIM card into drawer.
•Verify if SIM card fits in the drawer properly (as shown).
•Insert the drawer into the modem.
SIM car drawer
can be
completely
taken out
Put Your SIM card
into drawer and
insert the drawer
into modem
Eject SIM
holder using
yellow button and
pull out drawer

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
16
•Connect the antenna to the SMA connector
•Connect the modem using RS-232 cable

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
17
•Plug the power supply cable to the power supply input
•Plug the hands-free headphones into Audio I/O (optionally)
•Now the modem is ready to work.

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
18
7.2 Mounting the modem
7.2.1 On DIN bus
To mount modem on DIN bus install DIN handle as shown below
•Unscrew front panel and put DIN handle inside small rail in the back
7.2.2 On the wall
To mount modem on the wall install wall handles as shown below.

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
19
7.3 Checking the communication with the modem
Once the modem is connected You can check communication between ELT-865
terminal and the PC using Telit AT Controller available here [6]:
http://www.m2mgsm.com/download/Tools/Common/Telit_AT_Controller_r2_1_0.zip
Configuration of the DTE (port COM) in TATC settings should be set as follows:
•Bits per second: 115200 bps,
•Data bits: 8,
•Parity: None,
•Stop bits: 1,
•Flow control: hardware.
If the connection with the modem cannot be established do the following:
•Check if modem is connected with PC via RS-232.
•Check the configuration of the COM port.
Examples of AT commands:
•ATE1 enables modem echo function,
•AT+CGMI modem answers “Motorola” when connection is OK.
•AT+CPIN? shows current status of SIM card
•AT+CPIN=xxxx to enter PIN, where 'xxxx' are digitals
•AT+CSQ to verify received signal strength
•ATD<phone_number>; to initiate a voice call
•ATH to hang up a voice call
For further information about Telit AT commands and their usage, refer to [1].

Poland:
Eltronika Sp. z o.o.
ul. Warszawska 41/7
05-092 Łomianki
www.eltronika.pl
Czech Republic:
Eltronika CMS s.r.o.
Vyšehradská 1349/2
120 00 Praha 2
www.eltronika.cz
20
7.4 Python scripts
ELT-865 terminal integrates embedded Python interpreter. See simple guides here or
refer to [5] for more details. To find more information about python programming refer to [7].
7.4.1 Downloading script
Command: AT#WSCRIPT=“< script_name >“,< size >,< know-how >
<parameter>
Description
< script_name >
file name
< size >
file size (number of bytes)
< know-how >
know how protection, 1 = on, 0 = off (default)
The script, the compiled script, any text or binary file, can be downloaded on the
module using the #WSCRIPT command. In order to guarantee your company know-how,
you have the option to hide the script text so that the #RSCRIPT command does not return
the text of the script and keeps it "confidential", you can see the name of the script only
using the #LSCRIPT command. Remember that if you chose to hide the script text, it is your
responsibility to keep the information about what is executed on the module.
In order to download the (compiled) script, you have to choose a name for your script
on the module, taking care of the following:
the extension for scripts is .py
the maximum length allowed is 16 characters
script names are case sensitive (“Script.py” and “script.py” are two different
scripts).
Then you have to find out the exact size of the script in bytes (or pre-compiled script,
or generic text or binary file). For example, right clicking on the file and selecting “size” in
“properties” (attention: this is different from selecting “size on the disc”).
For further information refer to [5] Telit_Easy_Script_Python.pdf
