Elumen8 Evora Zoom Spot CMY300 User manual

Order codes: ELUM027
Evora CMY300 Zoom Spot
User Manual

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Before your initial start-up, please make sure that there is no damage caused during transportation.
• Should there be any damage, consult your dealer and do not use the equipment.
• To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
• Please note that damages caused by user modications to this equipment are not subject to warranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Never let the power cable come into contact with other
cables. Handle the power cable and all mains voltage
connections with particular caution!
• Never remove warning or informative labels from the unit.
• Do not open the equipment and do not modify the unit.
• Do not connect this equipment to a dimmer pack.
• Do not switch the equipment on and off in short intervals,
as this will reduce the system’s life.
• Only use the equipment indoors.
• Do not expose to ammable sources, liquids or gases.
• Always disconnect the power from the mains when
equipment is not in use or before cleaning! Only handle
the power-cable by the plug. Never pull out the plug by
pulling the power-cable.
• Make sure that the available mains supply voltage is
between 100~240V AC, 50/60Hz.
• Make sure that the power cable is never crimped or
damaged. Check the equipment and the power cable
periodically.
• If the equipment is dropped or damaged, disconnect the
mains power supply immediately and have a qualied
engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic
temperature uctuation (e.g. after transportation),
do not connect power or switch it on immediately.
The arising condensation might damage the equipment.
Leave the equipment switched off until it has reached
room temperature.
• If your product fails to function correctly, stop use
immediately. Pack the unit securely (preferably in the
original packing material), and return it to your Prolight
dealer for service.
• Only use fuses of same type and rating.
• We recommend this xture should be serviced at least
once every 3 months to prevent build-up of dust, dirt and
debris that could affect the xtures operation.
• Repairs, servicing and power connection must only be
carried out by a qualied technician. THIS UNIT CONTAINS
NO USER SERVICEABLE PARTS.
• This lighting xture is for professional use only - it is
not designed for or suitable for household use. The
product must be installed by a qualied technician in
accordance with local territory regulations. The safety of
the installation is the responsibility of the installer. The
xture presents risks of severe injury or death due to re
hazards, electric shock and falls.
• Warning! Risk Group 2 LED product according to
EN 62471. Do not view the light output with optical
instruments or any device that may concentrate the beam.
• High power lighting xtures are capable of producing
powerful, concentrated beams of light that can create a
re hazard or a risk of eye injury if the safety precautions
are not followed.
• WARRANTY: Two years from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than
those described in this manual, the product may suffer
damage and the warranty becomes void. Incorrect
operation may lead to danger e.g: short-circuit, burns
and electric shocks etc. Do not endanger your own
safety and the safety of others!
Incorrect installation or use can cause serious damage
to people and/or property.

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 3
Safety advice
This xture falls under Protection Class 1, therefore it has to be connected
to a mains socket with a protective earthing connection.
Risk group 2, RG-2: CAUTION!
Do not stare at exposed LED in operation as it may damage/be harmful to
the eyes. Avoid looking directly into the light source.
CAUTION!
If the lens gets damaged ie. cracks or deep scratches so the output is impaired
then it must be replaced.
CAUTION!
The maximum ambient temperature (Ta) of 40° must not be exceeded.
CAUTION!
To avoid damage to internal parts ie. optics, colour lters, gobos, prisms, frost
lters, iris, shutters, motors, belts, wiring or LEDs never expose the front lens to
direct sunlight, lighting xtures or lasers even when the xture is not in use.

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 4
Product overview & technical specications
• 1 x 300W white LED (6,700K)
• Adjustable beam angle: 4.5°- 38°
• 4.5° - 16,750 Lux @ 10m, 38° - 340 Lux @ 10m
• CRI: >68
• Adjustable refresh rate: 900Hz-25kHz
• Motorised zoom, focus and iris
• 6 facet circular rotating indexable prism plus 6 facet linear rotating
indexable prism
• Variable frost filter
• Gobo wheel 1: 8 rotating, indexable, replaceable gobos + open
• Gobo wheel 2: 10 static gobos + open
• CMY colour mixing: Cyan 0-100%, Magenta 0-100% and Yellow
0-100%
• Colour wheel: 7 colours + CTO filter + open
• High CRI filter (CRI: 84)
• Control protocols: DMX, Kling-net, Art-net and sACN
• DMX channels: 32
• Wireless control (W-DMX Sweden transceiver)
• Manual control and master/slave modes plus built-in programs
• Pan/tilt transit lock and auto correction
• 16-Bit pan/tilt positioning
• Pan: 540° or 630° selectable, Tilt: 270°
• 0-100% dimming and variable strobe
• 5 dimming modes: Standard, stage, TV, architectural and theatre
• PowerCON TRUE1, 5-Pin XLR and EtherCON inputs/outputs
• RDM (Remote Device Management)
• 6 push button menu with 1.8” LCD display
• Display battery backup for ofine conguration
• Supplied with quick release omega clamps
• USB port (rmware updates)
• Temperature controlled fan
• Supplied with an additional 8 rotating gobos
Evora CMY300 Zoom Spot
Specications Evora CMY300 Zoom Spot
Power consumption 437W
Fuse T5A 250V
Power supply 100~240V, 50/60Hz
Dimensions 600 x 370 x 230mm
Weight 19.3kg
Order code ELUM027
0m 10m 15m 20m
4.5° - Lux
38° - Lux
16750
340
5m
67000
1360
7444
151
38°
4187
85
4.5°
The Evora CMY300 Zoom Spot moving head boasts an immensely bright
300W LED with crystal clear optics, and with adjustable beam angle from
4.5° to 38° it can achieve tight beams through to wide washes. This
feature packed head offers both static and rotating gobo wheels, linear
and circular prisms, variable frost lter, high CRI lter along with motorised
zoom, focus and iris. Endless colours can be achieved with CMY colour
mixing, along with its colour wheel and CTO lter. Suited to rental, stage
and touring the LED is icker-free with an adjustable refresh rate.
Control is via DMX, RDM, Kling-Net, Art-NET and sACN protocols,
and for further convenience wireless DMX is on-board via W-DMX.

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 5
Technical specications
422mm
442mm
600mm
507mm
103mm
230mm 278mm
370mm
355mm
220mm
100mm

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 6
Technical specications
01 - LCD display
02 - Function buttons
03 - 5-Pin DMX input
04 - 5-Pin DMX output
05 - EtherCON input
06 - EtherCON output
07 - PowerCON TRUE1 input
08 - PowerCON TRUE1 output
09 - Fuse T5A 250V
10 - Wireless DMX Antenna
11 - Fans
In the box: 1 x xture,
2 x omega clamps,
1 x gobo pack
& 1 x power cable
11
03
0510
09
01 02 0807 06 04
11

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 7
Installation
Before installing the xture, the supporting structure (ie. truss) must be able to hold a minimum of 10
times the xtures weight without any deformation (eg. 15kg - 150kg point load). The xture must be
secured with a secondary safety attachment when being installed (ie. an appropriate safety cable).
Never stand directly below the xture when mounting, removing, and/or servicing.
Overhead installation requires experience and qualications to calculate working load limits, the
material being used at the installation area and periodic safety inspections of the xture and installation
material. If you do not have the relevant experience and/or qualications please do not attempt the
installation yourself. The installation should be checked annually by a qualied person.
The eLumen8 Evora CMY300 Zoom Spot can be operated where the base of the xture is horizontally
orientated, this includes standing the xture upright on a at, level surface or hanging the xture upside
down. Do NOT install the xture in a sideways position or in a position where the base of the xture is
orientated vertically or at an angle. Always use a safety wire as an extra safety precaution to prevent
damage/injury in the event a clamp fails (see the next page for clamp installation). Never use the carry
handles for secondary attachments.

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 8
Installation
Installation:
1. Fasten each clamp to the omega clamps with a bolt and lock nut through the hole in the
omega clamp.
2. Align and insert the omega clamp quick-lock fasteners with the respective holes on the bottom
of the unit.
3. Tighten both locking fasteners clockwise on each omega clamp ensuring they’re fully secure.
4. Mount the xture onto your truss system via the clamps and tighten to ensure secure.
5. Pull the safety cable through the safety cable holes located on the metal base plate on the
underside of the xture and around the truss.
1
2
5
3
4

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 9
LOCKED
UNLOCKED
Pan mechanism lock and release every 45°
45°
45°
45°
45°
45°
45°
45°
45°
Pan/Tilt Lock Mechanism
LOCKED
UNLOCKED
45°
45°
45°
45°
45°
45°
Tilt mechanism lock and release every 45°

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 10
Rotating Gobo Replacement:
The xture is supplied with 8 rotating, replaceable gobos. See below for installation instructions.
1) Place the xture on a stable, at surface ensuring you are indoors in a dust free location. Disconnect and
isolate from power and let the unit cool for at least 15 minutes. Engage the pan and tilt locks (shown above).
2) Use a Phillips head screwdriver to loosen the four
screws on each side of the head casing. These are
twist lock screws and do not come free of the casing.
3) Remove the safety clips securing the casings to the
head chassis.
Rotating Gobo Replacement

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 11
4) On the prism module, nd the 4-pin connector located behind the left motor, just beside the left thumbscrew
(see yellow box above). Disconnect this connector. This will help improve access to the gobo wheel module.
5) Loosen the thumbscrews on the prism module, these do not come free of the prism module.
Carefully slide the prism module out of its runners. Put the prism module to one side for reinstallation
after the gobo(s) have been replaced.
Rotating Gobo Replacement

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 12
6) On the gobo wheel module, locate the circuit board on the left hand side, on the right hand side nd the 3-pin
and 4-pin connector located behind 3 capacitors (see yellow box above), disconnect this connector.
7) Loosen the thumbscrews on the gobo wheel module, these do not come free of the gobo wheel module.
Carefully slide the gobo wheel module out of its runners. Place the gobo wheel module to on a at surface
ensuring you are indoors in a dust free location.
Rotating Gobo Replacement

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 13
8) Locate the gobo that will be replaced. Grip the edges of the gobo holder and carefully lift the holder until is
raised from the surface of the gobo wheel (pictured left). Pull the gobo holder towards you, away from the gobo
wheel (pictured right).
9) Place the gobo on a at surface with the gear side down. Locate the tab of the spring clip using a precision pick
(or similar) and push the spring clip inwards to release it and remove the spring clip. Carefully remove the gobo
from the holder avoiding scratching the gobo. Install the new gobo and follow the previous steps in reverse order.
Rotating Gobo Replacement

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 14
Operating instructions
Control Panel Menu:
The LCD control panel situated on the front of the xture allows the user to access the menu system to
adjust the xtures settings.
When the unit has been powered on the display will show “Software Update” followed by “eLumen8
Evora CMY300 Zoom Spot” and then “Ethernet Reset Please Wait...” followed by “Motor Reset Please
Wait...”. The xture will then return to its home screen.
Pressing the “MENU” button once will take the user to the xtures main menu. Using the “UP” and
“DOWN” buttons you can then navigate between the different options in the main menu. Pressing the
“ENTER” button on one of these options allows you to access the sub menu where you can use the
“LEFT” and “RIGHT” buttons to select option/value required. Once the option/value has been selected
press the “ENTER” button once more to conrm the setting.
To exit out of any of the above options, press and hold the “MENU” button.
The LCD control panel can be used via the internal battery. To access this press and hold the
“MENU” button for 5 seconds until the xtures home screen is displayed. The LCD display will
automatically shut off after 20 seconds of inactivity.
Error Codes:
When the unit is powered on the unit will automatically perform a motor reset. If there is a problem with
any of the motors the display will ash and display “Error:” along with a list of motor errors on the LCD
control panel. Please power the unit off and on to reset the motors again.
(The full list of errors codes can be found on the next page).
MENU
USB
DRIVE
UP
LEFT ENTER RIGHT
DOWN
Evora CMY300
Zoom Spot

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 15
Operating instructionsOperating instructions
Error Code Description
Pan The movement is not located in the default position after the reset. This message will appear
if the sensor has failed or magnet is missing, or if there is a motor failure (defective motor or
a defective motor IC drive on the main PCB). This error may also be displayed if the yoke was
blocked during a reset function.
Tilt
Cyan
The movement is not located in the default position after the reset. This message will appear
if the sensor has failed or magnet is missing, or if there is a motor failure (defective motor or a
defective motor IC drive on the main PCB).
Magenta
Yellow
Colour
RotGobo
RotGoboInd
Gobo
Prism1
Prism1Rot
Prism2
Prism2Rot
Focus
Zoom
Iris
Frost
HeadTemp
This message will appear if the sensor or fan has failed or the xtures temperature is too hot.
HeadFan
BaseTemp
BaseFan

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 16
Operating instructions
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
DMX Address 001-512 DMX Address Setting
Network
Input OFF Activate/deactivate
network input
ON
Protocol ArtNET Network Protocol Setting
sACN
Address
ServicePIN 000-255 (PIN = 050) Pin to enter Address Menu
Universe 000-255 Universe Setting
(PIN Required)
IP Address xxx.xxx.xxx.xxx
(002.000.000.002)
IP Address Setting
(PIN Required)
Subnet Mask xxx.xxx.xxx.xxx
(255.000.000.000)
IP Subnet Mask Setting
(PIN Required)
DMX Output OFF Output network signal
via DMX
ON
Wireless
W-DMX OFF Activate/deactivate
W-DMX
ON
Transmit/
Receive
Transmit Congure W-DMX as a
transmitter/receiver
Receive
W-DMX Protocol G3 G3 Transmission Standard
G4S G4S Transmission Standard
Tx/Rx Link Link
Link with W-DMX devices.
W-DMX must be active for
all devices and the link
with a transmitter must be
suspended (Receive Reset)
UnLink Unlink all devices
Rx Reset
NO Do not suspend link with
transmitter
YES Suspend link with
transmitter

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 17
Operating instructions
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
Stand Alone
Manual Control
Pan
000-255 Manual Control Settings
Pan Fine
Tilt
Tilt Fine
Colour
Macros
CMY Mode
Cyan
Cyan Fine
Magenta
Magenta Fine
Yellow
Yellow Fine
High CRI
Rot Gobo
Gobo Index
Index Fine
Fixed Gobo
Strobe
Dimmer
Dimmer Fine
Zoom
Zoom Fine
Focus
Focus Fine
Iris
Frost
Prism
Prism 1 Rot
Prism 2 Rot
Programs
Program 1 Speed (000-255)
Internal Programs
Fade (000-255)
Program 2 Speed (000-255)
Fade (000-255)
Program 3 Speed (000-255)
Fade (000-255)
...
Program 16 Speed (000-255)
Fade (000-255)
Slave Mode OFF Slave Mode
ON

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 18
Operating instructions
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
Settings
Split Colour OFF Split Colour Setting
ON
Display
Backlight 02M-60M (06M) LCD Backlight Setting
Rotate 180° OFF LCD Display Inverse Setting
ON
Key Lock
OFF Control Panel Lock Setting
(Press and hold MODE
for 3 seconds to unlock)
ON
DispFlash OFF Display Flash Setting
When No DMX Signal
ON
Power Saver Hibernation OFF Hibernation Setting
01M-099M
DMX Fail
Blackout
DMX Fail Setting
Hold
Programs
Manual
Dim Mode
Standard
Dimming Curve Speed
Stage
TV
Architectur
Theatre
Frequency
900Hz
LED Refresh Rate Setting
1000Hz
1100Hz
1200Hz
1300Hz
1400Hz
1500Hz
2500Hz
4000Hz
5000Hz
10kHz
15kHz
20kHz
25kHz
Pan/Tilt
Pan Inverse OFF Pan Inverse Setting
ON
Tilt Inverse OFF Tilt Inverse Setting
ON
Pan Angle 540 Pan Angle setting
630
Fans Head Fan
Auto
Head Fan Speed SettingLow
High

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 19
Operating instructions
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
Settings Fans Base Fan
Auto
Base Fan Speed SettingLow
High
Service Calibrate (PIN = 050)
Pan
000-255 Calibration Settings
Tilt
Cyan
Magenta
Yellow
High CRI
Colour
Colour 0-1
Colour 1-2
Colour 2-3
Colour 3-4
Colour 4-5
Colour 5-6
Colour 6-7
Colour 7-8
Colour 8-0
Gobo
GoboRot. 1
GoboRot. 2
GoboRot. 3
GoboRot. 4
GoboRot. 5
GoboRot. 6
GoboRot. 7
GoboRot. 8
FocusGoboR1
FocusGoboR2
FocusGoboR3
FocusGoboR4
FocusGoboR5
FocusGoboR6
FocusGoboR7
FocusGoboR8
Fixed Gobo
FocusFixG1
FocusFixG2
FocusFixG3
FocusFixG4
FocusFixG5

www.prolight.co.uk Evora CMY300 Zoom Spot User Manual 20
Main Menu Sub Menu Options/Values (Default Settings in BOLD) Description
Service
Calibrate (PIN = 050)
FocusFixG6
000-255 Calibration Settings
FocusFixG7
FocusFixG8
FocusFixG9
FocusFixG10
Prism1
Prism1 Rot
Prism2
Prism2 Rot
Focus
Zoom
Iris
Frost
Auto Test Testing... Auto Test
Motor Reset
All
Motor ResetPan & Tilt
Head
USB Update OFF USB Update
ON
Factory OFF Factory Settings
ON
Information
Runtime
Total Time
Runtime Information
CurrentTime
Password (PIN = 050)
Reset
Temperature
Head xxx°
Temperature InformationBase xxx°
Units C°/ F°
Fan Speed
Head-1: xxxxRPM
Fan Speed Information
Head-2: xxxxRPM
Base-1: xxxxRPM
Base-2: xxxxRPM
Model eLumen8 Evora CMY300 Zoom Spot Model Information
RDM UID 0x09A5-xxxxxxxx RDM UID
Firmware
1U: Vx.x.xx
2U: Vx.x.xx
3U: Vx.x.xx
4U: Vx.x.xx
5U: Vx.x.xx
6U: Vx.x.xx
7U: Vx.x.xx
Software Version
Error. Info NONE/Pan, Tilt... (See page 11) Current Fixture Errors
