eMachines Notebook Series
Quick Guide
Product registration
When using your product for the first time, it is recommended that you immediately
register it. This will give you access to some useful benefits, such as:
•Faster service from our trained representatives.
•Membership in the eMachines community: receive promotions and participate in
customer surveys.
•The latest news from eMachines.
Hurry and register, as other advantages await you!
How to register
To register your eMachines product, please visit www.eMachines.com. Select your
country, click PRODUCT REGISTRATION and follow the simple instructions.
You will also be asked to register your product during the setup process, or you can
double-click the Registration icon on the desktop.
After we receive your product registration, you will be sent a confirmation email with
important data that you should keep in a safe place.
Obtaining eMachines accessories
eMachines store has been conceived around the same philosophy as eMachines
products: Affordable with high value and great performance. Come and find original
accessories or a warranty extension to increase the life and the performance of your
computer at store.emachines.com.
The eMachines store is being progressively rolled out, and, unfortunately may not be
available in some regions. Please check back regularly to see when it will be available in
your country.

Model number: _____________________________________
Serial number: ______________________________________
Date of purchase: ___________________________________
Place of purchase: ___________________________________
© 2011. All Rights Reserved.
eMachines Notebook Series Quick Guide
Original Issue: 06/2011
eMachines recommends...
Productivity Software
Work Great with Microsoft®Office 2010 - Express your ideas, solve problems and simplify everyday projects with
Office 2010.
Photo editing - Easily edit and print your photos with Windows Live Photo Gallery. Then share them on Facebook,
YouTube or Windows Live.
Search & Decide with Bing - Find and organize the answers you need using Bing™, so you can make faster, more
informed decisions.

3
English
First things first
We would like to thank you for making an eMachines notebook your choice for
meeting your mobile computing needs.
Your guides
To help you use your eMachines notebook, we have designed a set of guides:
First off, the setup poster helps you get started with setting up your computer.
The eMachines Generic User Guide contains useful information applying to all
models in the eMachines product series. It covers basic topics such as using the
keyboard and audio, etc. Please understand that due to its nature, the Generic User
Guide will occasionally refer to functions or features which are only contained in
certain models of the series, but not necessarily in the model you purchased. Such
instances are marked in the text with language such as "only for certain models".
The Quick Guide introduces you to the basic features and functions of your new
computer. For more on how your computer can help you to be more productive,
please refer to the eMachines Generic User Guide. This guide contains detailed
information on such subjects as system utilities, data recovery, expansion options
and troubleshooting. In addition it contains warranty information and the general
regulations and safety notices for your notebook. It is available in Portable
Document Format (PDF) and comes preloaded on your notebook. Follow these
steps to access it:
1 Click on Start > All Programs > Documentation.
2 Click on eMachines Generic User Guide.
Note: Viewing the file requires Adobe Reader. If Adobe Reader is not
installed on your computer, clicking on eMachines Generic User
Guide will run the Adobe Reader setup program first. Follow the
instructions on the screen to complete the installation. For instructions
on how to use Adobe Reader, access the Help and Support menu.

4
English
Your eMachines notebook tour
After setting up your computer as illustrated in the setup poster, let us show you
around your new eMachines notebook.
Top view
#Icon Item Description
1 Microphone Internal microphone for sound recording.
2 Display screen Also called Liquid-Crystal Display (LCD),
displays computer output (configuration may
vary by model).
1
3
2
4
5
6
9
78

5
English
Hotkeys
The computer employs hotkeys or key combinations to access most of the
computer's controls like screen brightness and volume output.
To activate hotkeys, press and hold the <Fn> key before pressing the other key in
the hotkey combination.
3 Speakers Deliver stereo audio output.
4 Power button Turns the computer on and off.
5 Keyboard For entering data into your computer.
6 Touchpad Touch-sensitive pointing device which
functions like a computer mouse.
7 Power indicator Indicates the computer's power status.
Battery indicator Indicates the computer's battery status.
1. Charging: The light shows amber when
the battery is charging.
2. Fully charged: The light shows blue
when in AC mode.
8 Click buttons (left
and right)
The left and right buttons function like the left
and right mouse buttons.
9 Integrated webcam Web camera for video communication.
Hotkey Icon Function Description
<Fn> + <F3> Communication Enables/disables the computer’s
communication devices.
<Fn> + <F4> Sleep Puts the computer in Sleep mode.
<Fn> + <F5> Display toggle Switches display output between the
display screen, external monitor (if
connected) and both.
<Fn> + <F6> Screen blank Turns the display screen backlight off
to save power. Press any key to
return.
<Fn> + <F7> Touchpad toggle Turns the internal touchpad on and off.
#Icon Item Description

6
English
<Fn> + <F8> Speaker toggle Turns the speakers on and off.
<Fn> + < > Brightness up Increases the screen brightness.
<Fn> + < > Brightness down Decreases the screen brightness.
<Fn> + < > Volume up Increases the sound volume.
<Fn> + < > Volume down Decreases the sound volume.
<Fn> +
<Home>
Play/Pause Play or pause a selected media file.
<Fn> +
<Pg Up>
Stop Stop playing the selected media file.
<Fn> +
<Pg Dn>
Previous Return to the previous media file.
<Fn> +
<End>
Next Jump to the next media file.
Hotkey Icon Function Description

7
English
Left view
#Icon Item Description
1 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Note: Wrap the computer security lock
cable around an immovable object such as
a table or handle of a locked drawer. Insert
the lock into the notch and turn the key to
secure the lock. Some keyless models are
also available.
2 External display (VGA)
port
Connects to a display device (e.g.,
external monitor, LCD projector).
3 Ethernet (RJ-45) port Connects to an Ethernet 10/100-based
network.
4 HDMI port Supports high-definition digital video
connections.
5 USB 2.0 port Connects to USB 2.0 devices (e.g., USB
mouse, USB camera).
6 2-in-1 card reader Accepts Secure Digital (SD),
MultiMediaCard (MMC).
Note: Push to remove/install the card.
Only one card can operate at any time.
213456

8
English
Right view
#Icon Item Description
1Microphone jack Accepts inputs from external microphones.
Headphone/speaker
jack
Connects to audio devices
(e.g., speakers, headphones).
2 USB 2.0 ports Connect to USB 2.0 devices (e.g., USB
mouse, USB camera).
3 Optical drive Internal optical drive; accepts CDs or DVDs.
4 Optical disk access
indicator
Lights up when the optical drive is active.
5 Optical drive eject
button
Ejects the optical disk from the drive.
6 Emergency eject hole Ejects the optical drive tray when the
computer is turned off.
Note: Insert a paper clip to the emergency
eject hole to eject the optical drive tray
when the computer is off.
7 DC-in jack Connects to an AC adapter.
12 3456 7

9
English
Base view
Environment
#Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Memory compartment Houses the computer's main memory.
Hard disk bay Houses the computer's hard disk (secured
with screws).
4 Battery release lock Releases the battery for removal.
•Temperature:
•Operating: 5 °C to 35 °C
•Non-operating: -20 °C to 65 °C
•Humidity (non-condensing):
•Operating: 20% to 80%
•Non-operating: 20% to 80%
1
2
3
4
