Ember Overland Series User manual

Overland Series and Overland Micro Series
OWNER’S MANUAL

2
This Manual Belongs to:
______________________________________________________________________________
VIN __________________________________________________________________________
DEALER _____________________________________________________________________
ADDRESS ____________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
DEALER PHONE ______________________________________________________________
DEALER CONTRACT __________________________________________________________

3
DATE DESCRIPTION OF SERVICE SERVICE PERFORMED BY

4
Congratulations on your new Ember, and welcome to the Ember Recreational
Vehicles family! On behalf of everyone at Ember, we’re glad you’re here. At Ember,
we’re focused on creating a truly unique and exceptional ownership experience.
We hope that you’ll see this in not only the quality we build into our units, but
through the interactions you’ll have with our company and our dealer partners if
you haven’t already!
Not only does it comply with all the Recreational Vehicle Industry Association’s
regulations, standards, and safety requirements, but it meets our own high standards
of quality and testing.
We ask that you please read and understand the contents of this owner’s manual as
well as the other manuals for the various components from other manufacturers that
came with your RV. Your personal safety and that of those traveling with you depends
upon you becoming familiar with and learning how to properly operate the various
systems, appliances, and components that your RV came equipped with. Take extra
care in reading all cautions, warnings, and notices, and familiarize yourself and your
family with the safety features built into your RV and what actions to take
to assure a safe camping trip.
We proudly back our units with our 1-2-3 Warranty: 1 time transfer in the first year of
ownership, a 2-year limited base warranty, and a 3-year limited structural warranty.
Dear Ember Owner,
Your Ember has been designed from
the ground up to provide you with a
reliable and quality way to enjoy family
fun and recreation.

5
Please read through the details of our warranty carefully so you are familiar with the
extent of the coverage and duration, along with the various exclusions, restrictions,
and limitations that may apply. Ongoing maintenance and upkeep are important to
upholding our warranties, so we ask that you please understand what those are. Some
components used in the construction of your Ember from other suppliers come with
additional warranties that extend beyond our warranty. Please be sure to understand
these warranties as well and submit any necessary registration forms included in your
Owners Packet.
Your dealership should be able to answer any questions or concerns you may have
after reading through this Owner’s Manual regarding your new Ember. If your dealer is
unable to do so, please feel free to contact our Ownership Experience department.
We hope that your Ember brings you many years of adventures and fun with memories
to last a lifetime! We are thankful you chose to be a part of the Ember family and wish
you safe travels!
Best,
ASHLEY BONTRAGER
Founder / CEO
Ember Recreational Vehicles

6
This Owner’s Manual for your Ember Recreational Vehicle (RV) is intended to serve as
a guide for safety, care, and normal operation of your unit. Information contained in
this document is subject to change without notice and includes relative information
available at time of the publication of this version. The photographs, drawings,
components, and systems described may not represent what is in the RV you
purchased due to available options, ongoing upgrades, and improvements. This
document also contains information for both the Overland Series and the Overland
Micro Series, and not all information applies to both series. Your Ember 1-2-3 Limited
Warranty is included at the end of this Owner’s Manual. Nothing in this Owner’s
Manual will or is intended to in any way modify, supplement, or change the terms and
conditions of the 1-time transfer in the first year of ownership, the 2-year limited base
warranty and the 3-year limited structural warranty that comes with your Ember RV. This
Owner’s Manual does not alter or supplement any component manufacturer warranty.
Your Ember came with an Owner’s Packet that contains various
component manufacturers’ manuals and warranty information.
These documents can also be found online at the Ember RV
Owner’s Resources page. QR Codes are provided throughout this
manual and represent the hardware in the coach at the time of
this documents publication and may not be accurate in all cases.
Please be sure to look through all these documents and register
for the available warranties beyond the 1-2-3 warranty offered by
Ember Recreational Vehicles.
Please use the procedures outlined in this guide for typical operating conditions.
The obligation for safe operation and use of your RV lies on you, and we have tried
to include information to help, but not serve as a tutorial for how to camp or where to
camp in your Ember RV. For questions, concerns, or assistance, please contact your
dealer or Ember directly.
MAILING ADDRESS:
Ember Recreational Vehicles
PO Box 970
Bristol, IN 46507
Phone: [phone]
Email: [e-mail]
Website: www.emberrv.com
About this Manual
EMBER RV OWNER’S
RESOURCES

7
Contents
OVERVIEW OF OWNER’S MANUAL
Safety Terms 10
Key Safety Items 10
Bunk Loads 10
Carbon Monoxide (CO) Detector 11
Egress Windows 11
Extinguisher 11
Smoke Detector 11
Propane Gas Leak Detector 11
Safety Regulations for LP 12
Fire Safety 14
YOUR EMBER RECREATIONAL VEHICLE
Technical Data and General
Specifications 16
PRE-TRIP PREPARATION
Pre-Trip Checklist 16
Loading 16
Wheel Lug Nuts 16
Tire Inflation 16
Trailer Coupler 16
Safety Cables 16
Electrical 16
Exterior 17
Interior 17
Tool Kit Items 17
Hitching 18
Pre-Hitch/Coupling/Trip
Considerations and Inspection 18
7-Way Connector 19
Hitching Steps and Instructions 19
Sway Control and Weight
Distribution Hitch 20
LOADING
Key Terms 21
Cargo Capacities 22
How to Weigh your RV 22
TOWING
Guidelines 23
Safety Chains 23
Breakaway Switch 23
Tire Pressure 24
Brakes 24
Lights 24
General Towing and Driving 24
Sway and Fishtailing 25
Winding Narrow Roads 25
Sharp Turns 26
Steep and Long Grades 26
Slippery and Icy Pavement 26
Freeways and Highways 26
Corner Turns 26
Mud and Sand 26
Parking 26
Additional Towing and
Safety Information 26
TIRES
General Information 27
Tire Fundamentals 27
Sidewall Markings and
Important Terms 27
Tire Tread 28
Pressure and Load Limits 28
Checking Tire Pressure 28
Wheel Nut Torque 29
Torque Adjustments 29
Tire Safety Checklist 30
Lifting the Coach 30
Travel Trailer Set Up at Destination 31
Leveling 31
Stabilizers 31

8
Hook Ups 32
EXTERNAL EQUIPMENT
AND SYSTEMS
European Windows 33
Condensation 33
Cleaning 34
Independent Suspension 34
Front Electric Flat Jack 36
Stabilizers 38
Gear Box 38
Exterior Telescoping Ladder 38
Outdoor Kitchen 39
Griddle 39
Cooler 39
Refrigerator 39
Television 40
INTERNAL EQUIPMENT
AND SYSTEMS
Safety 41
Propane Appliance Maintenance 41
Operating Appliances at High Altitude 42
Air Conditioner 42
Dual-Zone Thermostat 43
Television 43
TV Signal Booster 43
Winegard Air 360 43
Cable Hook-Up 43
Awning 44
Rear Observation Monitoring System 44
EmberLink™ Smart System 44
Microwave 45
Cook Top (Range) 45
Range Hood 46
Refrigerator 47
Roof Vents (Power and Manual) 47
Solar Prep 47
Removable Table 47
D-Rings Loading 48
Elevated Beds 48
Standard Elevated Beds 48
Use of Bed Rails 48
Tips for Safe Elevated Bed Usage 49
Murphy Beds 49
Murphy Bed Setup and Storage 49
Slideout Systems 50
Slideout Operation 50
Troubleshooting the Slide Room 51
Slideout Manual Override 52
ELECTRICAL SYSTEM
Electrical System Maintenance 53
120-Volt Alternate Current System 53
Inverter 56
Battery Cutoff Switch 56
12-Volt Direct Current System 57
Converter 57
Converter Inspection and
Maintenance 57
DC to DC Battery Charger
(Max solar only) 57
Solar Power System and Batteries 58
Solar Charge Controller 58
EmberLink™ Smart System 59
PROPANE SYSTEM
Overview 60
Regulator 60
Regulator Freeze-Up 60
Other Cold Weather Factors 61
LP PIGTAIL 62
LP GAS DETECTOR 62
PLUMBING SYSTEM
Fresh Water System 63
TRUMA Combi 63
Truma Pressure Relief Valve 66
Water Pump 66
Monitoring Tank Status 67
Holding Tank Sensor Problems 67
Draining the Fresh Water System 67
Plumbing Control Center 68
Nautilus 68

9
Docking Station 68
Nautilus Water Management
System 68
Fresh Water System 69
Santizing the Fresh Water System 69
Filling the Fresh Water Tank 70
Using a Pressurized Water Source 71
The Lavatory 71
Showermi$er 71
Shower Maintenance 72
Bathroom Skylight 72
Toilet 72
Toilet Maintenance 72
External Shower 72
Wastewater System 73
Black & Gray Water Holding Tanks 73
Rinsing and Draining the Black Tank 73
Emptying the Black and Gray
Water Tanks 74
Vents & Vent Pipes 75
WARRANTY, REPAIR, AND SERVICE
General Care and Maintenance 76
Cleaning the Interior 76
Exterior Finish 76
Frame and Chassis 76
Hitch Couplers 77
Safety Chains 77
Jacks 77
Tires and Wheels 77
Brake Adjustment 77
Sealants 77
Ceiling, Interior Walls,
Countertop, Tabletops 77
Faucets and Fixtures 78
Fabric and Upholstery 78
Owner Responsibilities 78
Leaking 78
Mold 78
Warranty Registration and
Change of Address 78
REQUIRED MAINTENANCE
SCHEDULE 79
WINTERIZING AND STORAGE
Winterizing Your RV 80
Dewinterizing Your RV 85
Storing your RV 85
SERIAL NUMBER, VIN, DECALS
Deciphering the VIN 86
WARRANTY
Warranty Service Tips 87
Obtaining Emergency
Warranty Repair 88
Service & Warranty 88
Have the Following
Available When You Call 89
Owner Aid 89
Verify the Issue 89
Do it Yourself 90
Write it Down 90
Part Lead Times 90
Inspect Repairs 90
Use Your Unit as Intended 90
THE 1-2-3 LIMITED WARRANTY
Important Definitions 91
What Is a 1-2-3 Limited
Warranty and How to Obtain
Warranty Service 91
EMBER’S TWO (2) YEAR LIMITED
BASE WARRANTY 92
EMBER’S THREE (3) YEAR LIMITED
STRUCTURAL WARRANTY 93
Remedies 95
Primary Remedy 95
Secondary Remedy 95
What is Not Covered by the
Ember Limited Warranties 95
Appliance and Component
Manufacturer Warranties and
Administration 96
Legal Remedies 97
ACCEPTING DELIVERY 98

10
After you have thoroughly reviewed the manual, you will have a good understanding
of the do’s and dont’s of owning and operating an Ember Recreational Vehicle. If you
aren’t sure of a certain feature, you can easily locate the section that addresses your
concern and look up the information you need. As you read through the manual, you
will encounter the following items:
DANGER indicates an imminently hazardous situation
that, if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation
that, if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation that,
if not avoided, may result in minor or moderate injury.
NOTICE is used to address practices not related to
personal injury. This applies to hazardous situations
involving property damage only.
BUNK LOADS
The maximum weight in single bunks is 300lbs and 600lbs for double bunks.
SAFETY TERMS
KEY SAFETY ITEMS
Overview of Owner’s Manual
EXCEEDING THE LOAD LIMITS FOR THE BUNKS MAY
RESULT IN FAILURE CAUSING SERIOUS INJURY.

11
CARBON MONOXIDE (CO) DETECTOR
For your safety, a carbon monoxide (CO) detector is installed in every RV. Depending on the
model, it may be operated by battery (9V, AA), or wired so that it will be powered by an RV
battery (if equipped), or 12V power from the converter. Please refer to the manufacturer’s
instructions supplied with the RV for care and operation.
EGRESS WINDOWS
Egress or “Emergency Exit” windows are labeled from the factory with the word EXIT. All
Egress windows can be distinguished by red operational handles or levers. Dependent upon
the window type, an egress window may be a large section or an entire window. Review the
locations and operational instructions posted upon the window with all people staying in the RV.
EXTINGUISHER
Each Ember Recreational Vehicle includes a fire extinguisher which is located near the main
entry door. The fire extinguishers are rated for Class B (gasoline, grease, and flammable liquids)
and Class C (electrical) fires. Please refer to the manufacturer’s instructions supplied with the
Owner’s Packet for care and operation.
SMOKE DETECTOR
For your safety a smoke detector is installed in every RV. Most detectors are powered by a 9-volt
battery. Check the manufacturer’s expiration date on the label, replace the batteries if needed,
and clean dust away from the slots so that smoke can enter freely. All smoke alarms should be
replaced every ten years. Please refer to the manufacturer’s instructions supplied with the RV for
care and operation.
PROPANE GAS LEAK DETECTOR
Your Ember RV contains a propane gas leak detector in every camper. It is a safety device that
is permanently mounted near the floor and is powered by 12V of electricity (the RV battery
and/or converter). The detector is operational only if 12V of power is available. If the power is
disconnected, the monitor will not operate.
Should a propane leak occur, the detector will sound an alarm and continue until the gas has
dissipated or until a mute button is pressed. The mute button will only stop the alarm from
sounding for 60 seconds and the alarm will reoccur if gas is still present. The alarm may sound
at times when no propane is present when household products are in use such as aerosol hair
spray, cleaners, adhesives, alcohol, etc. Be sure to air out the RV thoroughly after delivery and
when using these products. Please refer to the manufacturer’s instructions supplied with the RV
for care & operation.
PROPANE POWERED APPLIANCES PRODUCE CARBON
MONOXIDE. CARBON MONOXIDE CAN BE FATAL!

12
IF THE LP GAS ALARM SOUNDS:
1. EXTINGUISH ANY OPEN FLAMES, PILOT LIGHTS, AND ALL
SMOKING MATERIALS.
2. DO NOT TOUCH ELECTRICAL SWITCHES.
3. SHUT OFF THE PROPANE SUPPLY AT THE CONTAINER VALVE(S) OR
PROPANE SUPPLY CONNECTION.
4. OPEN DOORS AND OTHER VENTILATING OPENINGS.
5. LEAVE THE AREA UNTIL THE ODOR CLEARS.
6. HAVE THE PROPANE SYSTEM CHECKED AND LEAKAGE SOURCE
CORRECTED BEFORE USING AGAIN.
FAILURE TO COMPLY COULD RESULT IN EXPLOSION RESULTING IN DEATH
OR SERIOUS INJURY.
SAFETY REGULATIONS FOR LP
Your Ember RV uses pressurized propane gas and, as such, requires that you as the owner
be made aware of the risks involved. The following warnings are posted throughout your
recreational vehicle to provide information on LP gas safety. They have been installed
not only because of the requirement to do so, but also as a reminder to occupants of
the recreational vehicle to exercise proper caution when using or being around LP gas
appliances and equipment. We list several safety procedures here for you to study. Be sure
that you and your family understand and follow them.
DO NOT PLACE PROPANE CYLINDERS INSIDE THE
VEHICLE. PROPANE CYLINDERS ARE EQUIPPED WITH
SAFETY DEVICES THAT RELIEVE EXCESSIVE PRESSURE BY DISCHARGING PROPANE
TO THE ATMOSPHERE. PROPANE GAS IS HIGHLY FLAMMABLE. CAN LEAD TO A FIRE
OR EXPLOSION AND RESULT IN DEATH OR SERIOUS INJURY.
The propane gas leak detector has a self-check circuit which runs at all times while receiving 12V
of power. If the circuitry fails, a failure alarm will sound, and the operating indicator will cease to
light. Replace the detector when recommended by the manufacturer (typically every five years).

13
Cooking appliances need fresh air for safe operation. Before operation:
1. Open an overhead vent or turn on an exhaust fan.
2. Open a window.
A warning label is in the cooking area to remind you to provide an adequate supply
of fresh air for combustion. Unlike homes, the amount of oxygen supply is limited due
to the size of the recreational vehicle, and proper ventilation when using the cooking
appliance(s) will avoid dangers of asphyxiation.
If you smell gas:
• Extinguish any open flames, pilot lights, and all smoking materials.
• DO NOT touch electrical switches.
• Shut off the gas supply at the tank valve(s) or gas supply connection.
• Open doors and other ventilating openings.
• DO NOT USE THE RANGE HOOD.
• Leave the area until the odor clears.
• Have the system checked and leakage source corrected before using again.
IT IS NOT SAFE TO USE COOKING APPLIANCES FOR
COMFORT HEATING.
DO NOT FILL CONTAINERS TO MORE THAN 80%
CAPACITY. A PROPERLY FILLED CONTAINER CONTAINS
APPROXIMATELY 80% OF ITS VOLUME AS LIQUID PROPANE. OVERFILLING THE
PROPANE CONTAINER(S) CAN RESULT IN UNCONTROLLED PROPANE FLOW, WHICH
COULD LEAD TO A FIRE OR EXPLOSION AND RESULT IN DEATH OR SERIOUS INJURY.
DO NOT STORE LP GAS CONTAINERS, GASOLINE, OR
OTHER FLAMMABLE LIQUIDS INSIDE THE VEHICLE, AS
A FIRE OR EXPLOSION MAY RESULT.
IT IS ESPECIALLY IMPORTANT THAT COOKING
APPLIANCES NOT BE USED FOR COMFORT HEATING
AS THE DANGER OF ASPHYXIATION AND/OR CARBON MONXIDE POISONING IS
GREATER WHEN THE APPLIANCE IS USED FOR PROLONGED PERIODS OF TIME.

14
FIRE SAFETY
Fire safety is an important part of owning a recreational vehicle. The following basic rules
of fire prevention can help eliminate the possibility of a fire.
1. Never store flammable liquids in the recreational vehicle.
2. Never leave cooking food unattended.
3. Never smoke in bed and always use an ashtray.
4. Never allow children to play with LP gas or electrical equipment.
5. Never use an open flame as a flashlight.
6. Have faulty or damaged wiring and electrical components repaired immediately.
7. Never overload electrical circuits.
8. Locate any LP leaks and have them repaired immediately.
9. Keep cooking surfaces clean and free from debris.
10. Don’t allow rubbish to accumulate.
11. Never clean with a flammable substance.
12. Spray fabrics annually with a flame retardant.
13. Be sure everyone in your RV is familiar with the location of the exits including
the emergency exit.
In the event of a fire, get everyone outside, then determine if you should attempt to
extinguish the fire. If it is a large fire or a chemical fire, DO NOT HESITATE! Leave the
vehicle immediately and call the fire department.
If you decide it is safe to fight a fire with an extinguisher:
1. Remove the tamper tape which covers the discharge push button.
(Do not shake).
2. Hold it upright and stand six to ten feet from the fire, with a clear path to an exit.
3. Press the button down completely, aiming at the base of the fire, and spray with
a quick side to side sweeping motion.
ENSURE EVERYONE IN YOUR RV IS FAMILIAR WITH THE
OPERATION AND LOCATION OF ALL FIRE EXTINGUISHERS.

15
USE ONLY THE APPROVED FIRE EXTINGUISHER TO
PUT OUT A FIRE. DO NOT ATTEMPT TO USE WATER.
WATER MAY SPREAD CERTAIN TYPES OF FIRE AS WELL AS INCREASE THE
LIKELIHOOD OF ELECTROCUTION.
AVOID INHALING THE DRY CHEMICALS FROM THE FIRE
EXTINGUISHER. ALTHOUGH NON-TOXIC, THEY COULD
CAUSE TEMPORARY IRRITATION. WHEN THE FIRE IS OUT, CLEAN THE AREA AS SOON
AS POSSIBLE. THE DRY CHEMICALS MAY CAUSE SURFACE DAMAGE IF LEFT TOO LONG.
LP GAS REGULATORS MUST ALWAYS BE INSTALLED
WITH THE DIAPHRAGM VENT FACING DOWNWARD.
REGULATORS THAT ARE NOT IN COMPARTMENTS HAVE BEEN EQUIPPED WITH A
PROTECTIVE COVER. BE SURE THAT THE REGULATOR VENT FACES DOWNWARD
AND THE COVER IS KEPT IN PLACE TO MINIMIZE VENT BLOCKAGE WHICH COULD
RESULT IN EXCESSIVE GAS PRESSURE CAUSING FIRE OR EXPLOSION.
PORTABLE FUEL BURNING EQUIPMENT, INCLUDING
WOOD OR CHARCOAL BURNING GRILLS AND STOVES,
SHALL NOT BE USED INSIDE THE RV. DOING SO MAY CAUSE A FIRE, EXPLOSION,
CARBON MONOXIDE POISONING, OR ASPHYXIATION.
Use the ‘PASS’ method. Familiarize yourself and all RV
occupants with this procedure:
1. Pull the pin. (Some extinguishers may have a
cartridge that you need to push).
2. Aim the nozzle at the base of the fire.
3. Squeeze the handle to release the extinguishing agent.
4. Spray the base of the fire. (If you aim at the flames,
you won’t extinguish the fire).

16
TECHNICAL DATA AND GENERAL SPECIFICATIONS
Please look at your specific RV’s weights and measures on the sticker located on the
entry door. You can also visit www.emberrv.com for general weights and measures for
your specific floorplan.
Your Ember Recreational Vehicle
Before leaving on your first trip with your new Ember Recreational Vehicle, read the
information in this manual very carefully. After reading through the manual, run through
the following checklist at least once.
PRE-TRIP CHECKLIST
LOADING
Properly load and secure your trailer by carefully and evenly distributing the weight,
properly following add-on equipment (Thule, Yakima, etc.) guidelines, and not
exceeding the overall weight. (See Towing Guidelines)
WHEEL LUG NUTS
Check the torque on your wheels before your first trip. Recheck them at 25- and
50-mile intervals to be sure they remain secure.
TIRE INFLATION
Tires leave the dealer at the recommended pressure as indicated on the tire sidewall.
To help ensure that you don’t run into premature or uneven tire wear, always check
the tire pressure before heading out on the road.
TRAILER COUPLER
Do a visual check to make sure the trailer coupler is securely latched to the tow
vehicle’s ball hitch and the indicator marker is in the “green” section.
SAFETY CABLES
Check that safety cables have been attached to your tow vehicle. (Cables should
crisscross beneath the Tongue/Drawbar).
ELECTRICAL
Attach the 4-wire connector to the tow vehicle’s mating electrical outlet. Check to
see that all camping trailer lights are functioning properly.
Pre-Trip Preparation

17
EXTERIOR
Close the valves on the LP bottles.
Empty gray/black holding tanks.
Inspect all exterior baggage doors and lockers to ensure they are locked for travel.
Inspect tires and check the pressures.
Check the wheel lug nuts.
Inspect the awning(s) to ensure they are properly retracted and secured.
Turn the battery disconnect on.
Remove all snow from the roof.
Disengage the wheel brake.
Disconnect all park connections and securely store.
INTERIOR
Close all vents and windows.
Retract all slide rooms.
Inspect the interior of the RV to ensure all doors, including the refrigerator,
are closed and secured.
Verify that all safety devices are in working condition.
Engage the deadbolt on the entrance door for travel.
TOOL KIT ITEMS
Before leaving on your first trip, it is a good idea to put together your own tool kit that
contains the following items:
¾-inch lug wrench or ¾-inch socket (for lug nuts)
Socket set with metric sockets (10, 13, and 17mm)
Tire pressure gauge
Phillips head screwdriver
Small level
Pliers
Adjustable wrench (1-inch standard)
Metric hex set (4, 5, and 6mm)
Spare key to storage box
Electrical tape
Duct tape
Repair kits for tent and mattress pads

18
HITCHING
Ember RVs come equipped standard with a 2 5/16 -inch diameter hitch ball mounted in a
variable height coupler referred to as a VersaCoupler Hitching System. Figure 1 demonstrates
how to change coupler height.
Use of any other sized hitch ball will create an extremely dangerous condition that can result
in separation of the coupler and ball, and/or hitch ball failure. Other than this crucial 2
5/16-inch diameter requirement, there are numerous trailer hitches and hitching components
available to you for your trailer. Be sure to consult with your tow vehicle manufacturer for
hitch and/or hitch assembly alternatives.
PRE-HITCH/COUPLING/TRIP CONSIDERATIONS AND INSPECTION
Be sure your hitch and tow vehicle are rated for the Gross Vehicle Weight Rating (GVWR) of
your trailer. Remember that the hitch load rating must be equal to or greater than the coupler
load (the hitch is attached to the towing vehicle, the coupler to the trailer). Be sure the hitch
size matches the coupler size.
Examine all hitch components before hitching. Look for wear, corrosion, deformations,
stripping, and cracks. Replace worn, corroded, or cracked hitch components before coupling
the trailer to the tow vehicle. Be sure the hitch components are tight and that the ball-locking
device works freely before coupling the trailer to the tow vehicle. Remember to also inspect
the safety chains. Be sure to correct any noted problems or defects before towing the trailer.
Important Note: Be sure to raise all stabilizers and the tongue jack and close the RV fully
before hitching (i.e., close all doors and windows and raise the steps).
CHANGING VERSACOUPLER HEIGHT
THE PROPER SELECTION AND CONDITION OF THE
COUPLER AND HITCH IS ESSENTIAL TO THE SAFE TOWING
OF YOUR TRAILER. A LOSS OF COUPLING MAY RESULT IN DEATH OR SERIOUS INJURY.

19
HITCHING STEPS AND INSTRUCTIONS
Hitching up your trailer will get easier with practice. The hitching steps described below
are typical. However, we highly recommend that you also consult the hitching and
unhitching instructions associated with your tow vehicle and hitching configuration.
Raise the Flat Jack until the hitch coupler is raised enough to clear the tow vehicle.
1. Back the tow vehicle to the trailer until the hitch ball is directly under the trailer coupler. The
use of a backing aid mirror may be helpful, especially if you are hitching alone.
2. Set the parking brake in the tow vehicle.
3. Be sure the coupler latch-locking lever is fully open and then lower the tongue jack
until the ball is firmly seated in the socket.
4. Close the coupler latch and secure it with a locking pin or bolt.
5. Securely attach the safety chains in a crossing pattern to the tow vehicle and confirm that
they are properly connected to the trailer. Do not fasten chains to any part of the hitch
unless the hitch has holes or loops designed specifically for that purpose. Be sure the
chains do not drag during towing.
HITCHING PROCESS
AN IMPROPERLY COUPLED TRAILER CAN RESULT IN
DEATH OR SERIOUS INJURY. USE OF A TOW VEHICLE
WITH A TOWING CAPACITY LESS THAN THE LOAD RATING OF THE TRAILER CAN
RESULT IN LOSS OF CONTROL, AND MAY LEAD TO DEATH OR SERIOUS INJURY.
7-WAY CONNECTOR
Your trailer is equipped with a 7-way connector which synchronizes the lights of your tow
vehicle and trailer and can connect their respective braking systems.
Each wire is color coded to identify the system it powers:
•White: Ground
•Red: Left Turn Signal
•Green: Running Lights
•Yellow: Backup Lights
•Brown: Right Turn Signal
•Black: Charge Line

20
6. Connect the breakaway switch. Attach and secure the breakaway switch cable to the
tow vehicle bumper or frame independently of the safety chains. The following are
guidelines for attaching the cable:
• The cable should come straight out from the switch to attach to the tow vehicle.
• The switch and cable should be located and secured on the same side of the
trailer and tow vehicle.
• Do not loop the cable over the hitch ball. The cable may bounce off while the
vehicle is moving.
• Before towing, you may test the breakaway assembly by pulling the pin out of the
switch to confirm activation of the trailer electric brakes.
Note: Your breakaway switch will automatically engage the electric trailer brakes if
the safety chains fail during uncoupling.
7. Connect the power cord between the tow vehicle and the trailer, leaving enough
slack for the tow vehicle to turn without disconnecting the power cord.
8. Adjust side mirrors.
9. Check all lights on the trailer and tow vehicle, ensuring that they are
communicating properly.
10.Confirm that the brakes are working properly prior to towing the trailer on a public
road. You can, for example, check the operation of the trailer brakes by pulling
forward and using the hand control.
SWAY CONTROL AND WEIGHT DISTRIBUTION HITCH
You may, depending on your tow vehicle or intended usage of the trailer, want to consider
the use of a weight distributing hitch and/or sway bars. These distribute the tongue weight
of the trailer further away from the rear and can help in vehicle handling. Each towing
situation is different due to the tow vehicle and trailer. Ember suggests speaking with your
dealer prior to choosing a system.
IMPROPER RIGGING OF THE SAFETY CHAINS CAN
RESULT IN THE LOSS OF CONTROL OF THE TRAILER
AND TOW VEHICLE, LEADING TO DEATH OR SERIOUS INJURY IF THE TRAILER
UNCOUPLES FROM THE TOW VEHICLE.
DO NOT CONNECT THE BREAKAWAY SWITCH LANYARD
TO THE HITCH BALL OR ANY PART OF THE HITCH ASSEMBLY.
