hymer ERIBA Touring 2012 User manual

Instruction manual
2048869
2012
Edition 04/11-1 englisch
© 2011 HYMER AG Bad Waldsee
Touring
Instruction manual
Dear Customer,
We are pleased that you have chosen a caravan from HYMER and would like to thank you for the trust you
have shown in our company.
This instruction manual is intended to help you get to know and use your new caravan. It is essential that you
read and comply with the safety instructions in chapter 2.
Don't hesitate to contact our HYMER service centres if you have any questions. Their staffs are fully conver-
sant with your vehicle and will be pleased to help in any way they can. Our list of HYMER service centres in
Europe is updated regularly. You can obtain a copy of the latest edition from our customer service department
or from your HYMER dealer.
This instructionmanualalsoincludesthewarrantycertificate foryour vehicle. You willbereceiving thewarranty
stamp shortly. Please paste this stamp into the field provided. To maintain the HYMER weatherproof guar-
antee against water ingress, your vehicle must be inspected for a fee by an authorised HYMER dealer or an
authorised specialist workshop once a year. A confirmation stamp will be stuck into this manual for each
inspection. We also recommend a general inspection of the conversion at yearly intervals.
In addition to this instruction manual you will also receive the instruction manuals for the various built-in appli-
ances.
We are sure that you will get a lot of enjoyment from your caravan. Have a good trip!
You will also find HYMER AG on the Internet at: http://www.hymer.com
Yours, HYMER AG

Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Instruction manual

3Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Guarantee
Confirmation:
I have today received the documents for the
annual servicing intervals and the water in-
gress test for the stated model.
Please paste the
warranty stamp
in here.
Date:
Selling dealer's signature and stamp Customer's signature

4Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Water ingress test
For the water ingress test your HYMER contract partner checks the complete
construction of your vehicle at all composite locations, windows, skylights,
service flaps and doors for tightness.
Important The performance and the exact adherence to the intervals is decisive for the
continuation of the 6 year weatherproof guarantee. The water ingress test
must be carried out on an annual basis. The interval may be carried out max.
six months before or six months after the date on which the test is due. For
additional information concerning the 6 year weatherproof guarantee, please
refer to the following text. Also your HYMER contract partner will be pleased
to advise you.
Conditions for the HYMER 6 year weatherproof
guarantee
The vehicle vendor gives guarantee for the following:
1. Scope of guarantee
Under certain prerequisites, the vendor guarantees that
zthe necessary prerequisites according to Point 2 are available
zand the buyer has had all impermeability inspections carried out acc. to
Point 3 continuously and on time,
that for the vehicle, for a period of six years, for motorhomes, up to a max-
imum of 100,000 km, with normal use, no rain water will penetrate the body
manufactured by HYMER AG through the connections, bored holes, and
joints in the floor, wheel housing, side wall, front wall, rear wall and roof,
including alcoves.
2. Prerequisites of the guarantee
The guarantee presupposes
zthat the vehicle area that is leaking is in the original condition or, if work
has been carried out on it, then such jobs have been performed exclu-
sively by the vendor or by an authorised HYMER AG dealer or service
centre;
zthat there was no improper handling or overload;
zthat the vehicle was not exposed to environmental pollution which
exceeds that which is normal and permissible,
zthat the HYMER AG care instructions and the operating instructions
were adhered to;
zthat the purchaser immediately handed over the vehicle for remedy of a
detected fault to the vendor or to an authorised HYMER AG dealer or
service centre.
The individual prerequisites will not be considered if they are not the cause
or contributory cause for the leakage. Prerequisite for the enforcement of
the guarantee is that the purchaser reported any leakage detected in the
vehicle or any evidence of dampness indicating this leakage to the vendor
latest 14 days after detection and made available the vehicle for repair, as
far as long this was not unreasonable.

5Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
3. Annual inspection
The purchaser shall send the vehicle regularly, every year, to the vendor or
to an authorised HYMER AG dealer or service centre for inspection. The
purchaser shall bear the cost of the inspection. The first inspection
must be conducted within the first year after delivery of the vehicle to the
purchaser, however, latest within the first year from the date of initial regis-
tration of the vehicle. The subsequent annual inspections must be con-
ducted by the calendar, corresponding to the latest date for the first
inspection.
If the inspection is carried out six months after expiry of the period at
the latest, then the right to claim under the guarantee remains in
force, otherwise it is invalid. The time for the next inspection shallnot be
postponed by a delayed inspection. The inspections are to be proven by
means of the guarantee stamps pasted into the guarantee booklet, with the
date, stamp and signature from the workshops.
4. Guarantee period
The guarantee period commences with the delivery of the vehicle to the
purchaser, on the date of the initial registration at the latest. It terminates
prematurely when the vehicle is written off or it's capability of use ceases
to exist for other reasons. Work carried out on the vehicle which does not
fall under this guarantee do not extend the guarantee period.
5. Guarantees
Any leakage covered by the guarantee will be remedied by the vendor.
Should the remedy not succeed and the party covered by the guarantee
cannot be reasonably expected to accept additional guarantees provided
by the vendor, then the party covered by the guarantee can have the
leakage remedied by HYMER AG, at the expense of the vendor. No further
claims apply.
The vendor is not required to remedy the leakage when the vehicle is
written off or it's capability of use ceases to exist for other reasons as well
as when the costs for the guarantee work exceed the value of the vehicle
at that time.
A change of ownership has no effect on this guarantee.
6. Other claims
Claims made by the purchaser especially with respect to any performance,
damage claims or warranty and guarantee claims made against the vendor
or claims resulting from product liability are not affected by this guarantee.
As far as the purchaser's duty of disclosure are required as part of this
agreement, they refer exclusively to any claims from this guarantee.
7. Statute of limitations
The claims with respect to the remedying of a leakage falls under the
statute of limitations 6 months after discovery of the leakage or dampness
indicating this leakage, upon expiry of the guarantee period at the latest.
Inspection
After each service, the inspection plan provides you with supplementary and
detailed information concerning the work which has been specifically carried
out on your vehicle. You receive the inspection checklist when you collect your
vehicle from your HYMER contract partner. Should it be determined during an
inspection that additional work is necessary, then the carrying out of this work

6Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
is dependent on the customer commissioning this to be done. Please also
adhereto theserviceintervalsstipulatedbythemanufacturersof theindividual
equipment. Information is included in the service documents enclosed.
Important The carrying out of the planned inspections is a prerequisite for any guarantee
claims.

7Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Inspection record for a motorhome or caravan
Body inspection 1 Water ingress test 1
12 months after delivery
Water ingress test:
Paste in the inspection stamp for
the 12 month check here (subject
to payment).
Liable to charges
Date:
Mileage reading: 12 months
Dealer's signature and stamp:
Should it be determined during an inspection that additional
work is necessary, then the carrying out of this work is de-
pendent on the customer commissioning this to be done.
Please also adhere to the service intervals stipulated by the
manufacturers of the individual equipment. Information is in-
cluded in the service documents enclosed.
Your next water ingress test is due on:
Earliest:
Latest:
Inspection record for a motorhome or caravan
Body inspection 2 Water ingress test 2
24 months after delivery
Water ingress test:
Paste in the inspection stamp for
the 12 month check here (subject
to payment).
Liable to charges
Date:
Mileage reading: 24 months
Dealer's signature and stamp:
Should it be determined during an inspection that additional
work is necessary, then the carrying out of this work is de-
pendent on the customer commissioning this to be done.
Please also adhere to the service intervals stipulated by the
manufacturers of the individual equipment. Information is in-
cluded in the service documents enclosed.
Your next water ingress test is due on:
Earliest:
Latest:

8Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Inspection record for a motorhome or caravan
Body inspection 3 Water ingress test 3
36 months after delivery
Water ingress test:
Paste in the inspection stamp for
the 12 month check here (subject
to payment).
Liable to charges
Date:
Mileage reading: 36 months
Dealer's signature and stamp:
Should it be determined during an inspection that additional
work is necessary, then the carrying out of this work is de-
pendent on the customer commissioning this to be done.
Please also adhere to the service intervals stipulated by the
manufacturers of the individual equipment. Information is in-
cluded in the service documents enclosed.
Your next water ingress test is due on:
Earliest:
Latest:
Inspection record for a motorhome or caravan
Body inspection 4 Water ingress test 4
48 months after delivery
Water ingress test:
Paste in the inspection stamp for
the 12 month check here (subject
to payment).
Liable to charges
Date:
Mileage reading: 48 months
Dealer's signature and stamp:
Should it be determined during an inspection that additional
work is necessary, then the carrying out of this work is de-
pendent on the customer commissioning this to be done.
Please also adhere to the service intervals stipulated by the
manufacturers of the individual equipment. Information is in-
cluded in the service documents enclosed.
Your next water ingress test is due on:
Earliest:
Latest:

9Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Inspection record for a motorhome or caravan
Body inspection 5 Water ingress test 5
60 months after delivery
Water ingress test:
Paste in the inspection stamp for
the 12 month check here (subject
to payment).
Liable to charges
Date:
Mileage reading: 60 months
Dealer's signature and stamp:
Should it be determined during an inspection that additional
work is necessary, then the carrying out of this work is de-
pendent on the customer commissioning this to be done.
Please also adhere to the service intervals stipulated by the
manufacturers of the individual equipment. Information is in-
cluded in the service documents enclosed.
Your next water ingress test is due on:
Earliest:
Latest:
Inspection record for a motorhome or caravan
Body inspection 6 Body inspection 7
6 years after delivery 7 years after delivery
Date: Date:
Mileage reading: Mileage reading:
Dealer's signature and stamp: Dealer's signature and stamp:
Should it be determined during an inspection that additional work is necessary, then the carrying out of this work is dependent on the
customer commissioning this to be done. Please also adhere to the service intervals stipulated by the manufacturers of the individual
equipment. Information is included in the service documents enclosed.

10 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Guarantee
Inspection record for a motorhome or caravan
Body inspection 8 Body inspection 9
8 years after delivery 9 years after delivery
Date: Date:
Mileage reading: Mileage reading:
Dealer's signature and stamp: Dealer's signature and stamp:
Should it be determined during an inspection that additional work is necessary, then the carrying out of this work is dependent on the
customer commissioning this to be done. Please also adhere to the service intervals stipulated by the manufacturers of the individual
equipment. Information is included in the service documents enclosed.
Inspection record for a motorhome or caravan
Body inspection 10 Body inspection 11
10 years after delivery 11 years after delivery
Date: Date:
Mileage reading: Mileage reading:
Dealer's signature and stamp: Dealer's signature and stamp:
Should it be determined during an inspection that additional work is necessary, then the carrying out of this work is dependent on the
customer commissioning this to be done. Please also adhere to the service intervals stipulated by the manufacturers of the individual
equipment. Information is included in the service documents enclosed.

11Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Contents
1Introduction. . . . . . . . . . . . . . . . . . 17
1.1 General . . . . . . . . . . . . . . . . . . . . . . . . 18
1.2 Environmental tips. . . . . . . . . . . . . . . . 18
2Safety. . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 Fire prevention . . . . . . . . . . . . . . . . . . 21
2.1.1 Avoidance of fire risks. . . . . . . . . . . . . 21
2.1.2 Fire-fighting. . . . . . . . . . . . . . . . . . . . . 21
2.1.3 In case of fire. . . . . . . . . . . . . . . . . . . . 21
2.2 General . . . . . . . . . . . . . . . . . . . . . . . . 22
2.3 Road safety. . . . . . . . . . . . . . . . . . . . . 22
2.4 Towing. . . . . . . . . . . . . . . . . . . . . . . . . 23
2.5 Gas system. . . . . . . . . . . . . . . . . . . . . 24
2.5.1 General instructions . . . . . . . . . . . . . . 24
2.5.2 Gas bottles . . . . . . . . . . . . . . . . . . . . . 25
2.6 Electrical system. . . . . . . . . . . . . . . . . 26
2.7 Water system . . . . . . . . . . . . . . . . . . . 26
3 Before the journey . . . . . . . . . . . 27
3.1 Start-up . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2 Connecting . . . . . . . . . . . . . . . . . . . . . 27
3.3 Caravan couplings . . . . . . . . . . . . . . . 28
3.3.1 AK 300/160 caravan coupling. . . . . . . 29
3.3.2 AKS 1300 stabiliser. . . . . . . . . . . . . . . 29
3.3.3 WS 3000 D stabiliser. . . . . . . . . . . . . . 30
3.4 Detaching . . . . . . . . . . . . . . . . . . . . . . 30
3.5 Payload. . . . . . . . . . . . . . . . . . . . . . . . 31
3.5.1 Terms . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.5.2 Calculating the payload. . . . . . . . . . . . 33
3.5.3 Loading the caravan correctly. . . . . . . 34
3.5.4 Caravan load, nose weight
and axle load. . . . . . . . . . . . . . . . . . . . 35
3.6 Road safety. . . . . . . . . . . . . . . . . . . . . 36
4 During the journey . . . . . . . . . . . 39
4.1 Driving with the caravan . . . . . . . . . . . 39
4.2 Brakes. . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3 Driving in reverse . . . . . . . . . . . . . . . . 39
5 Pitching the caravan . . . . . . . . . 41
5.1 Handbrake. . . . . . . . . . . . . . . . . . . . . . 41
5.2 Wheel chocks . . . . . . . . . . . . . . . . . . . 41
5.3 Corner steadies. . . . . . . . . . . . . . . . . . 42
5.4 Entrance step . . . . . . . . . . . . . . . . . . . 43
5.5 240 V connection . . . . . . . . . . . . . . . . 43
5.6 Refrigerator. . . . . . . . . . . . . . . . . . . . . 43
6 Living . . . . . . . . . . . . . . . . . . . . . . . . 45
6.1 Conversion door . . . . . . . . . . . . . . . . . 45
6.1.1 Conversion door, outside . . . . . . . . . . 45
6.1.2 Conversion door, inside . . . . . . . . . . . 46
6.1.3 Insect screen on the
conversion door. . . . . . . . . . . . . . . . . . 46
6.2 External flaps. . . . . . . . . . . . . . . . . . . . 46
6.2.1 Flap lock, elliptical-shaped. . . . . . . . . . 47
6.2.2 Flap for the drinking water
filler neck . . . . . . . . . . . . . . . . . . . . . . . 47
6.2.3 Flap for sewage tank . . . . . . . . . . . . . . 48
6.3 Heating . . . . . . . . . . . . . . . . . . . . . . . . 48
6.4 Ventilation . . . . . . . . . . . . . . . . . . . . . . 49
6.5 Windows . . . . . . . . . . . . . . . . . . . . . . . 49
6.5.1 Hinged window . . . . . . . . . . . . . . . . . . 50
6.5.2 Blind and insect screen . . . . . . . . . . . . 51
6.6 Lifting roof . . . . . . . . . . . . . . . . . . . . . . 52
6.7 Tables . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.7.1 Fixed table for the
round seating group. . . . . . . . . . . . . . . 53
6.7.2 Suspension table . . . . . . . . . . . . . . . . . 54
6.7.3 Folding table Troll single
bed seating group . . . . . . . . . . . . . . . . 55
6.8 Extending the Troll single
bed seating group . . . . . . . . . . . . . . . . 56
6.9 Fixed bed (gas-pressure springs) . . . . 57
6.10 Sleeping conversion . . . . . . . . . . . . . . 57
6.10.1 Front seating group . . . . . . . . . . . . . . . 58
6.10.2 Front seating group Troll . . . . . . . . . . . 59
6.10.3 Seating group with two single beds . . . 60
6.10.4 Seating group with bed 1400 x 1900 . . 61
6.10.5 Rear seating group . . . . . . . . . . . . . . . 62
7 Gas system. . . . . . . . . . . . . . . . . . . 63
7.1 General . . . . . . . . . . . . . . . . . . . . . . . . 63
7.2 Gas bottles. . . . . . . . . . . . . . . . . . . . . . 64
7.3 Changing gas bottles. . . . . . . . . . . . . . 65
7.4 Gas isolator taps . . . . . . . . . . . . . . . . . 66
7.5 External gas connection . . . . . . . . . . . 66
7.6 DuoControl switching facility . . . . . . . . 67
8 Electrical system . . . . . . . . . . . . . 69
8.1 General safety instructions . . . . . . . . . 69
8.2 Terms. . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.3 12 V power supply . . . . . . . . . . . . . . . . 70
8.3.1 Living area battery
(Power Pack SE) . . . . . . . . . . . . . . . . . 70
8.3.2 Energy balance of the
living area battery . . . . . . . . . . . . . . . . 72
8.4 Power supply unit CSV 300. . . . . . . . . 73
8.5 Power supply unit CSV 409
(Power Pack SE) . . . . . . . . . . . . . . . . . 74
8.5.1 Battery selector switch. . . . . . . . . . . . . 74
8.5.2 Charging the battery . . . . . . . . . . . . . . 75
8.6 On/Off switch (Power Pack SE). . . . . . 75
8.7 240 V power supply . . . . . . . . . . . . . . . 75
8.7.1 240 V connection. . . . . . . . . . . . . . . . . 76
8.7.2 Connecting the 240 V power supply . . 76

Contents
12 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
8.8 Fuses. . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.8.1 12 V fuses . . . . . . . . . . . . . . . . . . . . . . 77
8.9 External socket . . . . . . . . . . . . . . . . . . 79
8.10 Connection to the towing vehicle . . . . . 80
8.10.1 Thirteen-pin plug
connection diagram . . . . . . . . . . . . . . . 80
8.10.2 Towing vehicle installation
(Power Pack SE) . . . . . . . . . . . . . . . . . 82
8.11 Circuit diagrams. . . . . . . . . . . . . . . . . . 83
8.11.1 Block diagram 240 V . . . . . . . . . . . . . . 83
8.11.2 Block diagram 12 V . . . . . . . . . . . . . . . 84
9 Appliances . . . . . . . . . . . . . . . . . . . 85
9.1 General . . . . . . . . . . . . . . . . . . . . . . . . 85
9.2 Heater . . . . . . . . . . . . . . . . . . . . . . . . . 85
9.2.1 To heat properly. . . . . . . . . . . . . . . . . . 86
9.2.2 Heater S 3002 . . . . . . . . . . . . . . . . . . . 86
9.2.3 Circulation fan . . . . . . . . . . . . . . . . . . . 88
9.2.4 Ultraheat additional electric heater . . . 89
9.3 Boiler . . . . . . . . . . . . . . . . . . . . . . . . . . 90
9.3.1 Models with waste gas vent on
the right-hand side of the vehicle. . . . . 90
9.3.2 Truma boiler . . . . . . . . . . . . . . . . . . . . 90
9.3.3 Hot water source . . . . . . . . . . . . . . . . . 92
9.4 Cooker . . . . . . . . . . . . . . . . . . . . . . . . . 94
9.4.1 Gas cooker. . . . . . . . . . . . . . . . . . . . . . 94
9.5 Refrigerator . . . . . . . . . . . . . . . . . . . . . 95
9.5.1 Refrigerator ventilation grill . . . . . . . . . 96
9.5.2 Operation (Dometic). . . . . . . . . . . . . . . 96
9.5.3 Refrigerator door locking
mechanism. . . . . . . . . . . . . . . . . . . . . . 98
10 Sanitary fittings . . . . . . . . . . . . . . 99
10.1 Water supply, general . . . . . . . . . . . . . 99
10.2 Water tank . . . . . . . . . . . . . . . . . . . . . 100
10.2.1 Drinking water filler neck with flap . . . 100
10.2.2 Filling with water . . . . . . . . . . . . . . . . 100
10.2.3 Draining water (stopper) . . . . . . . . . . 101
10.3 Waste water tank. . . . . . . . . . . . . . . . 101
10.4 Filling the water system . . . . . . . . . . 102
10.5 Emptying the water system . . . . . . . . 103
10.6 Toilet . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.6.1 Swivel toilet . . . . . . . . . . . . . . . . . . . . 104
10.6.2 Winter operation. . . . . . . . . . . . . . . . . 106
11 Care . . . . . . . . . . . . . . . . . . . . . . . . . 107
11.1 External care . . . . . . . . . . . . . . . . . . . 107
11.1.1 General . . . . . . . . . . . . . . . . . . . . . . . 107
11.1.2 Washing with a high-pressure
cleaner. . . . . . . . . . . . . . . . . . . . . . . . 107
11.1.3 Washing the vehicle. . . . . . . . . . . . . . 108
11.1.4 Windows of acrylic glass . . . . . . . . . . 108
11.1.5 Hot galvanized chassis . . . . . . . . . . . 108
11.1.6 Add-on parts made of glass-fibre
reinforced plastic (GRP). . . . . . . . . . . 109
11.1.7 Underbody . . . . . . . . . . . . . . . . . . . . . 109
11.1.8 Waste water tank . . . . . . . . . . . . . . . .109
11.1.9 Entrance step . . . . . . . . . . . . . . . . . . .110
11.2 Interior care . . . . . . . . . . . . . . . . . . . .110
11.3 Cushions. . . . . . . . . . . . . . . . . . . . . . .111
11.4 Water system . . . . . . . . . . . . . . . . . . .112
11.4.1 Cleaning the water canister
or the water tank. . . . . . . . . . . . . . . . .112
11.4.2 Cleaning the water pipes . . . . . . . . . .112
11.4.3 Disinfecting the water system. . . . . . .113
11.5 Winter care . . . . . . . . . . . . . . . . . . . . .114
11.6 Lay-up. . . . . . . . . . . . . . . . . . . . . . . . .114
11.6.1 Temporary lay-up . . . . . . . . . . . . . . . .114
11.6.2 Winter lay-up . . . . . . . . . . . . . . . . . . .116
11.6.3 Starting up the vehicle after
a temporary lay-up or after
lay-up over winter . . . . . . . . . . . . . . . .116
12 Customer service
and maintenance . . . . . . . . . . . .119
12.1 Inspection work. . . . . . . . . . . . . . . . . .119
12.2 Maintenance work . . . . . . . . . . . . . . .119
12.3 Stabilisers. . . . . . . . . . . . . . . . . . . . . .119
12.3.1 General. . . . . . . . . . . . . . . . . . . . . . . .119
12.3.2 AKS 1300 . . . . . . . . . . . . . . . . . . . . . .120
12.3.3 WS 3000 D . . . . . . . . . . . . . . . . . . . . .120
12.4 Replacing bulbs, external . . . . . . . . . .121
12.5 Replacing bulbs . . . . . . . . . . . . . . . . .122
12.5.1 Halogen spotlight . . . . . . . . . . . . . . . .123
12.5.2 Surface-mounted halogen light. . . . . .123
12.5.3 Surface-mounted halogen light
(swivelling) . . . . . . . . . . . . . . . . . . . . .124
12.5.4 Awning light . . . . . . . . . . . . . . . . . . . .124
12.6 Adjusting the springs of the
blind and the insect screen. . . . . . . . .125
12.7 Spare parts. . . . . . . . . . . . . . . . . . . . .125
12.8 Vehicle identification plate . . . . . . . . .126
12.9 Warning and information stickers . . . .126
12.10 Dealers . . . . . . . . . . . . . . . . . . . . . . . .127
12.11 Replacement key . . . . . . . . . . . . . . . .127
13 Wheels and tyres . . . . . . . . . . . .129
13.1 General. . . . . . . . . . . . . . . . . . . . . . . .129
13.2 Tyre selection . . . . . . . . . . . . . . . . . . .130
13.3 Tyre specifications . . . . . . . . . . . . . . .131
13.4 Handling of tyres. . . . . . . . . . . . . . . . .131
13.5 Changing wheels . . . . . . . . . . . . . . . .131
13.5.1 General instructions . . . . . . . . . . . . . .131
13.5.2 Tightening torque . . . . . . . . . . . . . . . .132
13.5.3 Changing the wheel . . . . . . . . . . . . . .132
13.5.4 Changing a wheel at
alloy wheel rims . . . . . . . . . . . . . . . . .134
13.6 Spare wheel under the floor plate. . . .134
13.7 Tyre pressure . . . . . . . . . . . . . . . . . . .135

13Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Contents
14 Troubleshooting . . . . . . . . . . . . 139
14.1 Chassis . . . . . . . . . . . . . . . . . . . . . . . 139
14.2 Braking system . . . . . . . . . . . . . . . . . 139
14.3 Electrical system. . . . . . . . . . . . . . . . 140
14.4 Gas system. . . . . . . . . . . . . . . . . . . . 141
14.5 Gas cooker . . . . . . . . . . . . . . . . . . . . 142
14.6 Heater, boiler and
hot water source . . . . . . . . . . . . . . . . 142
14.6.1 Truma hot-air heater . . . . . . . . . . . . . 142
14.6.2 Truma boiler . . . . . . . . . . . . . . . . . . . 142
14.6.3 Truma hot water source . . . . . . . . . . 143
14.7 Refrigerator. . . . . . . . . . . . . . . . . . . . 144
14.8 Water supply. . . . . . . . . . . . . . . . . . . 145
14.9 Body . . . . . . . . . . . . . . . . . . . . . . . . . 146
15 Special equipment . . . . . . . . . . 147
15.1 Weight details for
special equipment. . . . . . . . . . . . . . . 147
16 Technical data . . . . . . . . . . . . . . 149
16.1 Technical data. . . . . . . . . . . . . . . . . . 149

Contents
14 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN

15Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Checklist before first journey of the vehicle
Checklist before first journey of the vehicle
Observe the following instructions before first journey
of the vehicle:
Observe the following instructions before each journey
of the vehicle:
If there is any risk of frost, observe the following
instructions:
XRe-tighten the wheel nuts/wheel bolts after 50 km (30 miles).
XRead the instruction manual to avoid personal and material
damage.
XCheck the tyre pressures.
See Tyre pressure section.
XLoad the vehicle correctly. Observe the maximum permissible
gross weight.
See Payload section.
XFully charge battery before each journey.
See section Living area battery.
XIn case of external temperatures below 0 °C first heat vehicle, then
fill water system.
See Water supply/Filling the water tank section.
XGas bottles should only be transported within the designated gas
bottle compartment and should be checked to be secure and in the
off position prior to travelling.
XKeep forced ventilations clear.
See Skylights and Ventilation sections.
XBefore filling the towing vehicle with fuel switch off gas-operated
appliances.
XIf there is any risk of frost, always heat the vehicle.
See Heater section.
XIf the vehicle is not being used when there is risk of frost, empty the
entire water system. Leave the water taps on in central position.
Leave the safety/drainage valve (if there is one) and drain cocks
open. This will avoid frost damage to appliances and to the vehicle.
See Emptying the water system section.

16 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Checklist before first journey of the vehicle

17Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Introduction 1
1Introduction
Please read this instruction manual completely before
using the vehicle for the first time!
Always keep this instruction manual in the vehicle. Also inform all other users
of the safety regulations.
This instruction manual contains sections which describe model-spe-
cific equipment or special equipment. These sections are not specially
marked. It may be that your vehicle has not been fitted with this special
equipment. In some cases, the actual equipment of your vehicle may
therefore be different from that shown in some illustrations and descrip-
tions.
However, your vehicle may be fitted with other special equipment not
described in this instruction manual.
Special equipment is described when an explanation is required.
Adhere to the instruction manuals which are separately enclosed.
Should the vehicle be subjected to damage due to a failure to follow the
instructions in this instruction manual, then the warranty claim is deemed
invalid.
Our vehicles are subjected to continuous development. Please understand
that we reserve the right to alter the form, equipment and technology. There-
fore, no claims can be made against the manufacturer as a result of the con-
tents ofthis instructionmanual. Theequipmentwhich wasknownand included
at the time of going to press is described.
The reprinting, translation and copying, including extracts is not permitted
without prior written authorisation from the manufacturer.
XThe non-observance of this symbol can lead to personal injury.
ZThe non-observance of this symbol can lead to damage being caused to,
or inside the vehicle.
ZThis symbol indicates recommendations or special aspects.
ZThis symbol indicates actions which lead to environmental awareness.
ZThe details "right", "left", "front" and "rear" always refer to the vehicle in
direction of travel.
ZAll dimensions and weight details are "approximate".
ZThe metric specifications are binding for physical dimensions.

18 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
1 Introduction
1.1 General
The vehicle is constructed in accordance with the latest technology and the
recognised safety regulations. Nevertheless, personal injury may result and
the vehicle may be damaged if the safety instructions in this instruction manual
are not followed.
Only use the vehicle in a technically impeccable condition. Follow the instruc-
tions in the instruction manual.
Malfunctions which impair the safety of persons or the vehicle should be
immediately remedied by qualified personnel. To avoid further damages,
observe the duty to avert, minimise or mitigate loss for the user during faults.
Have the vehicle's braking and gas systems inspected and repaired by an
authorised specialist workshop only.
Alterations to the body are only to be carried out with the authorisation of the
manufacturer.
Luggage and accessories may only be transported up to the maximum permis-
sible gross weight.
Observe the test and inspection periods stipulated by the manufacturer.
1.2 Environmental tips
ZThe vehicle comes without a wheelbrace and vehicle jack. We suggest you
obtain a commercially available wheelbrace before you first use your car-
avan, in case of an emergency. If no AL-KO vehicle jack (special equip-
ment for AL-KO chassis) is present, obtain a conventional commercial
scissor-type jack or an hydraulic vehicle jack, in order to have it ready in
the case of mishap or emergency. Our authorised dealers and service cen-
tres will be happy to advise you.
ZBe considerate of the environment.
ZRemember that: All kinds of waste water and household waste are not to
be disposed of in drains or in the open countryside.
ZOn board, collect waste water only in the waste water tank or – if
necessary – in other containers designed for that purpose.
ZOnly empty the waste water tank and sewage tank at disposal stations,
camping sites or caravan sites especially provided for this purpose. When
stopping in towns and communities, observe the instructions at caravan
sites or ask where there are disposal stations.
ZEmpty waste water tank as often as possible, even when it is not com-
pletely full (hygiene).
If possible, flush out waste water tank and, if necessary, drainage pipe with
fresh water every time it is emptied.
ZNever allow the sewage tank to become too full. Empty the sewage tank
frequently, at the latest as soon as the filling level display lights up.
ZSeparate household waste according to glass, tin cans, plastic and wet
waste also when on a journey. Enquire at the town or community authority
about disposal points. Household waste is not to be disposed of in waste
paper baskets which are situated at car parks.
ZEmpty waste bins as often as possible into the containers provided for this
purpose. This helps to avoid unpleasant smells and an accumulation of
rubbish on board.

19Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
Introduction 1
ZWhen parked, do not allow the engine of the towing vehicle to run more
than necessary. When running idle, a cold engine releases more contami-
nants than usual. The running temperature of the engine is achieved more
quickly whilst the vehicle is in motion.
ZUse an environmentally-friendly WC chemical agent for the WC which can
also be biologically degraded and only use small doses.
ZWhen staying in towns and communities for long periods, search for
parking areas which are specially reserved for caravans and towing vehi-
cles. Enquire at the town or community authority about parking spaces.
ZAlways leave the parking places in a clean condition.

20 Touring - 04/11-1 - englisch (EN) - 2048869 - HYW-0102-09EN
1 Introduction
