Emerson Research SMARTSET CKD5809C User manual

OWNER’S MANUAL
CKD5809C
Visit our web site at www.emersonelectronics.ca
SmartSet ®CD Clock Radio
with Automatic Time Setting System
Digital Tuning Stereo Receiver
and Touchless Snooze Control
(U.S. Patent No. 6,567,344)
CKD5809_021705.p65 17/2/2005, 14:5839

1
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1.) Read these instructions.
2.) Keep these instructions.
3.) Heed all warnings.
4.) Follow all instructions.
5.) Do not use this apparatus near water.
6.) Clean only with dry cloth.
7.) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8.) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11.) Only use attachments / accessories specified by the manufacturer.
12.) Unplug this apparatus during lightning storms or when unused for long periods of time.
13.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
14.) This appliance shall not be exposed to dripping or splashing water and no object filled with
liquids such as vases shall be placed on the apparatus.
15.) Do not overload wall outlet. Use only power source as indicated.
16.) Use replacement parts as specified by the manufacturer.
17.) The product may be mounted to a wall only if recommended by the manufacturer.
18.) Upon completion of any service or repairs to this product, ask the service technician to
perform safety checks.
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow-
head symbol, within an equi-
lateral triangle is intended to
alert the user to the presence
of uninsulated‘dangerousvoltage’
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
Theexclamationpointwithin
an equilateral triangle is in-
tended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompany-
ing the appliance.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER
(OR BACK), NO USER
SERVICEABLE PARTS INSIDE
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
CAUTION
CKD5810_102104.p65 4/3/2005, 14:481


7KDQN <RX««««
)RUSXUFKDVLQJWKLV(PHUVRQ5HVHDUFK6WHUHR&'&ORFN5DGLRZLWKWKHSDWHQWHG
6PDUW6HWDXWRPDWLFWLPHVHWWLQJV\VWHP$VVRRQDV\RXSOXJLQ\RXUUDGLRIRU
WKHILUVWWLPHDQGDIWHUHYHU\SRZHULQWHUUXSWLRQWKHFORFNZLOODXWRPDWLFDOO\VHW
LWVHOIWRWKHFRUUHFW\HDUPRQWKGDWHGD\DQGWLPH,WZLOODOVRDXWRPDWLFDOO\
DGMXVWLWVHOIIRUDOO'D\OLJKW6DYLQJ7LPHFKDQJHVWKURXJKWKH\HDU
7KHUHDUHGXDODODUPVWKDWFDQEHVHWDQGXVHGLQGHSHQGHQWO\7KHDODUPVFDQEH
VHWIRUZHHNGD\VRQO\ZHHNHQGVRQO\RUHYHU\GD\RSHUDWLRQ<RXFDQZDNHWRDQ
HOHFWURQLFEX]]HUWRQH\RXUIDYRULWH$0RU)0VWDWLRQRUDVSHFLILFWUDFNRQ\RXU
IDYRULWH&'$QGLI\RXFDQ¶WUHDFKWKHVQRR]HEDUZKHQWKHDODUPJRHVRII\RXFDQ
MXVWZDYH\RXUKDQGLQIURQWRIWKH³7RXFKOHVV´ VQRR]HVHQVRURQWKHIURQWSDQHO
7KHDODUPZLOOVKXWRIIIRUPLQXWHVDQGWKHQWXUQRQDJDLQ7KHUH¶VDSURJUDPPDEOH
PLQXWHVOHHSWLPHUWKDWDOORZV\RXWRIDOODVOHHSWRXSWRPLQXWHVRIPXVLF
DQGWKHQVKXWVWKHSRZHURIIDXWRPDWLFDOO\
$SURJUDPPDEOHPLQXWHQDSWLPHUOHWV\RXZDNHXSDIWHUDQDSZLWKRXWGLVWXUELQJ
\RXUQRUPDODODUPVHWWLQJV
7KH&'SOD\HUKDVDWUDFNSURJUDPPDEOHPHPRU\DQGUHSHDWSOD\EDFN,WZLOO
DOVRSOD\&'5DQG&'5:GLVFVLQDGGLWLRQWRQRUPDO&'V7KHGLJLWDOWXQLQJ
VWHUHRUHFHLYHUORFNVLQ\RXUIDYRULWHVWDWLRQVSHUIHFWO\DQGVWRUHVXSWRVWDWLRQV
$0DQG)0LQPHPRU\IRULPPHGLDWHUHFDOO
7KLVPRGHODOVRLQFOXGHVDGXDOEDWWHU\EDFNXSV\VWHP7KHUH¶VDEXLOWLQ&5
OLWKLXPEDWWHU\WKDWZLOOPDLQWDLQWKHWLPHDQGDODUPVHWWLQJVIRUXSWR\HDUVRU
ORQJHUGHSHQGLQJRQWKHIUHTXHQF\DQGOHQJWKRIWKHSRZHULQWHUUXSWLRQV\RX
H[SHULHQFHLQ\RXUKRPH:H¶YHDOVRSURYLGHGD6XUH$ODUPEDWWHU\EDFNXSV\VWHP
WKDWZLOODFWLYDWHWKHDODUPHYHQLIWKHSRZHURI\RXKRXVHLVRIIDW\RXUZDNHXSWLPH
7KH6XUH$ODUPFLUFXLWUHTXLUHVD 9ROWEDWWHU\QRWLQFOXGHG
7KHWLPHUDGLRIUHTXHQF\DQG&'WUDFNQXPEHUDOODSSHDURQDODUJHVXSHUEULJKW
/('GLVSOD\WKDWLVHDVLO\UHDGDEOHIURPDQ\ZKHUHLQ\RXUURRP$QGRIFRXUVH
ZH¶YHLQFOXGHGDGLPPHUVZLWFKLQFDVH\RXZDQWWRUHGXFHWKHGLVSOD\EULJKWQHVV
IRUVOHHSLQJ
:LWKVRPDQ\XVHIXOIHDWXUHVSDFNHGLQWRVXFKDFRPSDFWXQLWLW¶VLPSHUDWLYHWKDW
\RXUHDGWKLV2ZQHU¶V0DQXDOFDUHIXOO\DQGFRPSOHWHO\
&.'BS 

3
We have taken great care to make sure that this unit was in perfect working order
when it left our factory. If you have any problems with the set-up or operation of
this model please do not return it to the dealer. Please call the Emerson Consumer
Products Customer Service Hotline, toll-free at: 1-800-287-4871. One of our
customer service representatives will try to diagnose and correct the problem for
you. If we cannot solve the problem by phone you will be instructed how to receive
a replacement unit.
Once again, all of us at Emerson Radio thank you for your purchase.
The serial number of your unit is located on a label on the bottom cabinet. Please
take a moment to locate the serial number of your unit and write it in the space
provided below. You may be asked to provide this number when calling to request
customer service.
Model Number: CKD5809C
Serial Number:
CKD5809_021705.p65 17/2/2005, 14:583

5
PREPARATION FOR USE
Unpacking and Set-up
• Remove the unit from the shipping carton and remove all packing material
from the unit. Please save the carton and packing material if possible in the
event that your unit ever needs to be returned for service. Using the original
carton and packing materials is the only way to protect your unit from damage
in transit.
• Carefully remove any small strips of tape that may have been used to keep the
CD door closed during shipment.
• Press on the CD door in the area marked OPEN/CLOSE to open the door.
Inside the CD compartment you will see a white “dummy CD” transit protection
card. This card prevents the laser pick-up from moving during shipment and it
must be removed before you can load your own CDs. Carefully remove this
transit protection card and discard it.
• Place the unit on a stable, level surface such as a table, desk, shelf, stand, etc,
out of direct sunlight and away from sources of excess heat, dust, vibration,
moisture, or humidity, and convenient to a 120V 60Hz AC outlet.
• Unwind the AC power cord and extend it to its full length. This is important. The
FM antenna is built into the AC power cord.
Battery Back-up Systems
This model has two separate battery back up systems. There is a built in 3-Volt
CR2430 long life lithium battery that will maintain the clock settings, the alarm
settings and the tuner preset memory settings. The lithium battery may last for up
to five years or even longer, depending on the frequency and length of the power
interruptions that you experience in your home. If AC power is interrupted the
display will go off but the lithium battery will continue to power the clock. When AC
power is restored the display comes on again and all your settings are correct.
We have also provided a separate Sure-Alarm battery back up circuit that requires
a 9-Volt battery, not included.
If you install a 9-Volt battery, the buzzer alarm will operate in BUZZER or RADIO
mode, even if the power is off at the selected wake-up time.
CKD5809_021705.p65 17/2/2005, 14:585

6
Installing The Sure-Alarm Back-up Battery (Not Included)
The Sure-Alarm battery compartment is located on the back panel.
1.) Press down on the battery door locking tab as
shown and remove the battery door.
2.) Gently pull the battery terminal outside
of the compartment just far enough so
you can connect the battery.
3.) Connect a fresh, well-known brand of
9-Volt Alkaline battery to the battery
terminal. It can only be connected one
way.
4.) Push the battery back into the battery compartment and replace the battery
door.
CKD5809_021705.p65 17/2/2005, 14:586

7
Low Battery Indicator
The Low Battery indicator “ ” only appears in the main display when the
unit is in the power ‘Off’ mode.
• If you install a 9-Volt battery in the Sure
Alarm circuit as described above, the
Low Battery indicator disappears.
• If the Low Battery indicator remains ‘On’,
this indicates that either you have not
installed the 9-Volt battery, or that the
9-Volt battery is exhausted and needs
to be replaced.
• If the Low Battery indicator flashes, this
indicates that the 3-Volt lithium battery
is getting weak and should be replaced
as soon as possible.
Instructions for changing the lithium battery will be found on page 32 of this manual.
CKD5809_021705.p65 17/2/2005, 14:587

8
Power Source
This system is designed to operate on 120V AC 60Hz house current only.
Connecting this system to any other power source may cause damage to the
system and such damage is not covered by your warranty.
NOTE: The system has a polarized AC plug with one wide blade and one narrow
blade. The plug will only fit into matching polarized AC outlets.
This is a safety feature to reduce the
possibility of electric shock. If the plug will
not fit in your AC outlet, you probably have
an outdated non-polarized outlet. You
should have your outdated outlet changed
by a qualified, licensed electrician. Do not
file the wide blade on the plug, or use an
adapter to make the plug fit into your
outlet. This defeats the safety feature and
could expose you to electric shock.
Protect Your Furniture
This model is equipped with non-skid rubber 'feet' to prevent the product from
moving when you operate the controls. These 'feet' are made from non-migrating
rubber material specially formulated to avoid leaving any marks or stains on your
furniture. However certain types of oil based furniture polishes, wood preservatives,
or cleaning sprays may cause the rubber 'feet' to soften, and leave marks or a
rubber residue on the furniture. To prevent any damage to your furniture we strongly
recommend that you purchase small self-adhesive felt pads, available at hardware
stores and home improvement centers everywhere, and apply these pads to the
bottom of the rubber 'feet' before you place the product on fine wooden furniture.
AC Plug
A
C Outlet
CKD5809_021705.p65 17/2/2005, 14:588

9
LOCATION OF CONTROLS AND INDICATORS
FRONT PANEL
29
1
2
3
1
4
11 12
10
9
13
8
14
7
6
15
16
5
17
18
19
32
31
30 29 28 27 26 25 24 23 22 21 20
TOP PANEL
CKD5809_021705.p65 17/2/2005, 14:589

10
1.) Speakers.
2.) Multi-Function LED Display.
3.) 3-Volt Lithium Battery Compartment (Bottom Cabinet).
4.) TOUCHLESS SNOOZE SENSOR.
5.) POWER ON/OFF Button.
6.) SLEEP Button.
7.) ALARM 1 (BUZZER/RADIO/CD/OFF) Selector Switch.
8.) ALM (Alarm) 1Button.
9.) ALARM 2 (BUZZER/RADIO/CD/OFF) Selector Switch.
10.) DIMMER (LO/HI) Selector Switch.
11.) 9-Volt Battery Compartment (Back Cabinet).
12.) AC Power Cord.
13.) CD Door.
14.) PRESET + Button.
15.) REV. SKIP/TUNING – Button.
16.) FWD. SKIP/TUNING + Button.
17.) VOLUME Control.
18.) PLAY/PAUSE Button.
19.) STOP Button.
20.) WAKE UP TRACK Button.
21.) MEMORY Button.
22.) PRESET – Button.
23.) AM/FM Button.
24.) REPEAT Button.
25.) NAP Button.
26.) PROGRAM Button.
27.) SNOOZE/SLEEP/NAP OFF Button.
28.) TIME Button.
29.) MONTH/DATE Button.
30.) TIME ZONE Button.
31.) ALM (Alarm) 2Button.
32.) ALARM MODE Button.
CKD5809_021705.p65 17/2/2005, 14:5810

11
OPERATING INSTRUCTIONS
• Make sure that you have extended the AC power cord to its full length.
The FM antenna is built into the power cord.
• Make sure that you have installed a fresh 9-Volt battery in the Sure
Alarm circuit if you want the Sure Alarm battery back up circuit to
operate. If you do not install a 9-Volt battery the Low Battery indicator
will remain ‘on’, but this will not affect any other functions or operation
of this product.
• Make sure that you have removed the “dummy CD” transit protection
card from the CD compartment.
A Word About The And Controls
In order to minimize the number of controls on this model
a few of the controls perform more than one function.
For example, the and buttons on the top panel
perform the following functions:
• When pressed together with the TIME ZONE button, the and buttons
allow you to select a lower or higher numbered time zone.
• When pressed together with the TIME button, the and buttons adjust
the time display backward or forward.
• When pressed together with the ALM 1 or ALM 2 buttons, the and
buttons adjust the wake up time display backward or forward.
• When pressed together with the MONTH/DATE button, the and buttons
adjust the Month and Date display backward or forward.
• When pressed together with the TIME and MONTH/DATE buttons, the
and buttons adjust the year display backward or forward.
• When pressed together with the SLEEP or NAP buttons, the and buttons
adjust the amount of Sleep Time or Nap Time display down or up.
• In Tuner mode (AM/FM) pressing the and buttons moves the tuner
display down or up to lower or higher numbered frequencies.
• In CD mode pressing the and buttons allows you to skip to lower or
higher numbered tracks, or to search backward or forward within a track to
locate a specific musical passage.
All of the functions of the and buttons will be fully explained in the appropriate
sections of this manual.
CKD5809_021705.p65 17/2/2005, 14:5811

12
Setting The Time, The First Time
IMPORTANT: The first time you connect your new SmartSet®CD clock radio to
the AC outlet the internal computer will automatically set the time correctly for the
Eastern Time Zone, which is the initial default setting. The display will scan for a
few seconds and then show the correct Day and Time in the Eastern zone. If you
live in the Eastern Time zone, there’s nothing else to do. Your clock is set correctly
and running.
If you do not live in the Eastern Time zone you must change the default zone
display to your own zone. You only do this one time and the SmartSet®will remember
the new default zone setting and will always return to that setting after a power
interruption
There are 7 time zones programmed into your SmartSet®clock radio as follows:
ZONE 1 — Atlantic Time
ZONE 2 — Eastern Time (Default Setting)
ZONE 3 — Central Time
ZONE 4 — Mountain Time
ZONE 5 — Pacific Time
ZONE 6 — Yukon Time
ZONE 7 — Hawaiian Time
To change the default time zone display, depress the TIME ZONE button. The
number “02” will appear on the display indicating that the default zone is ZONE 2,
Eastern Time.
Hold the TIME ZONE button and then press either the or buttons until your
own time zone appears on the display, then release the buttons.
The clock display will change to the correct time in the time zone you selected. The
clock will always return to the correct time in the zone you selected after every
power interruption. If you move to a different time zone, simply change the default
zone display to the new zone and the SmartSet®will remember that setting for you.
CKD5809_021705.p65 17/2/2005, 14:5812

13
Date Display
To see the correct date at any time, depress the MONTH/DATE button. The display
changes from time to month and date (MM/DD).
For example, May 21st will appear as “521”.
When you release the MONTH/DATE
button the display returns to the correct time.
Year Display
To see the correct year, depress the
MONTH/DATE and TIME buttons together,
the display changes from time to year.
When you release the MONTH/DATE and TIME buttons the display returns to the
correct time.
Daylight Saving and Leap Year Adjustments
All Daylight Saving and Leap Year adjustments are made automatically by
the SmartSet®internal computer as follows:
•Start of Daylight Saving Time:
At 1:59.59 AM on the first Sunday in April, the clock will automatically
advance to 3:00 AM.
•End of Daylight Saving Time:
At 2:59.59 AM on the last Sunday in October, the clock will automatically
reset to 2:00 AM.
•Leap Year:
At 12:00 Midnight on February 28th, the calendar display will change
to "2 29"
CKD5809_021705.p65 17/2/2005, 14:5813

14
Manual Time Adjustments
Some people like to set their clocks 5 to 10 minutes fast to make sure that they will
always be on time. Even though the SmartSet®sets the time by itself, you still have
the option of adjusting the time manually if you wish.
To manually adjust the time display depress and hold the TIME button, and press
either the or buttons to adjust the time display ahead or back as desired.
Each press of the or buttons will change the display by one minute. If you
hold the or buttons the display will continue to change. The display will
change slowly at first, one minute at a time. But if you continue holding the or
buttons the display will change rapidly..
Note:If you manually adjust the time, your new setting is entered into the
SmartSet®memory. If the power is interrupted, the display will return to your
new setting, not the original setting, when the power is restored.
Adjusting The Wake Up Times
Your SmartSet®clock radio has two separate alarms that can be set and used
independently. You may use the alarms to wake two people at different times, or
you may use one alarm for weekdays and the other for weekend wake up times.
The procedure for adjusting the wake up time is the same for both Alarm 1 and
Alarm 2.
1.) Depress and hold either the ALM 1 or
ALM 2 setting button. The display will
change from the correct time to the
Alarm 1 or Alarm 2 wake up time.
2.) While holding the ALM 1 or ALM 2 setting button, depress either the or
button to move the display ahead or back to your desired wake up time.
3.) When the desired wake up time appears on the display, release the or
buttons.
Note: Be sure that you have set the wake up time correctly by observing
the AM indicator. If the AM indicator is ‘On’ the wake up time is “AM”. If the
AM indicator is ‘Off’, the wake up time is “PM”.
4.) When the desired wake up time (AM or PM) appears on the display, release
the ALM 1 or ALM 2 setting buttons.
CKD5809_021705.p65 17/2/2005, 14:5814

15
Selecting The Alarm Mode
Your SmartSet®clock radio allows you to select from among three different alarm
operation modes for either alarm. The alarm modes are:
•Everyday – the alarm will turn on all 7 days.
•Weekdays only – the alarm will only turn on Monday through Friday;
•Weekends only – the alarm will only turn on Saturday and Sunday;
To check the Alarm Mode setting for Alarm 1, depress the ALM 1 setting button.
The display will show the Alarm 1 wake up time and the day of the week indicators
will show you the alarm mode which is selected.
• If all 7 indicators are ‘On’, the Everyday mode is selected.
• If only the Monday through Friday indicators are ‘On’, the Weekdays only mode
is selected.
• If only the Saturday and Sunday indicators are ‘On’, the Weekends only mode is
selected.
To change the Alarm Mode setting for Alarm 1, hold the ALM 1 setting button and
press the ALARM MODE button until the day indicators show the desired mode
setting, Weekdays only, Weekends only, or Everyday operation.
Release the ALARM MODE and ALM 1 setting buttons and the display will return
to the correct time.
Follow the same procedure to select the desired Alarm Mode for Alarm 2 if
necessary.
Checking The Wake Up Times And Alarm Mode
Whenever you want to check the wake up time or the alarm mode settings, simply
press either the ALM 1 or ALM 2 setting buttons. The display will change from
correct time to wake up time and the day indicators will show you the alarm mode
which is currently selected.
Release the ALM 1 or ALM 2 setting buttons to return to correct time.
CKD5809_021705.p65 17/2/2005, 14:5815

16
Listening To The Radio
1.) Press the POWER ON/OFF button on the top panel. The display will change
from time to radio frequency. The first time you turn your unit on the display will
show FM 87.5 MHz.
2.) To switch between the FM and AM bands press the AM/FM button. The first
time you select the AM band the display will show AM 520 KHz.
3.) Tune to the desired station with the or buttons on the top panel as
follows:
• Manual Tuning
Repeatedly press either the or button until the display shows the
frequency of the desired station.
• Automatic Tuning
Depress and hold either the or button until the display begins to move,
then release the button. The tuner searches down or up the band until it finds
a strong signal and then stops on that station. Repeat this process until the
tuner stops on the desired station.
4. If you tuned to an FM Stereo station the
FM ST indicator appears in the display.
5. Five seconds after you release the or button the display automatically
changes from radio frequency back to the correct time.
To see the station frequency again, press the TIME button. The display will
change from time to radio frequency for 5 seconds and then return to the
correct time
6. Adjust the VOLUME control on the right side of the cabinet to the desired level.
7. When you are finished listening press the POWER ON/OFF button to shut the
power ‘Off’.
Note: The Tuner remembers the last station that was tuned before the power
is switched off and automatically returns to that station when the power is
switched on again.
CKD5809_021705.p65 17/2/2005, 14:5816

17
Presetting Stations In The Tuner Memory
You can store a total of 20 stations, 10 FM and 10AM, in the tuner memory for
easy recall at any time.
1.) Using either the Automatic or Manual
Tuning method described above, tune
to the first station you wish to store in
the tuner memory.
Example: FM 92.5 MHz
2.) When the desired frequency appears on the display press the MEMORY button
once.
“F 1” will begin flashing on the display
indicating that you can now store your
station in FM Preset Memory #1.
3.) Press the MEMORY button again. The flashing “F 1” disappears and the station
frequency returns to the display. This indicates that FM 92.5 is now stored in
FM Preset Memory #1.
4.) Tune to the next station that you wish to store.
Press the MEMORY button once, then
press the PRESET + button to select
Preset Memory number 2.
“F 2” begins flashing in the display.
5.) Press the MEMORY button once more to enter your desired station in Preset
Memory number 2.
6.) Repeat steps 4 and 5, using the PRESET – or + buttons to select a different
preset memory number each time until you have stored up to 10 FM stations in
the memory.
7.) Press the AM/FM button to switch to the AM band and repeat the above
procedure to store up to 10 AM stations in the tuner memory.
CKD5809_021705.p65 17/2/2005, 14:5817

18
Notes:
• The FM memories are numbered F1 through F10. The AM memories are
numbered A1 through A10.
• After you press the memory button the first time you must select a Preset
Memory number and press the MEMORY button again within 10 seconds,
while the memory number is flashing, or the station will not be memorized.
Recalling Preset Stations
Press the AM/FM button to select the desired band.
Press the PRESET – or + buttons to scroll through the preset stations one by one.
Changing Preset Stations
1.) Tune to the new station that you want to store.
2.) Press the MEMORY button and then press the PRESET – or + buttons to
select the memory number that you wish to change.
3.) When the desired Preset Memory number is flashing, press the MEMORY
button again. The new station is now stored and the previous station is deleted
from the memory.
CKD5809_021705.p65 17/2/2005, 14:5818

19
Antenna Information
FM:The FM antenna is built in the AC power cord. You may have to extend and
vary the direction of the AC power cord until you find the position that provides
the best reception.
AM:The AM bar antenna is inside the cabinet of the main unit. You may need to
change the position of the main unit until you find the position that provides
the best reception for your favorite AM stations.
CKD5809_021705.p65 17/2/2005, 14:5819
