Emerson Turbo HR2003 User manual

WATER RESISTANT
PERSONAL STEREO RADIO
with DIGITAL TUNING
AM/FM/TV/WEATHER BANDS
HR2003
OWNER’S MANUAL
Visit our web site at www.emersonradio.com
HR2003_ib040903.p65 9/4/2003, 11:3619

1
Thankyou forpurchasing thisEmerson Water-ResistantPersonalstereo radio
withAM/FM/TVand WeatherBand digitaltuner.
Ourengineershaveincluded manyusefuland convenientfeaturesinthisproduct.
Pleasebe suretoread thisOwner’s Manualcompletelytomakesureyou are
getting the maximumbenefitfromeachfeature.
Thisproductwasmanufactured usingthehighestqualitycomponentsandstandards
ofworkmanship.It wastested byEmerson inspectorsand found tobe inperfect
working orderbeforeitleft ourfactory.However,thereisalways the chancethat
someproblemmayoccurbecauseofrough handling during shipmenttothe retail
storeortothe finalconsumer.
If, afterreading thisManual,you experienceanyproblemswiththe operation of
thisproduct, pleaserefertothe instructionsforobtaining serviceatthe end ofthis
Manual.Emerson and Emerson retailersarecommitted toyoursatisfaction.
Onceagain,thanks forpurchasing thisEmerson audioproduct.
ModelNumber:HR2003
SerialNumber:
HR2003_ib040903.p65 9/4/2003, 11:121

2
IMPORTANTNOTES
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. Thisequipmentgenerates,usesand can radiateradio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user authority to operate the equipment.
HR2003_ib040903.p65 9/4/2003, 11:122

3
PREPARATIONFORUSE
POWER SOURCES
This personal stereo radio with AM/FM/TV and Weather Band digital tuner is
designed to operate on one alkaline “AAA” battery, not included. Attempting to
operate this unit on any other power source may cause damage to the unit and
such damage is not covered by your warranty.
INSTALLING THE BATTERY
The battery compartment is located on the back-side of the radio cabinet.
1.) Press down on the mark on the battery cover and slide the cover in the
direction of the arrow.
2.) Insert one fresh “AAA” alkaline battery in the battery compartment. Be sure to
follow the polarity making in the battery compartment. If the battery is inserted
incorrectly the unit will not work.
3.) Replace the battery compartment cover.
WHEN TO CHANGE THE BATTERY
When the Battery Indicator begins to “empty” the batteries are getting weak.
When the indicator starts flashing in the display the battery is almost exhausted
and should be changed as soon as possible. Do not leave a weak or exhausted
battery in the radio as it will eventually leak and cause corrosion inside the battery
compartment.
HR2003_ib040903.p65 9/4/2003, 11:123

4
ARM-BAND STRAP INSTALLATION
This radio is supplied with an accessory arm-band strap to secure the radio on
your arm while you are jogging or performing other strenuous activities.
To install the arm-band strap, thread the strap through the two slots on the back
cabinet as shown, and then through the buckle. Adjust the Velcro®strap to fit
comfortably but securely around your arm.
HR2003_ib040903.p65 9/4/2003, 11:124

5
LOCATIONOFCONTROLSAND INDICATORS
PRESET
UP
DOW
N
SNOOZ
E
M
U
T
E
B
A
N
D
MHzkHz
POWER
C
L
O
C
K
S
E
T
M
E
M
O
R
Y
R
H
M
ALAR
M
FRONTCABINET
1.)BAND (AM/FM/TV/Weather) Button.
2.)POWER(SLEEP)Button.
3.)MEMORY/CLOCKSETButton.
4.)SNOOZEButton.
5.)ALARMButton.
6.)MUTEButton.
7.)TUNERDisplay.
8.)PRESETUPButton.
9.)PRESETDOWNButton.
10.)TUNING+/CLOCKSET–H(Hour) Button.
11.)TUNING–/CLOCKSET–M(Minute)Button.
12.)HOLDSwitch.
SIDECABINET
13.)VOLUMEControl.
14.)PHONES Jack.
15.)BASS BOOSTButton.
BACK CABINET
16.)BatteryCompartment.
17.)Arm-band Strap Brackets.
1
2
3
17
4
5
6
16
14 13
7
15
8
9
10
11
12
17
HR2003_ib040903.p65 9/4/2003, 11:125

6
1.)PRESETIndicator.
2.)BASS –Bass BoostIndicator.
3.)SLEEP Indicator.
4.)HOLD“ ”Indicator.
5.)Alarm Indicator.
6.)BatteryLevelIndicator.
7.)RadioFrequency /ChannelDisplay.
8.)AM/PMIndicators.
9.)Band Indicators–WB/TV/FM/AM.
10.)PresetMemoryNumberDisplay.
MULTIFUNCTIONLCD DISPLAY
FM
AM
PRESET
PM
TV
WB
BASS
SLEEP
1
2 3 4 5
10 9 8 7
6
HR2003_ib040903.p65 9/4/2003, 11:126

7
OPERATINGINSTRUCTIONS
• Make sure the battery is installed correctly.
• Set the VOLUME control to a low level.
• Fully unwind the headphone cord and connect the headphone plug to
the PHONES jack. The plug must be fully inserted into the jack, otherwise
the sound may be intermittent.
• Make sure that the HOLD switch is in the ‘Off’ position.
IMPORTANT INFORMATION
This personal stereo radio is designed to be “water-resistant”. Jogging
in the rain with this radio will cause no problems. However this radio is
not “water-proof” and should never be fully or partially immersed in water,
or any other liquid. Water should never be allowed to get inside the
cabinet when changing the battery. Keep the rubber headphone jack
cover in place when the unit is not in use. If the cabinet does become
wet after jogging in the rain, wipe away any excess moisture with a soft
dry towel before putting the radio away.
SPORTS STYLE LIGHTWEIGHT STEREO HEADPHONES
The lightweight stereo headphones supplied with this personal stereo radio have
earpieces designed to fit directly into your ear. Be sure to observe the “L” (Left)
and“R”(Right) markings onthe earpieces tomake sure that youput the headphones
on correctly. Always set the VOLUME control to a low level before putting on the
earphones, and then gradually increase the volume to a comfortable listening level.
PHONES Jack
VOLUMEControl
HR2003_ib040903.p65 9/4/2003, 11:127

8
HOLD Switch “ ”
The HOLD switch locks all of the other controls
buttons. If you are carrying the radio in a
backpack, handbag, gym bag, etc, set the HOLD
switch to the ‘On’ positionto prevent it fromturning
‘On’ accidentally by something pressing against the POWER button. Likewise,
once you start listening to the radio you can set the HOLD switch to the ‘On’ position
to prevent you from accidentally pressing the POWER button again or the TUNING
+ / – or PRESET UP/DOWN buttons while you are carrying or jogging with the
radio. Remember that to use any of the other controls the HOLD switch must be
set to the ’Off’ position.
PRESET
UP
DOW
N
SNOOZ
E
M
U
T
E
B
A
N
D
MHzkHz
POWER
C
L
O
C
K
S
E
T
M
E
M
O
R
Y
R
H
M
ALAR
M
HOLDSwitch
FM
PRESET
BASS
HR2003_ib040903.p65 9/4/2003, 11:128

9
SETTING THE CLOCK
The clock must be set with the radio ‘Off’.
1.) Press the MEMORY/CLOCK SET button for
at least two seconds. The time display begins
to flash.
2.) While the display is flashing press the TUNING + /CLOCK SET-H button to
adjust the hour. Be sure to set correctly for AM or PM.
3.) Press the TUNING – /CLOCK SET-M button to adjust the minutes.
4.) When the display shows the correct time,
press the MEMORY/CLOCK SET button
once more. The display stops flashing and
the clock begins to run.
Note: The correct time will always appear on the display when the radio is ‘Off’.
AM
PM
HR2003_ib040903.p65 9/4/2003, 11:129

10
LISTENING TO RADIO
Information
This radio receives normal AM and FM broadcasts plus the TV sound from VHF
TV stations 2 through 13. In addition it receives all 7 NOAA weather frequencies
so you can listen to continuous National Weather Service broadcasts.
Please note that the weather channels are identified as “1 ch” through “7 ch”.
•Most USA residents will find their local weather broadcast on channels 1, 2, or 3.
•Channels 4 through 7 are newer stations used in some areas. If you live in a
densely populated area you may be able to receive the weather broadcasts on
more than one channel. If so, choose the channel with the strongest reception
since that is likely to be the closest station to your location.
Keep in mind that the weather station transmitters operate at much lower power
than commercial radio stations. Normally the volume of the weather stations will
be lower and you may have to raise the volume control to hear these stations
clearly. If you raise the volume control to hear the weather station be sure to reduce
the volume control before switching back to AM/FM or TV bands, because the
difference can be substantial.
BASS BOOST Button
Press the BASS BOOST button for added Bass response. The BASS indicator
appears in the display. Press again to cancel Bass Boost and resume normal
sound. The BASS indicator disappears.
PRESET
UP
DOW
N
SNOO
Z
E
M
U
T
E
B
A
N
D
MHzkHz
POWER
C
L
O
C
K
S
E
T
M
E
M
O
R
Y
R
H
M
ALAR
M
BASS BOOSTButton
HR2003_ib040903.p65 9/4/2003, 11:1210

11
OPERATION
1.) Make sure that the HOLD button is in the ‘Off’ position. (The HOLD
indicator does not appear in the display.)
2.) Press the POWER button to turn the radio
‘On’. An AM, FM, TV or Weather Band
frequency will appear in the display.
3.) If necessary press the BAND button to switch
between AM, FM, TV and Weather bands.
The appropriate band indicator appears in the
display to confirm your selection.
4.) Press the TUNING “ + ” or TUNING “ – ” buttons to select the desired station
as follows:
• Manual Tuning
Repeatedly press the TUNING “ + ” or TUNING “ – ” buttons until the display
shows the frequency of the desired radio station.
The desired TV channel (“ 2 ch ” through “ 13 ch ”), or
The desired Weather Band channel (“ 1 ch ” through “ 7 ch ”).
• Automatic Tuning
Depress and hold either the TUNING “ + ” or TUNING “ – ” button until the
display begins to move then release the button. The tuner will search up or
down until it finds the next strong station and stops on that station. Repeat this
procedure until it stops on your desired station.
5.) Adjust the VOLUME and BASS BOOST controls as desired.
6.) When you are finished listening press the POWER button to turn the power
‘Off’. The display will return to the correct time of day.
FM
PRESET
PRESET WB
HR2003_ib040903.p65 9/4/2003, 11:1211

12
PRESETTING STATIONS IN THE TUNER MEMORY
You may preset up to 42 of your favorite stations (20 FM, 10 AM, 7 TV, and 5
Weather) in the tuner memory for easy recall at any time.
1.) Tune to the first station that you wish to memorize. Example: FM 103.5 MHz.
When the desired frequency appears in the display depress and hold the
MEMORY/CLOCK SET button for at least 2
seconds.The PRESETindicator appears and
preset memory “1” begins to flash.
2.) Within 5 seconds press the PRESET UP or PRESET DOWN to select a desired
preset memory number, or just use preset memory “1” for the first station.
3.) Press the MEMORY/CLOCK SET button
again to enter your station in the selected
preset memory.
4.) Repeat steps 1 through 3, selecting a different station and a different preset
memory number each time until you have entered up to 20 FM stations, then
press the BAND button to switch bands and follow the same procedure to
enter up to 10AM stations, 7 TV stations, and 5 Weather stations in the tuner
memory.
FM
PRESET
FM
PRESET
HR2003_ib040903.p65 9/4/2003, 11:1212

13
RECALLINGPRESETSTATIONS
1.)Turnthe radio‘On’and press the BAND button toselectthe desired band.
2.)Press the PRESETUPorPRESETDOWNbuttonstoscroll through the preset
numbers.
CHANGINGAPRESETSTATION
Tochangeapresetstation simplytunetothenewstation thatyouwishtomemorize,
presstheMEMORY/CLOCKSETbutton,andthenselectthenumberofthememory
you wishtochange bypressing the PRESETUPorPRESETDOWNbuttons.
Whenthedesiredpresetnumberappearsinthedisplaypress theMEMORY/CLOCK
SETbutton oncemoretoenterthe newstation inthe desired presetmemory
number.The previouslymemorized station will be deleted fromthe memory.
AntennaInformation
FM
Theheadphone wireservesastheFMantenna.Keeptheheadphone wireextended
toitsfull lengthforbestFMreception.
AM
TheAMbarantenna islocated inside the cabinet. IfAMreception isunsatisfactory
tryrotating the entireunitslightlyuntil you find the position thatprovidesthe best
reception.
HR2003_ib040903.p65 9/4/2003, 11:1213

14
SETTINGTHEALARMTIMER
You can settheAlarmTimertoturnthe radioon automatically.Howeverthereisno
buzzeralarminthismodelsoyou musthavethe headphoneson tohearthe radio
alarm.
The AlarmTimecan onlybe setwhilethe radiois‘Off’.
1.)Press the ALARMbutton.The displaywill
show“AAM12:00”.
2.)Immediatelypress MEMORY/CLOCKSET
button.The timedisplaybeginstoflash.
3.)Press the TUNING+button tosetthe desired alarmhour,AMorPM.
Press the TUNING–button tosetthe desired alarmminute.
4.)When the desired alarmtimeisflashing on the displaypress the MEMORY/
CLOCKSETbutton again.The display
changesback fromalarmtimetocurrenttime
butthe Alarmindicatorappearsinthe
displayindicating thatthe alarmisactivated.
5.)Atthe selected alarmtimethe radiowill turn
‘On’automaticallyand the alarmindicator
flashes.The radiowill playfor1hourand then
shutoff automatically.Toshutthe radiooff
soonerpress the POWER(SLEEP)button.The radiostopsbutthe alarm
remainsactiveand the radiowill turnon eachdayatthe sametimeuntil the
alarmisdeactivated.
Todeactivatethe alarmpress theALARMbutton tochange the displayfromcurrent
timetoalarmtime,thenpresstheALARMbuttononcemore.TheAlarmindicator
disappearsandthealarmisnowdeactivated.Repeatthissameproceduretoactivate
the alarmagain.
AM
AM
PM
FM
PRESET
HR2003_ib040903.p65 9/4/2003, 11:1214

15
SNOOZE/REPEATALARM
Afterthe radioturns‘On’automaticallyyou may
press the SNOOZEbutton tostop the radiofora
fewmoreminutes.The radiostopsbuttheAlarm
indicatorcontinuestoflash.After5minutesthe
radioturns‘On’again.
SLEEP Timer
You can usethe Sleep timertoshutthe radio‘Off’automaticallyafterup to100
minutesofoperation.
Note:The radiomustbe ‘Off’inordertosetthe Sleep timer.
1.)Depress and holdthe POWER(SLEEP)
button.The radioturns‘On’,the SLEEP
indicatorflashesand the displayshows“100”,
indicating thatthe radiowill shutoff
automaticallyafter100 minutes.
2.)If you continue todepress the POWER(SLEEP)button the displaywill begin
counting downfrom100minutesin10-minutesteps.Whenthedisplayindicates
the desired amountofsleep time,releasethe POWER(SLEEP)button.
3.) When the display counts down to “00” the radio will shut off automatically. You
may also cancel the Sleep timer and shut the radio ‘Off’ at any time by pressing
the POWER (SLEEP) button once more. The SLEEP indicator disappears.
MUTE Button
Press and hold the MUTE button to stop the sound temporarily. Release the MUTE
button to restore the sound.
PM
SLEEP
PRESET
UP
DOW
N
SNOO
Z
E
M
U
T
E
B
A
N
D
MHzkHz
POWER
C
L
O
C
K
S
E
T
M
E
M
O
R
Y
R
H
M
ALAR
M
MUTEButton
POWER(SLEEP)Button
SNOOZEButton
HR2003_ib040903.p65 9/4/2003, 11:1215

16
CAREAND MAINTENANCE
Thereareno userserviceablepartsinside thisradio.Pleasereferall service
problemstoaqualified servicefacility.
If the cabinetbecomesdusty,wipe the exteriorwithasoft dustclothonly.Never
usedusting sprays orpolisheson the cabinet.
If the cabinetbecomesdirtyorsmudged withfingerprintsitmaybe wiped witha
soft cloththathasbeen slightlydampened withamildsoap and watersolution.and
neverallowanyliquidtogetinside the cabinet.
TOFIND THELOCATIONAND PHONE
NUMBEROFYOUR NEARESTSERVICE
CENTERPERMITTEDTOPERFORM
WARRANTY...
CALL TOLL FREE:1-800-695-0098
SERVICE
FORCUSTOMERSERVICE,PLEASE WRITETO:
Emerson RadioCorp.
ConsumerAffairsDept.
1901 DiplomatDrive,
FarmersBranch,TX75234.
FORADDITIONALSET-UPOROPERATINGASSISTANCE
PLEASE CALL:
1-800-898-9020
R
HR2003_ib040903.p65 9/4/2003, 11:1216

17
LIMITEDWARRANTY
Emerson RadioCorp. warrantsmanufacturingdefectsin originalmaterial,including
originalpartsand workmanship, undernormaluseand conditions, foraperiod of
ninety (90)daysfromthedateoforiginalpurchasein theU.S. With yourdated
proofofpurchase, wewill providerepairservice atno chargeforlaborand parts
atan authorized DepotRepairFacility, orreplace theproductin ourdiscretion.
Forrepairorreplacement, pack yourunit in apadded box, encloseyourcheck or
money orderpayableto Emerson Radio Corp. in theamountof$5.00 (notrequired
by Californiaresidents)to covershipping and handling costs, and encloseacopy
ofyourproofofpurchase. Send yourunit to:
EmersonRadio Corp.
1901 DiplomatDrive,
FarmersBranch, TX75234.
Thiswarranty doesnotcoverdamagefromnegligence, misuse, abuse, accident,
failureto followoperating instructions, commercialuse, rental, repairsby an
unauthorized facility, orproductspurchased, used, serviced ordamaged outside
oftheUnited States.
THISWARRANTYGIVESYOU SPECIFICLEGALRIGHTS,ANDYOU MAY
ALSOHAVEOTHERRIGHTSWHICHVARYFROMSTATE TOSTATE.
AU898H
HR2003_ib040903.p65 9/4/2003, 11:1217

EMERSONRADIOCORP.
EMERSON
PartNo.:16-2903
304-01 PRINTEDINCHINA
HR2003_ib040903.p65 9/4/2003, 11:1218
