Emerson 810-1600 User manual

Emerson Programmable Touchscreen
Thermostat Installation and Operation
Manual
026-1739 Rev 0

Emerson
1065 Big Shanty Road NW, Suite 100
Kennesaw, GA 30144 USA
770-425-2724 • www.emerson.com

Table of Contents • v
Contents
1 OVERVIEW ....................................................................................................................................... 1
1.1. SPECIFICATIONS ................................................................................................................................ 1
1.1.1. Technical Specifications........................................................................................................... 1
1.2. TERMINAL IDENTIFICATION AND ELECTRICAL RATINGS.................................................................. 2
2 INSTALLATION ............................................................................................................................... 3
2.1. ENCLOSURE....................................................................................................................................... 3
2.2. THERMOSTAT LOCATION .................................................................................................................. 3
2.3. THERMOSTAT INSTALLATION ........................................................................................................... 4
2.3.1. Opening and Closing the Thermostat Enclosure .................................................................... 4
2.3.2. Mounting the Baseplate on the Wall ........................................................................................ 4
2.3.3. Wires and Electrical Connection ............................................................................................. 5
2.4. WIRING AND CONNECTIONS ............................................................................................................. 6
2.4.1. Thermostat – Power Terminals ................................................................................................ 6
2.4.2. Thermostat – Modbus Connections.......................................................................................... 6
2.4.3. Thermostat – Input Terminals .................................................................................................. 6
2.4.4. Thermostat – Output Terminals ............................................................................................... 7
2.4.5. Wiring Guide - Conventional Systems (24VAC) ...................................................................... 7
2.4.6. Wiring Guide - Heat Pump Systems (24VAC).......................................................................... 8
3 OPERATION...................................................................................................................................... 9
3.1. GRAPHICAL USER INTERFACE (GUI)................................................................................................ 9
3.2. CONFIGURATION MENU .................................................................................................................... 9
3.2.1. Configuration Menu – Modbus Device Address .................................................................... 10
3.2.2. Configuration Menu – Modbus Device Baud Rate ................................................................ 11
3.2.3. Configuration Menu – Thermostat System Configuration ..................................................... 11
3.2.4. Configuration Menu – Full Segments Display Test ............................................................... 15
3.2.5. Configuration Menu – System Revision Display.................................................................... 15
3.3. TEMPERATURE UNIT SELECTION .................................................................................................... 16
3.4. TIME AND DATE SETTING ............................................................................................................... 16
3.5. MENUS & INTERFACE ..................................................................................................................... 18
3.5.1. Temperature Setpoints............................................................................................................ 19
3.5.2. Thermostat Mode.................................................................................................................... 20
3.5.3. Fan Mode ............................................................................................................................... 20
3.5.4. Active Stage(s) Indicator ........................................................................................................ 21
3.5.5. Fan Indicator.......................................................................................................................... 22
3.5.6. Schedule Mode ....................................................................................................................... 23
3.5.7. Occupancy Mode (Energy Saving Mode)............................................................................... 24
3.5.8. Manual Override .................................................................................................................... 25
3.5.9. Screen Lock ............................................................................................................................ 25
3.6. COMMUNICATION NETWORK .......................................................................................................... 26
3.6.1. RS-485 Serial Link.................................................................................................................. 26

vi • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
3.7. POWER OUTAGE ............................................................................................................................. 27
3.8. ADVANCED SETTINGS .................................................................................................................... 27
3.8.1. Thermostat System Configuration ......................................................................................... 27
3.8.2. Thermostat Stage(s) Behavior ............................................................................................... 28
3.8.3. Input Settings ......................................................................................................................... 28
3.8.4. Dehumidification Mode ......................................................................................................... 29
3.8.5. Economizer Mode .................................................................................................................. 29
3.8.6. Internal Temperature Offset .................................................................................................. 30
3.8.7. Delay Fan .............................................................................................................................. 30
3.8.8. Temperature Filter Time (Sampling Rate)............................................................................. 30
3.8.9. Temperature Hysteresis ......................................................................................................... 31
3.8.10. Minimum Temperature Deadband (Read-Only)................................................................. 31
3.8.11. Temperature Minimum Setpoint ......................................................................................... 31
3.8.12. Temperature Maximum Setpoint......................................................................................... 31
3.8.13. Temperature Stage Difference ............................................................................................ 31
3.8.14. Compressor Min ON time ................................................................................................... 31
3.8.15. Compressor Min OFF time................................................................................................. 31
4 PROGRAMMABLE TOUCHSCREEN THERMOSTAT SETUP FOR E2 AND SITE 
SUPERVISOR.................................................................................................................................. 32
4.1. NEW INSTALLATION OF DESCRIPTION FILE TO E2......................................................................... 32
4.1.1. Uploading the Touch_TStat Description File to E2 .............................................................. 32
4.2. DEVICE AND COM PORT SETUP IN E2 .......................................................................................... 34
4.2.1. Modbus Device Setup............................................................................................................. 34
4.2.2. E2 COM Port Setup ............................................................................................................... 34
4.3. INSTALLING THE THERMOSTAT IN E2 ............................................................................................ 36
4.3.1. Installing the Thermostat Application ................................................................................... 36
4.3.2. Commissioning the Thermostat ............................................................................................. 36
4.4. DEVICE AND COM PORT SETUP IN SITE SUPERVISOR................................................................... 37
4.4.1. Modbus Device Setup............................................................................................................. 37
4.4.2. Site Supervisor COM Port Setup ........................................................................................... 38
4.4.3. Adding the Touchscreen Thermostat Application in Site Supervisor .................................... 39
4.4.4. Installing and Commissioning the Touchscreen Thermostat................................................. 39
4.4.5. Viewing the Status.................................................................................................................. 40
5 TROUBLESHOOTING .................................................................................................................. 41
6 REGULATORY INFORMATION ................................................................................................ 42

Specifications Overview • 1
1Overview
The Emerson Programmable Touchscreen Thermostat (P/N 810-1600) is a 
configurable device intended for light commercial applications. The thermostat is a
communicating, intelligent sensor and controller combination with built-in 
temperature and humidity sensors used to control systems such as conventional
Rooftop Units (RTU) and Heat Pumps (HP). The thermostat communicates over a
Modbus RTU network that easily integrates with a building management system
(BMS).
1.1. Specifications
1.1.1. Technical Specifications
18VAC to 30VAC, 50-60Hz, less than 3.6 VA at 24VAC nominal, 
Class 2
18AWG maximum, 22AWG recommended
Max 1.0A per Relay, Max Total 2.0A (R, Rc and C terminal)
Fan Proof switch input (floating or GND)
Designed for 10K Ω NTC thermistor
Modbus RTU on RS-485, 9600 or 19200 bps (default)
2C, 2H, Fan, ECO, AUX, O/B
Local integrated temperature sensor, digital output (I2C)
Conventional systems, Heat-pump systems
32°F to 122°F (0°C to 50°C)
+/- 0.6°C, +/- 1.1°F, within operating temperature range
Default value is 4°F / 2°C, between cooling and heating
32°F to 122°F (0°C to 50°C)
-4°F to 140°F (-20°C to 60°C)
+/- 5% @ 50% RH @ 77°F (25°C)
0% to 95%
Designed to comply to UL60730, FCC CFR 47 Part 15 Subpart B 
Class B
Designed to comply to E60730, Industry Canada ICES-003 Issue 6
H 4.72” x W 5.47” x T 1.32”
Power Requirements
Wire Size
Relay Contact Rating
Binary Input
Analog Input
Serial Data Link
Relay Output
Temperature Sensor Type
Supported Configurations
Temperature Setting Range
Temperature Accuracy
Minimum Temperature 
Deadband
Operating Temperature
Storage Temperature
Humidity Accuracy
Humidity Display Range
Compliance (USA)
Compliance (Canada)
Dimensions
Table 1-1 - Technical Specifications

2 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
1.2. Terminal Identification and Electrical Ratings
C24AVAC Power Supply Common 18-30VAC 50/60Hz 2.0A
R24AVAC Power Supply 18-30VAC 50/60Hz 2.0A
W1 Heat Stage 1, relay output 18-30VAC 50/60Hz 1.0A
W2 Heat Stage 2, relay output 18-30VAC 50/60Hz 1.0A
AUX Dehumidification, relay output 18-30VAC 50/60Hz 1.0A
O/B Reversing Valve, relay output 18-30VAC 50/60Hz 1.0A
Rc 24VAC Power Supply for Y1, Y2 18-30VAC 50/60Hz 2.0A
Y1 Cool Stage 1, relay output 18-30VAC 50/60Hz 1.0A
Y2 Cool Stage 2, relay output 18-30VAC 50/60Hz 1.0A
ECO Economizer, relay output 18-30VAC 50/60Hz 1.0A
GFan Control, relay output 18-30VAC 50/60Hz 1.0A
GND Reference for DC Signals
B+ RS-485 B+ Signal
A- RS-485 A- Signal
IN1 Remote 10K thermistor (Indoor) 0-3.3VDC (10K NTC)
IN2 Remote 10K thermistor (Outdoor) 0-3.3VDC (10K NTC)
IN3 Remote 10K thermistor (Supply) 0-3.3VDC (10K NTC)
IN4 Remote Humidity sensor (0-5V) 0-5VDC
IN5 Fan proof input 0VDC or floating
GND Reference for DC Signals
Signal
Name Description Voltage Maximum Current Rating
Table 1-2 - Terminal Identification and Electrical Ratings

Enclosure Installation • 3
2 Installation
2.1. Enclosure
2.2. Thermostat Location
The thermostat should be mounted:
> About 5 ft (1.5 m) from the floor.
> On a part of wall without hidden pipes or ductwork.
> In a room that operating limits are within 32°F to 122°F (0°C to 50°C).
> In a room that humidity operating range is within 0% to 95% relative humidity, 
non-condensing.
The thermostat should not be mounted:
> Nearby a window, on an outside wall, or next to a door leading to the outside.
> Where exposed to direct light and heat from any heat source, such as a lamp, the sun,
a fireplace, or any heating element which may cause a false reading (temperature 
measurement offset).
> Nearby a direct airflow from supply registers (air vent or duct outlet).
> In areas and locations with poor air circulation such as behind a door.
Figure 2-1 - Emerson Programmable Thermostat Enclosure

4 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
2.3. Thermostat Installation
2.3.1. Opening and Closing the Thermostat Enclosure
To open the thermostat enclosure, grip the top and the bottom edge of the front part
of the device and pull straight. A certain physical resistance is normal from the 
24x contacts pins (terminal strips and terminal blocks) that have to be separated
during the operation.
To close the thermostat enclosure, make sure to align the top and the bottom tabs 
between the front part and the baseplate, and then push the front part firmly toward
the wall. Again, some force is required to mate both parts.
2.3.2. Mounting the Baseplate on the Wall
Figure 2-2 - Exploded View of Thermostat
NOTE: Both top and bottom securing screws are optional and normally not installed on the
units.
Figure 2-3 - Baseplate (Back view)

Thermostat Installation Installation • 5
To fix the baseplate on a wall, pass the wires through the opening of the baseplate,
and use either 2x self-taping screws and dry-wall anchors, or regular 6-32 machine
screws to attach on a standard single-gang electrical junction box (2” x 4”).
2.3.3. Wires and Electrical Connection
Once the baseplate is affixed on the wall, proceed with the wiring connections to the
terminal block. Please refer to Section 2.4., Wiring and Connections for 
configuration and signals definition.
CAUTION! Do not over-tighten the screws when attaching the baseplate on a wall as
physical damage may occur.
CAUTION! Keep the thermostat housing and vents clean and free of any debris to avoid
malfunction of the device.
Figure 2-4 - Baseplate with Terminal Blocks Labels

6 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
2.4. Wiring and Connections
2.4.1. Thermostat — Power Terminals
R24VAC Power Supply
Rc 24VAC Power Supply for Y1, Y2
C24VAC Power Supply Common
2.4.2. Thermostat — Modbus Connections
A- RS-485 A- Signal
B+ RS-485 B+ Signal
GND Reference for DC Signals
2.4.3. Thermostat — Input Terminals
IN1 Remote 10K thermistor (Indoor)
IN2 Remote 10K thermistor (Outdoor)
IN3 Remote 10K thermistor (Supply)
IN4 Remote Humidity sensor (0-5V)
IN5 Fan proof input
GND Reference for DC Signals
WARNING! Turn off power of the HVAC system at the main power panel or on the
controlled-system itself to avoid any electrical shock or damage to the system.
Thermostat Power
Table 2-1 - Power Terminals
Modbus Connections
Table 2-2 - Modbus Connections
Thermostat Inputs
Table 2-3 - Input Terminals

Wiring and Connections Installation • 7
2.4.4. Thermostat — Output Terminals
Y1 Cool Stage 1, relay output
Y2 Cool Stage 2, relay output
W1 Heat Stage 1, relay output
W2 Heat Stage 2, relay output
GFan Control, relay output
O/B Reversing valve, relay output
ECO Economizer, relay output
AUX Dehumidification, relay output
2.4.5. Wiring Guide - Conventional Systems (24VAC)
Shorting
Jumper
R24VAC Power Supply
Rc 24VAC Power Supply for Y1, Y2
C24VAC Power Supply Common
Y1 Cool Stage 1, relay output
Y2 Cool Stage 2, relay output
W1 Heat Stage 1, relay output
W2 Heat Stage 2, relay output
GFan Control, relay output
Thermostat Outputs
Table 2-4 - Output Terminals
2H / 2C System with
1 Transformer
Table 2-5 - Single Transformer System

R24VAC Power Supply
Rc 24VAC Power Supply for Y1, Y2
C24VAC Power Supply Common
Y1 Cool Stage 1, relay output
Y2 Cool Stage 2, relay output
W1 Heat Stage 1, relay output
W2 Heat Stage 2, relay output
GFan Control, relay output
8 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
For systems with only one stage, second stage terminals (Y2,W2) can be left 
floating (open).
2.4.6. Wiring Guide - Heat Pump Systems (24VAC)
Shorting
Jumper
R24VAC Power Supply
Rc 24VAC Power Supply for Y1, Y2
C24VAC Power Supply Common
Y1 *Cool Stage 1, relay output
Y2 *Cool Stage 2, relay output
O/B Reversing Valve, relay output
GFan Control, relay output
For systems with only one stage, second stage terminal (Y2) can be left floating
(open).
2H / 2C System with 2 Transformers
Table 2-6 - Dual Transformer System
2H / 2C System
Table 2-7 - Heat Pump Systems
*NOTE: Stage 1 and Stage 2 for Heat Pumps are Compressor Stages (Heat/Cool) and not
only Cool Stages.

Graphical User Interface (GUI) Operation • 9
3Operation
3.1. Graphical User Interface (GUI)
The display of the device is used as the Graphical User Interface to show some of
the status, setpoints and actual measurements such as room temperature and relative
humidity. The display is a resistive touch-type that allows users to navigate and to
change values that are shown on the display (see Figure 3-1).
3.2. Configuration Menu
To access the Configuration Menu (see Figure 3-2), press the icon for five (5)
times within 15 seconds. This step is to prevent unintentional access to the 
configuration menus.
Figure 3-1 - Display With All Segments Shown

10 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
3.2.1. Configuration Menu — Modbus Device Address
The first configuration menu (see Figure 3-3) allows users to change the Modbus
device address. Ad is shown on the right side of the display to indicate which 
parameter is being changed (Ad stands for Address). To change the value, press 
either the up or down arrow, and then press the check icon to go to the next 
parameter. Press CA to cancel and exit the configuration menu without saving any
changes.
1 to 247 Range from 1 to 247
Figure 3-2 - Configuration Menu Access
Figure 3-3 - Modbus Address Configuration Menu
Address Number Modbus Device Address
Table 3-1 - Modbus Device Address Range

Configuration Menu Operation • 11
3.2.2. Configuration Menu — Modbus Device Baud Rate
The second configuration menu (see Figure 3-4) allows users to change the Modbus
device baud rate. “br” is shown on the right side of the display to indicate which 
parameter is being changed (br stands for Baud Rate). To change the value, press 
either the up or down arrow, and then press the check icon to go to the next 
parameter. Press CA to cancel and exit the configuration menu without saving any
changes.
09600 bps
119200 bps (default)
3.2.3. Configuration Menu — Thermostat System Configuration
The third configuration menu (see Figure 3-6) allows users to set the thermostat 
system configuration. SC is shown on the right side of the display to indicate which
parameter is being changed (SC stands for System Configuration). The current 
revision of the Emerson Programmable Touchscreen Thermostat supports 
Conventional HVAC Systems such as RTU and Heat-pump Systems using a 
reversing valve. There are 4x possible configurations: IDLE, RTU, HP_O and 
finally HP_B. The first system configuration is IDLE. In this configuration, all the
outputs of the thermostats are open and the thermostat controls are inactive. This is
to prevent any issue in current configuration compared to the equipment connected
Figure 3-4 - Modbus Baud Rate Configuration Menu
Menu Option Number Corresponding Baud Rate
Tabl e 3-2 - Modbus Baud Rate

12 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
to the thermostat. To change the value, press either the up or down arrow, and then
press the check icon to go to the next parameter. Press CA to cancel and return to the
normal display without saving any changes.
0IDLE
1RTU (Conventional Systems)
2*HP_O (Heat-pump with O as reversing signal)
3*HP_B (Heat-pump with B as reversing signal)
0IDLE
(1, 2, or 3) Current Configuration
• When the system is not in nominal configuration, for example, configured in IDLE,
then all the configurations are accessible through the menu as below:
• When the system is already configured in RTU, HP_O or HP_B, only the IDLE and the
current configuration are accessible through the menu:
NOTE: The thermostat is always as a 2H/2C configuration system for both RTU and Heat
Pump. In the case the system has only 1 stage (1H/1C), this configuration is inclusive within
the 2-stages configuration. In this case, connect stage 1 terminals (Y1 and W1) and leave
stage 2 terminals floating.
Menu Option Number System Configuration
Table 3-3 - Thermostat System Configuration
*NOTE: O and B signals are both reversing valve control signals, but are logically
complementary (opposite).
Menu Option Number System Configuration
Table 3-4 - Thermostat System Configuration
IMPORTANT! Prior to any change of system configuration, the unit must be set to IDLE
configuration first, and then to the final desired configuration.

Configuration Menu Operation • 13
IMPORTANT! A factory reset of all parameters will occur when the system is in IDLE
configuration, except the current date and time that are kept with the use of a Real-Time
Clock (RTC). This factory reset will be triggered on the first start of the device, and when
newly configured from RTU, HP_O or HP_B to IDLE configuration.
IMPORTANT! Upon the first start of the thermostat, the default System Configuration will
be set to IDLE. This means that the first step to get the device started is to configure the
appropriate system configuration. This menu will appear by default upon the first start (See
Figure 3-5). To access the configuration menu, press the icon for five (5) times
within 15 seconds.
Figure 3-5 - Thermostat Display When in IDLE Configuration (First start or after a System
Configuration Change)
Figure 3-6 - Thermostat System Configuration Menu (First Step is IDLE)

14 • Emerson Programmable Touchscreen Thermostat I&O Manual 026-1739 Rev 0
IMPORTANT! Device restart time is about 5 to 10 seconds. Prior to device restart, the
display will show “- -” to indicate that the device is not in trouble and that the booting
sequence is underway. (See Figure 3-7). When the device is rebooting, the display will turn
off for few seconds until reboot operation is completed.
Figure 3-7 - Thermostat Display When Restarting to Occur (Rebooting)
Figure 3-8 - Thermostat System Configuration Menu (New System Configuration Mode after IDLE)
IMPORTANT! To change the current system configuration to a different one, the operating
system requires the system configuration is set to IDLE prior to the final configuration each
time. This mechanism is to prevent any undesired operation on such an important setting.

Configuration Menu Operation • 15
3.2.4. Configuration Menu — Full Segments Display Test
The fourth configuration menu (see Figure 3-9) allows users to test the full 
segments display. This allows a complete review of the display segments and to 
inform the user of all possible segments in the current Emerson Programmable
Touchscreen Thermostat revision. Press the check icon to go to the next parameter.
3.2.5. Configuration Menu — System Revision Display
The fifth and last configuration menu (see Figure 3-10) allows users to obtain the
current system revision number. This number is shown with 3 digits. Note that there
is no decimal after the first digit, but the revision number contains the decimal point.
For example, revision number 100 shown on the display means in fact 1.00. The
software revision will be updated for the latest official release, and will likely be
higher than 1.00. Press the check icon to terminate the configuration menus. Press
CA to cancel any previous change and return to the normal display without saving.
Figure 3-9 - Full Segments Display Test
Figure 3-10 - System Revision Display (For revision 1.00)
