Emerson Liebert PowerSure PST User manual

PowerSure™PST
Quick-Start Guide for 500-650VA; 230V
WHAT’SINTHE BOX
• Quick-Start guide
• PowerSure family user manual
on CD (also at www.liebert.com)
• Warranty card
• USB cable (PAXXX-230U models only),1.8m (6ft.)
• RJ-11 cord, 2.1m (7 ft.)
• Two (2) 10A output power cords, 2.0m (6.6 ft.)
For more details, refer to the PowerSure user manual on CD.
Pour de plus amples informations, voir le manuel
d'utilisateur de la gamme des produits PowerSure sur CD.
Para una información más detallada, consulte el manual del
usuario de la familia PowerSure en el CD.
Per informazioni ulteriori e più particolareggiate, consultare
il manuale dell'utente delle attrezzature PowerSure
contenuto sul CD.
Ausfuhrlichere Informationen finden Sie im Benutzerhandbuch der PowerSure-Familie auf CD.
Refer to Bottom for
Cautionary Markings
* Power ON/OFF/
Alarm Silence
Mains/Battery Indicator (Green) *
***USB port
(for PAXXX-230U models only)
Circuit
protector
** Black output
receptacles
(surge protec-
tion only)Data Line **
Protection
Connectors
TOP OF UPS LEFT SIDE
OF UPS
RIGHT SIDE OF UPS
** AC Inlet
For details, see
* Controls and Indicators
** Installation
*** Communications
** Orange output recep-
tacles (battery backup
and surge protection)
Fault Indicator (Red/Green) *
INSTALLATION
Read all safety, installation and operating instructions in the PowerSure family user
manual on the included CD or at www.liebert.com before operating the UPS. Adhere
to all warnings on the unit and in the manual.
1. Install the UPS indoors in a controlled environment, where it cannot be accidentally turned
off. Place it in an area of unrestricted airflow around the unit, away from water, flammable
liquids, gases, corrosives and conductive contaminants. Maintain an ambient temperature
range of 0°C to 40°C (32°F to 104°F).
2. Connect equipment to the receptacles on the back of the PST with one of the two supplied
output cables. Computers and monitors should be connected to the orange receptacles for
battery backup and surge protection; other office machines that do not exceed the capac-
ity of the UPS may be plugged into either of the two black receptacles, which provide
surge protection only.
3. Connect an input cable removed from the load equipment to the PowerSure PST and to
the mains supply socket.
4. Connect Phone/Fax/DSL/Internet/Modem devices to data line connectors.
5. Press and release the ON/OFF/Alarm Silence button to turn on the UPS. The UPS will beep and the Mains Indicator will illuminate (green).
6. Turn on connected equipment.
Plug this type of equipment
into black receptacles ONLY
Plug computers, monitors,
routers and cash registers into
orange receptacles
Inkjet
printers
Scanners Fax
machines
CONTROLS AND INDICATORS
This button controls output power to
the connected load and has three
functions:
•Turns the PowerSure PST ON
•Turns the PowerSure PST OFF
•Silences PowerSure PST alarms
TURN THE UPS ON: Press and release the
main ON/OFF button to start the UPS. An
audible alarm will sound briefly.
TURN THE UPS OFF: When the PST is ON,
hold the main ON/OFF button down for more
than 2 seconds to shut it down. An audible
alarm will sound briefly.
SILENCE AN ALARM: When a UPS alarm is
active, press and release the main ON/OFF
button to silence the audible alarm (Excep-
tions: low battery, overload and overtempera-
ture). DO NOT hold the button down for more
than 2 seconds or the PST will shut down.
CHECK THE PST’S CONDITION: Three sta-
tus indicators on the front of the UPS illumi-
nate to specify the status of the UPS (see
Troubleshooting section for details).
SPECIFICATIONS
Model Number PA500-230U
PA500-230
PA650-230U
PA650-230
Model Rating
VA / W 500 / 300 650 / 360
DIMENSIONS: mm (in.)
Unit
W x D x H
168 x 250 x 95
(6.6 x 9.8 x 3.7)
168 x 250 x 95
(6.6 x 9.8 x 3.7)
Shipping
W x D x H
238 x 350 x 142
(9.4 x 13.8 x 5.6)
238 x 350 x 142
(9.4 x 13.8 x 5.6)
WEIGHT: kg (lbs)
Unit 4.7 (10.4) 5.7 (12.5)
Shipping 5.7 (12.5) 6.7 (14.8)
INPUT AC PARAMETERS
Surge Protection 220J
Rated Input
Voltage 230VAC
Voltage Range
Without
Battery Operation
180VAC - 264VAC (±6VAC)
Frequency 47 - 63 Hz (±0.4 Hz)
OUTPUT AC PARAMETERS
Output
Receptacles
(3) IEC-320-C13 (orange)
battery backup+surge protection
(2) IEC-320-C13 (black) surge protection
Output Cord 2m (6.6 ft) detachable, w/IEC-320 (Wire
Type: 1mm2, H05W-F 3G)
Voltage (Battery
Mode) 230VAC (±8%)
Output Current 2.9 A 4.2 A
Waveform (Battery
Mode) Stepped Sinewave
Frequency
(Battery Mode) 50/60 Hz (±1 Hz)
Overload Warning >100%
Overload
Shutdown >110%
BATTERY PARAMETERS
Type Valve-regulated, nonspillable, lead acid
Quantity x Voltage
x Rating 1 x 12V x 5 Ah 1 x 12V x 7 Ah
Transfer Time 4 – 6 ms typical
Back-up Time: At 25°C (77°F), resistive loading,
w/ fully charged batteries:
Full load 2 minutes 1 minute
Half load 8 minutes 8 minutes
Recharge Time 12 hours to 90% rated capacity, after full
discharge into resistive load
ENVIRONMENTAL
Operating
Temperature
0°C to +40°C
(+32°F to +
104°F)
Storage
Temperature
-15°C to +50°C
(+5°F to + 122°F)
Relative
Humidity
0% to 95%,
non-condensing
Operating
Elevation
Up to 3000 m
(10,000 ft.) at
35°C (95°F)
w/o derating
Audible Noise < 40 dBA, at
1 meter
AGENCY
Safety
EN50091-1-1,
TUV/GS listed,
CE Compliance
Mark
Surge
EN61000-4-5,
Level 3,
Criteria A
ESD
EN61000-4-2,
Level 3,
Criteria A
Susceptibility
EN61000-4-3,
Level 2,
Criteria A
Electrical Fast
Transient/
Burst
EN61000-4-4,
Level 3,
Criteria A
Emissions EN50091-2,
Class B
Harmonics EN61000-3-2
Conducted
Immunity EN61000-4-6
Flicker EN61000-3-3
Transportation ISTA
Procedure 1A
COMMUNICATIONS
The PowerSure PST has a USB interface port
for communication that will work with the built-
in Microsoft Power Manager software on the
user’s PC, if the PC is so equipped. It will pro-
vide UPS status and manages the automatic,
orderly shutdown of the computer. The UPS
(USB) communications meets HID standard,
version 1.11. All USB models are compatible
with Microsoft Windows 2000, Windows XP
and Mac OS 10.2 or later. All USB models ship
with a 6 ft. (1.8m) USB cable.

SLI-23275QS (9/03) Rev.0
TROUBLESHOOTING
The information below indicates various symptoms a user may
encounter in the event the PowerSure PST experiences a problem.
Use this information to determine whether external factors caused
the problem. See Troubleshooting Chart for suggested remedy.
GUIDE TO STATUS INDICATORS
1. The Fault indicator illuminates,
indicating the UPS detected a
problem.
2. An alarm sounds, alerting that the
UPS requires attention. The alarm
can be silenced except for low
battery, overload and
overtemperature warning
conditions.
3. Mains/Battery indicator may be
illuminated as a diagnostic aid to
the operator, as shown below:
Fault
(Red)
Mains/Battery
(Green) Diagnosis/
Audible Alarm
Normal Mode
—ON
UPS is operating in
Normal Mode; no
beep.
— Flashing
Battery Test has
been initiated; no
beep.
Flashing ON
The unit is
overloaded; beep
every half-second
ON ON The UPS has
failed; continuous
Flashing —
Unit has shutdown
due to overload;
continuous beep
ON —
The UPS shutdown
due to failure;
continuous beep
Battery Mode
— Flashing
The UPS is
operating in Battery
mode; beep every
5 seconds.
— Flashing
UPS battery is low;
beep every
half-second
Flashing Flashing
The unit is
overloaded; beep
every half-second
ON Flashing
The UPS has
failed; continuous
beep
Fault
Indicator
Mains/Battery
Indicator
!
+-
TROUBLESHOOTING CHART
If the UPS fails to operate properly, turn off the unit and repeat
the steps in the Installation section of this manual. If the prob-
lem persists, refer to the chart below:
Problem Cause Solution
UPS will
not start
Overload/
Short circuit
Check the circuit protector
on the side of the UPS. If
it is tripped, reset it and
restart the UPS.
For further help, call your
local dealer, Liebert
representative or the
Liebert Worldwide
Support Group.
UPS starts
on battery,
but will
not switch
to AC
UPS not
plugged in
Plug in power cord
securely.
Circuit
protector
tripped
Reset the circuit protector
and restart the UPS.
Power not
available at
mains
receptacle
Have the mains
receptacle checked by a
qualified electrician.
Input voltage
below
threshold
Wait until the voltage rises
to an appropriate level or
have the mains receptacle
checked by a qualified
electrician.
AC
overvoltage
Wait until voltage lowers
to an appropriate level or
have the mains receptacle
checked by a qualified
electrician.
UPS shuts
down,
Fault
Indicator
lit
Overload/
Short circuit
Check the circuit protector
on the rear of the UPS. If
it is tripped, reset it and
restart the UPS.
If the problem persists,
disconnect some of the
equipment from your
UPS—the total wattage of
your equipment must not
exceed the capacity of the
UPS. For further help, call
your local dealer, Liebert
representative or the
Liebert Worldwide
Support Group.
Internal UPS
fault
UPS not
providing
expected
backup
time
Overload Reduce load.
Battery not
charged due
to a recent
outage
Recharge battery.
MAINTENANCE
The PowerSure PST UPS requires very little maintenance. Follow these
practices to prevent problems.
CLEANING THE UPS
The following will help ensure trouble-free operation for years:
• Vacuum dust from the ventilation intake occasionally.
• Wipe the cover periodically with a dry cloth.
MAINTAINING BATTERIES
The batteries are valve-regulated, nonspillable, lead acid and must be
kept charged to retain their design life. The UPS continuously charges the
batteries when connected to the mains supply, even while the UPS is
switched off.
When storing the UPS, it is recommended to plug in the UPS for at least
24 hours every four to six months to ensure full recharge of the batteries.
WARRANTY REGISTRATION
To register for warranty protection:
• Visit the Quick Links section of our Web site at:
http://www.liebert.com
• Click on Product Warranty
Registration and fill in the form.
IF YOU HAVE ANY QUESTIONS,
PLEASE CONTACT US AT:
US: 800-222-5877
Outside the US: 614-841-6755
up[email protected]
