Eminent EM3751 User manual
EM3751 - USB Audio Blaster
2 |
ENGLISH
EM3751 - USB Audio Blaster
Warnings and points of attention
Opening a product and/or products may cause serious injuries! Always have products
repaired by qualified Eminent personnel!
Table of contents
1.0 Warranty conditions...............................................................................................2
2.0 Introduction ...........................................................................................................2
2.1 Function and features........................................................................................3
2.2 Packing contents ...............................................................................................3
3.0 USB Audio Blaster connectors...............................................................................3
4.0 Installation procedure ............................................................................................3
4.1 Software installation ..........................................................................................3
5.0 Volume and balance controls.................................................................................4
6.0 Frequently asked questions...................................................................................4
7.0 Service and support...............................................................................................4
1.0 Warranty conditions
The five-year Eminent warranty applies for all Eminent products unless mentioned
otherwise before or during the moment of purchase. When having bought a second-
hand Eminent product the remaining period of warranty is measured from the moment
of purchase by the product’s first owner. The Eminent warranty applies to all Eminent
products and parts indissolubly connected to and/or mounted on the main product.
Power supply adapters, batteries, antennas and all other products not integrated in or
directly connected to the main product and/or products of which, without reasonable
doubt, can be assumed that wear and tear show a different pattern than the main
product are not covered by the Eminent warranty. Products are not covered by the
Eminent warranty when exposed to incorrect/improper use, external influences and/or
when opened by parties other than Eminent.
2.0 Introduction
Congratulations on your purchase of this high-quality Eminent product! This product
has undergone extensive testing by Eminent’s technical experts. Should you
experience any problems with this product, you are covered by a five-year Eminent
warranty. Please keep this manual and the receipt in a safe place.
Register this product now on www.eminent-online.com and receive product updates!
3 |
ENGLISH
2.1 Function and features
The Eminent USB Audio Blaster provides your computer with speakers and
microphone connections. The microphone mute button allows you to temporarily mute
sound.
2.2 Packing contents
The following items are present in the package:
•USB Audio Blaster.
•Extension cable.
•CD-rom with drivers and manuals.
•Manual.
3.0 USB Audio Blaster connectors
Your USB Audio Blaster has 2 connectors on the front side.
1. Headset: This is where you connect your headset or amplified speakers
2. Microphone: This is where you connect your microphone
4.0 Installation procedure
If you have Windows XP, Vista or Windows 7 you don’t have to install
drivers on your computer to use the USB Audio Blaster. These versions of Windows
have built-in drivers for this product. Installation will occur automatically.
Hint! If your USB Audio Blaster does not fit into the USB port of your computer, you
can use the enclosed extension cable.
Attention! When you install on Windows XP, a ‘Windows logo test’ warning may
appear. Click ‘Continue anyway’ to continue the USB Audio Blaster installation.
4.1 Software installation
1. Insert he supplied CD-rom in your computer’s CD-rom player or DVD player.
2. The wizard will start automatically.
3. Select your language.
4. Click ‘Next’.
5. Select ‘Install Software’.
6. Click ‘Next’.
7. Follow the installation steps as displayed on your screen to finish the installation.
4 |
ENGLISH
5.0 Volume and balance controls
1. Double click the new icon (the volume controller at the lower-right corner, next to
the clock).
2. The volume control window will appear.
In the volume control window you can adjust several sound settings:
•The balance can be adjusted by dragging the balance bar from left to right.
•The volume can be adjusted by dragging the volume bar up or down.
•To mute the sound you can check ‘Mute’.
•By clicking ‘Options’ and then ‘Properties’ you can select which devices will be
shown in the ‘Volume settings’ window.
6.0 Frequently asked questions
Q: Windows does not recognize the USB Audio Blaster.
A: If you have rebooted your computer and the USB Audio Blaster is not
recognized, there may be a conflict or the USB port is not working. Connect the
USB Audio Blaster to another USB port.
Q: I do not hear any sound, although the USB Audio Blaster is installed correctly.
A: Check whether your headset or speakers are turned on and whether you have
connected your earphones or speakers correctly. Do you still don’t hear any
sound when playing an audio file? Then check the volume controls (chapter 5).
Probably the sound is muted.
7.0 Service and support
This users manual has been carefully written by Eminent’s technical experts. If you
have problems installing or using the product, please fill out the support form at the
website www.eminent-online.com/support.
You can also contact us by phone. Below you will find a list with phone numbers for
each supported country.
Country
Ph
one number
Rate per minute*
Belgium (Dutch) 070 277 286 €0.30
Belgium (French) 070 277 286 €0.30
Denmark +45 69918565 Local Costs
Finland +35 8942415826 Local Costs
Germany 1805 982 234 €0.14
Italy +39 0240042016 Local Costs
Norway +47 21075033 Local Costs
Spain 807 080 042 €0.41
5 |
ENGLISH
Sweden +46 840 309985 Local Costs
The Netherlands 0900-3646368 €0.45
UK 905 871 0013 £0.30
* Rates mentioned in this table do not include cell phone charges.
Declaration of Conformity
To ensure your safety and compliance of the product with the directives and laws
created by the European Commission you can obtain a copy of the Declaration of
Conformity concerning your product by sending an e-mail message to: info@eminent-
online.com. You can also send a letter to:
Eminent Computer Supplies
P.O. Box 276
6160 AG Geleen
The Netherlands
Clearly state ‘Declaration of Conformity’ and the article code of the product of which
you would like to obtain a copy of the Declaration of Conformity.
EM3751 R1 | 04-2010
