Emotion Fitness 900 Series User manual

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 1 from 17
Instructions for use
for
Treadmills of the
motion cardio line 900 &
motion cardio line 900 med
motion sprint 900 SE/SL
motion sprint 900 med SE/SL
0483
Sprintex Training Equipment Ltd.
At the saw 23a
79692 Little Meadow Valley

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 2 from 17
Table of contents
General introduction ........................................................................................................................................ 3
1.1 Description / classification of the medical device ........................................................... 3
1.2 General safety instructions .......................................................................................... 4
2. technical description ................................................................................................................................... 5
2.1 Details of inscriptions on the outside ............................................................................ 5
2.1.1 Type plate ............................................................................................................... 5
2.1.2 Label ...................................................................................................................... 5
2.1.2.1 Safety note for pulse systems ........................................................................................ 5
2.1.2.2 Safety advice for walking on the running surface ........................................................... 6
2.1.2.3 Safety notice "DO NOT INCLUDE". ............................................................................... 6
2.1.2.4 Safety notice "SITTING PROHIBITED ........................................................................... 6
2.1.2.5 Safety note "SUPERVISION .......................................................................................... 6
2.1.2.6 Command plate .............................................................................................................. 6
2.1.2.7 Serial number (beat numbers) ........................................................................................ 6
2.1.2.8 Disconnection from the supply network .......................................................................... 7
2.1.2.9 Reverse operation (reversal of running direction) .......................................................... 7
2.1.2.10 General pictorial signs .................................................................................................. 8
3. environmental conditions, transport, storage ......................................................................................... 8
4 Commissioning / Installation ....................................................................................................................... 9
4.1 Installation site ........................................................................................................... 9
4.2 First commissioning .................................................................................................... 9
5. options ........................................................................................................................................................ 10
5.1 Reverse operation (reversing the direction of travel) .................................................... 10
5.2 Polar pulse systems (receiver included) ...................................................................... 10
5.3 Pulse transmission via ANT+ technology .................................................................... 10
5.4 Load increase to 250 kg ............................................................................................ 10
6 Safe Training ............................................................................................................................................... 10
7. care ............................................................................................................................................................. 12
8. maintenance .............................................................................................................................................. 12
8.1 Minimum qualification for maintenance personnel ....................................................... 12
8.2 Maintenance instructions ........................................................................................... 12
8.3 Replacing fuses, mains connection cables and other parts ........................................... 13
8.4 Circuit diagrams / component list ............................................................................... 13
9. maintenance .............................................................................................................................................. 13
10. operation "display ................................................................................................................................... 14
Overview display/key functions ........................................................................................ 14
Programme selection ..................................................................................................... 15
11. technical data .......................................................................................................................................... 16
12. Warranty ................................................................................................................................................... 17

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 3 from 17
1. General introduction
1.1 Description / classification of the medical device
Note: The devices motion sprint 900 SE/SL med are medical devices according to the directive
93/42 EWG.
Modifications to the MP are not permitted!
The MP is designed for a useful life of eight years.
The motion sprint 900 SE/SL med stands for safety and quality. The applied slat technology with
rubber overlay ensures optimal damping of impact forces and promotion of walking that is easy on
the joints.
The naming of the two models refers to the presence of a gradient. I.e.: SLà with slope; SEà
without slope . The basic design with all safety and ergonomic aspects remains unaffected.
Basically, MPs are used for defined loading of the patient by walking or running on level ground or
on an incline. This addresses large muscle groups, primarily using the lower extremity and the
stabilising trunk muscles. When running, the muscles of the upper extremity are also used.
The MP is not designed for a specific user group, it can be used by younger and older people as
well as people with special needs and children for walking and running. For proper use of the MP,
people with special needs and/or children require 1:1 supervision. The MP is designed for use by
one person only. Simultaneous use by more than one person is prohibited. The maximum standard
load is 160 kg, which can be increased to 250 kg depending on the model.
For this purpose, the MP can be provided with different speed and gradient. The necessary settings
are made manually or programme-controlled via the corresponding terminal. With the help of the
integrated pulse receiver, heart rate measurement and thus individual pulse training is possible. If
the heart rate set by the user is exceeded, the load is reduced.
The MP motion sprint 900 SE/SL med belongs to accuracy class A: high accuracy. In the use
class, it is assigned to class S. (Studio: professional and/or commercial use).
Accuracy class A is achieved according to DIN EN 957-6. The device has complied with the following
tolerances: Time ± 1 %; Distance ± 5 %; Speed ± 5 % up to 2 km/h ± 0.1 km/h. If there is an incline,
it has an accuracy of ± 10 % above 2 % incline.
The device may only be used under the supervision of authorised qualified personnel or after
instruction by appropriate personnel. Before starting the training, make sure that all adjustable parts
of the respective training device are fully locked and do not protrude into the range of motion.

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 4 from 17
Requirements from standards:
Interference from electromagnetic fields can cause the MP to stand still. (Standstill=basic safety) The emergency stop also leads to standstill.
Warning: Use of this appliance immediately adjacent to or with other appliances, or with other appliances in stacked form, should be avoided as
this may result in incorrect operation. If use in the manner described above is nevertheless necessary, this unit and the other units should be
observed to ensure that they are operating properly.
Warning: The use of accessories, transducers and wiring other than those specified or provided by the manufacturer of this unit may result in
increased electromagnetic emissions or decreased electromagnetic immunity of the unit and may result in improper operation.
Warning: Portable RF communications equipment should not be used within 30cm of the manufacturer's designated parts and wiring of the ME
unit/system. Failure to do so may result in degradation of the unit's performance characteristics.
Warning: To avoid the risk of electric shock, this appliance must only be connected to a supply mains with a protective earth conductor.
Warning; Modification to the ME unit is not permitted. It must not be modified without the permission of the manufacturer. If the ME unit is
modified, appropriate examinations and tests must be carried out to ensure continued safe use.
1.2 General safety instructions
Read these operating instructions with all the warnings before using the
MP for the first time. MP before using it for the first time, in order to ensure
safe and use of the product. Keep this document in a safe place for
reference and give it to others if you pass on the unit of the appliance.
Only use Sprintex Trainingsgeräte GmbH - accessories, otherwise no liability will be accepted.
Visually inspect the equipment before each use and listen for atypical noises. The tread surface of
the frames can provide a safe resting zone with the railing in case of emergency or other need. If
the MP does not respond as intended, there are the following ways to control the situation:
2. Pull the rip cord or press the "emergency stop button".
3. Grasp the railing, unload the body, place the feet on the tread and exit the belt.
4. Pull out the plug. (by outside person)
In case of any error symptoms, leave the unit. The fault should be recorded and reported to the
manufacturer/service. Do not transport any objects with the MP. Environmental conditions must be
observed. (see chapter 3) Moving or rolling objects that could get under the belt must be removed
from the immediate vicinity. Damage that could impair the function or cause injury must be repaired.
Otherwise, no liability will be accepted. Make sure there is enough space around the MP. (Chapter
4.1) It is essential to disconnect the mains plug before carrying out any work on the MP, even if the
unit is to be moved.
EMERGENCY STOP SYSTEM
An emergency stop push button or emergency stop cord is provided on each treadmill. This is either
on the display or on a side handrail in combination with another one on the opposite side handrail.
(Chapter 6)

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 5 from 17
2. Technical description
2.1 Information on inscriptions on the outside
2 .1.1 Type plate
The type plate is attached to the left frame on the rear side.
The nameplate contains information about the manufacturer, the model, the serial number and the
year of manufacture, the sound pressure level (see chapter "Maintenance"), as well as all information
necessary to commission and operate the unit. (chapter 2.1.2)
2.1.2 Indicators
2.1.2.1 Safety note for pulse systems
The safety notice for pulse systems is located on the terminal.
The motion sprint 900 SE/SL med devices have an original heart rate system where the
signal acquisition is done by chest strap as standard (the chest strap transmitter is not included).
The new "auto-pairing" function is a technology that enables the pairing of a compatible heart
rate sensor (e.g. H9 or H10) via a coded 5kHz connection. A stable and almost interference-free
connection is then automatically established with the above-mentioned sensors. A
downward compatibility with older 5kHz sensors from (e.g. T31c) is still guaranteed. This
technology is based on signal transmission through a magnetic field. This magnetic field can be
disturbed by some factors. For example, loudspeakers, TV, power cables, fluorescent tubes and
motors with high power can interfere with the transmission. For the most interference-free
transmission of the heart rate, we therefore recommend the use of original sensors with the
"auto-pairing" function, such as the H10 sensor.
Sprintex Trainingsgeräte GmbH
Bei der Säge 23 a; D-79692 Kleines Wiesental
Treadmill type: Callis - XXX
Serial number: XXXX/XX
Year of manufacture: XXXX
Power: 1300W (230V 50/60Hz; 6.3A)
Load: 160 kg (optionally 250 kg)
S., G., V. class: 1 S A
Sound pressure level :<75 dB
0483
Safety instruction according to DIN EN 957-6
"WARNING - Heart rate monitoring systems can be
inaccurate. Excessive exercise can cause serious injury or
death. If you feel close to fainting, stop exercising
immediately."

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 6 from 17
2.1.2.2 Safety advice for walking on the running surface
The safety notice for stepping on the tread is located above the switch-on
button, at the rear right of the MP frame.
For safety reasons, it is necessary to switch on the MP before operation
and only then step on the running surface. This prevents injuries in the
event of a fault.
2.1.2.3 Safety notice "DO NOT PUT IN".
The safety notice is located on the front pulley and on the rear pulley.
" REACH IN PROHIBITED"
Do not reach into the slats!
2.1.2.4 Safety notice "SITTING PROHIBITED
The safety notice, if present, is applied to the armpit supports.
"SITTING FORBIDDEN"
Sitting on the armpit supports is prohibited!
2.1.2.5 Safety notice " SUPERVISION".
"For children, 1:1 care is mandatory".
As soon as the MP is equipped with child axle supports
and/or child HvBv (height and width adjustable guardrails),
this safety notice is additionally applied.
2.1.2.6 Mandatory sign
"FOLLOW INSTRUCTIONS FOR USE"
The instructions for use must be read before use.
be read and followed!
2.1.2.7 Serial number (beat numbers)
The serial or unit number of the MP is located below the power button, stamped on the rear right
frame. It consists of a 6-digit number. The unit number can also be read on the type plate and is
identical to it.
1
child
1 Care
:
First
Switch on,
then tread
enter
Switch on
first before
entering the
running surface

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 7 from 17
2.1.2.8 Disconnection from the supply network
The safety notice is located below the power button, on the
rear right frame.
The note "Pull out the mains plug before opening" is
intended to inform service personnel during installation or
maintenance work to disconnect the unit from the power
supply so that no live components can be touched and no
electric shock can occur to the service personnel.
2.1.2.9 Reverse operation (reversing the direction of travel)
The safety notice is located on the terminal if reverse operation is available.
Reverse mode is designed to run backwards on the treadmill so
that you can always see the treadmill parameters. Only with HzP
(Personal Safety Bracket) is it allowed to simulate uphill running
with the incline set.
Pull out the
mains plug
before opening

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 8 from 17
2.1.2.10 General pictograms
Type B applied part, protection class 1
The MP must not be disposed of in normal household waste.
It is subject to the EAR.
MP was placed on the market after 23.03.2006.
3. Environmental conditions, transport, storage
Humidity: < 80 %; Temperature range: 0/40 °C; Storage temperature: 0/40 °C (Protect from strong
temperature fluctuations // When used in a cold environment, warm up the unit slowly (risk of
breakage of all plastics)). The unit should not be exposed to direct sunlight! The mains plug and
socket must be accessible at all times so that the MP can be disconnected from the mains
immediately. The mains plug must be disconnected before carrying out any work on the MP, even if
the unit is to be moved.

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 9 from 17
4. Commissioning / Installation
4.1 Installation site
Observe ambient conditions. (Chapter 3) Place the unit on a firm, level, non-slip and vibration-free
surface. Make sure that the units do not stand on thick "rubber mats". There must be sufficient
clearance under the MP to allow the tread to swing. A safety area of at least 2,000 mm length and
the width of the MP must be available behind the MP. There must be no foreign objects in the entire
safety area. If the unit has the reverse option, the same safety area must also be maintained in front
of the MP.
Make sure that there is no electromagnetic radiation that can affect the pulse measurement.
4.2 First commissioning
Observe ambient conditions. (Chapter 3) The MP must be acclimatised for several hours before
initial operation.
The MP is connected to the mains (220 - 230V) via the mains cable. Only use a socket with the
appropriate voltage for the electrical connection. The socket must be protected with a slow-blow
fuse (16 A). The highest internal resistance of the supply mains is 2W (calculated from max. 40 V
voltage drop at max. inrush current of 20 A). No live cables, plugs or sockets may be laid directly
under the MP. Make sure that the emergency stop pull cord (also serves as a locking function) is in
the position provided on the terminal and that the emergency stop button is not in the pressed
position. The on/off button is located on the rear right frame of the MP. When switching on, the user
must not stand on the running surface. On the operating part of the MP are the operating buttons,
which can be operated by tapping lightly and without force. (Operating the terminal, chapter 11)

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 10 from 17
5. Options
5.1 Reverse operation (U mverse direction)
See chapter 2.1.2.9
5.2 Polar pulse systems (receiver included)
The motion sprint 900 SE/SL med units are equipped with the original pulse system, which
uses a chest strap for signal acquisition as standard. This enables individual training in various
programmes. The wireless data transmission to the display electronics is coded (either via 5kHz or
. The new "Auto-Pairing" technology is based on secure and interference-free data
transmission via Bluetooth. This technology requires the use of the H10 or H9 transmitters. Other
parameters, such as HRV and respiratory rate, are also transmitted to the monitor via the
connection.
If the old transmitters are used, e.g. T31coded, there is downward compatibility. It should be noted
that there may be interference during signal transmission.
The colour of the flashing heart symbol gives an indication of the technology used. light
blue=Bluetooth green=5kHz
5.3 Pulse transmission via ANT+ technology
ANT+
The motion sprint 900 SE/SL med devices enable optional data transmission via in addition to heart rate
transmission via 5kHz/ .
By default, Polar 5kHz/ technology is activated. To activate transmission via , the "ANT+" switch in the
info box ( ) must be switched on (marked yellow here). After that, a connection to a transmitter unit that sends the
heart rate via can be established.
A dark blue flashing heart symbol confirms heart rate transmission via .
5.4 Load increase to 250 kg
For loads over 160 kg, the treadmill must be in a horizontal position. Setting the incline above 160
kg is prohibited, as is the use of the HzP .
Accessories are: Axle supports (steel, powder-coated), child axle supports (steel, powder-coated),
ramp (wood), rehab belt corset (fabric). If you have received one or more of these accessories, more
information can be found in the appendix.
Removable parts include: Emergency stop magnet, Removable gel keypad, Carabiner, Suspension
straps.
6. Safe training
Chapter 2.1.2 "Markings" must be observed!
Chapter 9 "Maintenance" must be observed!

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 11 from 17
EMERGENCY STOP device: The existing EMERGENCY STOP ripcord and/or the
EMERGENCY STOP button are to be actuated in an emergency and immediately bring the MP to a
standstill. The "STOP button" can always be actuated as a safety function. It reduces the speed of
the running surface until it comes to a standstill. Before starting training, the fitness should be
checked by an authorised person.
Note: Be aware of the contraindications listed. Note that excessive training
can be harmful.
When training, wear tight-fitting, lightweight sports clothing that cannot get caught in parts of the MP
during training. The plastic clip attached to the rip cord must be attached to the clothing when the
MP is put into operation so that when the rip cord is tightened, the magnet comes off the terminal.
The rip cord must be adjusted so that the magnet releases at no more than 70% of the length of the
tread. Always wear suitable sports shoes for a secure footing on the running surface. Check the unit
for secure footing, any defective parts or other tampering before you start exercising. If you discover
any defects or are not sure, ask the supervisor before you start training.
Note: Make sure to run in the middle of the tread at all times. Adjust to the speed.
With regard to persons exercising, see chapter 1.1.
Indications:
Cardiology: Economisation of the Cardio-Pulmonary System through Targeted Training
Aids for exercise ECG
Pneumology: Aids for spiroergometry
Economisation through breathing training under load
Orthopaedics: Muscle building training, primarily of the lower extremities and to warm up for
further exercises
Muscle building for muscle atrophy of the lower extremity
Mobilisation of the joints through movement of the lower extremity
Walking school after amputation
Mobilisation training and walking school
Neurology: Walking school for neurological deficits e.g. stroke
General: Accompanying treatment of obesity
Stimulation of the metabolism through strength-endurance training
Accompanying treatment through sport in oncology
Foreseeable contraindications:
If you are taking any kind of medication, please discuss the training with your
doctor beforehand.
Unstable angina pectoris
Symptomatic cardiac arrhythmias and/or impaired haemodynamics
Acute dyspnoea
Circulatory disorders with rest pain in the affected limbs
Coronary atherosclerosis
Acute infections (diseases in the respiratory tract)
Febrile illnesses, febrile infections Circulatory complaints,
Dizziness, nausea, vomiting
Acute coronary syndrome
Acute myocardial infarction
Symptomatic high-grade aortic stenosis
Acute pulmonary embolism
Acute carditis (myo-, endo-, pericarditis)
Acute phlebothrombosis of the lower extremities
Acute aortic dissection

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 12 from 17
Fresh fractures not treated
Foreseeable relative contraindications:
Hypertension, i.e. when blood pressure is constantly elevated.
Pain on exertion in the legs when walking less than 100 m
Decompensated heart failure
Fractures treated in partial weight bearing
Dizziness and/or balance disorders
Advanced osteoporosis
Mental disorders
Severe visual impairment
Termination criteria:
Chest pain
Malaise
Nausea
Dizziness
Dyspnoea
Significant pain in the musculoskeletal system
7. Care
Clean the plastic trim and frame parts with a damp cloth and mild soap to remove aggressive sweat
residue. Then rub the surfaces dry. If the MP needs to be disinfected, use only acryl-des®
disinfectant wipes. The safety level of the MP can only be maintained if the units are regularly
checked for damage and wear. Defective parts must be replaced immediately and the unit shut down
until repaired.
Attention: Do not use solvents!
8. Maintenance
8.1 Minimum qualification for maintenance personnel
The qualification required of our maintenance staff is a technical vocational training and training, as
well as instruction by emotion fitness GmbH & Co. KG or the company Sprintex Trainingsgeräte
GmbH.
8.2 Maintenance instructions
The unit is almost maintenance-free. Nevertheless, we recommend maintenance every 12 or 36
months. Please observe the following maintenance instructions.
In case of problems that you cannot solve yourself, notify emotion fitness GmbH & Co. KG . The
authorised service will help you quickly and competently or provide you with instructions.
Attention: Before working on the applianceà , pull out the MAINS CONNECTOR! Do not grease motor belt for running
surface and pitch! Poor maintenance leads to higher noise levels.

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 13 from 17
Every 12 months:
Remove panels left and right
Vacuuming out the accessible areas
Clean the encoder disc (up to 2005) on the pitch spindle.
Check the magnets (from 2006) on the pitch spindle for tightness, if necessary glue them on
again (with Pattex).
Clean and re-grease toothed and V-belts (Molykote grease).
Clean and relubricate taper roller bearings and ball bearings (penetrating oil).
Clean and re-grease the tilt spindles (Molykote grease).
Additionally every 24 months:
Clean toothed deflection pulley (deposits in the teeth)
Check tread tension
Tighten the pillow block screws on both deflection pulleys (50 Nm).
Check all screws for tightness
8.3 Replacing fuses, mains connection cables and other parts
Fuse replacement
Disconnect the mains plug from the mains supply! Loosen the side panel with a Phillips screwdriver.
Replace fuses on control board 2x6.3 A slow-blow via bayonet fitting, designation on circuit board,
2x10 A slow-blow on gradient board if gradient is present.
Replacing the mains connection line
Disconnect the mains plug from the mains supply! Loosen the side cover with a Phillips
screwdriver. Disconnect the mains cable from the mains filter, loosen the strain relief, remove the
mains cable, insert the new mains cable, insert the new strain relief, connect the mains cables to
the mains filter. After successful replacement, refit the side panels.
Other parts
When replacing parts that are not listed, the company Sprintex Trainingsgeräte GmbH must always
be contacted.
8.4 Circuit diagrams / component list
Note: Information required for maintenance measures (circuit diagrams, components, etc.) can be
requested directly from Sprintex Trainingsgeräte GmbH.
9. Maintenance
The MP motion sprint 900 SE/SL med must be subjected to the safety check (STK) in accordance
with the Medical Devices Operator Ordinance (MPBetreibV) every 12 months. The operator is
responsible for carrying out the inspection.
Pedestal
bearing
Magnets
Toothed idler pulley
Fine fuses T 8A
Plain
bearing
Tapered roller
bearing
Tilt spindle
Toothed and V-belts
Control box:
Fine-wire fuses
T10A

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 14 from 17
10. Operation "Display
Various training and test programmes enable individual and varied training with the motion cardio line 900 and motion
cardio line 900 med machines.
sprint 900 / 900 med
Basic equipment
Quickstart, timed training, pulse training (with SL pulse inclination/pulse speed)
incl. programme package
Quickstart
Qualifying
Pulse training (at SL pulse inclination/pulse speed)
+ 6 more programmes
Overview display/key functions
Fig. 2: Monitor view, explaining the button functions, actual view may vary in colour, button assignment is the same.
Explanation of the buttons:
• The Home button is a physical button below the display glass. It is pressed to enter the main menu. During
training, this button pauses the programme. The treadmill slows down and finally stops. A long press (at least
6 seconds) on the HOME button will reset the monitor electronics.
• Press the PAUSE button ( ) to pause the training.
• Pressing the PLAY button ( ) starts or resumes the training.
• The COOL button ( ) stops the training immediately. A summary of the training results is immediately
generated, displayed and, if necessary, sent to a compatible training control software. When the COOL button
is pressed, the current speed is maintained for the cool-down.
• Use the "+" key or "-" key to increase or decrease the parameters or power values to be set.
• Use the arrow keys to navigate through the corresponding menus and confirm values or settings.
• Swipe/swipe gestures navigate through the programme selection.
Depending on the programme, some of the following parameters are displayed:
• Programme name.
• Time: Training time completed or remaining.
• Pulse: Heart rate indicator, when using a compatible pulse transmitter belt. The pulse indicator display shows the
current pulse range for programmes with target or maximum pulse. The profile indicator in the display shows the
progression of the intensity range during training.
• Watt: Power is displayed in watts. In parallel, the intensity is clarified via a graphic display in the profile.
• km/h: Fictitious speed is displayed in km/h.
• HRV: Heart rate variability is displayed via the RMSSD value (requires H10 sensor).
• resp: Breathing rate (requires H10 sensor)
• km: Added or remaining distance. The display is in metres; from 1000 m in 10 m steps (1.00 km).
Home Button
PAUSE
COOL
PLAY

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 15 from 17
• K-Cal: Added or remaining calorie consumption.
• Level: Intensity level 1 - 21.
• : If the parameters are completed with this symbol, they are average values.
Results
After completion of a training programme or premature termination via COOL ( ), the results are displayed in the
monitor and a 3 minute cool-down takes place. This can be cancelled via the HOME button.
Some of the values are averaged (Watt, Km/h, RPM, Pulse, Altitude/ min), some are cumulated (Km, K-Cal, Time,
Altitude). The average values are marked with the symbol Ø.
These results make it possible to monitor personal performance development and thus serve as motivation.
Programme selection
The desired training programme can be selected in the main menu by tapping the corresponding symbol. You will then
be taken to the configuration page where you can set the corresponding training parameters. Press the PLAY button
( ) to confirm your entry and start the training. You can return to the main menu via the home icon or the home
button.
Fig. 3: Programme selection and configuration for manual training.

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 16 from 17
11. Technical data
Dimensions and weights may vary due to changes in equipment.
Dimensions
Weight
Max. user weight
Safe workload
172 cm x 76 cm x 148 cm (L/W/H)
170 kg
150 kg; boosted: 250 kg
320 kg;
boosted: 420 kg
Toothed belt controlled drive of aluminium lamellas with rubber overlay. No slippage, no heating of the running
surface, low continuous power consumption.
Tread height: 28 cm
Tread: Slat technology s²ap Sprintex, L x W 155 cm x 50 cm;
Weight: 190 kg with incline
Max. User weight: 150 kg
Drive: Brushless DC motor 1.3 KW
Voltage: 230V 50/60Hz
Current: 6 ampere
Fuses: 2 x 6.3 A slow-blow, 2 x 10 A m. Gradient
Humidity: < 80%
Noise emission :< 75 dB(A)
Temperature range: 0 to 40 ° C.
Storage temperature: 0 to 40° C.
Leakage current: < 0.5 mA
Degree of protection: IP X0
Speed: 0-17 km/h continuously adjustable
Gradient: 0-15 % infinitely variable (for motion sprint SL med)
Pulse measurement system: Ant+ and Bluetooth (chest strap or watch not included)
Medical device: according to 93/42/EEC
Applications include
following standards: DIN EN 20957-1
DIN EN 957-6
DIN EN 60601-1

Instruction manual treadmill 900 / 900 med SE/SL Version 1.1 25.01.2023
Page 17 from 17
12. Warranty
This is based on the statutory warranty.
emotion fitness GmbH & Co. KG, as the distributor of this product, will provide free service for 12 months on parts and
labour for professional users if the proper use and care listed in this user manual can be verified. For a further 12 months,
emotion fitness GmbH & Co. KG will provide replacement parts free of charge.
The warranty claim expires if the product has been serviced or repaired by unauthorised persons. As soon as a warranty
case occurs, you should immediately inform emotion fitness GmbH & Co KG of this in writing or by e-mail. Information
about the serial number of the device, the time of purchase, a detailed description of the fault and the source of supply
must be provided by the owner of the device.
emotion fitness GmbH & Co KG will arrange for a service, but reserves the right to determine the type of service.
The following procedures are conceivable:
1. the service is carried out on site by our service.
2. we send the desired spare part.
3. we will send a replacement unit.
The defective parts shall be returned to us immediately by the customer. Otherwise, the delivered spare parts will be
invoiced.
If the causes lie outside the scope of the warranty, emotion fitness GmbH & Co. KG reserves the right to charge all
repair costs.
Some wear parts are not covered by the warranty. These are in particular the saddle, cranks and crank attachment,
pedals, pedal loops, upholstery fabrics and the grip rubber on the handlebar. The pulse systems come with the
legal warranty.
These warranty provisions shall in no way affect the general statutory claims.
Our General Terms and Conditions of Delivery, as amended from time to time, can be viewed and downloaded from our
website www.emotion-fitness.de.
emotion fitness GmbH & Co. KG
Trippstadter Street 68
67691 Hochspeyer
Tel.: [phone]
Fax: [phone]
[email protected]
www.emotion-fitness
13. Document History
Version no.
Reason for the change
Author/
Date
checked/
date
released/
date
1.0
New creation BA Callis motion
sprint 900 SE/SL med
L.Huhn,
07.10.2022
W.R.
W.R.
1.1
Supplement motion sprint 900
SE/SL med
M. Brodehl
13.02.2023
L. H.
27.03.2023
L. H.
27.03.2023
