Metagenics Fitness MF-P096T User manual

1
FITNESS EQUIPMENT MANUFACTURER
SHANDONG JINGGONG FITNESS EQUIPMENT CO.,LTD
INSTRUCTIONS OF INSTALLATION, USE AND MAINTENANCE MANUAL
NOTICE:
1、Please read the manual carefully before using the electronic treadmill.
2、Please keep the instruction well for future reference.
COMMERCIAL TREADMILL
MF-P096T Touch
screen
Metagenics Fitness Inc.

2
SPECIFICATION
Size
2030*950*1600
Electricity
AC 220v～240v
Folded size
Non-folded
Rate of work
2200W
Running area
600*1550
Circuit
≤10A
N.W
210Kg
Speed
1.0-20Km/H
Gross weight
Kg
Temperature
0—40
Incline
0%～20%
degree
SB
Weight limit
≤180Kg
Dashboard
Time; distance; heart rate; calorie; speed; incline
Security
1,Red button on dashboard
2, PPTC
3,Circuit safety in the front of the dashboard
Implementation standard:
GB17498.1-2008/ISO20957-1:2005
GB5296.7-2008
Photos and specification is copyrighted by Metagenics Fitness Inc.
The modification shall be conducted without further notice.

3
INSTALLATION INSTRUCTION
NO. and description of each parts
NO
NAME
specification
QT
Y
NO.
NAME
specification
QT
Y
1
Mainframe of treadmill
1
12
Middle wire I
1
2
Left post
1
13
Middle wire II
1
3
Right post
1
14
Lower wire
1
4
Join part for Electrical
meter
1
15
Half round
Inside hexagonal
bolt
M8 *20
8
5
Horizontal frame for
handrail
1
16
Half round
Inside hexagonal
bolt
M10 *20
16
6
Electrical meter
1
17
Cross self-tapping
screw
ST4*15
14
7
Cover above motor
1
18
Flat gasket
Dia 10.5 * Dia
20
16
8
Side cover of right post
1
19
Flat gasket
Dia 8.4 * Dia
15
4
9
Side cover of left post
1
20
Safety lock
1
10
Lower cover for horizontal
frame
1
21
Power line
1
11
Upper wire
1
Installation tools
Cross screwdriver 6mm socket head wrench（Provide as spare parts）
Installation steps：
Open the plywood case，take out the main part of the treadmill, and lay the machine on the level ground.
Kind Remind：As taking out the machines from the plywood case, need at least 5 persons.

4
“ª°¢»ÁÕºÀ˘+ 棨œ»Ω´13∫Õ14¡¨Ω”∫√.
+++++ π” √ƒ ⁄¡ ˘Ω«∞‚+ ÷Ω´2∫ Õ3Õ®π ˝16∫ Õ18
++++« ·À ¯‘ ⁄1…œ.(¬ ›À ®œ»≤ ªÀ¯ΩÙ)
1
3
2
16
18
16
18
16
18
13
14
I. As
shown in the figure, firstly connect part 13 and 14, and then use inner hexagon spanner to lock part 2 and 3
onto part 1 lightly through 16 and 18.

5
2
3
16
18
18
1
13
12
∂ ˛° ¢» ÁÕ ºÀ ˘+ æ£ ¨œ »Ω ´12∫ Õ13¡ ¨Ω ”∫ √.
+++++ π” √ƒ ⁄¡ ˘Ω«∞‚+ ÷Ω´5Õ®π ˝16∫ Õ18
+ + + + À ¯Ω Ù‘ ⁄2∫ Õ3… œ. ‘ ŸÀ ¯Ω Ù≤ Ω÷ Ë“ ªµ ƒ
++++¬ ›À®.
5
II. As shown in the figure, firstly connect part 12 and 13, and then use inner hexagon spanner to lock part 5
onto part 2 and 3 lightly through 16 and 18. Then fasten the bolts of step 1.

6
»˝° ¢»ÁÕºÀ˘* 棨* π”√ƒ ⁄¡ ˘Ω«∞‚* ÷Ω´4
* * * * Õ ®π ˝15∫ Õ19À ¯Ω Ù‘ ⁄5… œ.
5
4
15
19
15
19
III. As shown in the figure, use inner hexagon spanner to lock part 4 onto part 5 tightly through 15 and 19.

7
22
Àƒ° ¢»ÁÕºÀ˘* 棨¥Úø™22(∫ ·≥≈œ¬∑‚∏«).
IV. As shown in the above figure, open part 22 (cross brace lower cover).

8
VI. As shown in the below figure, inserting part 6 into part 4, and connect part 11 with 12, A with a, C with c, D
with d. Then use inner hexagon spanner to lock part 6 onto 4 tightly through 15. At last cover part 22(cross
brace lower cover).
AB C
D
b
c
a
d
22
11
12
15
ŒÂ° ¢» ÁÕ ºÀ ˘+ æ£ ¨Ω ´6à ◊» Î4÷ –£ ¨
+ + + + œ »Ω ´11∫ Õ12° ¢A∫ Õa° ¢C∫ Õc° ¢D∫ Õd
++++¡ ¨Ω”∫ √.
++++‘ Ÿ+ π” √ƒ ⁄¡ ˘Ω«∞‚+ ÷Ω´6Õ®π ˝15
++++À¯ΩÙ‘ ⁄4…œ.
+ + + + ◊ Ó∫ Ûø €… œ22£ ®∫ ·≥ ≈œ ¬∑ ‚∏ «£ ©.
6
4

9
7
17
17
8
9
17
17
17
17
17
2
3
1
23 24
¡˘°¢»ÁÕºÀ˘*棨œ»≈°ø™23∫Õ24£¨
***** π” √* Æ◊ ÷¬ ›Àøµ ∂Ω´8∫ Õ9
****Õ®π ˝23° ¢24∫ Õ17À ¯ΩÙ‘ ⁄2∫ Õ3…œ
****‘ Ÿ* π” √* Æ◊ ÷¬ ›À øµ ∂Ω´7Õ®π ˝17
****À ¯ΩÙ‘ ⁄1…œ.
****◊ Ó∫ Û◊ ∞…œ20£ ¨Ω”…œµ Á‘ ¥œfl.
20
VI. As shown in the figure, firstly twist off part 23 and 24, use cross screwdriver to lock part 8 and 9 tightly
onto 2 and 3 through 23,24 and 17, and then use cross screwdriver to lock part 7 lightly onto 1 through 17. At
last install part 20, connect the power line.
Please notice: You can only connect the power line after confirming all the parts are installed according to the
instructions.
Kindly reminder: Please check whether the security lock reset or not before starting the treadmill.

10
Screen parameter：
Screen：18.5 inch，16:9 Capacitive touch screen
Resolution：1366*768
Operation system：Android 4.2
Function：Running，MP3，MP4, wireless internet
Image interface：HD true color digital display，high responding speed
Language：multilingual available
Video format：AVI,MPG,MPEG,MP4,WMV,RMVB,MKV
Audio：MP3，VMA,ACC
Power input：AC15V（+5%）
Operating temperature：-20 -60
Features:
lDual-core processing chip，1G RAM，4G NANDFLASH
lHigh-performance capacitive touch screen and Full view of the LCD screen. Multi-segment speed and inclination
lRunning program imitating Climbing, cross country, competition, weight loss, Multiple operating modes and
measuring fat.
lHandgrip with heart rate induction
lWith USB interface ，TFT card slot
lTo monitor the process of re-fresh system, completion tips, picture loss alarm, slope self-test function

11
lLock the time and distance, completely protect legitimate rights and interests of customers
lUnique battery management system to ensure that in case the sudden power failure, fast switching on and turning
off machines, the treadmill system will continue to operate,to further enhance the system security and stability
lUsing multiple isolation protection technology, completely solve the electromagnetic field to bring the touch screen
interference
lBuilt-in WIFI module can be connected to the effective wireless network High-speed Internet access,
lStereo system, a 3.5mm headphone output jack, built-in USB HOST, support U disk, USB mouse keyboard

12
IMPORTANT PRECAUTIONS
I’m appreciated that you choose our company’s product, when use a treadmill, basic precautions should always be
followed, including the followings:
1. Connect the power after Setting the treadmill up well according to the instruction and ensure it be in a stable place.
2. Connect this exercise to a properly grounded outlet only. Never operate the treadmill if it has a damaged power cord
or plug, if it is not working properly, call Customer Tech Support for examination and repair.
3. Each outlet you plug into should not have anything else running on that same circuit.
4. It is essential that your treadmill is only used indoors, in a climate controlled room and the location for treadmill must
be clean and flat, do not operate it on a thick blanket and the like. Use the treadmill only for its intended use as described
in the treadmill guide.
5. Do not wear clothes that might catch on any part of the treadmill. Always wear athletic shoes while using this
equipment.
6. Do not remove the console cover unless instructed by Customer Tech Support and unplug the outlet first.
7. At no time should children under of fourteen be closer to the treadmill when using.
8. Children should not use the treadmill without adult supervision.
9. If you never use the electric treadmill, please be sure to put hands on handrails until adapting yourself to it.
10. Please put the safety lock with a red thread on appropriate place in case of happening unexpectedly dangers during
exercises. When the safety lock is pulled off, the treadmill will stop working immediately, so that we get the security
assurance.
11. Please turn the electric treadmill’s power supply off in timely and pull the safety lock and power line away.
12. Absolutely forbid touching any operational part of one treadmill by hand.
13. Heart rate sensors do not belong to medical device. The test result is not accurate owing to many causes, which is
only for reference.
14. When you feel dangerous during doing exercises, you should jump on the ground or treadmill’s pedal plats on both
sides by using handrails.
15. The back part of electric treadmill has one safe district about 2000mmX1000mm during exercises, which can offer
urgently escaping space in case of unexpected dangers.
What the safe operation need the size of the free space should be 2000 x1000 x 2250mm (L x W x H) during doing
exercises.
Warming! Please don’t use the electric treadmill outsides because it belongs to indoor equipment, which applies to
aerobic exercise. It mainly increases cardiopulmonary functions and trains muscle as auxiliary functions.
18. Warning! Any adjustable installment that may be used can not deviate from the design.
Please keep the instruction well for future reference
