EmotionWings DSP XRROSS XP-025DSP User manual

EmotionWings DSP
Advanced in car Audio System
TM
All copyrights [email protected]
XP-025DSP
6 CHANNELS DSP.4x30W.CLASS-D.
User's Manual

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual
Content Table
nQuick Start
nWiring
nBluetooth Connection
nAPP

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-Quick Start
Wire the DSP Correctly
Download/Install the APP
Connect your Phone
Bluetooth to
“CAR AUDIO APP”
nQuick Start
Open the APP, Press
“Connect”
Star Enjoying Xrross
EmotionWings DSP

[POWER/HI-LEVEL AUDIO SOCKET]
ØHi-Level IN x4 Channels
ØHi-Level out x4 Channels
ØACC/VCC/REMOTE/GND
[SUB-WOOFER OUTPUT ]
Ø[IN]:Hi-Level Signal-IN x2
Ø[O]:Hi-Level Signal-OUT x2
All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-Wiring
[Auto Power ON/OFF Controlled]
Ø[HI-IN]: By Hi-Level Signal-IN ON/OFF
Ø[ACC]:By Acc ON/OFF

Hi-Level Low-Level
Hi Level Out put
(To Speakers)
All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-Wiring
Low-Level
output
(To Amplifier)

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-Wiring
[TO DSP]
[TO:
CAR SPEAKERS]
[FROM:
CAR POWER
ACC/VCC/GND]
[TO HEAD UNIT
POWER ACC/VCC/GND]
[FROM HEAD UNIT
HI-LEVEL SIGNAL]

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-Wiring
ISO male Plug
( Connect to Car Radio)
ISO female Plug
( Connect to Car Speakers and Power)

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-BT Connection
[Connect to Bluetooth 4.0]
ØTurn on your phone Bluetooth
ØSetup>Bluetooth>Conenct to “CAR AUDIO APP”
Ø Open “Conductor” APP, you just download
ØPress” Connect” to connect the DSP to your phone
[Connect to Bluetooth 4.0]
ØTurn on your phone Bluetooth
ØSetup>Bluetooth>Conenct to “CAR AUDIO”
Ø Play your Phone Music, the sound will streaming to
DSP
[Name:CAR AUDIO APP]
[Name:CAR AUDIO]
DSP comes with Dual Bluetooth
ØBluetooth 4.0 BLE for DSP controlling function connect to your
phone and run with the APP
ØBluetooth 3.0 wireless sound Streaming. You can wirelsss
Transfering any music to the DSP via Bluetooth

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-APP
【Apple iOS】 【Android】

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-APP
[Main Volume ]
[DSP Functions ]
[Preset Mode ]
[File Manage ]
[Bluetooth 4.0 Connect ]
[Source ]

All copyrights [email protected]
MODEL:XP-025DSP
User's Manual-APP
https://www.xrross.com
