EMP-Centauri A1/1PCU15dB-1 User manual

Dear Customer,
congratulations on the purchase of the EMP-Centauri
product. Before its installation and putting into operation,
read carefully the entire operation manual. Keep the
operation manual in a safe place. The product may only be
installed and connected ith strict observance of the manual
and of valid regulations.
The area of application, warranty
The product is designed for distributing satellite, terrestrial
TV and radio signals in normal house installations. The
arranty shall not apply, if the product is used for other than
specified purpose. The user ill be responsible for injury or
material damage hich may arise in consequence of any
Wiring diagram
Contact
EMP-Centauri s.r.o.
5. kvetna 690
339 01 Klatovy 1
Czech Republic
tel: [phone]
fax: [phone]
[email protected]
.emp-centauri.eu
INSTRUCTION MANUAL /002744
A1/1PCU15dB-1
A1/1PEU15dB-1
14

use of the product in contradiction ith the manual. The
product utilizes technologies hich are protected by
copyrights and patents. It is prohibited and unla ful to
dismantle the product and make any interventions in it.
EMP-Centauri Profi line products are covered under
arranty for up to 6 (six) years from the date of purchase. To
enable superior arranty and post arranty service, keep all
purchase and re ork (if any) records in a safe place. It is
also recommended to keep the original packaging for the
arranty period.
Product installation
Product must be installed and used on a dry place. To
connect inputs and outputs, use quality coaxial cable 75Ω
ith F connectors, hich are designed for satellite reception.
It is not allo ed to break coaxial cables, minimal bend radius
is 5 cm. Tighten the F connectors ith adequate po er.
Examples of practicable connections are sho n in this
manual or at ebsite .emp-centauri.eu.
Explanation of symbols
Certificate of conformity
DiSEqC (Digital Satellite Equipment control) –
international standard for digital satellite
equipment control, number (1.0, 1.1, 1.2 or 2.0)
determines DiSEqC version.
According to EU directive, electric and electronic
devices hich are identified by one of the follo ing
symbols must not be disposed of together ith
municipal aste. When disposing of the old device, use
local aste collection and separation systems.
Technical specifications
1in/1out universal (terrestrial and satellite) amplifier ith high
output level. The amplifier is supplied ith 9-20 V DC via a
DC 2.1 connector from an external po er supply
(A1/1PEU15dB-1, PA12 is recommended) or via output
cable from a receiver (A1/1PCU15dB-1). The input-output
line transmits DC.
Caution: Electrostatic sensitive devices inside, connect
po er source only after all RF connections are completed.
SPECIFICATIONS A / PEU 5dB - A / PCU 5dB -
Number of Inputs 1
Number of Outputs 1
Frequency Range 5-2300 MHz
Gain (avg) 12-15 dB
Maximum Input
Level* (avg)
TERR 94dBuV, SAT 98 dBuV
Maximum Output
Level* (avg)
TERR 109 dBuV, SAT 113 dBuV
Current Consumption
(avg)
85 mA (9-20 V) from 9-20 V
DC external po er supply
85 mA (9-20 V)
from receiver
Dimensions (w,d,h) 7.6 x 6.0 x 3.2 cm 7.6 x 6.0 x 1.7 cm
Temperature Range –30 °C - +70 °C
* TERR: EN 50083-3/60dB IMA3 [dBuV]; SAT: EN 50083-3/35dB IMA3 [dBuV]
2 3
