Emson DIGITAL DOUBLE DEEP FRYER User manual

Customer Service: 1-800-423-4248
Printed in China
Digital Double Deep Fryer ITEM NO.8387SI.
The Sharper Image®name and logo are registered trademarks.
Manufactured and Marketed by EMSON®. New York, NY 10001, USA
under license.
© The Sharper Image. All Rights Reserved.
INSTRUCTION MANUAL
DIGITAL DOUBLE DEEP FRYER

CONTENTS
IMPORTANT SAFEGUARDS............................................................................................................. 3
UNPACKING/BEFORE USE............................................................................................................... 5
PARTS AND FEATURES................................................................................................................... 6
USAGE............................................................................................................................................. 7
SUGGESTED COOKING TIMES......................................................................................................... 9
RESET BUTTON............................................................................................................................... 9
CLEANING ......................................................................................................................................10
2

3
Before using the electrical appliance, the following basic precautions should always be followed including the
following:
1. Read all instructions.
2. Keep oven out of reach of children.
3. Remove all packaging plastics and other materials from unit before operating. Wash all removable accessories before
using for the first time.
4. Before use check that the voltage of wall outlet corresponds to the one shown on the rating plate.
5. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged
in any manner. Return appliance to the nearest authorized service facility for examination, repair or electrical or mechanical
adjustment.
6. If the supply cord is damaged it must be replaced by the manufacturer or an authorized service agent or a qualified
technician in order to avoid a hazard.
7. Do not let cord hang over edge of table or hot surface.
8. Do not immerse plug, cord or housing into water due to the risk of electric shock.
9. Close supervision is necessary when your appliance is being used near children.
10. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
11. Do not touch hot surfaces, use knobs or handles.
12. Make sure the appliance is clean and dry prior to use.
13. Do not place near hot gas or electric burner.
14. The use of accessories not recommended by the manufacturer may cause injuries to persons.
15. Oversized foods must not be inserted in the appliance as they may cause a fire or risk of electrical shock.
16. Do not operate the appliance for other than its intended use.
17. Do not use outdoors.
18. Do not move the appliance when in use.
19. Use extreme caution when handling or disposing of hot oils or other hot liquids.
20. Always turn the unit OFF before removing the plug from the wall outlet.
21. A fire may occur if the appliance is covered or touching flammable material including curtains, draperies, walls and the like
when in operation.
22. Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts, involving a risk of electrical
shock.
IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS
23. Do not store any materials other than manufacturer's recommended accessories in this unit when not in use.
24. Do not place any of the following materials in the unit: paper, cardboard, plastic and / or similar non-food materials.
25. Servicing and repair should only be conducted by a qualified technician.
WARNING: CAUTION HOT SURFACES: This appliance contains hot oil and generates heat during use.
Proper precautions must be taken to prevent the risk of burns, fires, or other injury to persons or damage to property.
CAUTION: This appliance is hot during operation and retains heat for some time after turning off. Always use oven mitts when
handling hot materials and allow metal parts to cool before cleaning.
- Position the appliance so that it is never against a wall or in a corner, against curtains or upholstery.
- When operating the appliance on a work surface keep the surrounding areas clear and free from clutter. Ensure adequate air
space surrounding the appliance for circulation.
- Do not place anything on top of the appliance while it is operating or while it is hot.
- Do not operate this appliance with other major appliances plugged into the same power socket - there is a risk of blowing
the fuse.
- Do not touch the hot appliance surfaces while the unit is on or while cooling.
- All users of this appliance must read and understand this User’s Manual before operating or cleaning this appliance.
- If this appliance begins to malfunction during use, immediately unplug the cord. Do not use or attempt to repair the
malfunctioning appliance.
- Do not leave this appliance unattended during use.
4
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY.
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit
in a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
Do not attempt to repair the appliance, contact a qualified service technician.
A short power supply cord is provided to reduce the hazards resulting from entanglement or tripping over long cord.
Do not use extension cord as it can be pulled on by children causing the unit to tip over.

5
UNPACKING - BEFORE FIRST USE
MAIN FRYER BODY
DIGITAL CONTROL PANEL WITH HEATING ELEMENTS (2)
3 QT. OIL CONTAINERS (2)
FRYING BASKETS (2)
BASKET HANDLES (2)
FRYER LIDS (2)
DETACHABLE POWER CORDS (2)
PACKAGE CONTENTS:
PARTS AND FEATURES
UNPACKING - BEFORE FIRST USE
1. Remove all printed documents and any other packaging materials.
2. Pull out all removable parts (oil containers, lids, frying baskets and handles) and wash gently with mild soap and hot water.
CAUTION: Do not immerse the power cord and digital control panel with heating element of the deep fryer into any liquids.
3. Dry all parts thoroughly before assembling. Refer to PARTS AND FEATURES part of the manual on next page for reference.
1. Carrying Handle
2. Main Body
3. Basket Handle
4. 3 Qt. Oil Container (2)
5. Frying Basket (2)
6. Digital Control Panel (2)
7. Heating Element (2)
8. Detachable Power Cord (2)
9. Fryer Lid
10. Ventillation Holes
DIGITAL CONTROL PANEL
6
DIGITAL
DISPLAY
TIME
INDICATOR
TEMPERATURE
INDICATOR
POWER/
READY
INDICATOR
LIGHT
SELECT KEY
INCREASE KEY REDUCE KEY
ON/OFF KEY
6
1
3
2
4
5
3
6
7
8
9
9
10
10

7
USAGE (Refer to p. 6 for Parts Identification)
USAGE (Refer to p. 6 for Parts Identification)
8
OPERATING YOUR FRYER:
1. Make sure the Deep Fryer is unplugged.
2. Bring the handle of the basket from its stored position. Press into clip until secure. Refer to
Diagram A on right.
3. Fill the oil tank with your choice of oil between the MIN and MAX markings. Use only good
quality frying oil (peanut oil, vegetable oil, pure corn oil, sunflower oil, canola oil, light olive oil).
Do not mix oils. Do not fill over the MAX marking or lower than the MIN marking.
4. Connect the plug to the back of the unit. Refer to Diagram B on right. Make sure the connection
is properly secured.
5. Plug the other end of the power cord into an outlet, the digital panel will flicker --:-- and a beep
will sound.
6. Press the Select button to choose between setting the Time or Temperature.
When the display shows 250°F and the temperature indicator icon lights up, it is ready to accept
your temperature setting.
7. Press the + (increase) button or – (decrease) button to set the desired temperature according
to desired recipe. Temperature increases or decreases by 25 degrees. The temperature ranges
between 250°F - 375°F.
8. Once the temperature has been set, press the Select button again to set the time. The Time indicator icon will light up, it will
display the default temperature of 00:00.
9. Press the + (increase) button or – (decrease) button to set the desired frying time. The time increases or decreases by
1 minute (maximum time setting is 99:00). Set the time according to desired recipe.
10. After setting the Timer and Temperature, press the ON/OFF button to start the deep fryer. The Power/Ready indicator light
will turn red.
11. While the oil is preheating, prepare the food that is going to be fried. When the set temperature has been reached, the
Power/Ready indicator light will turn GREEN.
TIPS
- When frying several types of food, always fry the food that uses the lowest temperature setting first.
- Do not mix different types of oil for frying.
- Foods that are pre-cooked may take less time to fry than raw foods.
- Replace the oil after 10-15 uses, unless it becomes brown and thick sooner.
12. Place the desired food into the basket. Do not overfill the basket. Make sure the food is as dry as possible. Do not place foods that
are wet or have ice particles, it may cause HOT OIL SPLATTER. When frying frozen food, clear off any ice particles and thaw food
thoroughly.
13. Lower basket of food into hot oil and cover fryer with lid.
14. When the Timer is on display and you would like to check on the temperature setting, simply press the Select button, the unit
will beep and display the temperature, then flash back to the Timer.
15. When the desired cooking time has elapsed reaching 00:00, the unit will automatically shut off and an indicator alarm will sound.
16. When adding new food to be fried during the frying process, the oil temperature may drop. The GREEN Power/Ready indicator
light will periodically change to RED light and back while the oil temperature is being adjusted.
WARNING: DO NOT TOUCH THE CONTROL PANEL WHEN THE FOOD IS FRYING.
HOT STEAM MAY ESCAPE AND CAUSE BODILY HARM.
DIAGRAM B
AFTER THE FOOD IS FRIED:
1. Once food is done cooking, press the ON/OFF button to turn the unit off.
2. Carefully remove the lid. WARNING: Removing the lid will release hot steam. Take extreme care when handling.
Keep face and bare skin clear of the steam release. Hang the basket on the hook and let excessive oil drip into the oil pot.
3. Take out the basket and place the food on paper towels to absorb excess oil. Do not touch the basket while it is still hot.
Always use the handle.
4. Transfer food to a clean dish. Discard the paper towels.
5. Place the basket back into the deep fryer.
6. Unplug the unit. Do not move the deep fryer until it is cooled entirely.
7. Refer to cleaning instructions on page 10.
DIAGRAM
A

9
SUGGESTED COOKING TIMES - RESET BUTTON
10
Shrimp
Onion
Mushrooms
Fish Filet
Fish Filet in Batter
Fish Cakes or Balls
Sliced Meat
Steak
Chicken Strips
French Fries (1st time)
French Fries (2nd time)
3-5 minutes
3-4 minutes
6-8 minutes
5-6 minutes
6-8 minutes
6-8 minutes
7-10 minutes
7-10 minutes
7-10 minutes
6-10 minutes
3-5 minutes
275 °F
275 °F
275 °F
300 °F
300 °F
300 °F
350 °F
350 °F
350 °F
375 °F
375 °F
250 (8.8 oz)
150 (5.3 oz)
300 (10.5 oz)
250 (8.8 oz)
400 (14 oz)
400 (14 oz)
400 (14 oz)
400 (14 oz)
500 (17.6 oz)
500 (17.6 oz)
250 (8.8 oz)
FOOD TEMPERATURE WEIGHT (GRAMS) COOK TIME
*French Fries being fried a 2nd time will be lighter and crispier.
NOTE: The frying times given in the chart are only a guide and should be adjusted accordingly to
the quantity of food being fried.
CLEANING AND CARE
RESET BUTTON:
If your deep fryer’s heating elements shut off in the middle of frying and do not come back on, unplug the unit. Allow it to cool
off up to 10 minutes. Plug the power cord back in and power back on. If the deep fryer still does not power on or heat up,
the unit needs to be reset. Unplug the deep fryer from the power outlet.
Locate the Reset Button on the control box. It is located on the back of the control box next to the power cord socket.
The Reset Button is located inside a small hole. Use a small thin tool to insert into the small hole. Press in on the Reset
Button. Plug the power cord back in and power back on.
CLEANING THE DEEP FRYER
1. Remove the lid and basket.
WARNING: Before cleaning the deep fryer, make sure that it is disconnected from
the power outlet, make sure the unit and the oil has completely cooled. Oil retains
its temperature for a long period after use. Do not attempt to carry or move the
deep fryer while the oil is hot.
2. Wait for the fryer to cool. Remove the fryer basket (if still inside unit).
Lift out the Digital Control Panel assembly & Heating element.
3. Remove the oil pot and pour out the oil.
5. The oil containers, the main body (stainless steel), the fryer baskets
and lids are all dishwasher safe. You may also wash those in warm water
with mild detergent. The Digital Control Panels with Heating Elements and
power cords are NOT dishwasher safe.
6. The Control Panel & Heating Element should be wiped clean with absorbent
paper towels. Then use a damp cloth and a mild soap to clean.
WARNING: Do not immerse the Digital Control Panel & Heating Element into
water to clean.
7. Dry all parts thoroughly.
Note: Do not use abrasive scrubbing brushes or chemical cleaners
to clean the unit.
OIL
CONTAINER
